Transport layer

slide-2
SLIDE 2

Transport services and protocols

 Provide communication

between application processes running on different hosts

 Protocols run in end system

OS

 Sender transport

 Breaks application messages into

segments, passes to network layer  Receiver transport

 Reassembles segments into

messages, passes to destination application

 Two main transport protocols

 TCP and UDP

applicatio n transport network data link physical applicatio n transport network data link physical

slide-3
SLIDE 3

Transport Layer Functions

 Demux to upper layer

 Delivering data to correct application process

 Connection setup

 Providing a connection abstraction over a connectionless

substrate

 Delivery semantics

 Reliable or unreliable  Ordered or unordered  Unicast, multicast, anycast

 Flow control

 Prevent overflow of receiver buffers

 Congestion control

 Prevent overflow of network buffers  Avoid packet loss and packet delay

 Security

slide-4
SLIDE 4
  • 1. Demux to upper layer (both TCP &

UDP)

 Which process gets this request?  Done via 16-bit source port and 16-bit destination port

in both UDP and TCP

FTP HTTP DNS NTP TCP UDP IP NET1 NET2 NETn …

TCP/UDP IP

Port Number

Network

Protocol Field Type Field

slide-5
SLIDE 5

Internet services layered on top of TCP/UDP

 What uses TCP?

 HTTP (Web pre-2016)  SMTP (E-mail transmission)  IMAP, POP (E-mail access)‏

 What uses (mainly) UDP?

 DNS  NTP (network time protocol)  Highly interactive on-line games (First-Person Shooters)‏  Many protocols can use both

slide-6
SLIDE 6

Internet services layered on top of TCP/UDP

 Protocols and their ports listed in /etc/services on

*nix or C:\WIN*\system32\services

 IANA

 http://www.iana.org/assignments/port-numbers

echo 7/tcp echo 7/udp ssh 22/tcp # SSH Remote Login Protocol ssh 22/udp telnet 23/tcp smtp 25/tcp domain 53/tcp # Domain Name Server domain 53/udp http 80/tcp # WorldWideWeb HTTP http 80/udp # HyperText Transfer Protocol netbios-ssn 139/tcp # NETBIOS session service netbios-ssn 139/udp bgp 179/tcp # Border Gateway Protocol bgp 179/udp https 443/tcp # http protocol over TLS/SSL https 443/udp microsoft-ds 445/tcp # Microsoft Naked CIFS microsoft-ds 445/udp

slide-7
SLIDE 7

UDP: User Datagram Protocol

 Barebones transport protocol  UDP and transport layer functions

 Demux  Connection setup (none)

 Connectionless  No handshaking between sender and receiver  Minimal state

 Delivery semantics

 Unreliable, unordered, mostly unicast (multicast no longer

supported)  No flow control support  No congestion control support  No security support

slide-8
SLIDE 8

source port # dest port # 32 bits

Application data (message)‏ UDP segment format

length checksum Length, in bytes of UDP segment, including header

UDP: more

 Often used for streaming multimedia apps

 loss tolerant  rate sensitive

slide-9
SLIDE 9

 Flow and congestion

controlled:

 Pipelined operation to

control size of "pipe" (i.e. bandwidth)

 Pipeline of packets sized

by MSS (maximum segment size)

 Control algorithms to keep

sender from overwhelming receiver or network  Connection-oriented  Delivery semantics

 Reliable, in-order byte

stream

 3-way handshake to

initialize sender/receiver and provide connection integrity

 Error detection, correction  Retransmission  Duplicate detection

 Unicast (point-to-point)

 one sender, one receiver

 Full duplex (bi-directional

flow)

TCP: Overview

socket door TCP send buffer TCP receive buffer socket door

segment

application writes data application reads data

slide-10
SLIDE 10

source port # dest port #

32 bits

application data (variable length)‏ sequence number acknowledgement number

Receive window Urg data pnter checksum

F S R P A U

head len not used

Options (variable length)‏

URG: urgent data (generally not used)‏ ACK: ACK # valid PSH: push data now (generally not used)‏ RST, SYN, FIN: connection estab (setup, teardown commands)‏ # bytes rcvr willing to accept counting by bytes

  • f data

(not segments!)‏ Internet checksum (as in UDP)‏

TCP segment structure

slide-11
SLIDE 11

TCP

 TCP creates a reliable data transfer service on top of

IP’s‏unreliable‏service‏via

 Checksum  Sequence numbers  Acknowledgments  Retransmissions  Rate limits on sender

slide-12
SLIDE 12

What if the Data is Corrupted?

Internet GET windex.html GET index.html Solution: Add a checksum Problem: Data Corruption 0,9 9 6,7,8 21 4,5 7 1,2,3 6

X

slide-13
SLIDE 13

Segment integrity via checksum

 Checksum included in header by sender

 Generated by treating data in the packet as numbers and

adding them all up

 Receiver checks checksum

 Performs same operation as sender and checks

checksum field

 Corruption detected when no match

slide-14
SLIDE 14

Solution: Add Sequence Numbers Problem: Out of Order

What if the Data is Out of Order?

GET x.th inde ml GET x.thindeml GET index.html ml 4 inde 2 x.th 3 GET 1

slide-15
SLIDE 15

Sequence numbers

 Data‏in‏each‏packet‏is‏labeled‏with‏a‏“unique”‏number

 Establishes ordering amongst packets  Allows receiver to identify which packets have been received

and which have not

 Initialized during connection setup (i.e. 3-way handshake)

A B

SYN + Seq A SYN+ACK-A + Seq B ACK-B

slide-16
SLIDE 16

What if the Data is Lost?

Internet GET index.html Problem: Lost Data Internet GET index.html Solution: Timeout and Retransmit GET index.html GET index.html

slide-17
SLIDE 17

Acknowledgements and retransmissions

 TCP receiver sends an acknowledgement back to

sender for the data it receives

 Lets‏sender‏know‏to‏“move‏on”  Lets sender know that network has the capacity to deliver

its packets

 Retransmissions

 Via timeout events

 TCP uses single retransmission timer  Sender sends segment and sets a timer  Timer is based on measured round-trip times and round-trip time

variations

 (e.g. timeout after ave. rtt + 2*std. deviation)

 Exponential backoff if persistent loss

 Via missing acknowledgements

 If receiver reports it has received packets 1, 3, 4, and 5, sender

automatically resends 2 before timeout

slide-18
SLIDE 18

What if receiver has no resources (flow control)?

Internet PUT remix.mp3 Problem: Overflowing receiver buffers Solution: Receiver advertised window Internet PUT remix.mp3

16KB free

slide-19
SLIDE 19

TCP Flow control

 Receiver has a finite buffer

 App process may be slow reading it  Flow control to make sure sender won't overflow it  Match‏the‏send‏rate‏to‏the‏receiving‏app’s‏drain‏rate

 Rcvr advertises spare room in buffer by including value

  • f RcvWindow in each segment/ACK

 Also‏known‏as‏the‏“advertised”‏window  Sender limits unACKed data to RcvWindow to avoid

  • verflow
slide-20
SLIDE 20

TCP Flow control

 Problem: 16-bit advertised window field (in bytes)‏

 Maximum of 64KB !!

 Consider network with 1500 byte segments, 100ms

RTT, want 10 Gbps throughput

 BW*Delay = 10Gbs * 0.1s = 1Gbit

 In packets, W=83,333  In bytes, 1Gbit/8 = 125MB  Amount of data potentially in flight from sender to receiver  Need at least a 125MB receiver buffer to support!

 Solution: TCP window scaling option

 Scaling factor on advertised window specifies # of bits to shift to

the left

 Scaling factor exchanged during connection setup

slide-21
SLIDE 21

What if Network is Overloaded?

 Short bursts: buffer  What if buffer overflows?

 Packets dropped and retransmitted  Sender adjusts rate until load = resources

 Called‏“Congestion‏control”

slide-22
SLIDE 22

TCP congestion control

 End-host, window-based  Only place to really prevent collapse is at end-host  Added in late 80s due to congestion collapse on the

Internet

 Increase in network load results in decrease of useful

work

 A result of

 Spurious retransmissions of packets still in flight  Undelivered packets which consume network resources and are

dropped elsewhere in network

slide-23
SLIDE 23

TCP congestion control basics

 Keep a congestion window, (cwnd)‏

 Reduce when congestion is perceived  Increase otherwise (probe for bandwidth)‏  Size of window denotes how much network is able to

absorb

 “Size‏of‏the‏pipe”  Make cwnd as large as possible without loss  TCP‏“probes”‏for‏usable‏bandwidth‏continuously

 Increase cwnd until loss (congestion)‏  Decrease cwnd upon loss ,then begin probing (increasing)

again

 Recall‏receiver’s‏advertised‏window‏(rcv_wnd)‏  Sender’s‏maximum‏window

 min(rcv_wnd,cwnd)‏

slide-24
SLIDE 24

TCP slow start (circa 1990s)

 When connection begins, increase rate exponentially

fast until first loss event

 cwnd = 1 for 1st RTT  cwnd = 2 for 2nd RTT  cwnd = 4 for 3rd RTT

 When connection begins, cwnd = 1 MSS

 Example: MSS = 500 bytes & RTT = 200 msec  Initial rate = 20 kbps!

 Available bandwidth may be much larger than

MSS/RTT

 desirable to quickly ramp up to respectable rate

slide-25
SLIDE 25

TCP congestion avoidance

 Q: When should the exponential increase stop?  If loss occurs when cwnd = W

 Network can handle 0.5W ~ W segments  Cut cwnd in half, grow window more slowly  Grow cwnd by 1 every round-trip time  Results in additive increase

slide-26
SLIDE 26

1 2 4

RTT RTT RTT

W W+1 2W Congestion avoidance Fast Retransmit/Recovery Slow-start

TCP throughput

slide-27
SLIDE 27

TCP flow and congestion control issues

 Short transfers perform poorly  Flows timeout on loss if cwnd < 3

 Change dupack threshold for small cwnd

 Parameters tuned for 1980s modems!

 For a 1KB segment size and a 100ms RTT = 81kbps  Cable modems at 312x capacity  3-4 packet flows (most HTTP transfers) need 2-3 round-

trips to complete

slide-28
SLIDE 28

Short transfers

 Use larger initial cwnd

 IETF approved initial cwnd = 10  /usr/src/linux/include/net/tcp.h

/* TCP initial congestion window as per draft-hkchu-tcpm-initcwnd-01 */ #define TCP_INIT_CWND 10

slide-29
SLIDE 29

TCP flow and congestion control issues

 Problem: TCP Sawtooth for large W (long-fat pipes)

 For sawtooth W to 2W  Packets xferred in sawtooth

 W‏+‏(W+1)‏+‏(W+2)‏….‏+‏2W‏=‏(3W/2)‏*‏(W+1)‏=‏1.5W(W+1)‏  For W=83,333

 Packets xferred in sawtooth between losses = 10.4 billion  Loss rate = 1 packet loss per sawtooth ➜ L = 10-10 Wow

 Sawtooth length = W*RTT

 For W=83,333 and RTT=100ms, sawtooth length over 2 hours  Average connection throughput ¾ of capacity

slide-30
SLIDE 30

Standard TCP

 Low window size resilience to packet loss in High-

Speed Network

Packet loss Time (RTT) Congestion avoidance Packet loss Packet loss cwnd Slow start Packet loss

100,000 10Gbps 50,000 5Gbps 1.4 hours 1.4 hours 1.4 hours

TCP

Slow Increase cwnd = cwnd + 1 Fast Decrease cwnd = cwnd * 0.5

slide-31
SLIDE 31

Standard TCP over different capacities

155 622 2500 5000 10000 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1 2000 4000 6000 8000 10000 Link Utilization Link Capacity (Mbps)

Cannot fully utilize the huge capacity of high- speed networks!

NS-2 Simulation (100 sec)

 Link Capacity = 155Mbps, 622Mbps, 2.5Gbps, 5Gbps, 10Gbps,  Drop-Tail Routers, 0.1BDP Buffer  5 TCP Connections, 100ms RTT, 1000-Byte Packet Size

slide-32
SLIDE 32

TCP Cubic for long-fat pipes

 The congestion window is a cubic function of time

since the last congestion event, with the inflection point set to the window prior to the event.

 Used in QUIC and in Linux versions > 2.6.19  Details in a paper if interested

slide-33
SLIDE 33

CUBIC window curves with competing flows (NS simulation in a network with 500Mbps and 100ms RTT), C = 0.4, β = 0.8.

slide-34
SLIDE 34

TCP BBR

 Google's replacement to TCP Cubic  Bottleneck Bandwidth and Round-trip propagation time

 Use recent measurements of network delivery rate and

round-trip time to model how quickly to send

 Maximum recent bandwidth and minimum recent round-

trip delay

 Experimental, but Google now owns many clients and

servers

slide-35
SLIDE 35

SSL/TLS

slide-36
SLIDE 36

TCP/IP security

 No initial support for

 Secrecy (eavesdropping)  Server authentication (impersonation)  Message integrity (man-in-the middle tampering)

 Netscape Secure Sockets Layer (SSL)‏ (1994)

 Bolted on between application and transport layer to add

security

 Now: Transport Layer Security (TLS)

 HTTP over TLS => https://  www.openssl.org for more information

 Adoption initially slow

 Server overhead  Lack of incentive  Difficulty in obtaining certificates

 Now ubiquitous

 Hardware support (x86 instructions for AES, dedicated ASICs)  Snowden surveillance revelations  Let’s‏Encrypt‏(2014) free certificates

slide-37
SLIDE 37

SSL/TLS overview

 Public-key encryption

 PK = private key, SK=secret key  m = plaintext, c=ciphertext

 Bob generates (SKBob , PKBob ), publishes PKBob  Alice: using PKBob encrypts messages and only Bob

can decrypt

Alice Enc m c Bob Dec c m

PKBob SKBob PKBob

slide-38
SLIDE 38

Certificates

 How does Alice (browser) obtain PKBob ?

 Note: Implicit trust in Browser of CA and its Public Key CA PK+proof “I‏am‏Bob” Browser Alice SKCA check proof Issue Cert with SKCA Bob’s key is PK Bob’s key is PK choose (SK,PK) Server Bob PKCA Verify cert

Bob uses Cert for an extended period (e.g. one year)

PKCA

For Let's Encrypt (you own DNS and IP)

slide-39
SLIDE 39

Certificate Authorities

⋮ ⋮

Browsers accept certificates from a large number of CAs

Top‏level‏CAs‏≈‏60 Intermediate CAs ≈‏1200

slide-40
SLIDE 40

SSL/TLS (server auth only)

Client random + cipher suites Sever random + certificate signed by PK of CA + cipher suites

Server Hello Client Hello Client Key Exchange

Master secret encrypted w/ server public key

Finished Encrypted application data (e.g. https)

  • 1. Verify cert, extract

server public key, encrypt master secret w/ key

  • 2. Decrypt master

secret with private key, generate keys and randoms Slow

Client Server

  • 3. Generate keys from

master secret + randoms

Initial SSL Handshake

with public-key of certificate authority (PK of CA)

slide-41
SLIDE 41

TLS 1.3

 Fast-open

 Establish cryptographic key between client and server

upon first connection (used as a connection cookie similar to ssh key)

 Allow server to immediately send to client upon initial SYN

packet to remove an RTT delay

 Basis for 0-RTT handshake in QUIC

slide-42
SLIDE 42

Result

slide-43
SLIDE 43

Issue #1

 But, what if someone reserves 0regonctf.org?  Can they generate  Yes. Conflation in UI of security and identity  Let's Encrypt being used heavily for phishing attacks

slide-44
SLIDE 44

Issue #2

 Two browser windows or one?

slide-45
SLIDE 45

Issue #3

 2011: Comodo and DigiNotar CAs hacked, issue certs

for‏‏Gmail,‏‏Yahoo!‏Mail,‏…

 2013: TurkTrust issued cert. for gmail.com  2014: Indian NIC (intermediate CA trusted by the root

CA IndiaCCA) issue certs for Google and Yahoo! domains

 2015: MCS (intermediate CA cert issued by CNNIC)

issues certs for Google domains

 Rogue nation-states owning certificate authorities

slide-46
SLIDE 46

Man in the middle attack via rogue cert

Attacker proxies data between user and bank. Sees all traffic and can modify data at will. NSA's Flying Pig program

bank

attacker ClientHello ClientHello BankCert BadguyCert ServerCert (Bank) ServerCert (rogue) GET https://bank.com SSL key exchange SSL key exchange

k1 k1 k2 k2

HTTP data enc with k1 HTTP data enc with k2 (cert for Bank by a valid CA)

slide-47
SLIDE 47

Potential solutions

 See Web Security course  Dynamic HTTP public-key pinning

 Let a site declare CAs that can sign its cert  On subsequent HTTPS, browser rejects certs issued by

  • ther CAs

 TOFU: Trust on First Use

 Certificate‏Transparency:‏‏‏[LL’12]

 CA’s‏must‏advertise‏a‏log‏of‏all‏certs. they issued  Browser will only use a cert if it is published on log server

 Efficient implementation using Merkle hash trees

 Companies can scan logs to look for invalid issuance  Certs on a block-chain?

slide-48
SLIDE 48

Labs

slide-49
SLIDE 49

Transport Lab #1: netstat, nc

 Login to a linuxlab machine

 Perform a netstat –l –t -4 to find all listening sockets on the

machine (those accepting incoming connections)

 The command flags specify sockets listening on TCP ports on IPv4 interfaces

 If the -4 flag does not work, omit it (you are on an IPv4-only machine)  Note that as a superuser, you can add a –p flag to determine the program that

  • wns each socket

 Examine the "Local Address" field

 Servers such as ssh and nginx typically listen on "*" to accept connections

from on any interface (INADDR_ANY when specifying socket)

 Servers intended for local access listen only on the loopback interface

(INADDR_LOOPBACK) (described via man 7 ip)

 For the named services

 Identify whether they are listening on all interfaces or are local  Then, look up their descriptions in /etc/services to find out what they are  Note: netstat *should* provide the same information as an external nmap

scan from the previous lab unless malware has been installed to hide itself locally on the machine  Repeat the exercise on your Ubuntu VM to identify what default

services are installed

slide-50
SLIDE 50

Transport Lab #1: netstat, nc

 On the linuxlab machine

 Use ifconfig to find the IP address of the machine  netcat (nc) is a program that can connect to arbitrary ports on a

server

 For example, the following command connects up to the web

server (port 80) of 131.252.220.66

nc 131.252.220.66 80

 Using the IP address of the machine, use nc to connect up to the

ssh port in order to identify the version of ssh that is being used on linuxlab machines (Control-c to exit)

 Recall the "Local Address" settings previously listed

 Using the IP address of the machine, try and use nc to connect up

to the mail transfer port. What happens?

 Replace the IP address with localhost and try again. What

software is being used to transfer mail on this machine?

 Explain why CAT has configured the mail transfer port this way.

slide-51
SLIDE 51

Transport Lab #2: iperf and TCP cwnd

 In this lab, we'll look at TCP throughput (as determined

by its window size) based on round-trip times

 On GCP, go to Compute Engine and create 3 VMs

 Zone: one in us-west1-b, one in Australia, and one in

Europe

 Machine type: micro  Boot disk: Ubuntu 16.04  Allow HTTP on both

 ssh into each and install iperf sudo apt-get update sudo apt-get install iperf  Start the iperf server on the HTTP port (80) of all VMs

and note the external IP address of each instance

sudo iperf –s –p 80

slide-52
SLIDE 52

 On your Ubuntu 16.04 VM on linuxlab

 Perform the following to install xmgrace and iperf

sudo apt-get update sudo apt-get install iperf grace

 Install the TCP probe module into the Linux kernel and set

it to trace connections to/from port 80. Make the probe

  • utput readable

sudo modprobe -r tcp_probe sudo modprobe tcp_probe port=80 full=1 sudo chmod 444 /proc/net/tcpprobe

 In this setup, your local VM will attempt to send as much

data as possible to each of the 3 GCP VMs. The tcp_probe kernel module will periodically sample the state of TCP in order for it to be dumped out.

slide-53
SLIDE 53

 Trace the connection to the us-west server cat /proc/net/tcpprobe > uswest.raw & TCPCAP=$! iperf -c <uswest server IP address> -p 80 (Wait for 10 seconds) kill $TCPCAP cat uswest.raw | awk '{print $1 " " $7}' >| uswest.out

 /proc/net/tcpprobe is the file system interface for pulling data

  • ut of the kernel module. Performing a cat on it will stream the

measurements into the file uswest.raw

 $! in the shell gives the PID of the backgrounded cat process. Its

value is saved into an environment variable before killed

 awk statement prints the first and seventh field of the file (timestamp

and cwnd value)

slide-54
SLIDE 54

 Repeat for the European server cat /proc/net/tcpprobe > ~/eu.raw & TCPCAP=$! iperf -c <europe server IP address> -p 80 (Wait for 10 seconds) kill $TCPCAP cat eu.raw | awk '{print $1 " " $7}' >| eu.out  Repeat for the Australian server (10 seconds) cat /proc/net/tcpprobe > ~/aust.raw & TCPCAP=$! iperf -c <australian server IP address> -p 80 (Wait for 10 seconds) kill $TCPCAP cat aust.raw | awk '{print $1 " " $7}' >| aust.out

slide-55
SLIDE 55

 Plot the output using xmgrace and take screenshots of

each (or plot them all together)

xmgrace uswest.out xmgrace eu.out xmgrace austr.out

 or

xmgrace *.out  What do the results indicate when compared?  Take down all instances when complete
