Trinity uses nmap in the film The Matrix Reloaded to hack the city - - PowerPoint PPT Presentation

Trinity uses nmap in the film “The Matrix Reloaded” to hack the city power grid

Benjamin uses nmap in “Who Am I - No System is Safe” to compromise the local power company, causing a brief blackout

Lisbeth uses nmap in the film “The Girl with the Dragon Tattoo” (just in general)

E-Lita explains the nmap functionality in the soft-core porn “HaXXXor Volume 1: No Longer Floppy”

create your

• wn exercise

Network Scanning - Advanced Port Scanning with nmap

Marc Müller, Ellen Maeckelburg

9

Motjvatjon

Master your NMap skills in order to learn more about your network!

10

Motjvatjon

• Where is it relevant?

– Security scanning, informatjon gathering, hacking

• Who uses it?

– Private people, security personnel, hackers

• Why is it interestjng?

– Discover networks, essentjal skill in IT, awareness

11

Lecture overview

• Learning Goals
• Port scanning basics

– TCP – UDP

• Difgerent scanning techniques
• Idle scan
• Cool NMap features
• Scan Detectjon

12

Summary/ Learning Goals

13

The Following Learning Goals are Covered in the Lecture PreLab Lab Understand how port scanning works X Learn difgerent scanning techniques X X Understand and observe how scans are detected by target hosts X X X Firewalls basics X X Mastering the scanning tools NMAP X X Execute fancy stealthy scans and discover running services X

Port scanning basics

What are ports?

• Allow difgerent services to use single physical

connectjons

• Range 0-65535

– Well-known ports 0-1023 – Registered ports 1024-49151 – Ephemeral ports 49151-65535

6

Port scanning basics

TCP Handshake:

6

A B A B A B SYN SYN SYN/ACK SYN/ACK ACK RST RST Successful Unsuccessful Unexpected (RFC: 793)

Port scanning basics

UDP:

6

A B A B A B UDP packet UDP packet ICMP error

• > open

type 3 Code 3,

• > closed

tpe 3 Code 1,2,9...

• > filtered

no response

• > open|filtered

UDP packet UDP packet

Difgerent scanning techniques

• TCP

– connect scan – SYN scan – ACK scan – FIN scan – Idle scan

• UDP scan
• Host Discovery

7

Idle scan

source: htups://advancedinternetuechnologies.fjles.wordpress.com/2012/01/ipv4-header.png 7

Idle scan

9 Scanner Target Idle host 1: SYN / ACK 2: RST (IP Id)

Idle scan

10 Scanner Target Idle host 3: SYN with src address of Idle host 4: Open: SYN/ACK to Idle host IP Id increased 5: RST

Idle scan

11 Scanner Target Idle host 6: SYN / ACK 7: RST (IP Id)

Idle scan

Requirements:

• can predict IP Id (IP fragmentation identifier)
• probe Idle host for current sequence number
• host is truly idle

Conclusions:

• IP Id increased by 1

Port is closed or filtered

• IP Id increased by > 1

Port is open

12

Cool NMap features

Applicatjon & OS version detectjon

6

sudo nmap -A -6 dead:beef:11ab:1:92e2:baff:fe2a:8fc7 sudo nmap -O -sV -6 dead:beef:11ab:1:92e2:baff:fe2a:8fc7 Starting Nmap 7.60 ( https://nmap.org ) at 2019-03-15 08:48 CET Nmap scan report for hrtbrthtz5egd-v6.eduroam.dynamic.rbg.tum.de (dead:beef:11ab:1:92e2:baff:fe2a:8fc7) Host is up (0.000023s latency). Not shown: 999 closed ports PORT STATE SERVICE VERSION 22/tcp open ssh OpenSSH 7.6p1 Ubuntu 4ubuntu0.3 (Ubuntu Linux; protocol 2.0) Device type: general purpose Running: Linux 3.X OS CPE: cpe:/o:linux:linux_kernel:3 OS details: Linux 3.7 - 4.4 Network Distance: 0 hops Service Info: OS: Linux; CPE: cpe:/o:linux:linux_kernel OS and Service detection performed. Please report any incorrect results at https://nmap.org/submit/ . Nmap done: 1 IP address (1 host up) scanned in 6.90 seconds

Cool NMap features

Host detectjon

• -sL List Scan

simply list targets to scan

• -sP Ping Scan

go no further than determining if host is

• nline

6

Cool NMap features

Automatjon

• You can determine how the output of NMap

should look like -> can use it for automatjon

• oN
• utput in normal format
• oX

XML

• oS

s|<rIpt kIddi3

• oG

Grepable

6

Scan detectjon

How to detect port scans?

• Scan characteristjcs:

– One src IP address, many destjnatjon ports – High volume of difgerent connected ports

13
