TDDB68/TDDE47

Lesson 1

Felipe Boeira Based on previous slides from the course

Contents

• Overview of the labs
• General information about Pintos
• System calls
• Lab 0/Lab 1 details
• Debugging

Administration

Webreg:

• If you still could not register, send me an email!

General information
 about the labs

• The labs are based on Pintos: an educational OS

(developed at Stanford University)

• Pintos is written in C and well documented
• The labs are about adding functionality to Pintos
• Pintos is around 7 500 lines of code (LOC)

General information
 about the labs

• The complicated parts of the labs are understanding

how pintos is structured and what you should do: you do not need to write a lot of code

• In other words, try to read a lot!
• A proper understanding of C will save you a lot of

time debugging!

• You must work on non-scheduled time as well!

These labs tend to be time-consuming

General information
 about the labs

• If you pass the labs on time(2020-03-13), then you

earn 4 bonus points on the exam

• This offer is only available to new students
• The final deadline is 2020-03-30 in Webreg
• The procedure of handing in the labs
• gitlab.liu.se

Lab 0

• Setting up Pintos
• Linked lists
• Information about how to debug Pintos

Lab 1

• The first real lab
• Single user process
• Implement a number of system calls:
• Reading from and writing to the console
• Creating, reading from and writing to files
• Exit a process and halt the machine
• Tends to take some time since you have to familiarise yourself

with Pintos

Lab 2

• Multiple user processes
• Implement another system call: Sleep
• Sleep delays execution of the calling process by

the given number of milliseconds

• Synchronisation is now necessary
• This lab tends to take the least amount of time

Lab 3

• Multiple user processes
• Implement the exec system call
• Exec: Let processes start execute programs in a

child process

• Create parent-child relationship
• This lab together with the next two tend to take a

lot of time to finish!

Lab 4

• Programs cannot have arguments yet - fix it!
• Setup the user space program stack with

arguments according to the x86 convention

• This lab requires careful understanding of memory

layout and pointer arithmetic

Lab 5

• Multiple user processes
• Implement the system call Wait
• Wait: Let processes wait for their children to finish

executing

• Use or extend the parent-child relationship you

have already created

Lab 6

• If several processes write to the same file, they will
• verwrite each other’s content arbitrarily
• Make sure that no order of system call, or internal

calls, leads to an invalid state (open, close, write, read, and so on)

• Synchronise the file system! (readers/writers

algorithm, and more)

• This lab tends to take about as much time as lab 1

A closer look at Lab 0

• Linked list is a simple data structure to dynamically store data
• Singly linked list example:

struct Node { int data; struct Node* next; };

Node next next next NULL Node Node

A closer look at Lab 0

• Doubly linked lists are similar, they also point to the previous element
• Pintos implementation example:

next next

struct list_elem { struct list_elem *prev; /* Previous list element. */ struct list_elem *next; /* Next list element. */ }; struct list { struct list_elem head; /* List head. */ struct list_elem tail; /* List tail. */ }; struct Node { int data; struct list_elem elem; };

Node Node

prev prev

NULL

prev next prev

Head Tail NULL

next

A closer look at Lab 1

• Only one user process at a time - no concurrency!
• Suppose a user process wants to open a file, then it:
• 1. Calls the function int open(const char *file);
• 2. The function open puts the arguments on the stack,

together with the syscall no.;

• 3. Produces an interrupt to switch from user mode to

supervisor mode;

• 4. The interrupt handler then looks at the interrupt no. and

delegates it to the appropriate subhandler, in this case, the syscall handler;

Already implemented!

A closer look at Lab 1

... ...

esp+4 esp Stack growth syscall no. first argument User Stack Virtual Memory

/* Invokes syscall NUMBER, passing argument ARG0, and returns the return value as an `int'. */ #define syscall1(NUMBER, ARG0) \ ({ \ int retval; \ asm volatile \ ("pushl %[arg0]; pushl %[number]; int $0x30; addl $8, %%esp" \ : "=a" (retval) \ : [number] "i" (NUMBER), \ [arg0] "g" (ARG0) \ : "memory"); \ retval; \ }) int

• pen (const char *file)

{ return syscall1 (SYS_OPEN, file); }

lib/user/syscall.[h|c] - The syscall wrapper

A closer look at Lab 1

• The syscall handler then (in supervisor mode):
• 1. Reads the syscall no. to decide the type of syscall (write, read,
• pen, close, and so on).
• 2. Based on the type, the handler reads the correct number of

arguments from the stack, and performs the syscall.

• For example, the handler does not get the arguments to this syscall

directly: bool create(const char *file, unsigned size)
 To get them you have to read them from the stack: f->esp

• Note that the actual string is NOT on the stack. The stack only has

a pointer to the first character of the string.

• To return the result of the syscall, set this register: f->eax

This is the assignment!

A closer look at Lab 1

Files to study:

• lib/user/syscall.[h|c] - The syscall wrapper
• userprog/syscall.[h|c] - Implement syscalls here!
• threads/thread.[h|c] - Implement something here!
• threads/interrupt.[h|c] - Important structures
• lib/syscall-nr.h - Syscall numbers
• filesys/filesys.[h|c] - Pintos file system

A closer look at Lab 1

• Currently, the syscall handler kills every calling

process

• The handler must do the things that we discussed

earlier

• f->esp is the stack of the calling process
• The syscall number is at the top, then the arguments
• Every syscall has its own syscall number: use it to

decide the number of arguments

A closer look at Lab 1

File descriptors (FD)

• A FD is a non-negative integer that represents abstract

input/output resources

• Input/output resources are, for example, files, consoles,

network sockets, and so on

• The user processes only knows about FDs, and the OS

knows what concrete resource it represents

• In the labs, FD 0 and 1 are reserved for the console (stdin/

stdout)

A closer look at Lab 1

What to think about when implementing:

• create - Create a file. Return true if a file was created, false
• therwise. Hint: Use already implemented functions.
• open - Open a file. Return a FD to the user process. How do we

decide on a FD and how do we map it to an opened file? Every process has its own collection of opened files. FD values 0 and 1 are reserved for the console. Hint: Modify the struct thread to track file descriptors.

• close - Close the file associated with the given FD. Disassociate

the FD with the file. Hint: Use already implemented functions.

• exit - Kill the process. Deallocate all of its resources (eg. files). We

revisit this syscall in Lab 3. Hint: Free resources in thread_exit.

A closer look at Lab 1

What to think about when implementing:

• read - Read the file associated with the given FD. The user process

gives a buffer (a piece of memory) in which the read bytes are written to. Return the number of read bytes. Hint: Use already implemented functions. Use input_getc to read from the console.

• write - Write to the file associated with the given FD. The user

process gives a buffer with the content that should be written. Return the number of written bytes. Hint: Use already implemented

• functions. Use putbuf to write to the console (check lib/kernel/

stdio.h and lib/kernel/console.c).

• halt - Shutdown the machine (halts the processor). Hint: Use

already implemented functions.

A closer look at Lab 1

What to think about when implementing all of them:

• Every user process should be able to have at least 128

files opened at the same time

• It is dangerous to assume that the arguments are valid!

We will revisit this topic in future labs

• Special cases: What happens if the arguments of the

syscall are invalid? Such as NULL pointers, invalid buffer size, FDs with no associated file, and if the process has opened too many files

A closer look at Lab 1

Frequently Asked Questions:

• Use the function thread_current() to get the thread

structure of the calling process

• The function filesys_open(char *) opens a file, and the

function file_close(file *) closes it

• The function init_thread(…) initialises every thread,

whilst the function thread_init(…) initialises the thread module (once, when Pintos starts up). If you need to do some initialisation for every thread, modify the former function (at the end of it)

A closer look at Lab 1

• Run lab1test2 to test your code. It will:
• Create files
• Open files
• Read and write from the console
• Try to use bad FDs
• Gotchas:
• Remove all the files on the virtual hard drive before running it again:


pintos --qemu -- rm test0 rm test1 rm test2

• Passing lab1test does NOT mean that you have finished the lab! You must

ensure that there are no special cases

• Your implementation will be tested more thoroughly in Lab 3

System call overview

• 13 system calls to be implemented
• Linux: Around 320 system calls
• Windows: More than 1000 system calls

Debugging

• Read Appendix E: Debugging tools in the documentation
• ASSERT(p != NULL)
• If you get "Kernel Panic", then try the backtrace tool
• free sets bytes to 0xcc: If you see bytes with this value,

then something likely freed the memory

• Use versioning and commit frequently. It is common to

break Pintos in very obscure ways, and it is often easier to go back to a working version and redo the changes

Debugging

Backtrace example:

• If you were to get this:


Call stack: 0xc0106eff 0xc01102fb 0xc010dc22 0xc010cf67 0xc0102319 0xc010325a 0x804812c 0x8048a96 0x8048ac8

• Then type this:


backtrace kernel.o 0xc0106eff 0xc01102fb 0xc010dc22 0xc010cf67 0xc0102319 0xc010325a 0x804812c 0x8048a96 0x8048ac8

• To get this:


0xc0106eff: debug_panic (lib/debug.c:86)
 0xc01102fb: file_seek (filesys/file.c:405)
 0xc010dc22: seek (userprog/syscall.c:744)
 0xc010cf67: syscall_handler (userprog/syscall.c:444)
 0xc0102319: intr_handler (threads/interrupt.c:334)
 0xc010325a: intr_entry (threads/intr-stubs.S:38)
 …

Questions?
