The Whirlwind Silo

• NXT LEVEL ENERGY is an Energy Management and

Consulting Firm. We, along with our affiliated partner company, provide our clients with various turnkey Energy Solutions to reduce demand and consumption. We also implement renewable/sustainable energy initiatives while simultaneously reducing annual utility expenditure.

Who We Are

What We Do

• We Consult, Implement and Manage energy solutions

based on the needs and interests of our clients. We focus

• n the following:
• Power Factor & Voltage Optimization
• Lighting retrofits
• Rooftop Solar
• Hedging Strategies (Gas and Electricity)
• Process Enhancement and Data Analysis
• Wind Energy – Whirlwind Silo

• The latest and most

innovative turbine in Wind technology has arrived!

• Topics of Focus:
• Purpose
• Highlights
• How it works
• Energy monitoring
• Step-by-step Implementation
• Case Study

The Wind Silo

• To reduce overall electricity consumption

used from the Ontario Power Grid

• To reduce our clients annual electricity

consumption (based on location, size, and

• rientation of the property) by 10% to 35%
• To implement a renewable and sustainable

form of energy generation

Purpose

Highlights:

• Vibration free & extremely quiet
• Moves with wind from any direction
• Designed for all markets: Commercial, Industrial,

Agricultural and municipal

• Visually appealing (Company logo can be added

to every unit)

• Does not harm birds or wildlife
• Engineered to withstand hurricane winds
• Dimensions:

2 Vanes: 4m diameter; 4 m high 3 Vanes: 4m diameter; 6m high 4 Vanes: 4m diameter; 8m high

Highlights

Wind is captured by the vanes Vanes power the generator creating DC power Inverter converts DC power into AC power AC power feeds directly into the building’s main panel, reducing the amount of power used from the grid

How it Works

• Inside each Silo is a patented technology

called POLE-R-POWER, which uses a staggered magnetic array that allows the generator to turn with great ease

• Each Silo operates on the principles of Wind Encapsulation

How it Works

Triacta Monitoring System – The Key to Intelligent Energy Measurement

• Real time monitoring; either on or off-

site

• Ability to monitor multiple sites
• Identifies specific power consumption

from multiple sources

• Ability to monitor hundreds of meter

points in real-time

• Can monitor part of building, entire

building, or a series of buildings

Monitoring System

• Executive View Dashboard (for personal use): month-to-date cost &

consumption reports, demand gauges, interactive graphs & weather information

• Public View Dashboard (for your clients and visitors): provides four

views: electricity demand, water, weather & renewable energy

Monitoring System - Executive Shift Dashboard

Monitoring System - Dashboard Examples

• Step 1: Letter of Direction – Will grant NXT Level access to

property for first site visit (non-binding)

• Step 2: First Site Visit – Analyze placement of monitors &

wind silo

• Step 3: Offer presented to client by NXT Level Energy
• Step 4: Engineering analysis: Structural requirements and

municipal approval

• Step 5: Contract signed
• Step 6: Installation of silo’s and monitoring equipment

Implementation

• 1. Current Consumption / Cost:
• Yearly Consumption: 5.4 Million kWh
• Monthly Consumption: 449,596 kWh
• Electricity Rate: 0.10 cents / kWh
• Approx. Monthly Expenditure:

$44,960

Case Study

• 2. System Size / Cost:
• System Size (Based on roof size,

available space and building

• rientation): 200kw (20 10kw silos)
• System cost: $506,000
• 3. System Savings & ROI:
• System Savings: $9,490 / month:

21% reduction in cost

• ROI: 4.3 years

?

Questions…

PHILLIP RAFFI MANAGING DIRECTOR NXT LEVEL ENERGY INC. TEL: 1-800-NXT (698) – 4819 X 800 EMAIL: PHILLIP.RAFFI@NXTLEVELENERGY.COM
