UAS Applications in Real Estate and Land Development Presented by: - - PowerPoint PPT Presentation

6/27/2019 1

UAS Applications in Real Estate and Land Development

Presented by: Mary B. Wohnrade, P.E., Principal Engineer Kyle B. Reeder, P.E., Project Manager/Project Visualization

6/27/2019 2

Wohnrade Civil Engineers, Inc.

CORPORATE HISTORY

• Established Civil Engineering Consulting Firm based in Broomfield, Colorado
• Registered as a Colorado Corporation on November 4, 2002
• Specialties include: land development, municipal projects, floodplain management and water resource design.
• FAA Certified UAS Operator

6/27/2019 3

WCE Firsts

• An Early Adopter of UAS Technology
• One of the first few UAS operators in Colorado to receive

an FAA Section 333 Exemption and COA to perform commercial operations;

• One of the first licensed UAS operators to receive national

recognition of historic achievement for performing a precision mapping mission in a National Park;

• One of the first to incorporate UAS data into civil engineering design, and now virtual reality;
• One of 9 Honorees worldwide in the Inaugural 2017 Women to Watch in UAS by Drone 360

Magazine and Women and Drones;

3D Point Cloud of the Star Dune at the Great Sand Dunes National Park Collected and prepared by Wohnrade Civil Engineers using sUAS

6/27/2019 4

The Best UAS Aerial Mapping Data Available The Best UAS Aerial Mapping Data Available

Collection and Processing by OSHA trained FAA Licensed Pilots Collection and Processing by OSHA trained FAA Licensed Pilots Licensed Engineers and Surveyors Licensed Engineers and Surveyors ASPRS Strict Accuracy Standards ASPRS Strict Accuracy Standards Use the best Available Drones and Sensors Use the best Available Drones and Sensors In-House Cross- Trained Staff of Engineers, Pilots and GIS Technicians In-House Cross- Trained Staff of Engineers, Pilots and GIS Technicians Processing Workflows Vetted by CU Denver Staff Processing Workflows Vetted by CU Denver Staff

• Pioneers in the

Development

• f Precision UAS

Mapping

• The culmination
• f years of

refinement

The WCE Standard

• All Services are

Performed In- House by Cross- Trained Staff

6/27/2019 5

WCE Drone Division

Aircraft & Sensor Selection Flight Planning & Execution Processing Software

• Safely and successfully mapped thousands of acres throughout Colorado since early 2015
• The Aircraft, the Sensors, and the Processing Software all matter when preparing precision mapping
• As accurate as you can get using the best available UAS technology.
• A few Key Components to Successful Precision Mapping Include:

6/27/2019 6

Fleet Diversity

Multi-Rotor - Fixed-Wing - Helicopter

Large Areas Heavy Lift 3D Modeling

$,$$$ $$,$$$ $$$,$$$

6/27/2019 7

Strengths

• Maneuver in Tight Areas
• High Winds
• 3D Data Capture
• Topographic mapping up

to 150 acres Weaknesses

• Cybersecurity Concerns
• Firmware updates
• Limited flight time

Our Platforms

DJI Inspire 2

6/27/2019 8

Strengths

• Maps up to 1-square

mile areas

• High Endurance
• Corridor Mapping
• Cybersecurity
• Flight management

system Weaknesses

• Mountainous terrain
• Needs Room to

Maneuver and Land

Our Platforms

Black Swift S1

6/27/2019 9

Strengths

• Simultaneous Collection
• f LiDAR and Imagery
• Heavy Lift Capacity
• Topographic mapping
• Suited for Mountainous

Terrain and Highly Vegetated Areas Weaknesses

• Very Expensive
• Limited Endurance

Very few platforms of this caliber in the U.S.

Our Platforms

Altus ORC2

6/27/2019 10

• Autonomous Flight
• Offline Capability
• Intuitive User Interface
• Save flight plans for

reuse later

• Collects thousands of

Photos;

• Cybersecurity
• Datalink encryption

Flight Management Systems

Typical Features:

6/27/2019 11

Construction Monitoring Cut and Fill Analysis

Aerial Photography and Videography

• Generated with consumer grade drones;
• Very little flight planning, processing, piloting, and GIS experience required;
• No surveyed ground control required.

Standard Applications

6/27/2019 12

Topographic Mapping LiDAR Mapping Virtual Reality

• Generated using advanced sensors, professional grade platforms, and surveyed ground control.
• Surveying, data collection, processing, and GIS experience required.
• Products are geolocated in state or local coordinate systems.

Advanced Applications

6/27/2019 13

WCE Precision UAS Mapping Services:

Services Provided from August 2018 through December 2018 Total Area of Interest= 182 acres 38 GPS Surveyed Ground Control Points

Northwater Treatment Plant

6/27/2019 14

Superior Data as compared to Traditional Ground and Aerial Surveys

• Topographic Mapping at a 1-foot

Contour Interval

• Horizontal and Vertical Accuracy is

at or near Survey-Grade, which is 0.1-foot horizontally and vertically

• High-Resolution Orthomosaic

Image w/ 1” Pixel Resolution

• 3D Point Cloud with 24,027,418

Points with each Point Representing 1 square inch on the Ground

• 4k Video

All mapping was georeferenced and delivered in the Ralston Coordinate System

Northwater Treatment Plant Engineering Grade Deliverables

6/27/2019 15

Superior Data Quality

As Compared to Traditional Aerial and Ground Surveys

3D POINT CLOUD

• UAVs vastly reduce data capture costs and appreciably increase data quality and richness
• Point Cloud Contains 222,319,447 points
• Provides a Compete Representation of the Ground Surface

6/27/2019 16

WCE Compatible Workflows

• We don’t simply collect and deliver data.
• As engineers we can post-process the data and deliver it in virtually any format, and any

coordinate system.

• This is what sets us apart from other traditional UAS operators

6/27/2019 17

Vertical Accuracy Class Absolute Accuracy

RMSEz Non-Vegetated (cm) NVA at 95% Confidence Level (cm) VVA at 95th Percentile (cm) 1-cm 1.0 2.0 3 2.5-cm 2.5 4.9 7.5 5-cm 5.0 9.8 15 10-cm 10.0 19.6 30 15-cm 15.0 29.4 45 20-cm 20.0 39.2 60 33.3-cm 33.3 65.3 100 66.7-cm 66.7 130.7 200 100-cm 100.0 196.0 600

ASPRS Standards

Vertical Accuracy

6/27/2019 18

Horizontal Accuracy Class RMSEx and RMSEy (cm)

RMSEr (cm) Horizontal Accuracy at the 95% Confidence Level (cm) 0.63 0.9 1.5 1.25 1.8 3.1 2.50 3.5 6.1 5.00 7.1 12.2 7.50 10.6 18.4 10.00 14.1 24.5 12.50 17.7 30.6 15.00 21.2 36.7 17.50 24.7 42.8

ASPRS Standards

Horizontal Accuracy

6/27/2019 19

GPS SURVEYED CHECK POINT VS ORTHOMOSAIC IMAGE

How Accurate is Drone Mapping?

6/27/2019 20

Buyer Beware

Drone Operator Capability

• Not All Operators are Capable of Producing Engineering-Grade UAS Mapping
• Multi-million Dollar Construction Projects Demand the Best UAS Mapping Available

Multi-million dollar design and construction projects demand engineering-grade UAS Mapping

6/27/2019 21

“I must say, I was very impressed with

your work and very pleased to find a group who really understands how GIS, survey and reality capture come together in the civil engineering field.”

Mark Kauffman Technical Lead Project Visualization

Project Visualization

Combine Drone Data with Civil Engineering Design and Virtual Reality Provides Value Throughout the Project Life Cycle

6/27/2019 22

Benefits of using accurate 3D Data, from UAS in Due Diligence & Civil Engineering Design for Project Visualization:

• Virtual Site Visits
• Identify Conflicts
• Avoid Obstacles
• Mitigate Headaches
• Save Costs to Pay for Fees

Due Diligence & Civil Engineering Design

Riverbend Estates Subdivision

6/27/2019 23

Public Engagement & Approval

Augmentation Pond – Private Landowner – Phase 1

Benefits of using accurate 3D Data, from UAS in Virtual Reality (VR) for the Public Engagement and Approval Phase of Projects:

• Perception is Facilitated
• Critical Feedback Emerges
• Concerns Alleviated
• Property Agreements & Easements

Streamlined

6/27/2019 24

Client/Stakeholder Engagement

Jurisdictional Dam – Private Landowner – Phase 2

Benefits of using accurate 3D Data, from UAS in Virtual Reality (VR) for the Client/Stakeholder Engagement Phase of Projects:

• Sense of Place is Provided
• Sense of Time is Understood
• Project Vision is Embedded
• Construction Approval is Accelerated

6/27/2019 25

ASSESS PLAN DESIGN BUILD OPERATE MAINTAIN

3D, 4D, 5D & Integrated Modeling

Accurate 3D Data & the Project Lifecycle

Combining Drone Data with Civil Engineering Design and Virtual Reality Provides Value Throughout the Project Life Cycle

6/27/2019 26

October 19, 2016 – Top of the Star Dune at Great Sand Dunes National Park & Preserve

Questions and Answers

• Civil Engineering Services:
• Due Diligence
• Highway Design
• Stormwater Management
• Floodplain Modeling
• Land Development
• Construction Management
• Unmanned Aerial Survey Services:
• Precision Photogrammetric Mapping Services
• UAS to Engineering Workflow Consulting
• LiDAR Mapping Services
• UAS Program Implementation Consulting

Contact Info: Mary B. Wohnrade, P.E. mary@wcecivil.com www.wcecivil.com

GSDNP Staff Accolades

“Definitely the best imagery of the dunes to date”

–Andrew Valdez, NPS Geologist

WE ARE HERE TO HELP

• Take advantage of our expertise as a

preeminent UAS service provider.

• We provide engineering grade data you

can trust

Shaping the Future

• f Engineering
