The complexity of classical music networks Vitor Guerra Rolla Postdoctoral Fellow at Visgraf Juliano Kestenberg PhD candidate at UFRJ Luiz Velho Principal Investigator at Visgraf Summary Introduction Related Work Musical Networks

slide-1
SLIDE 1

The complexity of classical music networks

Juliano Kestenberg

PhD candidate at UFRJ

Luiz Velho

Principal Investigator at Visgraf

Vitor Guerra Rolla

Postdoctoral Fellow at Visgraf

slide-2
SLIDE 2

Summary

Introduction Related Work Musical Networks Scale-free Small-world Results Fractal Nature of Music Conclusions and Future Work

slide-3
SLIDE 3

Introduction

slide-4
SLIDE 4

Introduction

40 pieces of classical music → MIDI format Bach (6), Beethoven (9), Brahms (1), Chopin (1), Clementi (6), Haydn (5), Mozart (7), Schubert (4), and Shostakovitch (1) Built a network from each piece of music Perform scale-free and small-world tests

slide-5
SLIDE 5

Related Work → Music

slide-6
SLIDE 6

Related Work → Music

  • Liu et al.

“Complex network structure of musical compositions: Algorithmic generation of appealing music” Physica A: Statistical Mechanics and its Applications (2010)

  • Perkins et al.

“A scaling law for random walks on networks” Nature Communications (2014)

  • Ferretti

"On the Complex Network Structure of Musical Pieces: Analysis of Some Use Cases from Different Music Genres" Multimedia Tools and Applications (2017)

I.F. 12,124 18 citations I.F. 2,243 63 citations I.F. 1,530 1 citation

slide-7
SLIDE 7

Related Work → Music

  • Liu et al.

“Complex network structure of musical compositions: Algorithmic generation of appealing music” Physica A: Statistical Mechanics and its Applications (2010)

  • Perkins et al.

“A scaling law for random walks on networks” Nature Communications (2014)

  • Ferretti

"On the Complex Network Structure of Musical Pieces: Analysis of Some Use Cases from Different Music Genres" Multimedia Tools and Applications (2017)

I.F. 12,124 18 citations I.F. 2,243 63 citations I.F. 1,530 1 citation Scale-free: Yes Small-world: Yes Scale-free: Yes Small-world: No report Scale-free: Yes Small-world: Yes

slide-8
SLIDE 8

Related Work → Music

  • Liu et al.

“Complex network structure of musical compositions: Algorithmic generation of appealing music” Physica A: Statistical Mechanics and its Applications (2010)

  • Perkins et al.

“A scaling law for random walks on networks” Nature Communications (2014)

  • Ferretti

"On the Complex Network Structure of Musical Pieces: Analysis of Some Use Cases from Different Music Genres" Multimedia Tools and Applications (2017)

I.F. 12,124 18 citations I.F. 2,243 63 citations I.F. 1,530 1 citation 202 pieces → Classic & Chinese Pop 8473 pieces → Folk from Europe & China 8 pieces → Rock, Blues, Jazz...

slide-9
SLIDE 9

Related Work → Math Tests

slide-10
SLIDE 10

Related Work → Math Tests

  • Clauset et al.

“Power-law distributions in empirical data” Siam Review (2010)

  • Watts & Strogatz

“Collective dynamics of ‘small-world’ networks” Nature (1998)

  • Newman & Watts

"Renormalization group analysis of the small-world network model" Physics Letters A - Elsevier (1999)

I.F. 40,137 35731 citations I.F. 4,897 5947 citations I.F. 1,772 1364 citations

slide-11
SLIDE 11

Musical Networks

slide-12
SLIDE 12

Musical Networks

Mozart’s Sonata No. 16 (KV 545) first bar

(d)

slide-13
SLIDE 13

Musical Networks

Project's website: http://w3.impa.br/~vitorgr/CNA/index.html Python/NetworkX Software for complex networks https://networkx.github.io/

slide-14
SLIDE 14

Scale-free Property

slide-15
SLIDE 15

Scale-free Property

Node degree distribution → Power law estimation Least squares method (Old)→ used by Liu and Perkins Clauset's test

  • Cohen & Havlin

"Scale-free networks are ultrasmall" Physical Review Letters (2003) I.F. 8,462 801 citations

2 < α < 3

  • i. Maximum likelihood estimation (α)
  • ii. Kolmogorov-Smirnov ( p-value > 0.1 )
  • iii. Likelihood Ratio (LR)

power law vs. alternative hypotheses:

log-normal, exponential, stretched exp

slide-16
SLIDE 16

Related Work → Music

  • Liu et al.

“Complex network structure of musical compositions: Algorithmic generation of appealing music” Physica A: Statistical Mechanics and its Applications (2010)

  • Perkins et al.

“A scaling law for random walks on networks” Nature Communications (2014)

  • Ferretti

"On the Complex Network Structure of Musical Pieces: Analysis of Some Use Cases from Different Music Genres" Multimedia Tools and Applications (2017)

1 < α < 2

1,05 < α < 1,28

No report

slide-17
SLIDE 17

Small-world Property

slide-18
SLIDE 18

Small-world Property

Mean Shortest Path Length (MSPL) Six degrees of separation – Myth Average Cluster Coefficient (ACC) Fraction of triangles Musical Networks vs

Random Networks & Small-world Networks

(near equivalent)

Newman, Watts Strogatz

slide-19
SLIDE 19

Related Work → Music

  • Liu et al.

“Complex network structure of musical compositions: Algorithmic generation of appealing music” Physica A: Statistical Mechanics and its Applications (2010)

  • Perkins et al.

“A scaling law for random walks on networks” Nature Communications (2014)

  • Ferretti

"On the Complex Network Structure of Musical Pieces: Analysis of Some Use Cases from Different Music Genres" Multimedia Tools and Applications (2017)

No report

Small-world !!!

No report

slide-20
SLIDE 20

Results → Scale-free

slide-21
SLIDE 21

Results→Scale-free

Clauset’s test – i & ii steps:

(a) Sonata No. 23 in F minor (Appassionata) Opus 57 (1804) composed by Beethoven, (b) Sonata No. 12 in F major KV 332 (1783) composed by Mozart, (c) Piano Sonata in D major Hoboken XVI:33 (1778) composed by Haydn, (d) Violin partita No. 2 in D minor BWV 1004 (1720) composed by Bach, (e) Sonatina in F major Opus 36 No. 4 Opus 36 (1797) composed by Clementi, and (f) Sonatina in C major Opus 36 No. 3 Opus 36 (1797) also composed by Clementi.

slide-22
SLIDE 22

Results→Scale-free

Clauset’s test – iii step:

(a), (b), and (c) present the scale-free property. (d) behaves more like a log-normal (e) behaves like an exponential distribution (f) did not behave like any distribution tested.

slide-23
SLIDE 23

Results → Small-world

slide-24
SLIDE 24

Results→Small-world

MSPL and ACC for musical networks, random networks, and small- world networks.

slide-25
SLIDE 25

Final → Results

slide-26
SLIDE 26

Results

Scale-free Not Scale-free

52,5%

Small-world Not Small-world

B a c h B e e t h

  • v

e n B r a h ms C h

  • p

i n C l e me n t i H a y d n Mo z a r t S c h u b e r t S h

  • s

t a k

  • v

i c h B a c h B e e t h

  • v

e n B r a h ms C h

  • p

i n C l e me n t i H a y d n Mo z a r t S c h u b e r t S h

  • s

t a k

  • v

i c h

62,5%

slide-27
SLIDE 27

Fractal Nature of Music

slide-28
SLIDE 28

Fractal Nature of Music

  • Schroeder

“Is there such a thing as fractal music?” Nature (1987)

I.F. 40,137 19 citations

  • Henderson-Sellers & Cooper

“Has classical music a fractal nature?—A reanalysis” Computers and the Humanities (1993)

I.F. 0,738 10 citations

slide-29
SLIDE 29

Fractal Nature of Music

Fractal Dimensioning vs. Complex Network Analysis

  • Song et al.

“Self-similarity of complex networks” Nature (2005)

I.F. 40,137 1102 citations Self-similarity Mandelbrot

Scale-free property

Newman

  • Song et al.

“Origins of fractality in the growth of complex networks” Nature Physics (2006)

I.F. 22,806 424 citations

slide-30
SLIDE 30

Conclusions & Future Work

slide-31
SLIDE 31

Conclusions

Previous work (Liu et al., Perkins et al., Ferreti) disregarded:

– Harmony – One piece per network – Updated statistical methods → Clauset et. al.

Our work suggests that classical music may or may not present the scale-free and the small-world properties

slide-32
SLIDE 32

Future Work

Evaluation of other music genres Investigation of edge weight distribution Evaluation of fractal dimension according to Song et al. algorithms Understanding the community structure of our musical networks.

slide-33
SLIDE 33

Computer Music @ VISGRAF

Thank you!

slide-34
SLIDE 34

Extra – Hubs

Although we provide a precise evaluation of the power law, our musical networks did not present a long tail as many scale-free networks, i.e., we could not identify a small number of nodes with very high degree. On the other hand, according to Janssen due to the finite size of real-world networks the power law inevitably has a cut-off at some maximum degree. Such a cut-

  • ff can be clearly verified in Figures 2(a), 2(b), and 2(c).
  • Janssen

"Giant component sizes in scale-free networks with power-law degrees and cutoffs" Europhysics Letters (2016)

I.F. 1,957 3 citations

slide-35
SLIDE 35

Extra – ACC

Local clustering coefficient for undirected graphs: Average cluster coefficient:

slide-36
SLIDE 36

Extra – Cohen & Havlin

  • Cohen & Havlin

"Scale-free networks are ultrasmall" Physical Review Letters (2003) A power law distribution only has a well-defined mean over x [ 1 , ∞ ], ∈ if a > 2. When a > 3, it has a finite variance that diverges with the upper integration limit

I.F. 8,462 801 citations

2 < α < 3

∫

xmax as 〈 x

2

〉 = xmax xmin x

2

P ( x ) ~ xmax

3-a
