WI2000 Weld Bead Inspection System For Tube and Pipe Your Machine Vision Technology Partner 2010 Capabilities Overview | CONFIDENTIAL | DISTRIBUTION PROHIBITED The Objective Monitoring the Surface Profile to provide real-time information about:


slide-1
SLIDE 1

WI2000 Weld Bead Inspection System For Tube and Pipe

2010 Capabilities Overview | CONFIDENTIAL | DISTRIBUTION PROHIBITED

Your Machine Vision Technology Partner

slide-2
SLIDE 2

XIRIS OVERVIEW | CONFIDENTIAL | DISTRIBUTION PROHIBITED

The Objective

Monitoring the Surface Profile to provide real-time information about:

  • how the tube was formed;
  • quality of the weld; and
  • consistency of the process.
slide-3
SLIDE 3
slide-4
SLIDE 4

XIRIS OVERVIEW | CONFIDENTIAL | DISTRIBUTION PROHIBITED

The Solution: WI2000p Weld Inspection System

A 3D Laser Based Camera System that Scans Tubes Post Weld for Weld and Forming Issues, with:

 Up to 10 Different

Measurements Tracked

 100 - 400 Images/Sec  7 µm resolution  Rugged Housing  Generates Alarm Output

slide-5
SLIDE 5

XIRIS OVERVIEW | CONFIDENTIAL | DISTRIBUTION PROHIBITED

Where to Use it?

Feeding Store Uncoil Sizing Scarf Forming Weld #1 #2

slide-6
SLIDE 6

XIRIS OVERVIEW | CONFIDENTIAL | DISTRIBUTION PROHIBITED

HFI Line Installation - Startup

slide-7
SLIDE 7

XIRIS OVERVIEW | CONFIDENTIAL | DISTRIBUTION PROHIBITED

HFI Line Installation with “Fireballs”

slide-8
SLIDE 8

XIRIS OVERVIEW | CONFIDENTIAL | DISTRIBUTION PROHIBITED

Laser Line Installation – Low Angle

slide-9
SLIDE 9

XIRIS OVERVIEW | CONFIDENTIAL | DISTRIBUTION PROHIBITED

HFI Line Installation with Red Bead

slide-10
SLIDE 10

CONFIDENTIAL | UNAUTHORIZED DISTRIBUTION PROHIBITED

Types of Defects

slide-11
SLIDE 11

XIRIS OVERVIEW | CONFIDENTIAL | DISTRIBUTION PROHIBITED

Mismatch

Height Difference (h) = Mismatch

slide-12
SLIDE 12

XIRIS OVERVIEW | CONFIDENTIAL | DISTRIBUTION PROHIBITED

Weld Undercut

Height Difference (h) = Undercut

slide-13
SLIDE 13

XIRIS OVERVIEW | CONFIDENTIAL | DISTRIBUTION PROHIBITED

Bead Height

Height Difference (h) = Bead Height

slide-14
SLIDE 14

XIRIS OVERVIEW | CONFIDENTIAL | DISTRIBUTION PROHIBITED

Deflection

Height Difference (h) = Deflection

slide-15
SLIDE 15

XIRIS OVERVIEW | CONFIDENTIAL | DISTRIBUTION PROHIBITED

Freeze Line

Height Measured (h) = Freeze Line

slide-16
SLIDE 16

XIRIS OVERVIEW | CONFIDENTIAL | DISTRIBUTION PROHIBITED

Bead Roll/Position

Found Angle (θ) = Bead Roll

slide-17
SLIDE 17

XIRIS OVERVIEW | CONFIDENTIAL | DISTRIBUTION PROHIBITED

Bead Slope Angle

Found Angle (θ) = Left / Right Bead Slope Angle

slide-18
SLIDE 18

XIRIS OVERVIEW | CONFIDENTIAL | DISTRIBUTION PROHIBITED

Bead Width

Distance Measured (w) = Bead Width

slide-19
SLIDE 19

XIRIS OVERVIEW | CONFIDENTIAL | DISTRIBUTION PROHIBITED

Bead Ratio

Bead Ratio = Bead Height Measured (h) / Wall Thickness (e)

slide-20
SLIDE 20

XIRIS OVERVIEW | CONFIDENTIAL | DISTRIBUTION PROHIBITED

Scarf Width

Distance Measured (w) = Scarf Width

slide-21
SLIDE 21

XIRIS OVERVIEW | CONFIDENTIAL | DISTRIBUTION PROHIBITED

Defect Example: Laser Welded Tube with Mismatch

White Line = Laser Line Blue Line = Centre of Laser Line Red Line = Ideal Tube Profile

slide-22
SLIDE 22

XIRIS OVERVIEW | CONFIDENTIAL | DISTRIBUTION PROHIBITED

Defect Example: TIG Welded Tube with Sunken Weld

White Line = Laser Line Blue Line = Centre of Laser Line Red Line = Ideal Tube Profile

slide-23
SLIDE 23

XIRIS OVERVIEW | CONFIDENTIAL | DISTRIBUTION PROHIBITED

Defect Example: ERW Welded Tube with FreezeLine

White Line = Laser Line Blue Line = Centre of Laser Line Red Line = Ideal Tube Profile

slide-24
SLIDE 24

CONFIDENTIAL | UNAUTHORIZED DISTRIBUTION PROHIBITED

Defect Screenshots from a Recent Example

Sensor model SR12 Resolution: 0.021 mm x 0.021 mm Tube size 100mm x 3.10mm HF welded Carbon Steel

slide-25
SLIDE 25

XIRIS OVERVIEW | CONFIDENTIAL | DISTRIBUTION PROHIBITED

slide-26
SLIDE 26

XIRIS OVERVIEW | CONFIDENTIAL | DISTRIBUTION PROHIBITED

Large Mismatch Defect

slide-27
SLIDE 27

XIRIS OVERVIEW | CONFIDENTIAL | DISTRIBUTION PROHIBITED

At Butt Weld

slide-28
SLIDE 28

XIRIS OVERVIEW | CONFIDENTIAL | DISTRIBUTION PROHIBITED

Open Weld

slide-29
SLIDE 29

XIRIS OVERVIEW | CONFIDENTIAL | DISTRIBUTION PROHIBITED

Correlation between WI-2000p and Micrograph

Profile Display from WI2000p Micro Graph Sample

slide-30
SLIDE 30

XIRIS OVERVIEW | CONFIDENTIAL | DISTRIBUTION PROHIBITED

Benefits of Installing a WI2000p

 Find Defects Sooner  Faster Set Up of Mill  Detect defects not found by other NDT systems  Maintain Tighter Control of Production  Reduce Scrap Rate  Reduce Customer Returns

slide-31
SLIDE 31

XIRIS OVERVIEW | CONFIDENTIAL | DISTRIBUTION PROHIBITED

Partial Customer List

slide-32
SLIDE 32

XIRIS OVERVIEW | CONFIDENTIAL | DISTRIBUTION PROHIBITED

THANK YOU ! XIRIS AUTOMATION INC.

sales@xiris.com www.xiris.com
