The Btrfs Filesystem Chris Mason

Btrfs Design Goals

• Broad development community
• General purpose filesystem that scales to very large

storage

– Extents for large files – Small files packed in as metadata

• Flexible disk format that can adapt to new features

– Btree indexes based on extensible key/value lookups – Key ordering determines relative location in the btree

• Data and metadata checksumming

– Crc32c used for fast hardware enabled crcs

Btrfs Design Goals

• Data and metadata copy on write

– Block contents preserved until replacement is safely on disk

• Data and metadata reference counting with back

references

– Every block and filename link back to their owners

• Fast, writable snapshots

– COW enables O(1) snapshots of subvolumes – O(number of extents in the file) snapshots of single files

• Efficient detection of recently modified files

Btrfs Design Goals

• Simple, online disk administration

– Btrfs dev add /dev/xxx /mnt – Btrfs dev delete /dev/xxx /mnt – Btrfs filesystem resize XX /mnt

• Can also resize a single device

– Btrfs filesystem balance /mnt

• Multiple device support

– Flexible relocation of space – Easily find good copies when crcs fail

• Efficient synchronous operations that do not stall the

rest of the filesystem

• These goals have been met!

Snapshots and Subvolumes

• Subvolume is the unit of snapshotting
• Snapshots are very efficient, even when many are in

place against the same source

– Individual files may be cloned without a full snapshot – Cloning support now in cp --relink

• Subvolumes and snapshots may be created anywhere
• Subvolumes are roughly as expensive as directories

– But, you may not rename or hardlink files between subvolumes

• Snapshots can be written and snapshotted again

Snapshot Rollback

• The snapshot or subvolume used as the root of the

filesystem can be specified

– Btrfs subvol list to find subvolumes – btrfs subvolume setdefault to set a new default

• Allows you to snapshot before upgrading and rollback

if things don't work well

Current Work In Progress

• Fsck with repair

– Initially fs rescue

• Robust error handling
• RAID5/6

– Reuse MD's parity calculation code – Single stripe size, adapt allocator and FS writeback to send down full stripes

• SSD front end cache
• Locking bottlenecks

SSD Optimizations

• Really just turning off rotational optimizations
• Send IO to the device right away

– No stalling or waiting to collect more IO

• Don't avoid fragmentation
• Send large writes whenever possible
• Reuse blocks instead of spreading across the device

– Unless you're on a cheap SSD

• Send discards down in large batches

– Collected in bulk and sent down right after transaction commit

Why Discard/Trim

SSD Front End Cache

• Stage writes to a set of fast SSD devices
• Remapping layer to remember which blocks are up to

date on the SSD

• Push frequently read extents into the SSD as well
• Hot data will stay on the SSD without hitting spinning

disks

• Work in progress, slightly different from IBM's

experiments over the summer

Thin Provisioning

• Btrfs storage chunks are well suited to thin

provisioning

• Btrfs can return large chunks of storage back to the

array

• Btrfs can quickly expand the FS
• Discard support in Btrfs sends information about

unused blocks down to the storage at run time

• Fitrim ioctl support is important for thin provisioning

Atomic Writes for Applications

• COW writes to Btrfs can be atomic up to large sizes
• Some hardware support fast atomic writes of larger

Ios as well

• Work in progress to wire up Btrfs atomic write support

and use optimizations from the hardware

• We may also support linked atomic writes between

two or more files

Database Write Performance

• Poor random write performance in COW mode
• Large files tend to fragment badly, leading to huge

amounts of metadata and seeking

• New data from random writes can be collected in bulk

after transaction commit and copied back to the

• riginal location
• Work in progress

Finding Recent Modifications

• Btrfs subvol find-new

Btrfs Scrubbing

• Scrubbing finds and repairs bad data
• Read all the allocated extents
• Verify checksums
• Replace bad copies with correct mirror
• Work in progress, initial implementation working

Conclusions

• Many things working and stable
• Focused on stability and performance
• http://btrfs.wiki.kernel.org/
• chris.mason@oracle.com
