SLIDE 1
The Forces That Disrupt Netflix
- Nov. 7, 2016
Haley Tucker
ACROBAT FLEA
- ur world
parallel world
The Forces That Disrupt Netflix Haley Tucker Nov. 7, 2016 our - - PowerPoint PPT Presentation
The Forces That Disrupt Netflix Haley Tucker Nov. 7, 2016 our - - PowerPoint PPT Presentation
The Forces That Disrupt Netflix Haley Tucker Nov. 7, 2016 our world ACROBAT FLEA parallel world # A distributed system is one in which the failure of a computer you didn't even know existed can render your own computer unusable.
SLIDE 2
SLIDE 3
# A distributed system is
- ne in which the failure
- f a computer you didn't
even know existed can render your own computer unusable.
- -Leslie Lamport
SLIDE 4
ACROBAT FLEA
- ur world
parallel world computing
ENGINEER
SLIDE 5
SLIDE 6
PROLOGUE
DISTRIBUTED SYSTEMS
SLIDE 7
SLIDE 8
Proxy/Routing
DECOMPOSING THE MONOLITH
Devices Netflix Service Netflix Service Edge Service Traffic Netflix Playback Service Netflix Playback Service Edge Service Edge Service Edge Service Playback Service Traffic
SLIDE 9
Notes on Distributed Systems for Young Bloods
# Distributed systems are different because they fail often.
- -Jeff Hodges
SLIDE 10
TABLE OF CONTENTS
CHAPTER 1: THE WEIRD DATA IN THE CATALOG
- Metadata impacts on availability
CHAPTER 2: THE VANISHING OF CRITICAL SERVICES
- Crashing services and cascading failures
CHAPTER 3: THE THROTTLE
- Latency spikes and the impact of fallbacks
FORCES AT WORK
SLIDE 11
SLIDE 12
Whoops, something went wrong…
Netflix Streaming Error
We’re having trouble playing this title right now. Please try again later or select a different title.
SLIDE 13
CHAPTER ONE
THE WEIRD DATA IN THE CATALOG
SLIDE 14
SLIDE 15
45 MINUTES!!
Clock, by heyyobecky4lyfe, Tumblr
SLIDE 16
SLIDE 17
VIDEO METADATA
ARCHITECTURE
Video Metadata Service Amazon S3 Source System Source System Netflix Services Netflix Services Netflix Services Netflix Services Netflix Service Traffic
SLIDE 18
Amazon S3 Netflix Playback Service { String msg = “This should never happen!”; throw new IllegalStateException(msg); }
SLIDE 19
MITIGATION
BLAST RADIUS
Explosion, CC BY 2.0, Andrew Kuznetsov 2008, Flikr
SLIDE 20
Amazon WS Global Infrastructure
SLIDE 21
Amazon WS Global Infrastructure
STAGGERED ROLLOUT
SLIDE 22
Pager Diagnosis?
SLIDE 23
SLIDE 24
Canary, CC BY 2.0, Steve P2008 2014, Flikr
PREVENTION
CANARIES
SLIDE 25
TRADITIONAL CANARY
Canary (New Code) Baseline (Old Code) Traffic Traffic Video Metadata Service Amazon S3 Netflix Services Netflix Services Netflix Services Netflix Services Netflix Service Source System Source System Traffic
SLIDE 26
CONSISTENCY
VALID STATE TRANSITIONS
SLIDE 27
DATA CANARY
Netflix Services Netflix Services Netflix Services Netflix Services
Video Metadata Service Amazon S3 Source System Source System
Netflix Service Netflix Data Canary Service Data Tester Netflix Service Traffic
SLIDE 28
Australia with AAT, CC BY-SA 2.0, Ssolbergj 2010, Wikimedia
SEEING RETURNS
SLIDE 29
Verify consistency prior to applying state changes.
…one tool is a data canary.
SLIDE 30
CHAPTER TWO
THE VANISHING OF CRITICAL SERVICES
SLIDE 31
SLIDE 32
SLIDE 33
# A distributed system is
- ne in which the failure
- f a computer you didn't
even know existed can render your own computer unusable.
- -Leslie Lamport
SLIDE 34
Proxy/Routing Devices
LOG DATA
Log Data Service Traffic Cassandra Playback Service Netflix Playback Service Netflix Playback Service Edge Service Edge Service Edge Service Playback Service Traffic
SLIDE 35
SLIDE 36
Proxy/Routing Devices
Proxy
Log Data Service Traffic Cassandra Playback Service Netflix Playback Service Netflix Playback Service Edge Service Edge Service Edge Service Playback Service Traffic
SLIDE 37
SLIDE 38
Proxy/Routing Devices
CASCADING FAILURE
Log Data Service Traffic Cassandra Playback Service Netflix Playback Service Netflix Playback Service Edge Service Edge Service Edge Service Playback Service Traffic
SLIDE 39
{ throw new OutOfMemoryError(); }
Log Data Service Cassandra Playback Service
SLIDE 40
PREVENTION
MANAGING RESOURCE CONSTRAINTS
Whatever you ask, CC BY-SA 2.0, Kreg Steppe 2008, Flikr
SLIDE 41
Astronomical Clock, CC BY 2.0, Andrew Fleming 2011, Flikr
REDUCE SURFACE AREA
SLIDE 42
1
Keep Only Dependencies which are Necessary
SO MANY JARS!!
SLIDE 43
2
LIMIT “MAGIC”
Magic, CC BY-ND 2.0, Daniel Lee 2013, Flikr
SLIDE 44
3
Medusa Kill Switch, CC BY-NC-ND 2.0, Scott Hart 2013, Flikr
ADD KILL SWITCHES
SLIDE 45
DEV
FAVOR IMMUTABILITY
Playback Service TEST Playback Service PROD Playback Service
4
SLIDE 46
try { remoteService.call(); } catch( Throwable t ){ //Oops! System.exit(1); }
Log Data Service Cassandra Playback Service Proxy/Routing Traffic
SLIDE 47
It's Electric, CC BY ND 2.0, Alan Hochberg 2008, Flikr
MITIGATION
CIRCUIT BREAKERS
SLIDE 48
SLIDE 49
Wrecking Ball in Building, CC BY 2.0, Jason Eppink 2008, Flikr
FAILURE TESTING
SLIDE 50
Proxy/Routing Devices
FAILURE TESTING
Log Data Service Traffic Cassandra Playback Service Automating Chaos Experiments in Production by Ali Basiri Applying Failure Testing Research @Netflix by Kolton Andrus and Peter Alvaro
SLIDE 51
Manage resource constraints by reducing surface area.
Leverage circuit breakers and rigorously test failures.
SLIDE 52
CHAPTER THREE
THE THROTTLE
SLIDE 53
SLIDE 54
Proxy/Routing Devices
PLAYBACK ARCHITECTURE
Edge Service Edge Service Edge Service Playback Service Traffic Traffic URL Service
SLIDE 55
NETFLIX CLIENT JARS
Playback Service
URL Service URL Client
Circuit-breakers and Fallbacks Metrics Retries and Timeouts RPC Service Discovery
SLIDE 56
SLIDE 57
Playback Service
Traffic Concurrent Requests Throttled Requests (HTTP 503)
THROTTLING
SLIDE 58
SLIDE 59
} System.gc(); }
URL Service Playback Service Edge Service Proxy/Routing Traffic
SLIDE 60
NETFLIX CLIENT JARS
Playback Service
URL Service URL Client
Circuit-breakers Metrics Retries and Timeouts RPC Service Discovery
Heavy Fallback
SLIDE 61
FALLBACK TESTING
With 100% Fallback, CPU held at 90%
15 RPS
No fallback, CPU held at 90%
58 RPS
Siege: https://github.com/JoeDog/siege
SLIDE 62
SELECTING FALLBACKS
CACHE STATIC FALLBACK SERVICE
SLIDE 63
URL Service Playback Service Edge Service Proxy/Routing Traffic
} return Response .status(503) .build(); }
SLIDE 64
REQUEST BUCKETING
NON-CRITICAL
Experience or Performance Impact
CRITICAL
Customer Streaming Impact
Fire Buckets at Oakworth Statione, CC BY 2.0, Tim Greene 2015, Flikr
SLIDE 65
APPLICATION SHARDING
Non-Critical Playback Service Proxy/Routing Devices Edge Service Edge Service Edge Service Traffic Traffic URL Service Critical Playback Service Non-Critical URL Service
SLIDE 66
CRITICAL
Country Road at Sunrisee, CC BY-SA 2.0, Susanne Nilssone 2014, Flikr
SLIDE 67
NON-CRITICAL
Traffice, CC BY-NC 2.0, jonbgeme 2008, Flikr
SLIDE 68
APPLICATION SHARDING
Non-Critical Playback Service Proxy/Routing Devices Edge Service Edge Service Edge Service Traffic Traffic Critical Playback Service URL Service Non-Critical URL Service
SLIDE 69
No heavy fallbacks!! Fallbacks should be light and fast.
Shard your application based on
- perational characteristics.
SLIDE 70
EPILOGUE
KEY TAKEAWAYS
SLIDE 71
KEY TAKEAWAYS
CHAPTER 1: THE WEIRD DATA IN THE CATALOG
- Verify consistency prior to applying state changes.
- One tool is a data canary.
CHAPTER 2: THE VANISHING OF CRITICAL SERVICES
- Manage resource constraints by reducing surface area.
- Leverage circuit breakers and rigorously test failures.
CHAPTER 3: THE THROTTLE
- No heavy fallbacks!! Fallbacks should be light and fast.
- Shard your application based on operational characteristics.
SLIDE 72
The unexpected will happen. Plan to fail.
SLIDE 73
PARTING THOUGHT
DISTRIBUTED SYSTEMS SOCIAL
SLIDE 74
Questions?
Haley Tucker
