TCP CONGESTION SIGNATURES

1

Srikanth Sundaresan (Princeton Univ.) Amogh Dhamdhere (CAIDA/UCSD) kc Claffy (CAIDA/UCSD) Mark Allman (ICSI)

w w w . cai da.

• r

Typical Speed Tests Don’t Tell Us Much

2

w w w . cai da.

• r

Typical Speed Tests Don’t Tell Us Much

2

w w w . cai da.

• r

Typical Speed Tests Don’t Tell Us Much

2

w w w . cai da.

• r

Typical Speed Tests Don’t Tell Us Much

• Upload and download throughput measurements: no

information beyond that

2

w w w . cai da.

• r

Typical Speed Tests Don’t Tell Us Much

2

What type of congestion did the TCP flow experience?

w w w . cai da.

• r

Two Potential Sources of Congestion in the End-to-end Path

3

w w w . cai da.

• r

Two Potential Sources of Congestion in the End-to-end Path

• Self-induced congestion
• Clear path, the flow itself induced congestion
• eg: last-mile access link

3

w w w . cai da.

• r

Two Potential Sources of Congestion in the End-to-end Path

• Self-induced congestion
• Clear path, the flow itself induced congestion
• eg: last-mile access link
• External congestion
• Flow starts on an already congested path
• eg: congested interconnect

3

w w w . cai da.

• r

Two Potential Sources of Congestion in the End-to-end Path

• Self-induced congestion
• Clear path, the flow itself induced congestion
• eg: last-mile access link
• External congestion
• Flow starts on an already congested path
• eg: congested interconnect

3

Distinguishing the two cases has implications for users / ISPs / regulators

w w w . cai da.

• r

How can we distinguish the two?

• Cannot distinguish using just throughput numbers
• Access plan rates vary widely, and are typically not available to content /

speed test providers

• eg: Speed test reports 5 Mbps – is that the access link rate (DSL), or a

congested path?

4

w w w . cai da.

• r

How can we distinguish the two?

• Cannot distinguish using just throughput numbers
• Access plan rates vary widely, and are typically not available to content /

speed test providers

• eg: Speed test reports 5 Mbps – is that the access link rate (DSL), or a

congested path?

4

We can use the dynamics of TCP’s startup phase, i.e., Congestion Signatures

w w w . cai da.

• r

TCP’s RTT Congestion Signatures

5

w w w . cai da.

• r

TCP’s RTT Congestion Signatures

• Flows experiencing self-induced congestion fill up an

empty buffer during slow start

• Hence increase the TCP flow RTT

5

w w w . cai da.

• r

TCP’s RTT Congestion Signatures

• Flows experiencing self-induced congestion fill up an

empty buffer during slow start

• Hence increase the TCP flow RTT
• Externally congested flows encounter an already full buffer
• Less potential for RTT increases

5

w w w . cai da.

• r

TCP’s RTT Congestion Signatures

• Flows experiencing self-induced congestion fill up an

empty buffer during slow start

• Hence increase the TCP flow RTT
• Externally congested flows encounter an already full buffer
• Less potential for RTT increases
• Self-induced congestion therefore has higher RTT variance

compared to external congestion

5

w w w . cai da.

• r

TCP’s RTT Congestion Signatures

• Flows experiencing self-induced congestion fill up an

empty buffer during slow start

• Hence increase the TCP flow RTT
• Externally congested flows encounter an already full buffer
• Less potential for RTT increases
• Self-induced congestion therefore has higher RTT variance

compared to external congestion

5

We can quantify this using Max-Min and CoV of RTT

w w w . cai da.

• r

Example Controlled Experiment

• 20 Mbps “access” link

with 100 ms buffer

• 1 Gbps “interconnect”

link with 50 ms buffer

• Self-induced

congestion flows have higher values for both metrics and are clearly distinguishable

Max-Min RTT

6

CoV RTT

101 102 0.0 0.2 0.4 0.6 0.8 1.0

CDF External Self

10−2 10−1 100 0.0 0.2 0.4 0.6 0.8 1.0

CDF External Self

w w w . cai da.

• r

Example Controlled Experiment

• 20 Mbps “access” link

with 100 ms buffer

• 1 Gbps “interconnect”

link with 50 ms buffer

• Self-induced

congestion flows have higher values for both metrics and are clearly distinguishable

The two types of congestion exhibit widely contrasting behaviors

Max-Min RTT

6

CoV RTT

101 102 0.0 0.2 0.4 0.6 0.8 1.0

CDF External Self

10−2 10−1 100 0.0 0.2 0.4 0.6 0.8 1.0

CDF External Self

w w w . cai da.

• r

Model

• Max-min and CoV of RTT derived from RTT samples

during slow start

• We feed the two metrics into a simple Decision Tree
• We control the depth of the tree to a low value to minimize

complexity

• We build the decision tree classifier using controlled

experiments and apply it to real-world data

7

w w w . cai da.

• r

Validating the Method: Step 1- Controlled Experiments

8

Internet R2 R1

Server 1 Server 2 Server 3 Server 4 Pi 1 Pi 2 100 Mbps Shaped “access” 1 Gbps

w w w . cai da.

• r

Validating the Method: Step 1- Controlled Experiments

8

Internet R2 R1

Server 1 Server 2 Server 3 Server 4 Pi 1 Pi 2 100 Mbps Shaped “access” 1 Gbps

Background cross-traffic Interconnect cross-traffic

w w w . cai da.

• r

Validating the Method: Step 1- Controlled Experiments

8

Internet R2 R1

Server 1 Server 2 Server 3 Server 4 Pi 1 Pi 2 100 Mbps Shaped “access” 1 Gbps

Throughput tests Background cross-traffic Interconnect cross-traffic

w w w . cai da.

• r

It’s Real

9

w w w . cai da.

• r

It’s Real

9

Fantastic Cabling effort Post-it defined networking

w w w . cai da.

• r

Validating the Method: Step 1- Controlled Experiments

• Emulated access link + “core” link
• Wide range of access link throughputs, buffer sizes, loss rates, cross-

traffic (background and congestion-inducing)

• Can accurately label flows in training data as “self” or “externally”

congested

10

Internet R2 R1

Server 1 Server 2 Server 3 Server 4 Pi 1 Pi 2 100 Mbps Shaped “access” 1 Gbps

Throughput tests Background cross-traffic Interconnect cross-traffic

w w w . cai da.

• r

Validating the Method: Step 1- Controlled Experiments

11

Internet R2 R1

Server 1 Server 2 Server 3 Server 4 Pi 1 Pi 2 100 Mbps Shaped “access” 1 Gbps

Throughput tests Background cross-traffic Interconnect cross-traffic

High accuracy: precision and recall > 80% robust to model settings

w w w . cai da.

• r

Validating the Method: Step 2

• From Ark VP in ISP A identified congested link with ISP B using

TSLP*

12

*Luckie et al. “Challenges in Inferring Internet Interdomain Congestion”, IMC 2014

ISP A ISP B

Ark VP

w w w . cai da.

• r

Validating the Method: Step 2

• From Ark VP in ISP A identified congested link with ISP B using

TSLP*

12

*Luckie et al. “Challenges in Inferring Internet Interdomain Congestion”, IMC 2014

ISP A ISP B

congested link

Ark VP

w w w . cai da.

• r

Validating the Method: Step 2

13

ISP A ISP B

M-lab NDT server congested link

Ark VP

• Periodic NDT tests from Ark VP to M-Lab NDT server “behind”

the congested interdomain link

w w w . cai da.

• r

Validation of the Method: Step 2

14

5 10 15 20 25 30 02/18 02/25 03/04 03/11 d/l Mbps 10 20 30 40 50 60 70 02/18 02/25 03/04 03/11 TSLP latency (far side)

Strong correlation between throughput and TSLP latency: flows during elevated TSLP latency labeled as “externally” congested

w w w . cai da.

• r

Validation of the Method: Step 2

14

5 10 15 20 25 30 02/18 02/25 03/04 03/11 d/l Mbps 10 20 30 40 50 60 70 02/18 02/25 03/04 03/11 TSLP latency (far side)

Strong correlation between throughput and TSLP latency: flows during elevated TSLP latency labeled as “externally” congested “Externally” congested

w w w . cai da.

• r

Validation of the Method: Step 2

14

5 10 15 20 25 30 02/18 02/25 03/04 03/11 d/l Mbps 10 20 30 40 50 60 70 02/18 02/25 03/04 03/11 TSLP latency (far side)

Strong correlation between throughput and TSLP latency: flows during elevated TSLP latency labeled as “externally” congested “Externally” congested “self” congested

w w w . cai da.

• r

Validation of the Method: Step 2

15

5 10 15 20 25 30 02/18 02/25 03/04 03/11 d/l Mbps 10 20 30 40 50 60 70 02/18 02/25 03/04 03/11 TSLP latency (far side)

75%+ accuracy in detecting external congestion, 100% accuracy for self-induced congestion

w w w . cai da.

• r

Validation of the Method: Step 3

• We use Measurement Lab’s NDT test data for real-world

validation

• Cogent interconnect issue in late 2013/early 2014
• NDT tests to Cogent servers saw significant drops in throughput during

peak hours

• Several major U.S. ISPs were affected, except Cox
• The problem was identified as congested interconnects

16

w w w . cai da.

• r

Using the M-lab Data

17

January 2014 April 2014

5 10 15 20

Hour of day (local)

10 20 30 40

Mbps

Comcast Cox TimeWarner Verizon 5 10 15 20

Hour of day (local)

10 20 30 40

Mbps

Comcast Cox TimeWarner Verizon

w w w . cai da.

• r

Using the M-lab Data

17

January 2014 Drop in peak-hour throughput for for Comcast, TWC, Verizon April 2014

5 10 15 20

Hour of day (local)

10 20 30 40

Mbps

Comcast Cox TimeWarner Verizon 5 10 15 20

Hour of day (local)

10 20 30 40

Mbps

Comcast Cox TimeWarner Verizon

w w w . cai da.

• r

Using the M-lab Data

17

January 2014 Cox not affected Drop in peak-hour throughput for for Comcast, TWC, Verizon April 2014

5 10 15 20

Hour of day (local)

10 20 30 40

Mbps

Comcast Cox TimeWarner Verizon 5 10 15 20

Hour of day (local)

10 20 30 40

Mbps

Comcast Cox TimeWarner Verizon

w w w . cai da.

• r

Using the M-lab Data

17

January 2014 Cox not affected Drop in peak-hour throughput for for Comcast, TWC, Verizon April 2014 Interconnection dispute resolved; no diurnal effect

5 10 15 20

Hour of day (local)

10 20 30 40

Mbps

Comcast Cox TimeWarner Verizon 5 10 15 20

Hour of day (local)

10 20 30 40

Mbps

Comcast Cox TimeWarner Verizon

w w w . cai da.

• r

Using the M-lab Data

18

Peak hour tests in Jan/Feb 2014 are likely “externally” congested Off-peak tests in Mar/Apr 2014 are likely “self” congested

5 10 15 20

Hour of day (local)

10 20 30 40

Mbps

Comcast Cox TimeWarner Verizon 5 10 15 20

Hour of day (local)

10 20 30 40

Mbps

Comcast Cox TimeWarner Verizon

w w w . cai da.

• r

But didn’t you just say it’s hard to infer congestion using throughput tests??

19

w w w . cai da.

• r

But didn’t you just say it’s hard to infer congestion using throughput tests??

• Yes :)

19

w w w . cai da.

• r

But didn’t you just say it’s hard to infer congestion using throughput tests??

• Yes :)
• For that reason, our labeling is broad and coarse. All tests

labeled “external” may not be traversing congested interconnects

19

w w w . cai da.

• r

But didn’t you just say it’s hard to infer congestion using throughput tests??

• Yes :)
• For that reason, our labeling is broad and coarse. All tests

labeled “external” may not be traversing congested interconnects

• We do not expect the technique to identify all peak hour

tests as externally congested, and vice versa

• Looking for qualitative differences

19

w w w . cai da.

• r

But didn’t you just say it’s hard to infer congestion using throughput tests??

• Yes :)
• For that reason, our labeling is broad and coarse. All tests

labeled “external” may not be traversing congested interconnects

• We do not expect the technique to identify all peak hour

tests as externally congested, and vice versa

• Looking for qualitative differences
• The general observations about congestion were verified

by other sources, e.g., CAIDA’s TSLP measurements

19

w w w . cai da.

• r

Applying the Model to M-lab data

20

Comcast TimeWarner VerizonCox Comcast TimeWarner VerizonCox Comcast TimeWarner VerizonCox 0.2 0.4 0.6 0.8 1.0

% self-induced congestion

Cogent (LAX) Cogent (LGA) Level3 (ATL)

Jan-Feb Mar-Apr

w w w . cai da.

• r

Applying the Model to M-lab data

20

Comcast TimeWarner VerizonCox Comcast TimeWarner VerizonCox Comcast TimeWarner VerizonCox 0.2 0.4 0.6 0.8 1.0

% self-induced congestion

Cogent (LAX) Cogent (LGA) Level3 (ATL)

Jan-Feb Mar-Apr

Much lower incidences of self-induced congestion for Cogent in Jan/Feb 2014 as compared to Mar/Apr

w w w . cai da.

• r

Applying the Model to M-lab data

21

Comcast TimeWarner VerizonCox Comcast TimeWarner VerizonCox Comcast TimeWarner VerizonCox 0.2 0.4 0.6 0.8 1.0

% self-induced congestion

Cogent (LAX) Cogent (LGA) Level3 (ATL)

Jan-Feb Mar-Apr

Level3 does not show significant differences, was not affected by interconnection disputes

w w w . cai da.

• r

Applying the Model to M-lab data

22

Comcast TimeWarner VerizonCox Comcast TimeWarner VerizonCox Comcast TimeWarner VerizonCox 0.2 0.4 0.6 0.8 1.0

% self-induced congestion

Cogent (LAX) Cogent (LGA) Level3 (ATL)

Jan-Feb Mar-Apr

Cox does not show significant differences, was not affected by interconnection disputes

w w w . cai da.

• r

Looking at Throughput

• What throughput should we observe for “self” and

“external” congested flows?

• With congested interconnects affecting many flows, both

“self” and “external” should see similar throughput

• Without congested interconnects affecting many flows,

“self” congested throughput should follow access link speeds, generally higher than “externally” congested

23

w w w . cai da.

• r

Looking at Throughput

• Avg. throughput of self-induced congestion flows

significantly higher than externally congested in Mar-Apr (no interconnection disputes)

24

Comcast TimeWarner Verizon Cox 5 10 15 20

Throughput (Mbps) Jan-Feb Self Jan-Feb External Mar-Apr Self Mar-Apr External

w w w . cai da.

• r

Looking at Throughput

• Avg. throughput of self-induced congestion flows

significantly higher than externally congested in Mar-Apr (no interconnection disputes)

24

Comcast TimeWarner Verizon Cox 5 10 15 20

Throughput (Mbps) Jan-Feb Self Jan-Feb External Mar-Apr Self Mar-Apr External

Both “self” and “external” get similar throughput

w w w . cai da.

• r

Looking at Throughput

• Avg. throughput of self-induced congestion flows

significantly higher than externally congested in Mar-Apr (no interconnection disputes)

25

Comcast TimeWarner Verizon Cox 5 10 15 20

Throughput (Mbps) Jan-Feb Self Jan-Feb External Mar-Apr Self Mar-Apr External

w w w . cai da.

• r

Looking at Throughput

• Avg. throughput of self-induced congestion flows

significantly higher than externally congested in Mar-Apr (no interconnection disputes)

25

Comcast TimeWarner Verizon Cox 5 10 15 20

Throughput (Mbps) Jan-Feb Self Jan-Feb External Mar-Apr Self Mar-Apr External

“Self” get higher throughput than “external”

w w w . cai da.

• r

Takeaways

• It is possible to distinguish two kinds of congestion: self-

induced vs. externally congested

• The difference is important to identify the solution
• Upgrade service plan? Or talk to ISP?
• Also for regulatory purposes
• Simple, accurate technique using RTT during TCP slow

start dynamics

• Can be easily computed using packet captures or other tools such as

Web100 (future work)

26

w w w . cai da.

• r

Limitations

• Relies on buffering effect
• May not work on TCP variants that minimize buffer occupancy, e.g., BBR
• Only uses slow start dynamics
• Might be confounded by flows that perform one way during slow start

but differently afterward

• Real-world validation relies on coarsely labeled data
• It would be great to validate on more real-world data!

27

w w w . cai da.

• r

Thanks! Questions?

28
