Taxonomies of Collaborative Applications

Prasun Dewan

Department of Computer Science University of North Carolina CB 3175 Sitterson Hall Chapel Hill, NC 27599-3175 dewan@cs.unc.edu http:/www.cs.unc.edu/~dewan

Dewan 290-F99 2

• 7. Application Taxonomies
• Ellis’s Time Space
• Ellis’s Common Task/Shared Environment
• VR Taxonomy
• Malone’s Taxonomy

Dewan 290-F99 3

Ellis’s Time Space Taxonomy

Email File System Bulletin Board Augmented Reality Same Time Same Space Different Space Grove MUD Tivoli Ventura Different Time

Dewan 290-F99 4

RTCAL Vs Electronic Class Room

Proposal: 10am Vote: No Public Appts Public Appts Topic, Participants Chair, Controller

Dewan 290-F99 5

Ellis’s Shared Environment / Common Task Dimension

Electronic Classroom Time Sharing Environment Software Review System Mail Common Task Shared Environment

Dewan 290-F99 6

IBIS Vs Talk Vs Shared File

*I: Which processor should be used ?P: Processor A AS: Fast *P: Processor B AS: Cheap, already in use

* +

Dewan 290-F99 7

Smith’s Dimensions

• Information Type

– intangible private, ephemeral, tangible instrumental, tangible target

• Collaboration Time

– seconds, minutes, hours, days, weeks, months, years

• Space:

– office, floor, site, 1-hour travel, 1-day travel

• Agents

– people, informal coalitions, teams, team collections

Dewan 290-F99 8

IBIS Vs Email

Processor 2/24/99 Which one? (John Smith, responses) 2/25/99 Processor A (Mary Lowe, 1 response) 2/26/96 Processor B (Joe Doe) Meeting Time 2/24/96 10am? (Mary Lowe, 1 response) *I: Which processor should be used ?P: Processor A AS: Fast *P: Processor B AS: Cheap, already in use

Dewan 290-F99 9

Malone’s Coordination Taxonomy

Coordination Goal Goal Decomposition Task Assignment Recursive Allocation Synchronization Sequencing 1 Facilitates Coordinator Information Lens RTCAL Group Decision Making Proposing Alternatives Evaluating Alternatives 2 IBIS, PREP, Quilt Communication Transporting Messages Routing 3 email, ActionWorkflow Perception of Common Objects 4 Grove, CES, RTCAL

Dewan 290-F99 10

Hydra vs MAJIC MUDS Vs DIVE

User 2 User 3

John has entered the room (hear footsteps) John says, “Hi everyone”

Dewan 290-F99 11

Benford’s VE Taxonomy

Degree of Artificiality Degree of Transportation

• Augmented

Reality

• Physical

Meeting

• Telepresence
• Immersive

CVEs

• Hydra
• Video

Walls

• Video

Conference

• Shared

Application & Video Conf.

• MAGIC
• Projected

CVEs

• Desktop

CVEs

Dewan 290-F99 12

Concurrency Control

• RTCAL
• Grove
• CES
• GroupDraw
• Floor Control
• No Control
• Tickle Locks
• Optimistic

Locks

Dewan 290-F99 13

Flexible Model of Collaboration

Application Window Version 1 User 1 User 2 Coupling Window Version 1 Session Management User Merging Undo/Redo Awareness CC/AC

Dewan 290-F99 14

Design Dimensions

• Session Management
• Coupling
• Concurrency Control
• Access Control
• Undo/Redo
• Merging
• Awareness

Dewan 290-F99 15

Session Management

User 2 User 3

message from dewan, type talk dewan to join John has entered the room (hear footsteps) John says, “Hi everyone” talk jbs Faculty Meeting 290 Lecture Distinguished Lecture

Dewan 290-F99 16

Session 1 App1 App2

Session Management Operations

User 1 Join/Leave (User 2) User 2 Create/ Delete (Session 1) Add/Delete (App3) App3 Issue: How are these

• perations invoked?

Dewan 290-F99 17

Session Management

• Telephone
• Talk
• Menu System
• MUDs
• DIVE
• Invitation
• Invitation
• Name-based
• Room-based
• Aura-based

Dewan 290-F99 18

Joining in Explicit Sessions

App2 App3 User 1 User 2 Session 1 Join User 2 App1 App2 App3 User 1 User 2 Session 1 User 2 Invite Accept Name-based Joining Invitation-based Joining Rendezvous GroupKit RTCAL XTV Joining N App. Easy & General Applications Flexible Joining Auto Notification Creator Controlled App1

Dewan 290-F99 19

Implicit Sessions

• Artifacts being edited
• Location in rooms
• Intersection of auras in virtual

environment

Session Joining/Leaving Side Effect of:

Dewan 290-F99 20

Design of Collaboration Functions

• Session Management
• Coupling
• Concurrency Control
• Access Control
• Undo/Redo
• Merging
• Awareness

Dewan 290-F99 21

Awareness Examples

Outline Title

• 1. Readable and writeable item

1.1 Also readable and writeable *.Shared readable and writeable * .* Shared readable

Editing paper xxxx yyyyy

Dewan 290-F99 22

Awareness

App. I/O I/O Version 1 Version 2 Coupling Awareness Others Awareness

• f Others

Physical/Computer Environment Physical/Computer Environment User 1 User 2

Dewan 290-F99 23

Awareness Purpose

Location Current Tasks Potential for Interruptibility Presence of Coworkers Context for Smalltalk Curiosity

Dewan 290-F99 24

Awareness Dimensions

Shared? Degree? When? History? User 1 User 2

Dewan 290-F99 25

Subject Application Object Intermezzo Potholes CAVECAT, Cruiser GroupDraw, XTV Intermezzo Contact Grove, GroupDesign GroupDesign PREP, Active Diff

Shareable Information: Edward’s Model

Login, Name, Home, Shell, Office, Phone, Plan, Voice, Photo Physical Location, Appearance, Gestures, Speech Virtual Location Virtual Gestures Application, Start & Idle Time, Process and Display Host Identification, Type, Value, Attributes, Lock Status Command Location Size Diff

Dewan 290-F99 26

Awareness Degrees

Subject General Location < Specific Location Pseudo Name < Real Name < Photo, Voice Audio Volume Levels Application Editor < Emacs Object A command was invoked on a nearby object The edit command was invoked on a nearby object The edit command was invoked on this object (The new remote value of this object is ‘the brown fox’) The new remote value of this object is ‘the brown fox’ The remote value replaces the ‘dog’ in the local value with ‘fox’ Macro Chris is at (0,0) Chris is interacting with Emacs Chris is editing this paragraph Nearness Event Peripheral Full Diff Subject Application Object GroupDesign MASSIVE MASSIVE MASSIVE PREP MASSIVE

Dewan 290-F99 27

Coarseness of Pinpointing

Section Paragraph Sentence Word Section Paragraph Sentence Word Diff Diff Her bowl is over there, by the truck Her bowl is over there, by the car Sentence- Level Diffing car truck Word-Level Diffing

Dewan 290-F99 28

Additional Differencing Parameters

% Differences Inserted Length

• Max. % Differences

Distance to Look

• Dist. to Concatenate
• DIFF. PARAMETERS

Precent Differences < Max. Percent Differences Inserted Length < Max. Distance to Look for Commonalities Recursion Criteria The quick brown fox jumps over the lazy cat The slow brown dog jumps over the lazy cat quick brown fox slow brown dog quick, fox slow, dog Word-level Diffing

• DIFF. PARAMETERS

Dewan 290-F99 29

When Awareness Event Shared

Instantly Periodic Explicitly Retrieved Audio Video Diff Snapshots Diff Plan CAVECAT Active Diff Portholes PREP Finger

Dewan 290-F99 30

History of Events Shown

Current Value Since Last Access Since Conference Start GroupDesk REPLAYABLE WYSNIWIST

Dewan 290-F99 31

Design of Collaboration Functions

• Session Management
• Coupling
• Concurrency Control
• Access Control
• Undo/Redo
• Merging
• Awareness

Dewan 290-F99 32

Coupling Examples

File save load Mail send receive Sync Talk h hel h hel Async Talk hi hello hi hello

Dewan 290-F99 33

RTCAL Vs GroupKit

Public Appts Private Appts Public Appts Public Appts Public Appts

Dewan 290-F99 34

Coupling Design Space

Sync Talk ASync Talk Mail File GroupDraw

Dewan 290-F99 35

Sync Vs Async Talk

My Text Your Text My Text Your Text

Dewan 290-F99 36

Flexible Coupling

My Text Your Text My Text Your Text communicateOn: {Keystroke, Return}

Dewan 290-F99 37

Fine-grained Coupling

My Text Your Text My Text Your Text

Dewan 290-F99 38

Distributed Control

My Text Your Text My Text Your Text

Dewan 290-F99 39

Produced Exported

Coupling Principle

Imported Shared Max(T1, T2) (T1) (T2) (T0)

Dewan 290-F99 40

Distributed Control

My Text Your Text My Text Your Text Keystroke < Return communicateOn = Max (TransmitOn, ListenOn)

Dewan 290-F99 41

Shared Text

Text Text Asymmetric Control communicateOn : {Keystroke, Return, Delete) Keystroke < Return, Delete

Dewan 290-F99 42

File-based Coupling

Text Text File Commit Load communicateOn: {…, Committed}

Dewan 290-F99 43

Correctness-based Coupling

int num, num1 = 0 Text File Unparsed

Dewan 290-F99 44

Correctness-based Coupling

int num; num1 = 0 Text File Parsed

Dewan 290-F99 45

Correctness-based Coupling

int num1; num1 = 0 Text File Validated

Dewan 290-F99 46

Correctness-based Coupling

int num1; num1 = 0 Text File communicateOn: {Raw, Parsed, Validated, Committed} Commit Raw < Parsed < Validated < Committed

Dewan 290-F99 47

Time-based Coupling

int num1; num1 = 0 Text File communicateOn: {Period, Time) Commit

Dewan 290-F99 48

Mail-based Coupling

Text Text File Commit Load communicateOn: {…, Send, Receive)

Dewan 290-F99 49

Mail-based Coupling

Text Text File Commit Load transmitOn: {..., Commit, Send) Buffer listenOn: {..., Commit, Receive)

Dewan 290-F99 50

Sharing Objects

Version Version Base Commit Load transmitOn: {…, Increment, Completion) Buffer Completion= Return || Mouserelease Increment = Keystroke || Mousedrag

Dewan 290-F99 51

Suite Communication Model

Version Version Base Buffer

TTime LTime TPeriod LPeriod TOn TCorrectness LOn LCorrectness

Op Cur. Correctness Value Transmitted if: (Op, CurCorr) >= (TOp, TCorr) (LOp, LCorr) Value Received When Min (LPeriod, LTime) Receive Executed

Inc < Complete < Send Raw < Parsed < Valid< Comm

LPeriod, LTime: {T, ListenNow}

Dewan 290-F99 52

Coupling Objects Vs Versions

X = 6 X = 5 X = 5 X = 5 Y = 25

Dewan 290-F99 53

Coupling Objects Vs Versions

Hello world hello World hello world Hello John Hello John Goodbye John My Out Message /Input Line John’s Inbox/ Chat History

Dewan 290-F99 54

RTCAL Vs GroupKit

Public Appts Private Appts Public Appts Public Appts Public Appts

Dewan 290-F99 55

Suite Sharing Model

Version Version Base Buffer

Value TOp Font Cursor Widget Color RW Scrollbar

Dewan 290-F99 56

Suite Sharing Model

Version Version

Value Value Font Color Font Color TOp TCorr TOp TCorr ValueC ValueC FormatC ValueC FormatC FormatC CommC CoupleC

Dewan 290-F99 57

Coupling Policies

Semantics ValueC = T Syntax FormatC = T View ViewC = T Implicit TOn < Send Explicit TOn = Send Synchronous TOn, LOn = Inc ASynchronous TOn > Inc WYSIWIS *C = T Ton, Lon = Inc Serializable TCorr = Committed

Dewan 290-F99 58

Design of Collaboration Functions

• Session Management
• Coupling
• Concurrency Control
• Access Control
• Undo/Redo
• Merging
• Awareness

Dewan 290-F99 59

Concurrency Control Examples

• RTCAL
• Grove
• CES
• GroupDraw
• Sync
• Floor Control
• No Control
• Tickle Locks
• Optimistic,

Selection- based Locks

• Optimistic

Transactions

Dewan 290-F99 60

Concurrency Control Goals

• Consistency
• Concurrency
• Performance

Dewan 290-F99 61

Concurrency Control Dimensions

• Free Vs Controlled
• Correctness Criterion
• User-Transaction Mapping
• Sharing and Inconsistency Detection Time

– Lock Granularity – Locking/Unlocking Actions

Dewan 290-F99 62

Free Vs Controlled

• WYSIWIS Vs WYSINWIS Coupling
• Small Vs Large Teams
• Efficiency

Dewan 290-F99 63

Concurrency Control Correctness

T1

• 11
• 12

T2 T3

• 21
• 22
• 31
• 32

Actual Schedule

• 31 o21 o11o22 o12 o32

T3 T2 T1 Serial Schedule =

Dewan 290-F99 64

Concurrent Drawing

Dewan 290-F99 65

Concurrent Drawing

Dewan 290-F99 66

Concurrent Drawing

Dewan 290-F99 67

Non-Serializable: Reject

T1 R(Drawing) W (Drawing) T2 R (Drawing) W (Drawing)

Dewan 290-F99 68

Finer-Granularity: Serializable

T1 R(Line) W (Line) T2 R (Rectangle) W (Rectangle)

Dewan 290-F99 69

Non- Serializable: Accept

T1 R(Drawing) W (Line) T2 R (Drawing) W (Rectangle)

Dewan 290-F99 70

Concurrent Drawing

Dewan 290-F99 71

Concurrent Drawing

Dewan 290-F99 72

Concurrent Drawing

Dewan 290-F99 73

Type-Specific: Reject

T1 R(Line) Rotate (Line) T2 R (Line) Color (Line)

Dewan 290-F99 74

Type-Specific: Serializable

T1 R(Line.Bounds) Rotate (Line) T2 R (Line.Color) Color (Line)

Dewan 290-F99 75

Concurrent Drawing

Dewan 290-F99 76

Concurrent Drawing

Dewan 290-F99 77

Concurrent Drawing

Dewan 290-F99 78

Concurrent Drawing

Dewan 290-F99 79

Schedule

T1 R(Drawing) W (Line) T2 R (Drawing) W (Rectangle) R(Drawing) W (Line)

Dewan 290-F99 80

Splitting Transaction

T1 R(Drawing) W (Line) T2 R (Drawing) W (Rectangle) R(Drawing) W (Line) T3

Dewan 290-F99 81

Joining Transactions

U1 R(Drawing) W (Line) U2 R (Drawing) W (Rectangle) R(Drawing) W (Line)

Dewan 290-F99 82

Nested Long Transactions

Program Module L, M Module N, O Module L Module M Proc P Proc Q Team A Team B rogrammers Testers A B

Dewan 290-F99 83

Implicit Transaction Operations

Select Object => Begin Transaction Unselect Object => End Transaction Start Dragging => Begin Transaction Stop Dragging => End Transaction Stop Dragging => Begin Transaction Move Object End Transaction

Dewan 290-F99 84

Implicit Transaction Operations

Press Key => Begin Transaction Release Key => End Transaction Insert Char => Begin Transaction Return, Delete Char, Timeout => End Transaction Sync Couple => Join Transaction Async Couple => Split Transaction

Dewan 290-F99 85

Design of Collaboration Functions

• Session Management
• Coupling
• Concurrency Control
• Access Control
• Undo/Redo
• Merging
• Awareness

Collaborative Application

Application Window Window User 1 User 2

Access Control

Application Window Window User 1 User 2

Meta Access Control

Application Window Window User 1 User 2 Authorizer Meta Authorizer

Access Control Prevents

Alice’s Exam Alice Bob’s Exam Bob

Couple

Security Violations

Listener 1 Turing Lecture Session

Doug Engelbart

Create Join

Listener 1000

Join

Overuse of Scarce Resources

Bob’s Proposal

Read Write

Mistakes Alice

Dewan 290-F99 90

Access Control Principles

• Total Mediation
• No Secret Design
• Least Privilege (Need to Know)
• Ease of Use

Traditional Protected Objects

matmult.java Matrix matmult.java Graphics Button.java R W X R W I D M

Traditional Access Control

matmult.java Matrix matmult.java Graphics Button.java R W X R W I D M

Collaborative Systems

matmult.java Matrix matmult.java Graphics Button.java R W X R W I D M matmult.java public int i; void f() { public int i; void f() { void g() { int i, // tricky void g() make private! Data Rights Coupling Rights Buffer Rights Numerous Rights! UI Rights!

Dewan 290-F99 94

• Colab. Objects & Rights

Session JoinSessionR ReadSessionR ModifySessionR RemoveParticipantR DeleteSessionR Window CursorR ScrollR ResizeR MoveR No Leave SessionR Apply to Coupled windows

Dewan 290-F99 95

Model/View Rights

Semantic Object UpdateR WriteR InsertR DeleteR ReadR Interaction Object HideR ElideR SelectR TitleR FontR ColorR IndentR ValueCR ViewCR FmtCR TIncR TRawR LIncR Data Rights Coupling Rights View Rights

Dewan 290-F99 96

Optimistic Access Control

Semantic Object

• UpdateR

+WriteR +InsertR +DeleteR +ReadR Interaction Object

Dewan 290-F99 97

Pessimistic Access Control

Semantic Object

• UpdateR

Interaction Object

• WriteR
• InsertR
• DeleteR
• ReadR

Dewan 290-F99 98

Traditional Access Matrix

Objects

Subjects rights

Dewan 290-F99 99

Extended Access Matrix

Objects + groups

Subjects + groups rights + groups

Suite Access Control

AnAnnotation +CoupleR Annotator +ScrollCoupleR +DataCoupleR Bob Alice Alice’s Annotation Bob’s Annotation Bob Alice Access List Entry

Suite Access Control: Implications

UpdateR WriteR InsertR DeleteR ReadR

Dewan 290-F99 102

User Groups as Protected Objects

Role TakeR LeaveR DeleteR

Suite Access Control: Implications

+TransmitIncrementR +TransmitCompleteR +TransmitPeriodicR +TransmitExplicitR +ModifySessionR +CreateSessionR +ReadSessionR

Roles, Right Inheritance, Implications, User- defined rules

Suite Meta-Access Control: First- Class Access Control Objects

Protected Object User Authorizer Access Control Roles, Right Inheritance, Implications Rights Meta Rights Meta Control

Roles, Right Inheritance, Implications, User- defined rules

Suite Meta-Access Control: First- Class Access Control Objects

Protected Object User Authorizer Access Control Roles, Right Inheritance, Implications Rights Meta Rights Meta Control Bootstrapping!

Build Access-Control Class

Protected Object User AC

Instantiate Class Again

Protected Object User* User AC AC*

Must Instantiate Again

Protected Object User* User AC AC* User** AC**

Infinite Recursion

Protected Object User* User AC AC* User** AC** User*** AC***

Roles, Right Inheritance, Implications, User- defined rules

Stopping Recursion

Protected Object User Access Control Roles, Right Inheritance, Implications

Roles, Right Inheritance, Implications, User- defined rules

Existing Meta Control

Protected Object User Access Control Roles, Right Inheritance, Implications

• wner

central authorizer

Flexible Authorizer Assignment

public int i; void f() { public int i; void f() { No Authorizer

Flexible Authorizer Assignment

public int i; void f() { public int i; void f() { moderator Central Authorizer

Flexible Authorizer Assignment

public int i; void f() { public int i; void f() { Single Owner Alice

Flexible Authorizer Assignment

public int i; void f() { public int i; void f() { Multiple Owners Alice Bob

Partial Authorization

public int i; void f() { public int i; void f() { Alice Bob Professor

Partial Authorization

public int i; void f() { public int i; void f() { Alice Bob Professor Leader

Delegation

Professor TA 1 Exam +CoupleR Students Delegate TA 2 Delegate

Shallow Revocation

Professor TA 1 Exam +CoupleR Students TA 2 Delegate

Deep Revocation

Professor TA 1 Students TA 2

Proportional Overhead

Programming Contest Brainstorming Military Programming

Incremental Migration Path

Programming Contest Brainstorming Military Programming

Economy of Concepts

Protected Objects Meta Control Access Control

Fine-Grained Meta Rights => Partial Authorization

+CoupleR +CoupleR* +DataR +DataR* +SessionR +SessionR*

Automatically-Generated Include and Imply Relationships => Proportional Overhead, Economy

+ModifySessionR +CreateSessionR +SessionR +ModifySessionR* +CreateSessionR* +SessionR*

Authorizer Problem: Owner

+CoupleR* public int i; void f() { Bob (Object Creator) Alice (Application Starter) +ScrollR +ScrollR* +CoupleR

Authorizer Problem => Ownership

Bob (Object Creator) public int i; void f() { Alice (Application Starter)

Owner Lists => Joint Ownership

Bob (Object Creator) Alice Bob +OlistR +OlistR* public int i; void f() { Alice (Application Starter)

Default Ownership Semantics

+OwnerR +OListR, OListR*, AllR, AllR* Alice Bob +OwnerR +OwnerR Default Ownership public int i; void f() { OL ~ ACL

Flexible Ownership Semantics => Flexible Authorizer Assgnmt

No authorizer +OwnerR Class Object All AllR* ACL

Flexible Ownership Semantics => Flexible Authorizer Assgnmt

Class Object Administrator Central authorizer AllR* +OwnerR ACL

Total & Partial Delegation => Proportional Cost & Economy

Alice Alice Bob Exam +CoupleR Students Total

Total & Partial Delegation => Proportional Cost & Economy

Alice Alice Bob Alice Bob Exam +CoupleR Students Exam +CoupleR* Exam +CoupleR Students Total Partial

Shallow Revocation

Alice Alice Alice Bob Exam +CoupleR Students Exam +CoupleR Students Total Partial

Shallow Revocation

Alice Alice Alice Bob Exam +CoupleR Students Exam

• CoupleR*

Exam +CoupleR Students Total Partial

Delegation for Flexible Revocation

Alice Grantee Exam

• CoupleR

Faculty Student Grantee +AddMemberR Bob Grantee +AddMemberR*

Delegation for Flexible Revocation

Alice Grantee Exam

• CoupleR

Grantee +AddMemberR Bob Grantee +AddMemberR*

Delegation for Flexible Revocation

Alice Grantee Exam

• CoupleR

Faculty Student Grantee +AddMemberR Bob Grantee +AddMemberR*

Delegation for Flexible Revocation

Alice Grantee Exam +CoupleR Faculty Student Grantee

• AddMemberR

Bob Grantee

• AddMemberR*

Delegation for Flexible Revocation

Alice Grantee Exam +CoupleR Student Grantee

• AddMemberR

Bob Grantee

• AddMemberR*

Partial Undo

Delegation for Flexible Revocation

Alice Grantee Exam

• CoupleR

Grantee

• AddMemberR

Bob Grantee

• AddMemberR*

Total Revocation

Dewan 290-F99 142

Example Policies

Drawing +AllR All

Free for All

Outline +InsertR All

Grove

+OwnerR +DataR,+DataR*

Dewan 290-F99 143

Examples (Contd.)

User A Buffer +ReadR User B

2-Way Talk

+AllR User A User B Buffer +ReadR User A +AllR User B User N’s Buffer

N-Way Chat

+AllR User N Transcript +ReadR All

Dewan 290-F99 144

Examples (Contd.)

Program Name +WriteR Chairman

Software Inspection Tool

+AllR All Program +ReadR All +FormatR, FormatR* Formatter

Dewan 290-F99 145

Examples (Contd.)

Class Object

Programming Contest: Exam Phase

+ReadR, +AllR* Proctor Program1 +DataR Team1 Team1 +CouplingR (Team1, Proctor) +OwnerR +DataR,+DataR

Dewan 290-F99 146

Examples (Contd.)

Class Object

Programming Contest: Review Phase

+ReadR, +AllR* Proctor Program1 +DataR Team1 Team1 +CouplingR (Team1, Proctor) +OwnerR +CouplingR (All), +InsertR, +ReadR All +AllR, +AllR* +DataR,+DataR

Dewan 290-F99 147

Dynamic Role Assignment

I don’t mind sharing my workspace with others during demo day def predicate (subject me context) if date.today() == DEMO-DAY if me.location === “GVU Lab” if me.Activities.member(“Montage”) if subject.location == “GVU Lab” return true

Experience with Meta Control Specifications

• Grove
• Unix
• AFS
• Mail, Talk
• Collaborative Inspection Tool
• Programming Contest Tool (Competition

and Inspection Phases)

1-27 Access Specifications 6 ms Overhead

Experience (contd)

• Graphical Tool for Displaying

Inheritance and Implications

• Use 1-Dimensional Inheritance at

a Time

Summary of Access Control

• Flexible Authorizer

Assignment

• Partial Authorization
• Flexible Delegation &

Revocation

• Proportional

Overhead

• Economy of

Abstractions

• User-Defined Ownership

Semantics

• Fine-Grained Meta Rights
• Indirect Roles
• Inheritance, Implications
• Meta Rights, Owner Lists,

Owner Right

Dewan 290-F99 151

Undo/Redo: Motivation

• Recover from Self

Errors in 1-User Commands

• Explore Self

Alternatives

• Be more Daring
• Others’ Errors
• System Errors (Conc Inp)
• Colab Commands

– Coupling, Access, …

• Explore Group

Alternatives

• Dare to modify shared

information

Dewan 290-F99 152

Requirements

• Easy to Use
• Efficient
• Consistency
• Undo Hard to reverse

Action

• Matched to Do
• Undo Undo
• Undo Computation
• Undo remote displays
• Undo of remote

commands

• Undo collaboration

commands

• Compatibility with

single-user models

Dewan 290-F99 153

Multiuser UndoVs Database Abort

• Consistency

– Cascaded Abort – I/O not Undoable

• System Triggers

Generally

• Initiating User Can

Undo

• All Pending Actions

Undone

• Consistency

– Undoing Remote displays

• User Triggers

Generally

• Any User Can Undo
• Specific Pending or

Committed Actions Undone

Dewan 290-F99 154

US&R Model

C1 C2 C3 C1 C2 C3 Undo C1 C2 C3 C1 C2 C3 Undo Redo C1 C2 C3 C1 C2 C4 C3 C4 C1 C2 C4 C3 C1 C2 C4 C3 Undo Skip Redo C1 C2 C4 C3

Dewan 290-F99 155

History Model

C1 C2 C3 C1 C2 C3 Undo C1 C2 C3 C3’ C1 C2 C3 C3’ C2’ Undo C4 C1 C2 C3 C3’ C2’C4 Undo C1 C2 C3 C3’ C2’C4 C4’ Undo C1 C2 C3 C3’ C2’C4 C4’C2’’

Dewan 290-F99 156

Multi-user Undo Factors

• Single-User Undo
• Coupling
• Access Control
• Broadcast Scheme
• Concurrency Control

Dewan 290-F99 157

Global, Last-Command Undo

A1 B1 A2 A1 B1 A2 A1 B1 A1 B1 A2 Undo A1 B1 A2 A1 B1 A2

Dewan 290-F99 158

Disjoint Manipulation

Insert O1 Insert O2 Insert O1 Insert O2 Undo Insert O1 Insert O2 Insert O3 Insert O1 Insert O2 Insert O3

O1 O2

Insert O3

O3

Insert O1 Insert O2 Insert O3 Insert O1 Insert O2 Insert O3

Dewan 290-F99 159

Concurrent Serialized Interaction

A1 B1 A1 B1 A2 Undo A1 B1 A2 A1 B1 A2 A1 B1 A2 A1 B1 A2 Undo

Dewan 290-F99 160

Concurrent Non-Serialized Interaction

A1 B1 A1 B1 A2 Undo A1 B1 A2 A1 B1 A1 A2 B1 A1 B1 A2 Undo A2 Entire undo history can be locked

Dewan 290-F99 161

Non-WYSIWIS Coupling

A1 B1 A1 B1 A2

Dewan 290-F99 162

Local- Corresponding Undo

A1 B1 A2 A1 B1 A2 A1 B1 A2 B1 A1 B1 A1 A2 Undo B1 A1 A2 Undo

Dewan 290-F99 163

Cooperative Manipulation

Create O Move O Undo Undo Create O Move O O Create O Move O Exception!

Dewan 290-F99 164

Selection-based Undo

A1 B1 A2 A3 Undo(B1) A1 B1 A2 A3 A1 B1 A3 A1 B1 A3

Dewan 290-F99 165

Selection, Corresponding Undo

A1 B1 A2 A3 Undo Undo A1 B1 A2 A3 A1 B1 A3 A1 B1 A3 A1 B1 A3 A1 B1 A2 A3

Dewan 290-F99 166

Undo Filters

Create O1 Create O2 Move O1 Move O2 Create O2 Move O1 Create O1 Move O2 Filter Blue User Filter Red User Commands Executed

Dewan 290-F99 167

Undo Filters

Create O1 Create O2 Move O1 Move O2 Create O2 Move O2 Create O1 Move O1 Filter O1 Filter O2 Commands Executed

Dewan 290-F99 168

Ambiguities in Selection-based Undo

Color Red Color Yellow Color Green Undo (Color Yellow) abc Delete 2, b ac Delete 2, b Insert 2,d adc Delete 2, b Insert 2, d Undo (Delete 2, b

Dewan 290-F99 169

Asynchronous Commands

A1 B1 A2 A3 Transmit (A2, A3) A1 B1 A1 B1 A2 A3 A1 B1 A2 A3

Dewan 290-F99 170

Asynchronous Commands

A1 B1 A2 A3 Transmit (A2, A3) A1 B1 A2 A3 T(A2, A3) A1 B1 A1 B1 T (A2, A3)

Dewan 290-F99 171

Single-User Interaction

Dewan 290-F99 172

Single-User Undo

Dewan 290-F99 173

Multi-User Interaction

Dewan 290-F99 174

Multi-User Undo

Dewan 290-F99 175

Race Condition: Undo Decision

Dewan 290-F99 176

Race Condition: Concurrent Change

Dewan 290-F99 177

Undo by Reference

Dewan 290-F99 178

WYSINWIS Histories

Dewan 290-F99 179

Corresponding Undo

Dewan 290-F99 180

Transmitting Changes

Dewan 290-F99 181

Undoing Transmission

Dewan 290-F99 182

Triggering Computations

Dewan 290-F99 183

Undoing Computation
