TOPONYMS 26th International Cartographic Conference August 25-30, 2013 | Dresden Germany PLACEMENT ON WEB MAPS analysis with proposed solutions University of Zagreb Robert upan and Stanislav Frange Faculty of Geodesy rzupan@geof.hr


slide-1
SLIDE 1

TOPONYMS PLACEMENT ON WEB MAPS

University of Zagreb Faculty of Geodesy Croatia

Robert Župan and Stanislav Frangeš rzupan@geof.hr sfranges@geof.hr

26th International Cartographic Conference August 25-30, 2013 | Dresden Germany

analysis with proposed solutions

slide-2
SLIDE 2

Presentation content

2

Introduction

Common errors of label placement

Assumption and rules

Research process

Research findings

Conclusion and additional research

slide-3
SLIDE 3

Introduction

Geographic names are the heritage of material and spiritual culture of a people, and the set of all toponyms makes heritage of all mankind

Map labelling – attaching text (toponyms) to geographic features

Features must be labelled to convey information.

3

slide-4
SLIDE 4

Problem Definition

4

The Map Label Placement Problem

Placing map feature labels

Legibly

Without overlap (features / other labels)

Maintaining visual association between features and their labels

slide-5
SLIDE 5

Map without toponyms

Maps without toponyms or their labels give little information

The same holds for charts and graphs

5

slide-6
SLIDE 6

Common errors of label placement for some most popular and global web map servers

Google Earth and common errors of label placement.(left fig. – shows overlaps and the right fig. shows duplicate toponym)

6

slide-7
SLIDE 7

Left – Google Earth with many overlaps with all layers turned on. Right – Google Maps with different label generalization degree between Slovenia and Croatia.

Common errors of label placement for some most popular and global web map servers

7

slide-8
SLIDE 8

Ask Maps web map service with map from Nokia and Microsoft and their misrepresentation and toponym visualization.

Common errors of label placement for some most popular and global web map servers

8

slide-9
SLIDE 9

Large scale map in Openstreetmap and some toponyms are shown on the map but some are not visible until zooming in although there is enough space?

Common errors of label placement for some most popular and global web map servers

9

slide-10
SLIDE 10

Two possibilities

Label Size Maximization

Maximize the size of the placed labels The labeling has to be complete

Label Number Maximization

Maximize the number of placed labels Labels have fixed size

Most literature focuses on Label Number Maximization, so will this presentation

10

slide-11
SLIDE 11

Three kinds of labels

Town 1 Town 2 Town 3 Town 4 Straight, horizontal name Curved name Curved name with spacing between characters

11

slide-12
SLIDE 12

Assumptions

toponyms related item or coordinate (oikonyms, oronyms) and

toponyms following the line (oronyms, regionyms, territoryonyms, hydronyms)

toponyms inside the closed polygon or an area that provide information about the that area (regionyms and territoryonyms or the names of national parks, military training grounds, etc.)

there is a hierarchy showing the various types of toponyms according to the criterion such as the type of toponyms, the importance of objects for which provide attribute information, categorization of subspecies of toponyms, color, font size of toponym, etc. Hierarchy is needed due to the significance of one kind of toponym over the other and automatic decision on the choice

  • f toponym placement, as one of the processes of map

generalization.

12

slide-13
SLIDE 13

Elastic labels

According to first assumption, solution is:

13

slide-14
SLIDE 14

Proposal for geometric solution

How to represent a rectangle?

X1 <X2 , Y1 <Y2 , and so forth.

14

slide-15
SLIDE 15

Horizontal collision detection

4 cases for collision detection

15

slide-16
SLIDE 16

Vertical collision detection

4 cases for collision detection

16

slide-17
SLIDE 17

Collision detection

No edges overlap, but still a collision for map label of

  • toponyms. This case

happens whenever X1′ < X1 and X2′ > X1.

17

slide-18
SLIDE 18

Collision detection

Except in that special case, a collision only exists if there is both a vertical and horizontal collision.

18

slide-19
SLIDE 19

Possible rectangle movements?

Sliding label presenting possible positions for toponym, software choice for priority placement, and priorities for label placement according to different authors.

19

slide-20
SLIDE 20

Detection of the intersection of lines and rectangle

Test of collision for moving rectangles (left) and case with no collision in final position although there is intersection.

20

slide-21
SLIDE 21

Detection of the intersection of lines and rectangle

Case where paths do not intersect

21

slide-22
SLIDE 22

Detection of the intersection of lines and rectangle

Paths of rectangle r1 and r2 intersects without collision at the final point.

22

slide-23
SLIDE 23

Detection of the predicted trajectory

r2 is below r1 when the left edge

  • f r1 is collinear

with the right edge of r2 so r1 and r2 do not collide

23

slide-24
SLIDE 24

Detection of the predicted trajectory

r2 is initially to the left of r1 and finishes below and to the right of A, colliding with r1 along the way.

24

slide-25
SLIDE 25

Using rectangles and rhombs depending on the type of letters

25

Collision prediction along curve or trajectory approximating letters with rectangulars or rhombs.

slide-26
SLIDE 26

Using rectangles and rhombs for

  • verlap detection
slide-27
SLIDE 27

Conclusions

The overlap of toponym with other cartographic

  • bjects and map content in this case is been ignored,

though it also must be taken into account

New algorithmic framework for fast and consistent labelling

To be tested how the proposed model behaves in the real computing server environment.

27

slide-28
SLIDE 28

TOPONYMS PLACEMENT ON WEB MAPS

University of Zagreb Faculty of Geodesy Croatia

Robert Župan and Stanislav Frangeš rzupan@geof.hr sfranges@geof.hr

26th International Cartographic Conference August 25-30, 2013 | Dresden Germany

analysis with proposed solutions

THANK YOU FOR YOUR ATTENTION!
