The Need for Complex Analytics from Forwarding Pipelines

Tom Tofigh, AT&T Nic Viljoen, Netronome Bryan Sullivan, AT&T

• Problem Statement
• Gaps in Real Time Observability
• Proposed SDN Based Observability
• Importance of Real-time Programmable Analytics
• Data Plane Programmability for Complex Analytics
• Programmable NIC Cards
• Summary

2

Agenda

• Require real time observability at data plane and control plane level
• Require programmable granular systems without the unscalable

approach of metering all the data all the time

Looking for the Call Drop Reason!

Problem Statement

4

• Achieve autonomous control through programmable data plane

analytics

• Real time dynamic instrumentation-virtual probes that gather trend data
• Targets specific flows, SOC/SmartNICs, VMs or containers for
• bservation
• Enables instant root cause analysis
• Provide scalable solutions for fine grained observation

Gaps: Dynamic & Real-Time Programmable Analytics

Autonomous Control System Concept

Measure Analyze

Proposed Evolution for Dynamic Probing

Dynamic Probe & Measurement Examples

QoE

• Flow jitter, latency measurement
• Packet drop rate
• Application analysis
• DDoS detection
• Deep packet inspection
• Stateful flow monitor

Customer Care

• Custom statistics
• Flow tracing
• Root cause analysis

Optimization

• Load estimation
• Traffic matrix calculation
• Elephant flow identification

compile disseminate configure collect analyze present dynamic P4 query Models Complex analytics

Security

ROADM (Core)

Spine Routers

Leaf-Spine Fabric

Spine Routers Spine Routers Spine Routers Leaf routers Leaf Routers Leaf Routers Leaf Routers Leaf Routers Leaf Routers

VM VM VM VM

OVS

VM VM VM

GPON (Access)

PON OLT MACs

Measurement Abstraction Interface

Analytics Platform (XOS + Services)

Apps Apps Apps Customer Care Security Diagnosis

ONOS + XOS

SmartNIC

ACORD Observability @ L0 – L7

2.8Tbps

The SmartNIC

Nic Viljoen, Netronome Systems

The Programmable SmartNIC

Challenges with Fixed-Function NICs

• Networking applications have diverse requirements
• Fixed-function ASICs have “baked-in” functionality and lack

flexibility Programmable NIC Advantages

• Develop custom networking applications
• High performance at network
• Preserve CPU cycles
• CPU OVS @40Gbps-12 cores
• Offload OVS @40Gbps-1 core
• Dynamic analytics
• High-level languages-P4/C
• Examples of SmartNICs: Netronome’s Agilio, Cavium LiquidIO

Programmable NIC Architecture

“Sea of Workers” for customized networking workloads Support for P4 and Match/Action structures Optimized memory architecture

vProbe Application

• Interpret flow stats and features
• Aggregate info to controllers-More
• n next slide

Flow Cache

• Keep state for >million flows
• Programmable state based on

vProbe application requirements

• 25G/40G line rate
• Programmable payload size/

number of flows tradeoff

• Self-learning

Augmenting Netronome’s Agilio OVS Software for Virtual Probing

Compute Node vProbe Application VM VM OVS Userspace Processes (ovs-dbserver, ovs-vswitchd)

Action Arguments

Linux Kernel

Agilio-CX
 Adapter

OVS Datapath

Actions Match Tables

Controller

Tunnels

Deliver to Host Update Statistics

OVS Datapath

Kernel Flow Table,
 Fallback Path Actions Exact Match Flow Cache

Flow Stats
 and Features Offload

F i r s t P a c k e t

• f

F l

• w

R e m a i n i n g P a c k e t s

• f

F l

• w

Flow Stats and Features Packet
 Rx/Tx

vProbe Application

Exact Match Flow Cache

vProbe Application

• Flow-based data and stat aggregation using techniques

such as machine learning

• Enables powerful use-cases through use of flow

analytics:

• Dynamic configuration for DDoS at VM level using

high speed clustering/classification algorithms (next slide)

• Network shaping based on predictive flow

characteristics-Work with University of Arizona has shown 50% improvement in offload utilisation

• Elastic VM resource provisioning
• Filtering and grouping for analysis at various levels of

visibility

• Rack, Data Center, Metro, Regional, National

Classify Aggregate Analyze React and Configure

Cycle Required in < 12s

1 2 3 4

OVS vProbe vProbe OVS

East/West DDOS Use Case

Per VM egress clustering

Drop traffic (targeted/all), Reduce VM resources,
 Shut down VM

• E/W DDoS attacks are prevalent
• Use vProbe to quickly identify infected VMs

and react by modifying flow rules or VMs

• Policy dictated by higher-level orchestrator
• Aggregated data can be disseminated to

multiple orchestration levels

• Enables distributed response at server/

rack/DC/regional levels

1) Classify 2) Aggregate 3) Analyze 4) Configure

1 3 4 2

• Intelligent network would benefit from programmable switches, NICs

and CPU

• NIC based offload is essential as CPU power is not scaling at the rate
• f Network traffic increase
• AT&T’s John Donovan estimated our traffic has increased by 150,000%

since 2007

• This means offload is essential to negate cost and maintain

performance

• Flexible offload opens up potential analytics use cases that have

previously not been tenable

Observability-Intelligence at the Edge

Overview-What do you need to find a needle

OBSERVABILITY the ability to statefully observe connections COMPUTABILITY the ability to monitor and aggregate complex data in real time FLEXIBILITY the ability to create a real time feedback loop using dynamic data plane and control functions

With Dynamic Programmable vProbe

• We are looking to gather a list of use cases for a dynamic analytics platform

currently being developed

• Email: Tom Tofigh (Tofigh@att.com) or Nic Viljoen

(nick.viljoen@netronome.com)-email address with an k!

• Join us for the next series of POCs

Thank You!

Call to Action-We Need Your Use Cases!
