The NIDS Cluster: Scalable, Stateful Network Intrusion Detection on Commodity Hardware

Matthias Vallentin1, Robin Sommer 2,3, Jason Lee2, Craig Leres2 Vern Paxson3,2, and Brian Tierney2

1 TU München 2 Lawrence Berkeley National Laboratory 3 International Computer Science Institute

Recent Advances in Intrusion Detection 2007

Motivation

• NIDSs have reached their limits on commodity hardware
• Keep needing to do more analysis on more data at higher speeds
• However, CPU performance is not growing anymore the way it used to
• Single NIDS instance (e.g., Snort, Bro) cannot cope with Gbps links
• To overcome, we must either
• Restrict the amount of analysis, or
• Turn to expensive, custom hardware, or
• Employ some form of load-balancing to split analysis across multiple machines
• We do load-balancing with the “NIDS Cluster”
• Use many boxes instead of one
• Every box works on a slice of traffic
• Correlate analysis to create the impression of a single system

2

Recent Advances in Intrusion Detection 2007

Correlation is Tricky ...

• Most NIDS provide support for multi-system setups
• However, instances tend to work independent
• Central manager collects alerts of independent NIDS instances
• Aggregates results instead of correlating analysis
• NIDS cluster works transparently like a single NIDS
• Gives same results as single NIDS would if it could analyze all traffic
• Does not sacrifice detection accuracy
• Is scalable to large number of nodes
• Still provides a single system as the user interface (logging, configuration updates)

3

Recent Advances in Intrusion Detection 2007

NIDS Cluster

Architecture

4

Internet Local

Gbps Gbps Tap Tap

Recent Advances in Intrusion Detection 2007

NIDS Cluster

Architecture

4

Frontend Frontend

Internet Local

Gbps Gbps Tap Tap

Recent Advances in Intrusion Detection 2007

NIDS Cluster

Architecture

4

Frontend Frontend Backend Backend Backend Backend Backend Backend Backend Backend Backend Backend Backend Backend

Internet Local

Gbps Gbps Tap Tap

Recent Advances in Intrusion Detection 2007

NIDS Cluster

Architecture

4

Frontend Frontend Proxy Proxy Backend Backend Backend Backend Backend Backend Backend Backend Backend Backend Backend Backend

Internet Local

Gbps Gbps Tap Tap

Recent Advances in Intrusion Detection 2007

NIDS Cluster

Architecture

4

Frontend Frontend Proxy Proxy Backend Backend Backend Backend Backend Backend Backend Backend Backend Backend Backend Backend

Internet Local

Gbps Gbps

Manager

Tap Tap

Recent Advances in Intrusion Detection 2007

Environments

• Initial target environment:

Lawrence Berkeley National Laboratory

• LBNL monitors 10 Gbps upstream link with the Bro NIDS
• Setup evolved into many boxes running Bro independently for sub-tasks
• Cluster prototype now running at LBNL with 1 frontend & 10 backends
• Further prototypes
• University of California, Berkeley

2 x 1 Gbps uplink, 2 frontends / 6 backends for 50% of the traffic

• Ohio State University

450 Mbps uplink, 1 frontend / 2 backends (10 planned)

• IEEE Supercomputing Conference 2007

Conference’s 1 Gbps backbone / 10 Gbps “High Speed Bandwidth Challenge” network

• Goal: Replace operational security monitoring

5

Recent Advances in Intrusion Detection 2007

Challenges

Main challenges when building the NIDS Cluster

1.

Distributing the traffic evenly while minimizing need for communication

2.

Adapting the NIDS operation on the backend to correlate analysis with peers

3.

Validating that the cluster produces sound results

6

Recent Advances in Intrusion Detection 2007

Distributing Load

7

Recent Advances in Intrusion Detection 2007

Distribution Schemes

• Frontends need to pick a backend as destination
• Option 1: Route packets individually
• Simple example: round-robin
• Too expensive due to communication overhead (NIDS keep per-flow state)
• Option 2: Flow-based schemes
• Send all packets belonging to the same flow to the same backend
• Needs communication only for inter-flow analysis
• Simple approach: hashing flow identifiers
• E.g., md5(src-addr + src-port + dst-addr + dst-port) mod n
• Hashing is state-less, which reduces complexity and increases robustness
• But how well does hashing distribute the load?

8

Recent Advances in Intrusion Detection 2007

Simulation of Hashing Schemes

9

1 day of UC Berkeley campus TCP traffic (231M connections), n = 10

!"#$%&'((")"$*"+%,+-%","$%&'+.)'/0.'1$%234 5 6 75 76 85 !1$%75955 !1$%7:955 !1$%88955 ;0"%<955 =&6!< />(!< />(!<%277%$1&"+4 =&6!8

md5

Recent Advances in Intrusion Detection 2007

Simulation of Hashing Schemes

9

1 day of UC Berkeley campus TCP traffic (231M connections), n = 10

!"#$%&'((")"$*"+%,+-%","$%&'+.)'/0.'1$%234 5 6 75 76 85 !1$%75955 !1$%7:955 !1$%88955 ;0"%<955 =&6!< />(!< />(!<%277%$1&"+4 =&6!8

md5 md5-addr

Recent Advances in Intrusion Detection 2007

Cluster Frontends

10

• We chose the address-based hash
• Ports not always available (e.g., ICMP

, fragments) & more complex to extract

• Even with perfect distribution, load is hard to predict
• Frontends rewrite MAC addresses according to hash
• Two alternative frontend implementations
• In software with Click (SHA1)
• In hardware with a prototype of Force-10’s P10 appliance (XOR)

Recent Advances in Intrusion Detection 2007

Adapting the NIDS

11

Recent Advances in Intrusion Detection 2007

Cluster Backends

• On the backends, we run the Bro NIDS
• Bro is the NIDS used in our primary target environment LBNL
• Bro already provides extensive, low-level communication facilities
• Bro consists of two layers
• Core: Low-level, high-performance protocol analysis
• Event-engine: Executes scripts which implement the detection analysis
• Observation: Core keeps only per-flow state
• No need for correlation across backends
• Event-engine does all inter-flow analysis
• The scripts needs to be adapted to the cluster setting

12

Recent Advances in Intrusion Detection 2007

Adapting the Scripts ...

• Script language provides primitives to share state
• Almost all state is kept in tables, which can easily be synchronized across peers
• Main task was identifying state related to inter-flow analysis
• A bit cumbersome with 20K+ lines of script code ...
• Actually it was a bit more tricky ...
• Some programming idioms do not work well in the cluster setting and needed to be fixed
• Some trade-offs between gain & overhead exists are hard to assess
• Bro’s “loose synchronisation” introduces inconsistencies (which can be mitigated)
• Many changes to scripts and few to the core
• Will be part of the next Bro release

13

Recent Advances in Intrusion Detection 2007

Validating the Cluster

14

Recent Advances in Intrusion Detection 2007

Accuracy

15

• Goal: Cluster produces same result as a single system
• Compared the results of cluster vs. stand-alone setup
• Captured a 2 hour trace at LBNL’s uplink (~97GB, 134M pkts, 1.5 M host pairs)
• Splitted the trace into slices and copied them to the cluster nodes
• Setup the cluster to examine the slices just as if it would process live traffic
• Compared output of the manager with the output of a single Bro instance on the trace
• Found excellent match for the alarms & logs
• Cluster reported all 2661 alarms of the singe instance as well
• Slight differences in timing & context due to latency and synchronization semantics
• Some artifacts of the off-line measurement setup

Recent Advances in Intrusion Detection 2007

CPU Load per Node

16

0.0 0.1 0.2 0.3 0.4 0.5 5 10 15

CPU utilization Probability density

node0 node1 node2 node3 node4 node5 node6 node7 node8 node9

10 backends, ext. LBNL config, 2hr full trace, (~97GB, 134M pkts)

Recent Advances in Intrusion Detection 2007

Scaling of CPU

17

0.0 0.1 0.2 0.3 0.4 0.5 5 10 15 20 25

CPU utilization Probability density

10 nodes 5 nodes 3 nodes

• ext. LBNL config, 2hr full trace, (~97GB, 134M pkts)

Recent Advances in Intrusion Detection 2007

Load on Berkeley Campus

18

CPU load (%) 10 20 30 40 50 60 70 Tue 12:00 Tue 18:00 Wed 0:00 Wed 6:00 Wed 12:00 Wed 18:00 Thu 0:00 Thu 6:00 Backend 0 Backend 1 Backend 2 Backend 3 Backend 4 Backend 5 Proxy 0 Proxy 1 Manager

With 1 frontend = 50% of the total traffic

Recent Advances in Intrusion Detection 2007

Conclusion & Outlook

19

• Cluster monitors Gbps networks on commodity hardware
• Provides high-performance, stateful network intrusion detection
• Correlates analysis across its nodes rather than just aggregating results
• When building the cluster we
• Examined different load distribution schemes
• Adapted an open-source NIDS to the cluster setting
• Evaluated correctness & performance in a real-world setting
• Challenge was to build something which works
• Less to lead into fundamentally new research directions
• Now in the process of making it production quality
• We will soon release the Cluster Shell
• An interactive shell running on the manager

Robin Sommer

Lawrence Berkeley National Laboratory & International Computer Science Institute

robin@icir.org http://www.icir.org

This work is supported by the Office of Science and Technology at the Department of Homeland Security. Points of view in this document are those of the author(s) and do not necessarily represent the

• fficial position of the U.S. Department of Homeland Security or the

Office of Science and Technology.

Any questions ... ?
