slide-1
SLIDE 1

Time resolved scattering experiments

Clement Blanchet

slide-2
SLIDE 2

Time resolved experiments?

  • Studies of systems that changes over time
  • Collect data at different time point of the

reaction

6/24/2016 Time resolved scattering studies - C. Blanchet

slide-3
SLIDE 3

Time scale of biological processes

(protein folding)

6/24/2016 Time resolved scattering studies - C. Blanchet

Different time scales Different experimental setups

slide-4
SLIDE 4

Ingredients of time resolved experiments

  • Controlled triggering of the reaction of

interest

  • Way of monitoring the reaction

6/24/2016 Time resolved scattering studies - C. Blanchet

slide-5
SLIDE 5

Triggering

6/24/2016 Time resolved scattering studies - C. Blanchet

Modification of physical condition (T, P) Modification of chemical conditions

  • pH jump
  • Denaturing agent
  • Addition of salts or other additives

Modification of the system itself Flash photolysis, photosensitive protein

slide-6
SLIDE 6

Limitation – triggering

  • Triggering:

– Simultaneous, fast and homogeneous triggering at the time scale of the reaction

6/24/2016 Time resolved scattering studies - C. Blanchet

0.2 0.4 0.6 0.8 1 1.2 50 100 150 200 0.2 0.4 0.6 0.8 1 1.2 50 100 150 200 0.2 0.4 0.6 0.8 1 1.2 50 100 150 200

slide-7
SLIDE 7

How fast can you trigger the reaction?

  • Depends on the triggering methods

– Mixing:

  • seconds to ms (with fast mixing devices)
  • Limited by mixing, diffusion time

– P-Jump:

  • Diffusion of the pressure shockwave: speed of sound ms
  • In practice micros-ms

– Light triggered reaction:

  • Practically not limited for “direct” triggering (limitation:

speed of light)

  • Limited by intermediate reaction in the case of indirect

triggering (T-Jump, caged compound)

6/24/2016 Time resolved scattering studies - C. Blanchet

* Small measurement cell helps.

slide-8
SLIDE 8

Monitoring the reaction

  • Many spectroscopic technics can and have been used
  • SAXS is a good technics to study reaction of biological

system

– Samples are in solution, in a quasi-native state. Many reaction takes place in solution and can be triggered in a controlled manner – Data can be collected quickly: Possibility to study fast reaction

  • SANS: long collection time, limited to very slow reaction
  • Different mode of data collection

6/24/2016 Time resolved scattering studies - C. Blanchet

slide-9
SLIDE 9

Continuous vs pump-probe

6/24/2016 Time resolved scattering studies - C. Blanchet

t t

Perturbation Perturbation Probe Probe

∆t ∆t

Continuous Pump-probe

slide-10
SLIDE 10

Continuous vs pump-probe

6/24/2016 Time resolved scattering studies - C. Blanchet

t t

Perturbation Perturbation Probe Probe

∆t ∆t

slide-11
SLIDE 11

Continuous vs pump-probe

6/24/2016 Time resolved scattering studies - C. Blanchet

t t

Perturbation Perturbation Probe Probe

∆t ∆t

slide-12
SLIDE 12

Limitation – Collection time

6/24/2016 Time resolved scattering studies - C. Blanchet

0.2 0.4 0.6 0.8 1 50 100 150 200 0.2 0.4 0.6 0.8 1 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 160 170 180 190 200 210 220 0.2 0.4 0.6 0.8 1 50 100 150 200

slide-13
SLIDE 13

Limitation – Collection time

6/24/2016 Time resolved scattering studies - C. Blanchet

slide-14
SLIDE 14

Short collection time - Fast detector

  • Photon counting detector: Pilatus (300Hz),

Eiger (up to 3kHz), Xfel detectors,…

  • Gas detector (Theoretically, up to 1MHz)

6/24/2016 Time resolved scattering studies - C. Blanchet

slide-15
SLIDE 15

Short collection time – Short X-ray pulse

  • Use short beam pulse to overcome the

detector limitation (using fast shutter, chopper,…)

6/24/2016 Time resolved scattering studies - C. Blanchet

Chopper

Detector collection X-ray pulse

slide-16
SLIDE 16 11600 11800 12000 12200 12400 12600 12800 13000
  • 2e-7
2e-7 4e-7 6e-7 8e-7 1e-6 11600 11800 12000 12200 12400 12600 12800 13000
  • 2e-7
2e-7 4e-7 6e-7 8e-7 1e-6 11600 11800 12000 12200 12400 12600 12800 13000
  • 2e-7
2e-7 4e-7 6e-7 8e-7 1e-6

Short collection time: High flux

  • Third generation synchrotron
  • Multilayer monochromator
  • Pink beam

6/24/2016 Time resolved scattering studies - C. Blanchet

Undulator Double crystal monochromator Multilayer monochromator

slide-17
SLIDE 17

Example high flux beam (BL40XU, Spring8)

6/24/2016 Time resolved scattering studies - C. Blanchet

slide-18
SLIDE 18

But careful radiation damage

6/24/2016 Time resolved scattering studies - C. Blanchet

slide-19
SLIDE 19

But careful radiation damage

  • Adapt collection strategy (pump and probe)
  • Use short pulses

6/24/2016 Time resolved scattering studies - C. Blanchet

slide-20
SLIDE 20

FEL Beam (SLAC Stanford)

6/24/2016 Time resolved scattering studies - C. Blanchet

Stan, C. A., Milathianaki, D., Laksmono, H., Sierra, R. G., McQueen, T. A., Messerschmidt, M., ... & Guillet, S. A. (2016). Liquid explosions induced by X-ray laser pulses. Nature Physics.

slide-21
SLIDE 21

Dead time

  • Time between the reaction is triggered and

the first point is collected (depends on triggering methods and collection time)

6/24/2016 Time resolved scattering studies - C. Blanchet

0.2 0.4 0.6 0.8 1 50 100 150 200

Short dead time required to study fast kinetic

slide-22
SLIDE 22

Examples

  • Sub-Second TR experiments

– Stopped-flow

  • Millisecond TR experiments

– Continuous flow – Caged compound

  • Ultrafast TR experiments

– Synchrotron – FEL

6/24/2016 Time resolved scattering studies - C. Blanchet

slide-23
SLIDE 23

Sub-second kinetics

  • Stopped-flow (dead time: 2-10 ms)

6/24/2016 Time resolved scattering studies - C. Blanchet

slide-24
SLIDE 24

Stopped flow - Example

Characterization of Transient Intermediates in Lysozyme Folding with Time-resolved Small-angle X-ray Scattering

Segel et al. JMB, 1999, Volume 288 (3), 489-499

6/24/2016 Time resolved scattering studies - C. Blanchet

slide-25
SLIDE 25

Lysozyme Folding

Lysozyme 3.6M GdmCl Buffer Without GdmCl Lysozyme 0.6M GdmCl 1 x 5 x

6/24/2016 Time resolved scattering studies - C. Blanchet

slide-26
SLIDE 26

Lysozyme Folding

  • Evolution of Rg in time

6/24/2016 Time resolved scattering studies - C. Blanchet

slide-27
SLIDE 27

Refolding model

6/24/2016 Time resolved scattering studies - C. Blanchet

(Wildegger & Kiefhaber, 1997)

U C

Rg = 23.5 A Rg = 19.6 A

slide-28
SLIDE 28

Interrupted refolding experiment

  • Double mixing step monitored by fluorescence

6/24/2016 Time resolved scattering studies - C. Blanchet

C

slide-29
SLIDE 29

Interrupted refolding experiment

  • Double mixing step monitored by fluorescence

6/24/2016 Time resolved scattering studies - C. Blanchet

slide-30
SLIDE 30

Reconstruction of the scattering profile

6/24/2016 Time resolved scattering studies - C. Blanchet

) ( ) ( ) ( ) ( ) ( ) ( ) , ( s I t s I t s I t t s I

N N I I C C

ν ν ν + + =

∑

=

k k k

s I v s I ) ( ) (

slide-31
SLIDE 31

Refolding model

6/24/2016 Time resolved scattering studies - C. Blanchet

slide-32
SLIDE 32

Continuous flow

6/24/2016 Time resolved scattering studies - C. Blanchet

Concentric capillary mixer Mixing time: 30 microseconds

Moskowitz & Bowman, Science, 1966

Turbulent mixing Laminar mixing

slide-33
SLIDE 33

Continuous flow

  • Continuous flow  high sample consumption

– Microfluidic continuous flow system

  • Space <-> time

– low flux OK – time resolution <-> flow rate and size of the beam

  • Dead time (SAXS) ≈150 microseconds

6/24/2016 Time resolved scattering studies - C. Blanchet

slide-34
SLIDE 34

Example continuous flow

6/24/2016 Time resolved scattering studies - C. Blanchet

Conformational landscape of cytochrome c folding studied by microsecond-resolved small-angle x-ray scattering. Akiyama et al. PNAS 2002

slide-35
SLIDE 35

Continuous flow

6/24/2016 Time resolved scattering studies - C. Blanchet

slide-36
SLIDE 36

Radius of gyration

6/24/2016 Time resolved scattering studies - C. Blanchet

slide-37
SLIDE 37

Kratky plots

6/24/2016 Time resolved scattering studies - C. Blanchet

slide-38
SLIDE 38

SAXS Curves

6/24/2016 Time resolved scattering studies - C. Blanchet

slide-39
SLIDE 39

Conformational landscape of Cyto C

6/24/2016 Time resolved scattering studies - C. Blanchet

slide-40
SLIDE 40

Caged compound release by flash photolysis

  • DM-nitrophen

6/24/2016 Time resolved scattering studies - C. Blanchet

slide-41
SLIDE 41

Calmodulin

A Compact Intermediate State of Calmodulin in the Process of Target

  • Binding. Yamada et al. Biochemistry 2012

6/24/2016 Time resolved scattering studies - C. Blanchet

Mastoparan

slide-42
SLIDE 42

Equilibrium measurement

6/24/2016 Time resolved scattering studies - C. Blanchet

slide-43
SLIDE 43

Kinetics

6/24/2016 Time resolved scattering studies - C. Blanchet

slide-44
SLIDE 44

6/24/2016 Time resolved scattering studies - C. Blanchet

0.5 ms 10 ms 140 ms 30 s With mastoparan Without mastoparan

slide-45
SLIDE 45

Model

6/24/2016 Time resolved scattering studies - C. Blanchet

slide-46
SLIDE 46

ULTRA-FAST TIME RESOLVED

6/24/2016 Time resolved scattering studies - C. Blanchet

slide-47
SLIDE 47

Ultra short collection time

  • Beamline ID09B, ESRF, Grenoble
  • Using the pulsed structure of the synchrotron
  • About 5000000 bunch/sec

6/24/2016 Time resolved scattering studies - C. Blanchet

slide-48
SLIDE 48

Isolate one bunch

  • Isolate one bunch (ms shutter + fast chopper)

6/24/2016 Time resolved scattering studies - C. Blanchet

slide-49
SLIDE 49

Single bunch experiment

  • High flux needed
  • Repetition of the measurements

6/24/2016 Time resolved scattering studies - C. Blanchet

slide-50
SLIDE 50

Pump and probe experiment

t

Trigger with Laser pulse Probe with X-ray τ

6/24/2016 Time resolved scattering studies - C. Blanchet

Bunch length ≈ 100 ps Resolution: up to 100 ps

slide-51
SLIDE 51

What is 100ps?

100 ps  second Second  315 years Light travels 3 cm in 100ps

6/24/2016 Time resolved scattering studies - C. Blanchet

? ?

slide-52
SLIDE 52

TR WAXS

Tracking the structural dynamics of proteins in solution using time-resolved wide-angle X-ray scattering. Cammarata et al. Nature 2008.

6/24/2016 Time resolved scattering studies - C. Blanchet

slide-53
SLIDE 53

T and R states of hemoglobin

Looking at the unbinding of oxygen by hemoglobin

6/24/2016 Time resolved scattering studies - C. Blanchet

slide-54
SLIDE 54

Experimental setup

6/24/2016 Time resolved scattering studies - C. Blanchet

slide-55
SLIDE 55

Structural change in hemoglobin

6/24/2016 Time resolved scattering studies - C. Blanchet

slide-56
SLIDE 56

FEL

6/24/2016 Time resolved scattering studies - C. Blanchet

Levantino, M., Schirò, G., Lemke, H. T., Cottone, G., Glownia, J. M., Zhu, D., ... & Cammarata, M. (2015). Ultrafast myoglobin structural dynamics observed with an X-ray free-electron

  • laser. Nature communications, 6.
slide-57
SLIDE 57

What is 30fs?

100 fs  second Second  1000000 years Light travels 9 μm in 30fs

6/24/2016 Time resolved scattering studies - C. Blanchet

slide-58
SLIDE 58

Experimental results

6/24/2016 Time resolved scattering studies - C. Blanchet

slide-59
SLIDE 59

Protein quake

6/24/2016 Time resolved scattering studies - C. Blanchet

slide-60
SLIDE 60

Conclusion

  • SAXS is a good tool for time resolved

experiments

  • Good control on the initiation of the reaction

needed

  • Use experimental setup adapted to your

system

– Reaction triggering – time scale

6/24/2016 Time resolved scattering studies - C. Blanchet
