SLIDE 1

Teaching modes of reasoning: Redesigning the Art of Approximation in Science and Engineering

Sanjoy Mahajan

MIT & Olin College

mit.edu/sanjoy/www/ sanjoy@mit.edu

HHMI Education Group, MIT, 27 February 2014

SLIDE 2

Modes of reasoning or topics?

Doubling the block’s thickness changes the note frequency by what factor?

tap tap

a. 2

b. √ 2 c. 1

d. 1/

√ 2

e. 1/2

SLIDE 3

Modes of reasoning or topics?

Doubling the block’s thickness changes the note frequency by what factor?

tap tap

a. 2

b. √ 2 c. 1

d. 1/

√ 2

e. 1/2

SLIDE 4

A spring model explains the doubling in frequency

Compare the stored energies for the same deflection y:

y y

stored energy ∼ stiffness

k

×y2.

SLIDE 5

A spring model explains the doubling in frequency

Compare the stored energies for the same deflection y:

y y

SLIDE 6

A spring model explains the doubling in frequency

Compare the stored energies for the same deflection y:

y y

4× the energy per spring

SLIDE 7

A spring model explains the doubling in frequency

Compare the stored energies for the same deflection y:

y y

4× the energy per spring 2× the number of springs

SLIDE 8

A spring model explains the doubling in frequency

Compare the stored energies for the same deflection y:

y y

4× the energy per spring 2× the number of springs 8× the stored energy

stiffness×y2

SLIDE 9

A spring model explains the doubling in frequency

Compare the stored energies for the same deflection y:

y y

4× the energy per spring 2× the number of springs 8× the stored energy

stiffness×y2

(bending) frequency ∼

stiffness

mass =

8×

2× = 2×.

SLIDE 10

Modes of reasoning or topics?

SLIDE 11

Modes of reasoning are a better organization than topics

Using modes of reasoning makes the course finite Using modes of reasoning promotes transfer Using modes of reasoning promotes long-lasting learning

SLIDE 12

Topics are many, life is short

sound waves mechanical properties thermal properties weather fluid drag turbulence gravitation prime numbers retinal rod biomechanics astrophysics financial math . . . Where do you stop?

SLIDE 13

Teaching in Cambridge, England, I moved toward modes

f reasoning only subconsciously

SLIDE 14

I was influenced by problem solving in mathematics

The Invariance Principle Coloring Proofs The Extremal Principle The Box Principle Enumerative Combinatorics Number Theory Inequalities The Induction Principle Sequences Polynomials Functional Equations Geometry Games Further Strategies

SLIDE 15

I used it for Street-Fighting Mathematics

Dimensions Easy cases Lumping Pictorial proofs Taking out the big part Analogy

SLIDE 16

Modes of reasoning now seemed to appear everywhere

Pt. I. Incentives

Ex ante and ex post The idea of efficiency Thinking at the margin The single owner The least cost avoider Administrative cost Rents The Coase theorem . . .

SLIDE 17

Modes of reasoning for science and engineering

rganized themselves slowly

Easy cases Divide and conquer Spring models Lumping Proportional reasoning Symmetry/conservation Abstraction Probabilistic reasoning Dimensional analysis

SLIDE 18

Modes of reasoning for science and engineering

rganized themselves slowly

Abstraction Divide and conquer Easy cases Spring models Lumping Proportional reasoning Symmetry/conservation Probabilistic reasoning Dimensional analysis

SLIDE 19

Modes of reasoning for science and engineering

rganized themselves slowly

Organizing Abstraction Divide and conquer Discarding Proportional Symmetry/conservation Dimensional analysis Probabilistic Easy cases Spring models Lumping

SLIDE 20

Modes of reasoning for science and engineering

rganized themselves slowly

Organizing Abstraction Divide and conquer Discard: lossless Proportional Symmetry/conservation Dimensional analysis Discard: lossy Probabilistic Easy cases Spring models Lumping

SLIDE 21

Modes of reasoning for science and engineering

rganized themselves around mastering complexity

lossless lossy proportional reasoning symmetry/ conservation dimensional analysis to master complexity lumping probability easy cases springs

rganize it

discard it abstraction divide/conquer

SLIDE 22

Using modes of reasoning makes the course finite

SLIDE 23

Modes of reasoning are a better organization than topics

Using modes of reasoning makes the course finite Using modes of reasoning promotes transfer Using modes of reasoning promotes long-lasting learning

SLIDE 24

The tree gives each mode of reasoning a place

lossless lossy proportional reasoning symmetry/ conservation dimensional analysis to master complexity lumping probability easy cases springs

rganize it

discard it abstraction divide/conquer

SLIDE 25

Each mode of reasoning contains examples: Divide and conquer

How many barrels of oil does the United States import in a year?

car usage Ncars 3×108 miles/year 20 000 miles/gallon 30 gallons/barrel 60 height 1 m width 0.5 m depth 0.5 m gallons/meter3 250

−1 −1

SLIDE 26

Each mode of reasoning contains examples: Divide and conquer

How much energy does a 9-volt battery contain? battery life laptop power laptop-battery energy volume adjustment energy in a 9V battery

SLIDE 27

Each mode of reasoning contains examples: Divide and conquer

How much energy does a 9-volt battery contain? battery life 4 hr (104 s) laptop power 20 W laptop-battery energy 2×105 J volume adjustment 1/10 energy in a 9V battery 2×104 J

SLIDE 28

Using modes of reasoning promotes transfer

mode example

SLIDE 29

Using modes of reasoning promotes transfer

When teaching by topics, it is too easy to use too-similar examples.

M p e n u m b r a

SLIDE 30

Using modes of reasoning promotes transfer

Diverse examples help clarify the core idea.

M

Using modes of reasoning automatically produces diverse examples.

SLIDE 31

Modes of reasoning are a better organization than topics

Using modes of reasoning makes the course finite Using modes of reasoning promotes transfer Using modes of reasoning promotes long-lasting learning

SLIDE 32

The tree gives each mode of reasoning a place

lossless lossy proportional reasoning symmetry/ conservation dimensional analysis to master complexity lumping probability easy cases springs

rganize it

discard it abstraction divide/conquer

SLIDE 33

Each mode of reasoning contains examples: Symmetry and conservation

force energy distance volume density v2 mass

−1

How fast will the cone fall? (by conservation of energy)

A volume Ad distance d v

drag force = energy consumed by drag distance traveled .

SLIDE 34

Each mode of reasoning contains examples: Symmetry and conservation

force ρAv2 energy ρAv2d distance d volume Ad density ρ v2 mass ρAd

−1

How fast will the cone fall?

SLIDE 35

Each mode of reasoning contains examples: Symmetry and conservation

How fast will the cone fall? F ∼ ρAv2 v ∼

F

ρA ∼

10−3 kg × 10 m/s2

1 kg/m3 × 0.01 m2 ∼ 1 m/s.

SLIDE 36

The tree gives each mode of reasoning a place

lossless lossy proportional reasoning symmetry/ conservation dimensional analysis to master complexity lumping probability easy cases springs

rganize it

discard it abstraction divide/conquer

SLIDE 37

Each mode of reasoning contains examples: Proportional reasoning

Wood blocks

tap tap

frequency ∝ thickness?

SLIDE 38

Each mode of reasoning contains examples: Proportional reasoning

Falling cones again vfour stacked cones vone stacked cone =      4 2

r

√ 2 Equivalently, v ∝ (number of cones)?

SLIDE 39

The tree gives each mode of reasoning a place

lossless lossy proportional reasoning symmetry/ conservation dimensional analysis to master complexity lumping probability easy cases springs

rganize it

discard it abstraction divide/conquer

SLIDE 40

Each mode of reasoning contains examples: Dimensional analysis

Motto: The uncompared quantity is not worth knowing. cost of 9-volt battery energy cost of line (mains) power

SLIDE 41

Each mode of reasoning contains examples: Dimensional analysis

Motto: The uncompared quantity is not worth knowing. cost of 9-volt battery energy cost of line (mains) power ∼ $1 / 2×104 J $0.15 / 3.6×106 J ≈ 7 × 180 ∼ 1000.

SLIDE 42

Each mode of reasoning contains examples: Lumping

Every number is of the form:  

ne
r

few   × 10n, where few2 = 10.

SLIDE 43

Each mode of reasoning contains examples: Lumping

How many seconds in a year? 365 days year × 24 hours day × 3600 seconds hour

SLIDE 44

Each mode of reasoning contains examples: Lumping

How many seconds in a year? few×102 days year × 24 hours day × 3600 seconds hour

SLIDE 45

Each mode of reasoning contains examples: Lumping

How many seconds in a year? few×102 days year × few×101 hours day × 3600 seconds hour

SLIDE 46

Each mode of reasoning contains examples: Lumping

How many seconds in a year? few×102 days year × few×101 hours day × few×103 seconds hour

SLIDE 47

Each mode of reasoning contains examples: Lumping

How many seconds in a year? few×102 days year × few×101 hours day × few×103 seconds hour ∼ few×107 seconds year

SLIDE 48

The tree gives each mode of reasoning a place

lossless lossy proportional reasoning symmetry/ conservation dimensional analysis to master complexity lumping probability easy cases springs

rganize it

discard it abstraction divide/conquer

SLIDE 49

Each mode of reasoning contains examples: Springs

Wood blocks

y y

SLIDE 50

Each mode of reasoning contains examples: Springs

Why is the sky blue? How much energy does the earth–sun system lose in gravitational radiation?

SLIDE 51

Connections are more important than facts alone

big cluster = 12% pbond = 0.40

SLIDE 52

Connections are more important than facts alone

big cluster = 12% pbond = 0.40 big cluster = 42% pbond = 0.50

SLIDE 53

Connections are more important than facts alone

big cluster = 12% pbond = 0.40 big cluster = 42% pbond = 0.50 big cluster = 81% pbond = 0.55

SLIDE 54

Connections are more important than facts alone

big cluster = 12% pbond = 0.40 big cluster = 42% pbond = 0.50 big cluster = 81% pbond = 0.55 big cluster = 94% pbond = 0.60

SLIDE 55

Using modes of reasoning promotes long-lasting learning

SLIDE 56

Modes of reasoning are a better organization than topics

Using modes of reasoning makes the course finite Using modes of reasoning promotes transfer Using modes of reasoning promotes long-lasting learning

SLIDE 57

Modes of reasoning are a better organization than topics

The goal [of teaching] should be, not to implant in the students’ mind every fact that the teacher knows now; but rather to implant a way of thinking that enables the student, in the future, to learn in one year what the teacher learned in two years. Only in that way can we continue to advance from one generation to the next. —Edwin T. Jaynes (1922–1998)
