SLIDE 1
1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2
TSX:V - ZON 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 Disclaimer - - PowerPoint PPT Presentation
TSX:V - ZON 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 Disclaimer - - PowerPoint PPT Presentation
TSX:V - ZON 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 Disclaimer CAUTIONARY STATEMENT REGARDING FORWARD-LOOKING INFORMATION Except for the statements of historical fact, the information contained in this document is of a forward-looking
SLIDE 2
SLIDE 3
3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3
Fully Diluted:
~65,300,00
Shares outstanding:
~57,210,000
Cash:
~$1,000,000
Current trading range:
$0.23 - $0.30
Linear Gold (Brigus Gold, TSX-BRD), (2004 - 2007) - Chief Geoscientist & Manager of IR, Nayarit Gold (TSXV-NYG) (2007 - 2010) Chief Geoscientist. Director of Asher Resources Inc.
Terry
Christopher President , Director & CEO
+ 25 years of executive experience with public companies; including Franco-Nevada, Aur Resources, Brigus Gold (formerly Linear Gold), Avalon Rare Metals and Linear Metals (now Stockport Exploration).
Brian
MacEachen CA, CFO
+ 15 years in capital
- markets. Co-Founder of
First Canadian Capital Markets, integrated financial and corporate services, IR, financing, corporate development. Instrumental raising $500 Million in financings.
Jason Monaco, Director
+ 15 years public market experience; mergers, corporate development, corporate reorganizations and IR.
Norm Eyolfson, Director
Corporate Structure & Management
SLIDE 4
4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4
- Cross Hills Iron Oxide Copper Gold, NFLD (2018 acquisition)
- Large regional structure with IOCG style mineralization.
- Geophysical surveys completed; multiple targets to test.
- Dunns Mountian target phase 1 drilling completed with a high-grade discovery.
- McConnells Jest, Yukon (Nov 2016 acquisition)
- Large intrusion related gold target adjacent to Victoria Gold’s new developing mine.
- Five holes drilled in 2016. One hole showed a gold discovery.
- Drill ready and wide open for exploration.
- Wings Point Gold Project, NFLD
- Bulk tonnage, permitted gold project. Plus, potential Sedex Targets
- Colombia Application
- Application sits over open areas between titles directly centred on the Gramalote
- Deposit. Currently the case is in ‘Special Court’.
Objectives:
Exploring for Large-Scale Gold and Copper Deposits
Corporate Strategy
SLIDE 5
5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5
Cross Hills, NL Wings Point, NL McConnels Jest, Yukon Gramalote, Colombia
Zonte’s Projects
SLIDE 6
6 6 6 6 6 6 6 6 6 6 6 6 6 6 6 6 6 6 6 6
The Project covers 25 km of the Cross Hills Structure with known zones of copper, gold and silver typical of IOCG systems. Discovery at Dunns Mountain shows the belt is fertile in that it has copper mineralization. Four targets to date;
- 1. Dunns – drilling continuing
- 2. K6 – drilling later this year
- 3. K7 – drilling later this year
- 4. Big K – drilling this coming winter.
Much of the property has yet to be explored and
- ffers years of exploration potential.
Opportunity to find a new copper belt in Canada
Not yet explored
Big K Dunns Mtn K6 K7
Cross Hills, NL - IOCG Project
SLIDE 7
7 7 7 7 7 7 7 7 7 7 7 7 7 7 7 7 7 7 7 7
Cross Hills, NL - IOCG Project
- Image: Magnetic Anomaly with gravity
contours and drill holes projected to surface
- Phase 1 drilling completed. Phase 2 in
progress.
- High-grade discovery in DH-19-004
(DH4) with grades of 14.0% Cu, 15.8 g/t Au and 352 g/t Ag over 0.43 m interval.
- Multiple mineralized intervals over a
70m core length.
- Phase 2 drilling will test numerous
features within the target area, which remains largely untested.
SLIDE 8
8 8 8 8 8 8 8 8 8 8 8 8 8 8 8 8 8 8 8 8 8
Cross Hills, NL - IOCG Project
SLIDE 9
9 9 9 9 9 9 9 9 9 9 9 9 9 9 9 9 9 9 9 9
Cross Hills, NL - IOCG Project
Disseminated to massive copper mineralization with ankerite, magnetite and epidote alteration. CH-19-004; 168 -170.76m
Bornite-chalcocite with ankerite Massive bornite & chalcocite
SLIDE 10
10 10 10 10 10 10 10 10 10 10 10 10 10 10 10 10 10 10 10 10 10 10 10
Cross Hills, Gravity Surveys
D
0.28% Cu 3.1 g/t Ag Trace Au
SLIDE 11
11 11 11 11 11 11 11 11 11 11 11 11 11 11 11 11 11 11 11 11 11
Newly discovered mineralized corridor
Cross Hills, NL - IOCG Project
A
N
Recently completed programs Surface mineralization was discovered on the eastern side of the target area; in the area of mineralization in DH4 when projected to surface. An Induced Polarization, gravity and additional magnetic surveys were completed at Dunns area and the K6-K8 area. Results Summary:
- Gravity survey in K6-K8 area identified two targets; At K6 and K7. Two drill
holes just completed on K6. K7 will be tested later. No discernable target at K8.
- IP survey at Dunns identified signatures spatially related to mineralization
in DH4. Drilling in progress.
- Gravity survey at Dunns identified a large anomaly sitting under the
magnetic signature..
- Similar sized gravity discovered at Big K. Plans to drill this target will be
finalized at a later date.
SLIDE 12
12 12 12 12 12 12 12 12 12 12 12 12 12 12 12 12 12 12 12 12
Cross Hills, NL - IOCG Project
3D gravity signature (pink) 3D magnetic signature (red)
Dunns Mountain Gravity and Mag anomalies
Dunns Mountain gravity survey identified a large anomaly rooted under the magnetic profile. Gravity anomaly measures 750m L X 400m W and up to 1000m D. Phase 1 drill holes tested the magnetic signature. Phase 2 drilling will test a series combination of structure, gravity and IP signatures.
SLIDE 13
13 13 13 13 13 13 13 13 13 13 13 13 13 13 13 13 13 13 13 13 13 13 13
Cross Hills, NF - IOCG Project
K6 Target
Two drill holes completed. Anomalous values intersected. Native copper discovered in CH-19-006 Large parts of the target yet to be drill tested.
SLIDE 14
14 14 14 14 14 14 14 14 14 14 14 14 14 14 14 14 14 14 14 14 14 14 14
Cross Hills, NF - IOCG Project
Big K Target
Gravity and magnetic anomaly coincident. Large target to be drilled. High-grade copper at southern end of target area.
2.8% Cu & 10 g/t Ag
SLIDE 15
15 15 15 15 15 15 15 15 15 15 15 15 15 15 15 15 15 15 15 15
Cross Hills, NL - IOCG Project
Dunns Mountain and Big K Gravity anomalies
Dunns Mountain Gravity Anomaly Big K Gravity Anomaly
SLIDE 16
16 16 16 16 16 16 16 16 16 16 16 16 16 16 16 16 16 16 16 16 16 16 16
Cross Hills, NF - IOCG Project
K7 Target
The gravity anomaly sits adjacent to a mag high. It has significant size and depth profile. A large porphyritic unit in the target area shows IOCG alteration. Target shows elevated Cu in MMI soils above and adjacent to the target.
SLIDE 17
17 17 17 17
McConnells Jest, Yukon
Located Between Two Significant Resource Areas
17
McConnells Jest borders Victoria Gold’s Dublin Gulch to the west which has:
- 6.3 Million oz Au Resource
- 3.3 Million oz Au Reserve
- H2 2020 production
anticipated to be 85-100k
- unces at an all in sustaining
cost of $950-$1100/oz
- 10 year mine life
- New discovery close to
Zonte/Victoria border.
Eagle Mine in production at Dublin Gulch
Keno Mines going back into production Q4. Historic production +220M ounces of silver
To the east McConnells Jest borders Alexco Resources which is: Set to resume production of high- grade silver in Q4 2020 Mine is a past producer of +220M
SLIDE 18
18 18 18 18 18
Dublin Gulch (DG) vs. McConnells Jest (MJ)
18
- Identical age, geology, geochemistry and structural profile
- MJ is larger, not eroded hence providing additional exploration potential
- MJ has only five drill holes, with one showing a gold discovery
- MJ has only been lightly explored beyond drilled areas
VICTORIA GOLD ZONTE METALS
Dublin Gulch Project McConnells Jest
Comparison of Victoria Gold’s Dublin Gulch Project to Zonte’s McConnels Jest Project
SLIDE 19
19 19 19 19 19 19 19 19 19
McConnels Jest Project, Yukon
Discovery at Two-Four Zone
Two drill holes completed MJ-03 showed anomalous values over 100m (106.78m @ 0.18 g/t Au) MJ-04 intersected two zones:
- Top of core; 20.44m of 0.72 g/t
- Bottom of core; 20.28m of 0.69 g/t
McConnels Pluton
SLIDE 20
ZONTE
Victoria’s new discovery: Raven and Nugget
Not explored
Nugget & Raven Victoria Gold Zonte Zonte’s MJ intrusion and Victoria’s Raven/Nugget target. Are they related? Highlighted Raven trench results:
- 10.0m at 6.64 g/t Au;
- 12.0m at 7.91 g/t;
- 60m at 1.12 g/t Au;
- 124m at 3.51 g/t Au;
- 50m at 4.15 g/t Au.
Highlighted Raven drill results:
- 14.8m at 2.05 g/t Au;
- 2.8m at 7.72 g/t Au;
- 5.9m at 4.48 g/t Au;
- 15.9 m at 2.35 g/t Au;
- 7.7m at 3.36 g/t Au;
- 42.4m at 1.05 g/t Au;
- 88.1m at 0.60 g/t Au .
- Source; Victoria Gold
webapage.
Higher grade discovered at the Raven and focus of 10,000m of upcoming drilling
Eagle Mine in production
- 10 year mine life
- New exploration discovered Raven/Nugget
target close to Zonte’s boundary
SLIDE 21
21 21 21 21 21 21 21 21
Wings Point Gold Project, NL
21
3600 hectare property at Northern end of the central Gold Belt where New Found Gold has made a high-grade discovery. On the property:
1. Four IP Grids completed 2. Pit Grid has 6 drill holes with anomalous values. 3. All grid areas have targets of interest including IP anomalies that have never been followed up. 4. Targets included intreperted massive and disseminated sulphide targets and sedex targets. 5. Small soil sampling programs have identified further targets. 6. The southern claim block holds a Noranda discovered high-grade gold till
- f 59.2 g/t
Operating Gravel Pit
SLIDE 22
22 22 22 22 22 22 22 22
Wings Point Gold Project, NL
22
- 1. Pit target.
- 2. Six drill holes.
- Tested a small area.
- Anomalous values with sulphide
systems.
- 2. Eastern Anomaly
- Geophysical and As-in-Soil Anomaly
- 800m x 225m & up to 150 m deep
- Coincident with Au in bedrock
mineralization
- Structural/strain controls(?)
Operating Gravel Pit
SLIDE 23
23 23 23 23 23 23 23 23 23 23
Possible opportunity in Colombia:
Open Area Under Gramalote Target Application
- Permitted for
Production: 400,000
- z/yr over 9 years
- Zonte has filed legal
action to have the application titled according to the applicable mining code.
Deposit owned by AngloGold Ashanti (50%) and B2Gold (50%)
Zonte and Partners application
SLIDE 24
24 24 24 24 24 24 24 24 24 24 24 24 24 24 24 24 24 24 24 24 24 24 24 24 24
Summary
- Three drill ready projects:
(1) Cross Hills (2) McConnells Jest (3) Wings Point
- Phase 1 drilling at Cross Hills completed.
- Dunns first target drilled and has proven a fertile IOCG
system with a high-grade discovery and multiple mineralized intervals within CH-19-004. Drill Phase 2 in progress.
- Cross Hills could represent a new copper belt in Canada.
- Company is well structured and focused on discovery with
maintaining control on dilution.
