Towards a Reference Architecture for Service- Oriented Cross Domain Security Infrastructures

7th International Conference on Internet and Distributed Computing Systems

Wen Zhu

• Dr. Lowell Vizenor
• Dr. Avinash Srinivasan

Agenda

• Background
• Issues with Current Solutions
• Example Use Case
• CDS Reference Architecture
• Reference Architecture concerns
• CDC Participants
• CDS Protocol Candidates
• Putting It Together

Background

• Security Domain:
• Protection based on the classification and sensitivity of data
• Within each domain, a certain level of trust is assumed
• Cross Domain Solutions
• Filter and inspect traffic cross domain boundaries
• Primary consist of Guards that monitors communication

channels

Unclassified Top Secret CDS

Issues with Guard Implementations Today

• Mission applications design perspective
• Programs to design and implement their own individual

solutions

• No support workflows or full-duplex architectures
• Enterprise security infrastructure perspective
• Commonly associated with the links between domains
• CDS vendors define the mission application interfaces
• Limited configurability and API
• Lack of protocol for coordination among guards
• Effectiveness and performance perspective
• Lack of a standard and flexible framework for describing

information

CDC in the Context of Service Oriented Architecture (SOA)

• SOA Practices
• Communication at the

application layer

• Complex workflow
• Rich metadata (service

description and policy)

• End-to-end security
• Standard-based

interoperability

 Current Guards Capabilities

 Inspection at the transport

layer

 Not participate in workflow  Based on message context  Communication link  Lack of common standards

Example Use Case: Approval of Classified Travel

Unclassified Network Classified Network Financial Management System Guard Mission Planning System Mail Server Itinerary (S) Cost (U)

1 2 3 4

How is the guard inserted into the work flow? How does the guard determine which content to pass? And the redact action Is a single guard monitoring both Web Service and SMTP traffic on the network? Or it just monitors TCP/IP pockets?

Application Aspects

Architecture Concerns Policy Concerns

Infrastructure Aspects

Network Concerns Information Concerns Workflow Concerns

Framework Context Constraints Transport binding Information Encoding

CDS Reference Architecture

• The reference architect will provide
• A framework for discussing multi-faceted concerns of CDS
• A context in which interactions among CDS participants can be abstracted out, forming the

basis for protocols

CDS Participants

• Security Domain
• Implies a consistent a security vocabulary for users (human and systems), activities and

information

• Security Monitor (Optional)
• Defines consistent security policies for communication with other domains using the

security vocabulary.

• Mission Application
• Associate mission-specific concepts with the security vocabulary.
• Security Guard
• Enforces security policy defined by the mission application. MAY act a Policy Enforcement

Point for the domain.

Security Domain Security Domain Security Domain Mission Application Mission Application Mission Application Mission Application Mission Application Mission Application Mission Application Mission Application Mission Application Inter-guard Security Coordination Security Monitor Security Guard Security Guard Security Guard Security Administrator Security Monitor Enterprise Security System

Associating Guards with Security Domains

• A Guard SHOULD be associated with a single Domain.
• Security:
• Guard operates at the same security level as the

associated Domain without unnecessary privilege

• The same security monitor (system and human operator)

manages both the domain and the guard, avoiding policy conflicts and duplication

• Scalability:
• Avoid n square problem in a multi domain environment
• Implication:
• Guards needs to trust each other without revealing

mission information each other

Guards as Active Participants in Workflow

• Mission applications MUST be aware of the guards and communicate explicitly

with the guard

• Need a notification mechanism in case a message is blocked by the guard for the security

reasons.

• End-to-end encryption may prevent the guard from inspecting the
• Covert Channels will be impossible if the guard actively intercept and forward the

message.

• A Guard MAY provide additional information management services to mission

applications

• BPMN/BPEL could be extended to model the guards as part of the work flow

Opportunity for Standardizing Interactions – CDS Protocol Candidates

Security Domain Security Domain Security Domain Mission Application Mission Application Mission Application Mission Application Mission Application Mission Application Mission Application Mission Application Mission Application Inter-guard Security Coordination Security Monitor Security Guard Security Guard Security Guard Security Administrato r Security Monitor Enterprise Security System

Candidate 1: CDS Application Interface Candidate 2: Inter-guard Coordination Candidate 3: Security Monitor Interface Candidate 4: CDS Ontology

Putting It Together
