Sylvain Hallé

Jason Vallet, Aouatef Mrad, Sylvain Hallé*, Éric Beaudet

CRSNG NSERC

The Relational Database Engine:

An Efficient Validator of T emporal Properties

• n Event T

races

Université du Québec à Chicoutimi CANADA Novum Solutions CANADA

Sylvain Hallé

How high is this building? How high is this building?

?

Sylvain Hallé

How high is this building?

Sylvain Hallé

h = 4.9 t 2

How high is this building?

Sylvain Hallé

T = 2π 9.8 h

How high is this building?

Sylvain Hallé

2h = T c

How high is this building?

Sylvain Hallé

p

p = p 1 - L h T0

( (

g M R L

How high is this building?

Sylvain Hallé

How high is this building?

Answer derived from indirect measurements No single "best" solution

Sylvain Hallé

How high is this building?

Sylvain Hallé

τ ⊧ φ ?

A sequence of events Some assertion

• n that sequence

satisfies Web server log Execution trace . . . FSM LTL . . .

Sylvain Hallé

T race validation

Algos Tools

I t e r a t

• r

< T >

I t e r a t

• r

< T >

hasNext next

I t e r a t

• r

< T >

hasNext next A call to next must be preceded by a call to hasNext

B A

B A

No CartCreate request can occur before a LoginResponse message

Login

Login

Three successive login attempts should trigger an alarm

Receive order

Receive order Ready?

Receive order Ready? Yes

Receive order Ready? Yes File order No Ship

Receive order Ready? Yes File order No Ship

A received order must eventually be shipped

A

1 2 3 4 . . .

a a b c b

ℕ A trace m is a mapping from ℕ to the set of events :

A

Let be a set of event symbols.

A

Ground terms

→ ¬ ∧

→ ¬ ∧ Boolean connectives Temporal

• perators

X G F U next globally eventually until

+ + = Linear Temporal Logic

A

1 2 3 4 . . .

a a b c b

ℕ

Φ

Let be the set of all possible LTL formulas. The function ℒ : Φ → 2 labels each state with a set of LTL formulas

ℕ

a ∧ b a ∧ b

G (a→b)

b ∨ c b∨c a ∧ b

G (a→b)

ℒ(a∧b) = {0,1,4,...} Example: ℒ

A

1 2 3 4 . . .

a a b c b

ℕ

Φ

Let be the set of all possible LTL formulas. The function ℒ : Φ → 2 labels each state with a set of LTL formulas

ℕ

i ∈ ℒ(φ∨ψ) ⇔ i ∈ ℒ(φ) or i ∈ ℒ(ψ) i ∈ ℒ(φ∧ψ) ⇔ i ∈ ℒ(φ) and i ∈ ℒ(ψ) i ∈ ℒ(¬φ) ⇔ i ∉ ℒ(φ) i ∈ ℒ(G φ) ⇔ j ∈ ℒ(φ) for all j ≥ i i ∈ ℒ(X φ) ⇔ i+1 ∈ ℒ(φ) i ∈ ℒ(F φ) ⇔ j ∈ ℒ(φ) for some j ≥ i i ∈ ℒ(φ U ψ) ⇔ j ∈ ℒ(ψ) for some j ≥ i and k ∈ ℒ(φ) for all j ≥ k ≥ i i ∈ ℒ(a) ⇔ m(i) = a

i ∈ ℒ(φ) exactly when the trace m(i), m(i+1), ... satisfies φ Theorem

ψ φ σ

1 2 3 4 . . .

ψ φ σ

i ∈ ℒ(φ) exactly when the trace m(i), m(i+1), ... satisfies φ Theorem

ψ φ σ

1 2 3 4 . . .

ψ φ σ

0 ∈ ℒ(φ) ⇔ m ⊧ φ Therefore...

A call to next must be followed by a call to hasNext No CartCreate request can occur before a LoginResponse message A received order must eventually be shipped Three successive login attempts should trigger an alarm

A call to next must be followed by a call to hasNext No CartCreate request can occur before a LoginResponse message A received order must eventually be shipped Three successive login attempts should trigger an alarm G (next → X hasNext)

A call to next must be followed by a call to hasNext No CartCreate request can occur before a LoginResponse message A received order must eventually be shipped Three successive login attempts should trigger an alarm G (next → X hasNext) ¬ CartCreate U hasNext

A call to next must be followed by a call to hasNext No CartCreate request can occur before a LoginResponse message A received order must eventually be shipped Three successive login attempts should trigger an alarm G (next → X hasNext) ¬ CartCreate U hasNext G (receive → F ship)

A call to next must be followed by a call to hasNext No CartCreate request can occur before a LoginResponse message A received order must eventually be shipped Three successive login attempts should trigger an alarm G (next → X hasNext) ¬ CartCreate U hasNext G (receive → F ship) G ¬(fail ∧ (X (fail ∧ X fail)))

Sylvain Hallé

Four types of traces

τ : a mapping from ℕ to events in E = {e₀, e₁, ...}

Multi-valued eᵢ : Pᵢ → 2V

Parameters Values <event> <p>13</p> <q>8</q> <q>6</q> </event>

1

Single-valued eᵢ : Pᵢ → V

<event> <p>13</p> <q>8</q> <r>6</r> </event>

2 3

Fixed schema eᵢ : P → V

p 13 12 9 q 8 4 2 r 6 10 8

4

Atomic eᵢ = a

Sylvain Hallé

Specification languages

φ : an expression in some specification language

Linear Temporal Logic (LTL) G p₀ ≠ 0 First-order Linear Temporal Logic (LTL-FO+) F (∀x ∈ /event/p₀ : x = 0) Regular expressions

^a+b.*b?c$

SQL

SELECT * FROM events WHERE p0=0...

Sylvain Hallé

Software and algorithms

⊧ : an algorithm to evaluate satisfiability

for inputs in format T against assertions in language L BeepBeep, Monid, Logscope, MySQL, ProM, NuSMV , Spin, SEQ.OPEN, . . . 〈T,L〉

Sylvain Hallé

Islands?

〈LTL-FO+, multi-valued〉 〈SQL, fixed schema〉 〈XQuery, multi-valued〉 〈MFOTL, single-valued〉 Saxon BeepBeep NuSMV Spin MySQL Maude MonPoly 〈LTL, atomic〉 〈LTL, single-valued〉

Sylvain Hallé

BabelT race

XML CSV XES

Reader T ranslator

τ File

φ

Launcher Application

T/F

Sylvain Hallé

T ransduction

T ransducer

(τ,φ) ∈ 〈T,L〉 (τ',φ') ∈ 〈T ',L'〉

⊧〈T,L〉

τ φ

⊧〈T ',L'〉

τ' φ'

⇔

Transduction preserves logical equivalence Chaining transducers allows an application to verify a property on a trace expressed in a different format/language pair

Sylvain Hallé

Islands?

〈LTL-FO+, multi-valued〉 〈SQL, fixed schema〉 〈XQuery, multi-valued〉 〈MFOTL, single-valued〉 Saxon BeepBeep NuSMV Spin MySQL Maude MonPoly ⊆

*

〈LTL, atomic〉 〈LTL, single-valued〉 〈LTL-FO+, single-valued〉 ⊆ ⊆

*

Sylvain Hallé

Islands?

〈LTL-FO+, multi-valued〉 〈SQL, fixed schema〉 〈XQuery, multi-valued〉 〈MFOTL, single-valued〉 Saxon BeepBeep NuSMV Spin MySQL Maude MonPoly ⊆

*

〈LTL, atomic〉 〈LTL, single-valued〉 〈LTL-FO+, single-valued〉 ⊆ ⊆

*

Sylvain Hallé

Islands?

〈LTL-FO+, multi-valued〉 〈SQL, fixed schema〉 〈XQuery, multi-valued〉 〈MFOTL, single-valued〉 Saxon BeepBeep NuSMV Spin MySQL Maude MonPoly ⊆

*

〈LTL, atomic〉 〈LTL, single-valued〉 〈LTL-FO+, single-valued〉 ⊆ ⊆

*

Sylvain Hallé

Islands?

〈LTL-FO+, multi-valued〉 〈SQL, fixed schema〉 〈XQuery, multi-valued〉 〈MFOTL, single-valued〉 Saxon BeepBeep NuSMV Spin MySQL Maude MonPoly ⊆

*

〈LTL, atomic〉 〈LTL, single-valued〉 〈LTL-FO+, single-valued〉 ⊆ ⊆

*

Sylvain Hallé

Islands?

〈LTL-FO+, multi-valued〉 〈SQL, fixed schema〉 〈XQuery, multi-valued〉 〈MFOTL, single-valued〉 Saxon BeepBeep NuSMV Spin MySQL Maude MonPoly ⊆

*

〈LTL, atomic〉 〈LTL, single-valued〉 〈LTL-FO+, single-valued〉 ⊆ ⊆

*

Sylvain Hallé

Islands?

〈LTL-FO+, multi-valued〉 〈SQL, fixed schema〉 〈XQuery, multi-valued〉 〈MFOTL, single-valued〉 Saxon BeepBeep NuSMV Spin MySQL Maude MonPoly ⊆

*

〈LTL, atomic〉 〈LTL, single-valued〉 〈LTL-FO+, single-valued〉 ⊆ ⊆

*

Sylvain Hallé

Format of an event trace

n Action SessionId CartId ItemId CartCreate 1234 null null 1 CartCreateResponse 1234 45603 null 2 CartAdd 1234 45603 005-40958 3 CartClear 1234 45603 null

Event attributes Event Sequential number

Sylvain Hallé

From LTL to SQL

Recursive function

ω

LTL formula SQL query

n

2 ...

φ

i ∈ T

Evaluate

T : if and only if τ ⊧ φ

i

Sylvain Hallé

From LTL to SQL

ω (x = y) ≡

SELECT n FROM T WHERE x = y

ℓ

Base case: assertions of the form x=y Create a table containing event numbers n that satisfy the assertion

Sylvain Hallé

From LTL to SQL

ω (ϕ ∨ψ) ≡ ω +1(ϕ) UNION ω +1(ψ) ω (ϕ ∧ψ) ≡ ω +1(ϕ) INTERSECT ω +1(ψ) ω (¬ ϕ) ≡ T MINUS ω +1(ϕ)

ℓ ℓ ℓ ℓ ℓ ℓ ℓ ℓ

Boolean connectives: combine tables computed at a previous step

Sylvain Hallé

From LTL to SQL

ω (X ϕ) ≡

SELECT n−1 FROM ω +1(ϕ)

ℓ ℓ

X φ: put n-1 in the output table if n is in the table computed for φ

Sylvain Hallé

From LTL to SQL

ω (F ϕ) ≡

SELECT DISTINCT T

A, .n

FROM T AS T

A, JOIN ω +1(ϕ) AS T B,

WHERE T

A, .n ≤ T B, .n ℓ ℓ ℓ ℓ ℓ ℓ

F φ: put in the output table all values of T that are smaller than some value n is in the table computed for φ (can be optimized)

Sylvain Hallé

From LTL to SQL

T ≡

SELECT MAX(T

A, .n) AS n1, T B, .n AS n2

FROM ω +1(¬

ϕ) AS T

A, JOIN ω +1(ψ) AS T B,

WHERE n1 < n GROUP BY T

B, .n

ω (ϕ U ψ) ≡

SELECT T.n FROM T JOIN T WHERE T.n > T .n1 AND T.n ≤ T .n2

ℓ ℓ ℓ ℓ ℓ ℓ ℓ ℓ'

'

ℓ

'

.

ℓ

'

ℓ

φ U ψ: done in two steps Most expensive translation (two joins)

Sylvain Hallé

Experimental evaluation

Using BabelTrace, compared SQL translation with 7 other tools using the same inputs

Tool Input language Available? BeepBeep [12] LTL-FO+ Yes Logscope [7] Logscope — Maude [20] LTL Yes Monid [19] EAGLE — MonPoly [4] MFOTL Yes NuSMV [5] LTL Yes ProM [24] LTL Yes RuleR [3] RuleR — Saxon [11] XQuery Yes SEQ.OPEN [6] µ-calculus2 Yes SPIN [14] LTL Yes

Sylvain Hallé

Experimental evaluation

2 4 6 8 10 12 14 1000 2000 3000 4000 5000 6000 7000 8000 9000 10000 Time (s) Trace length Scenario Random property P9 BeepBeep Filter Monpoly MySQL MySQL-Opt ProMLTL Saxon

Sylvain Hallé Sylvain Hallé

Experimental evaluation

Surprise! When used as a trace validator, a relational database engine outperforms most software designed for that purpose ⇒ Trace validation capabilities are available through commodity software

Sylvain Hallé

Future work

Event data stored across multiple tables (n:1 or n:n relations) Optimize translation Handle past operators Row vs. column-oriented storage

Sylvain Hallé

The end

Thank you! Questions?
