Trees

Tiziana Ligorio

1

Today’s Plan

Trees Binary Tree ADT Binary Search Tree ADT

2

Announcements

Questions?

3

ADT Operations we have seen so far

Bag, List, Stack, Queue Add data to collection
 Remove data from collection
 Retrieve data from collection

 Stack and Queue always position based Bag, retrieval always value based (there are no positions) List has both. For all of them, data organization is linear

4

5

Tree

Non-linear structure A special type of graph Can represent relationships Hierarchical (directional) organization (E.g. family tree)

6

7

What can you tell me about this tree?

8

Node Edge

9

Node Child Parent Siblings Ancestor Descendant Edge

10

Node Child Parent Siblings Leaf Root Ancestor Descendant Edge Subtree

11

Node Child Parent Siblings Leaf Root Ancestor Descendant Edge Subtree How many leaves in this tree?

12

Node Child Parent Siblings Leaf Root Ancestor Descendant Edge Subtree Path Height = 4

Path: a sequence of nodes c1, c2, ..., ck where ci+1 is a child of ci. Height: the number of nodes in the longest path from the root to a leaf. Subtree: the subtree rooted at node n is the tree formed by taking n as the root node and including all its descendants.

13

Different shapes/structures

14

Both n = 16 Both 11 leaves Different height

We have already seen Trees!

Mostly as a “thinking tool”

• Decision Trees
• Divide and Conquer

15

Binary Tree ADT

16

BinaryTree

17

Each node has at most 2 children

BinaryTree

18

Each node has at most 2 children Left Child Right Child Left Subtree Right Subtree

Different shapes/structures

19

Both h = 3 and one leaf But different

Binary Tree Applications

20

Algebraic Expressions

21

* + + 3 * 3 4

(3 + 4) * 5

5

3 + 4 * 5

4 5

Decision Tree

22

Is it a mammal?

Does it have stripes? Does it fly? Is it carnivore? It’s a pig It’s an eagle It’s an ostrich It’s a tiger It’s a zebra Yes Yes Yes Yes No No No No

Huffman Tree

Huffman Encoding Compression Algorithm (Huffman Encoding):
 “In 1951, David A. Huffman for his MIT Information Theory class term paper hit upon the idea of using a frequency-sorted binary tree and quickly proved this method the most efficient.” IDEA: Encode symbols into a sequence of bits s.t. most frequent symbols have shortest encoding Not encryption but compression => use shortest code for most frequent symbols No codeword is prefix to another codeword (i.e. if a symbol is encoded as 00 no other codeword can start with 00)

23

Huffman Tree

24

50% 20% 20% 5% 3% 2%

Huffman Tree

25

50% 20% 20% 5% 3% 2% 5%

Huffman Tree

26

50% 20% 20% 3% 2% 5% 10% 5%

Huffman Tree

27

50% 20% 3% 2% 5% 10% 5% 30% 20%

Huffman Tree

28

50% 20% 3% 2% 5% 10% 5% 30% 20% 50%

Huffman Tree

29

50% 20% 3% 2% 5% 10% 5% 30% 20% 50% 100%

Huffman Tree

30

50% 20% 3% 2% 5% 10% 5% 30% 20% 50% 100%

1 1 1 1 1

Huffman Tree

31

50% 20% 3% 2% 5% 10% 5% 30% 20% 50% 100%

1 1 1 1 1

100 11 1010 10110 10111

Lecture Activity

Think about structure! Draw ALL POSSIBLE binary trees with 4 nodes Label each tree with its height and number of leaves.

32

33

IMGAGE FROM : http://www.durangobill.com/BinTrees.html

Tree Structure

34

A C D E F G B C D E G A E B D C F G E B D C F G B A F A

h = 3 h = 5 h = 7 h = 7

Structure definitions may vary across different sources. The following comes form your textbook and will be used in this course and on exams

35

Tree Structure

36

A C D E F G B C D E G A E B D C F G E B D C F G B A F A

h = 3 h = 5 h = 7 h = 7 What is the maximum (minimum) height of a tree with 7 nodes?

Tree Structure

37

A C D E F G B C D E G A E B D C F G E B D C F G B A F A

h = 3 h = 5 h = 7 h = 7 WE WILL LOOK AT THE GENERAL ANSWER NEXT

Full Binary Tree

38

Every node that is not a leaf has exactly 2 children Every node has left and right subtrees of same height All leaves are at same level h

Complete Binary Tree

39

A three that is full up to level h-1, with level h filled in from left to right All nodes at levels h-2 and above have exactly 2 children When a node at level h-1 has children, all nodes to its left have exactly 2 children When a node at level h-1 has

• ne child, it is a left child

(Height) Balanced Binary Tree

40

For any node, its left and right subtrees differ in height by no more than 1 All paths from root to leaf differ in length by at most 1

41

Balanced Unbalanced

Maximum Height

42

n nodes every node 1 child

h = n

Essentially a chain

Minimum Height

43

Binary tree of height h can have up to n = 2h - 1 For example for h = 3, 1 + 2 + 4 = 7 = 23 - 1 h = log2 (n+1) for a full binary tree For example: 1,000 nodes h ≈ 10 (1,000 ≈ 210) 1,000,000 nodes h ≈ 20 (106 ≈ 220)

Minimum Height

44

Binary tree of height h can have up to n = 2h - 1 For example for h = 3, 1 + 2 + 4 = 7 = 23 - 1 h = log2 (n+1) for a full binary tree For example: 1,000 nodes h ≈ 10 (1,000 ≈ 210) 1,000,000 nodes h ≈ 20 (106 ≈ 220)

Important when we will be looking for things in trees given some order!!! Recall analysis of Divide and Conquer algorithms

45

. . .

1 = 21 -1 1 h Total n 3 = 22 -1 2 7 = 23 -1 3 15 = 24 -1 4 n @ level 1 = 20 2 = 21 4 = 22 8 = 23 2h -1 h 2h-1

In a full tree:

Binary Tree Traversals

46

47

r TR TL Visit (retrieve, print, modify …) every node in the tree Essentially visit the root as well as it’s subtrees
 Order matters!!!

48

r TR TL Visit (retrieve, print, modify …) every node in the tree
 Preorder Traversal: if (T is not empty) //implicit base case
 {
 visit the root r
 traverse TL
 traverse TR
 }
 10 40 50 30 70 20 60

Preorder:

49

r TR TL Visit (retrieve, print, modify …) every node in the tree
 Preorder Traversal: if (T is not empty) //implicit base case
 {
 visit the root r
 traverse TL
 traverse TR
 }
 10 40 50 30 70 20 60

Preorder: 60

50

r TR TL Visit (retrieve, print, modify …) every node in the tree
 Preorder Traversal: if (T is not empty) //implicit base case
 {
 visit the root r
 traverse TL
 traverse TR
 }
 10 40 50 30 70 20 60

Preorder: 60, 20

51

r TR TL Visit (retrieve, print, modify …) every node in the tree
 Preorder Traversal: if (T is not empty) //implicit base case
 {
 visit the root r
 traverse TL
 traverse TR
 }
 10 40 50 30 70 20 60

Preorder: 60, 20, 10

52

r TR TL Visit (retrieve, print, modify …) every node in the tree
 Preorder Traversal: if (T is not empty) //implicit base case
 {
 visit the root r
 traverse TL
 traverse TR
 }
 10 40 50 30 70 20 60

Preorder: 60, 20, 10

53

r TR TL Visit (retrieve, print, modify …) every node in the tree
 Preorder Traversal: if (T is not empty) //implicit base case
 {
 visit the root r
 traverse TL
 traverse TR
 }
 10 40 50 30 70 20 60

Preorder: 60, 20, 10

54

r TR TL Visit (retrieve, print, modify …) every node in the tree
 Preorder Traversal: if (T is not empty) //implicit base case
 {
 visit the root r
 traverse TL
 traverse TR
 }
 10 40 50 30 70 20 60

Preorder: 60, 20, 10, 40

55

r TR TL Visit (retrieve, print, modify …) every node in the tree
 Preorder Traversal: if (T is not empty) //implicit base case
 {
 visit the root r
 traverse TL
 traverse TR
 }
 10 40 50 30 70 20 60

Preorder: 60, 20, 10, 40, 30

56

r TR TL Visit (retrieve, print, modify …) every node in the tree
 Preorder Traversal: if (T is not empty) //implicit base case
 {
 visit the root r
 traverse TL
 traverse TR
 }
 10 40 50 30 70 20 60

Preorder: 60, 20, 10, 40, 30

57

r TR TL Visit (retrieve, print, modify …) every node in the tree
 Preorder Traversal: if (T is not empty) //implicit base case
 {
 visit the root r
 traverse TL
 traverse TR
 }
 10 40 50 30 70 20 60

Preorder: 60, 20, 10, 40, 30

58

r TR TL Visit (retrieve, print, modify …) every node in the tree
 Preorder Traversal: if (T is not empty) //implicit base case
 {
 visit the root r
 traverse TL
 traverse TR
 }
 10 40 50 30 70 20 60

Preorder: 60, 20, 10, 40, 30, 50

59

r TR TL Visit (retrieve, print, modify …) every node in the tree
 Preorder Traversal: if (T is not empty) //implicit base case
 {
 visit the root r
 traverse TL
 traverse TR
 }
 10 40 50 30 70 20 60

Preorder: 60, 20, 10, 40, 30, 50

60

r TR TL Visit (retrieve, print, modify …) every node in the tree
 Preorder Traversal: if (T is not empty) //implicit base case
 {
 visit the root r
 traverse TL
 traverse TR
 }
 10 40 50 30 70 20 60

Preorder: 60, 20, 10, 40, 30, 50

61

r TR TL Visit (retrieve, print, modify …) every node in the tree
 Preorder Traversal: if (T is not empty) //implicit base case
 {
 visit the root r
 traverse TL
 traverse TR
 }
 10 40 50 30 70 20 60

Preorder: 60, 20, 10, 40, 30, 50, 70

62

r TR TL Visit (retrieve, print, modify …) every node in the tree
 Preorder Traversal: if (T is not empty) //implicit base case
 {
 visit the root r
 traverse TL
 traverse TR
 }
 10 40 50 30 70 20 60

Preorder: 60, 20, 10, 40, 30, 50, 70

63

r TR TL Visit (retrieve, print, modify …) every node in the tree
 Preorder Traversal: if (T is not empty) //implicit base case
 {
 visit the root r
 traverse TL
 traverse TR
 }
 10 40 50 30 70 20 60

Preorder: 60, 20, 10, 40, 30, 50, 70

64

r TR TL Visit (retrieve, print, modify …) every node in the tree
 Inorder Traversal: if (T is not empty) //implicit base case
 {
 traverse TL
 visit the root r
 traverse TR
 }
 10 40 50 30 70 20 60

Inorder: 10, 20, 30, 40, 50, 60, 70

65

r TR TL Visit (retrieve, print, modify …) every node in the tree
 Postorder Traversal: if (T is not empty) //implicit base case
 {
 traverse TL
 traverse TR
 visit the root r
 }
 10 40 50 30 70 20 60

Postorder: 10, 30, 50, 40, 20, 70, 60

BinaryTree ADT Operations

66

? ? ? ? ? ? ? ? ? ? ? ? ?

67

#ifndef BinaryTree_H_
 #define BinaryTree_H_
 template<typename ItemType>
 class BinaryTree
 {
 public:
 BinaryTree(); // constructor
 BinaryTree(const BinaryTree<ItemType>& tree); // copy constructor
 ~BinaryTree(); // destructor
 bool isEmpty() const;
 size_t getHeight() const;
 size_t getNumberOfNodes() const;
 void add(const ItemType& new_item);
 void remove(const ItemType& new_item);
 ItemType find(const ItemType& item) const;
 void clear();
 void preorderTraverse(Visitor<ItemType>& visit) const;
 void inorderTraverse(Visitor<ItemType>& visit) const;
 void postorderTraverse(Visitor<ItemType>& visit) const;
 BinaryTree& operator= (const BinaryTree<ItemType>& rhs);
 private: // implementation details here
 };// end BST #include "BinaryTree.cpp"
 #endif // BinaryTree_H_

#ifndef BinaryTree_H_
 #define BinaryTree_H_
 template<typename ItemType>
 class BinaryTree
 {
 public:
 BinaryTree(); // constructor
 BinaryTree(const BinaryTree<ItemType>& tree); // copy constructor
 ~BinaryTree(); // destructor
 bool isEmpty() const;
 size_t getHeight() const;
 size_t getNumberOfNodes() const;
 void add(const ItemType& new_item);
 void remove(const ItemType& new_item);
 ItemType find(const ItemType& item) const;
 void clear();
 void preorderTraverse(Visitor<ItemType>& visit) const;
 void inorderTraverse(Visitor<ItemType>& visit) const;
 void postorderTraverse(Visitor<ItemType>& visit) const;
 BinaryTree& operator= (const BinaryTree<ItemType>& rhs);
 private: // implementation details here
 };// end BST #include "BinaryTree.cpp"
 #endif // BinaryTree_H_

68

How might you add Will determine the tree structure This is an abstract class from which we can derive desired behavior keeping the traversal general

Considerations

69

Recall

Remember our Bag ADT?


• Array implementation

• Linked Chain implementation

• Assume no duplicates

Find an element: O(n) Remove: Find element and if there remove it O(n) Add: Check if element is there and if not add it O(n)

70

Recall

Remember our Bag ADT?


• Array implementation

• Linked Chain implementation

• Assume no duplicates

Find an element: O(n) Remove: Find element and if there remove it O(n) Add: Check if element is there and if not add it O(n)

71

Can we do better?

A Different Approach

72

• 2

2

• 1

3 6 4

A Different Approach

73

• 2

2

• 1

3 6 4

A Different Approach

74

• 2
• 1

3 6 4 2

A Different Approach

75

• 2
• 1

3 6 4 2

A Different Approach

76

• 2
• 1

3 6 4 2

A Different Approach

77

• 2
• 1

3 6 4 2

A Different Approach

78

• 2

3 6 4 2

• 1

A Different Approach

79

• 2

3 6 4 2

• 1

A Different Approach

80

• 2

3 6 4 2

• 1

A Different Approach

81

• 2

3 6 4 2

• 1

A Different Approach

82

• 2

6 3 2

• 1

4

A Different Approach

83

• 2

6 3 2

• 1

4

A Different Approach

84

• 2

6 3 2

• 1

4

A Different Approach

85

• 2

6 3 2

• 1

4

Find 5

A Different Approach

86

• 2

6 3 2

• 1

4

Find 5

A Different Approach

87

• 2

6 3 2

• 1

4

Find 5

A Different Approach

88

• 2

6 3 2

• 1

4

Find 5

A Different Approach

89

• 2

6 3 2

• 1

4 What’s special about the shape of this tree?

Binary Search Tree

90

• 2

6 3 2

• 1

4 Structural Property: For each node n
 n > all values in TL n < all values in TR

BST Formally

Let S be a set of values upon which a total ordering relation <, is defined. For example, S can be the set of integers.
 A binary search tree (BST) T for the ordered set (S,<) is a binary tree with the following properties:

• Each node of T has a value. If p and q are nodes, then we write p < q to mean that

the value of p is less than the value of q.


• For each node n ∈ T, if p is a node in the left subtree of n, then p < n.

• For each node n ∈ T, if p is a node in the right subtree of n, then n < p.

• For each element s ∈ S there exists a node n ∈ T such that s = n.

91

Binary Search Tree

92

Structural Property: For each node n
 n > all values in TL n < all values in TR r TR
 > r TL < r search(bs_tree, item)
 { if (bs_tree is empty) //base case
 item not found
 else if (item == root)
 return root
 else if (item < root)
 search(TL , item)
 else // item > root
 search(TR , item)
 }


Inserting into a BST

93

• 2

6 3 2

• 1

4 1

Inserting into a BST

94

• 2

6 3 2

• 1

4 1

Inserting into a BST

95

• 2

6 3 2

• 1

4 1

Inserting into a BST

96

• 2

6 3 2

• 1

4 1

Inserting into a BST

97

• 2

6 3 2

• 1

4 1

Inserting into a BST

98

• 2

6 3 2

• 1

4 1

Inserting into a BST

99

• 2

6 3 2

• 1

4 1 5

Inserting into a BST

100

• 2

6 3 2

• 1

4 1 5

Inserting into a BST

101

• 2

6 3 2

• 1

4 1 5

Inserting into a BST

102

• 2

6 3 2

• 1

4 1 5

Inserting into a BST

103

• 2

6 3 2

• 1

4 1 5

Inserting into a BST

104

• 2

6 3 2

• 1

4 1 5 You Grow a tree with BST property, you don’t get to restructure it (Self-balancing trees (e.g.Red-Black trees) will do that, perhaps in CSCI 335)

Growing a BST

105

7 4 10 2 1

Growing a BST

106

7 4 10 2 1 1 6 3 2 4 5

Lecture Activity

Write pseudocode to insert an item into a BST

107

Inserting into a BST

108

r TR
 > r TL < r add(bs_tree, item)
 { if (bs_tree is empty) //base case
 make item the root
 else if (item < root)
 add(TL , item)
 else // item > root
 add(TR , item)
 }


Traversing a BST

109

r TR
 > r TL < r Same as traversing any binary tree Which type of traversal is special for a BST?

Traversing a BST

110

r TR
 > r TL < r inorder(bs_tree)
 {
 //implicit base case if (bs_tree is not empty)
 {
 inorder(TL)
 visit the root
 inorder(TR)
 }
 }
 Same as traversing any binary tree Visits nodes in sorted ascending order

Efficiency of BST

Searching is key to most operations Think about the structure and height of the tree

111

Efficiency of BST

Searching is key to most operations Think about the structure and height of the tree O(h) What is the maximum height? What is the minimum height?

112

Tree Structure

113

5 8 1 4 7 9 7 3 5 4 8 9 3 1

h = 3 h = 7 n nodes

log2 (n+1) <= h <= n

Full BST Chain

n = 7

114

Operation In Full Tree Worst-case Search log2(n+1) 휪(h) Add log2(n+1) 휪(h) Remove log2(n+1) 휪(h) Traverse n 휪(n)

BST Operations

115

? ? ? ? ? ? ? ? ? ? ? ? ?

116

#ifndef BST_H_
 #define BST_H_
 template<typename ItemType>
 class BST
 {
 public:
 BST(); // constructor
 BST(const BST<ItemType>& tree); // copy constructor
 ~ BST(); // destructor
 bool isEmpty() const;
 size_t getHeight() const;
 size_t getNumberOfNodes() const;
 void add(const ItemType& new_item);
 void remove(const ItemType& new_item);
 ItemType find(const ItemType& item) const;
 void clear();
 void preorderTraverse(Visitor<ItemType>& visit) const;
 void inorderTraverse(Visitor<ItemType>& visit) const;
 void postorderTraverse(Visitor<ItemType>& visit) const;
 BST& operator= (const BST<ItemType>& rhs);
 private: //implementation details here
 };//end BST #include "BST.cpp"
 #endif // BST_H_

Looks a lot like a BinaryTree Might you inherit from it? What would you

• verride?

This is an abstract class from which we can derive desired behavior keeping the traversal general

#ifndef BST_H_
 #define BST_H_
 template<typename ItemType>
 class BST
 {
 public:
 BST(); // constructor
 BST(const BST<ItemType>& tree); // copy constructor
 ~ BST(); // destructor
 bool isEmpty() const;
 size_t getHeight() const;
 size_t getNumberOfNodes() const;
 void add(const ItemType& new_item);
 void remove(const ItemType& new_item);
 ItemType find(const ItemType& item) const;
 void clear();
 void preorderTraverse(Visitor<ItemType>& visit) const;
 void inorderTraverse(Visitor<ItemType>& visit) const;
 void postorderTraverse(Visitor<ItemType>& visit) const;
 BST& operator= (const BST<ItemType>& rhs);
 private: //implementation details here
 };//end BST #include "BST.cpp"
 #endif // BST_H_

117

Looks a lot like a BinaryTree Might you inherit from it? What would you

• verride?

This is an abstract class from which we can derive desired behavior keeping the traversal general
