The AESOP FP7 project

Jerker Delsing, Jens Eliasson, Per Lindgren, Paweł Pietrzak, Rumen Kyusakov, Henrik Mäkitaavola, +Jonas Gustafsson, etc.

2

The AESOP FP7 project

• Swedish partners

– LKAB, MIDROC,LTU/EISLAB + ProcessIT

• European partners

– Large companies

• Schneider
• SAP
• Honeywell
• Microsoft-EMIC

– Research Organizations

• Fho-Embden
• IFAK
• TUT (Tampere)

3

The AESOP FP7 project

• SOA Architecture

– E.g., described in Technologies for SOA-based Distributed Large Scale Process Monitoring and Control Systems (Schneider/Fr, Fho-Emden/De, LTU/Se, SAP/De, Honeywell/Cz, Microsoft-Emic/De)

• EISLAB

– Lightweight SOA

• 6LoWPAN, CoAP, EXI (LTU + Schneider + Ifak)
• TinyOS+CRO -> TOSPRO scheduling (LTU)

– Complex event processing for SOA

• CRO + CEP (LTU + Microsoft-Emic)

4

Motivation

• Pushing monitoring & control

down to embedded devices

Local “intelligence”

• Inherently event-based

Control systems traditionally scan-based current trend towards event-based

• Better responsiveness

Can act directly when an event occurs independent of scan time

• Minimize network traffic,

save bandwidth, etc.

• A. Colombo and S. Karnouskos, Towards the factory of the future:

A service-oriented cross-layer infrastructure, in ICT Shaping The World - A Scientific View, The European Telecommunications Standards Institute (ETSI). John Wiley and Sons Ed., April 2009, ch. 6.

Sensors ¡ Web ¡servers ¡ Feeds ¡

CEP CEP CEP CEP CEP CEP CEP CEP

Complex Analytics & Data Mining

5

Complex | Event | Processing

• Complex

– Made up of multiple detailed parts.

• Event

– Something that happens

• Processing

– A series of events to produce a result Source: Wiktionary.org

6

Events and Complex Events

• Basic (atomic) events

– A: church bells ringing, – B: the appearance of a man in a tuxedo with a woman in a flowing white gown, – C: rice flying through the air – Complex event: wedding? W = WHEN ALL (A, B, C)

7

Events and Complex Events

Events may have a Duration (start/stop)

W = WHEN ALL (A, B, C) A B C W Time

8

Complex Event Processing

• Most applications today in Business world

– Algorithmic stock-trading – Detection of credit-card fraud.

• Etc.

Business aspects, e.g., Microsoft

• R. Barga, H. Caituiro-Monge, …, Event Correlation and Pattern Detection in
• CEDR. Springer Berlin / Heidelberg, 2006, vol. 4254, pp.

Theoretical aspects, e.g., MDH

• J. Carlson and B. Lisper, A resource-efficient event algebra Science of

Computer Programming, vol. 75, no. 12, pp. 1215–1234, December 2010.

9

CEP vs SQL

SQL queries typically

• “one shot” (new queries created dynamically)
• return a result
• operate on database (relatively static)

CEP queries typically

• typically act as a filter (standing query)
• produce event when matching
• operate on streaming data (dynamic)

10

Complex Event Processing in “Our World”

• Combines data from multiple

sources

• Infer events or patterns that

suggest more complicated circumstances. The goal:

• Identify meaningful events (such as opportunities or threats)
• Respond, either by emitting new events or taking some action.

11

Embedded System

• Designed for specific purpose
• Often operating under real-time constraints
• Limited resources

– CPU – Memory – Communication bandwidth

12

CEDR - CRO

• CEDR : Complex Event Detection and Response

– Query language used commercially (Microsoft) – Capture event types and order

• CRO : Concurrent Reactive Objects

– Execution and concurrency model – React to atomic events – Between events: idle – Built in notion of time

13

CEDR

EVENT < query name > WHEN < event expression > WHERE < correlation expression > OUTPUT< instance transformation conditions >

14

CEDR - WHEN

• ALL(E1 , . . . , Ek )
• ANY(E1 , . . . , Ek )
• SEQUENCE(E1 , . . . , Ek )
• UNLESS(E1 , E2 , t)
• etc.

15

CEDR (Cont’d)

WHERE

• Correlation between values in events payload

Example: EVENT Temperature_alarm WHEN Any(Water_temp, Air_temp) AS x WHERE x.temperature > 100 OUTPUT Alarm x.ID

16

Concurrent Reactive Objects

• Reactivity

– React to external stimuli or internal events

• Objects and state encapsulation

– All states are encapsulated in objects O1, … , On

• Message passing and specification of timing

behavior

– ASYNC(O, m, t) : Asynchronous (may be delayed) – SYNC(O,m) : Synchronous call returns with a result

• Execution model behind the Timber language

and the TinyTimber C-code API.

17

CRO/Timber - Example

18

Event Processing in CRO

CEDR query into a CRO program EVENT Master_alarm WHEN UNLESS(ANY(High_temp,High_press) AS x, Button pressed , 10 seconds) (for the working example we omit payload)

19

An Event Expression Tree

WHEN UNLESS(ANY(High_temp,High_press) AS x, Button pressed , 10 seconds)

20

CEDR - CRO

O1 High_Temp O2 High_Temp O3 ANY O5 UNLESS O4 Button_Pressed 10 seconds WHEN UNLESS(ANY(High_temp,High_press), Button pressed , 10 seconds)

21

CEDR - CRO

22

Towards a Lightweight Complex Event Processing Engine for Embedded Systems

IECON 2012 : 38th Annual Conference of the IEEE Industrial Electronics Society Pawel Pietrzak, Per Lindgren, Henrik Mäkitaavola

• Lightweight and efficient implementation in TinyTimber

(C-Code API to CRO kernel)

– Simple states, no queues (besides inside kernel) – Static structure facilitates analysis

• Subset of CEDR rules (easily extendable)

Future work

• Support dynamic queries
• Support re-occurring/overlapping events
• Support real-time constraints

23

CEP in Monitoring and Control Systems

• CEP for Monitoring and Control

– Powerful mechanism to process streaming data (events can be time triggered, similar to scan-based) – Inherent support for event based control – Can connect loosely coupled Systems of Systems

• Requirements (quality)

– Accurate time of event occurrence – Bound & small delay of delivery

• processing and communication, boils down to
• scheduling of nodes and channels
• data representation

24

Challenges to solve

• Traditional CEP only deals with time in order to

correlate events, not the time to process and deliver

• Scheduling (prioritizing) is at best achieved through

assigning priority to a thread that process the query

– Time separated from query – Non compositional

• D. Anicic, P. Fodor, S. …, Ep-sparql: a unified language for event processing and

stream reasoning in Proceedings of the 20th international conference on World wide web, ser. WWW ’11. New York, NY, USA: ACM, 2011, pp. 635–644.

• R. Barga, H. Caituiro-Monge, …, Event Correlation and Pattern Detection in CEDR.

Springer Berlin / Heidelberg, 2006, vol. 4254, pp. 919–930

25

Real-Time Complex Event Processing using Concurrent Reactive Objects

Extends our prior work to address

– non-deterministic (out of order) execution improves schedulability – reoccurring events and overlapping timing windows relaxes the assumption that a query must be restarted after completion, multiple overlapping matches can now be handled – real-time properties allows CEP processing under hard real-time requirements

26

Our approach

• CRO Timing model

Message should be processed within execution window Each clause (sub-expression) is associated with a message

time baseline deadline event permissible execution window execution

tbefore tafter

UNLESS5 ANY3, High temp1 High press2 Button pressed4

10s

27

CEP encoding of unless in CRO-model

UNLESS5 ANY3, High temp1 High press2 Button pressed4

10s

• w is the window size (in this example 10s)
• Button_pressed operate under the deadline d1
• d2 is the deadline for processing the unless query
• by schdeuling the accept at w+d1 we can ensure

that outstanding Button_pressed events inside w have been processed.

• a triggering event (ANY) will be processed within

w+d1+d2 (end-end deadline for the processing) Deadlines can be either synthesized (from top level quieries) or derived (i.e., allowing timing of external hard-/software to be accounted for.) The notion of deadlines allows timing requirements to be fully compositional.

28

CEP encoding of unless in Timber

UNLESS5 ANY3, High temp1 High press2 Button pressed4

10s

unless e w d1 d2 = class tmr = new timer abortT := [] start = before w + d1 action after w + d1 send accept drop = before d1 action abortT := (<- tmr.sample) : abortT accept = before d2 action t = <-tmr.sample if elem True (map (inW t) abortT) then send e.drop else send e.accept abortT := (filter (inWOrL t) abortT) where inW t at = (at > t-w-d1) && (at < t-d1) inWOrL t at = at > t-w-d1-d2 result Cep {..}

29

CEP encoding of unless in Timber

unless e w d1 d2 = class tmr = new timer abortT := [] start = before w + d1 action after w + d1 send accept drop = before d1 action abortT := (<- tmr.sample) : abortT accept = before d2 action t = <-tmr.sample if elem True (map (inW t) abortT) then send e.drop else send e.accept abortT := (filter (inWOrL t) abortT) where inW t at = (at > t-w-d1) && (at < t-d1) inWOrL t at = at > t-w-d1-d2 result Cep {..}

• w d1 and d2 are parameters to the class
• timing specification directly in the language,

before and after constructs

• … rest is just implementation ….

30

Real-Time Complex Event Processing using Concurrent Reactive Objects

• Only a subset of CEDR rules have been

implemented but shows proof on concept

• Differs to traditional CEP by being point-point

instead of broadcasting

• i.e., sender is aware of listener
• Ok for static systems (like typical ES)
• dynamic queries requires registration of

listeners (not currently implemented)

31

Future work: A SOA Approach to Delay and Jitter Tolerant Distributed Real-Time Complex Event Processing Accepted to:

22nd IEEE International Symposium on Industrial Electronics

Per Lindgren, Rumen Kyusakov, Jens Eliasson, Henrik Mäkitaavola, Paweł Pietrzak

• Addresses

– Architecture for SOA and CEP in factory automation – Distributed and heterogeneous CEP processing – Real-time aspects are highlighted

• accurate time-stamping of physical events

in a distributed system

• end-to-end timing including communication

and CEP query processing

32

Future Work

• Implementation and use-case studies

– Process monitoring and control applications

• Control in System of Systems

– Further investigate SoS CEP for control

• Patterns/Templates for CEP in Timber

– Facilitate design of CEP queries

• Automatic generation of CRO/Timber CEP

from domain specific language (e.g., CEDR)

33
