TAIHAN FIBEROPTICS at a glance

Top Class Fiber Solution Provider

• Founded in 1955
• Developed Fiber Optic Cable in 1977
• Started production of Optical Fiber via VAD in 1984
• Developed Optical Ground Wire (OPGW) in 1987

TAIHAN FIBEROPTICS

3

TAIHAN FIBEROPTICS at a glance

Advanced Technology and Quality

• All products made in Ansan plant under strict quality management
• Solutions provided include from cables to engineering to FTTH/FTTA
• Developed low loss, bending insensitive, and NZDS fibers

TAIHAN FIBEROPTICS

4

TAIHAN FIBEROPTICS at a glance

Global Supply Experience

• Overseas sales account for over 60% of total sales
• Hundreds of customers in Asia, Middle East, Oceania, and Americas
• Started exporting in 1978 first in Middle East and Asia

TAIHAN FIBEROPTICS

5

TAIHAN Group focuses on serving cable users

TAIHAN FIBEROPTICS is specialized in communication sector

6

HV Cable MV/LV Cable Communication Cable & Accessory Specialty Cable Cu Rod & Magnet wire Engineering & Construction Total 2,078

372 417 162 92 893 142

ㆍOF Insulated Cable ㆍXLPE Insulated Cable ㆍCable Accessory

MAJOR OFFERINGS SALES[2012] MANUFACTURING

USD MIL

ㆍControl & Instrument Cable ㆍElectric Power Cable, Insulated Wire ㆍNucleaar Cable ㆍBusduct ㆍOptical Fiber ㆍFiber Optic Cable ㆍOPGW ㆍFTTH Equipment and Accessory ㆍCommunications Copper Cable ㆍTrolley Wire ㆍFA Cable ㆍHeating Cable ㆍEtc. ㆍCu Rod ㆍMagnet Wire ㆍCable System Design & Consulting ㆍInstallation & Maintenance *total sales of 6 cable and wire related affiliates

TAIHAN Group provides total cable solution

7

History – first three decades

1955

Founded TAIHAN Electric Wire. Co. , Ltd.

1961

Produced lead sheathed comm. cable first in Kore a

1966

Produced ACSR first in Korea

1968

Listed on Korea Stock Exchange

1977

Developed optic fiber cable

1978

Exported $50mm comm cable to Saudi Ariabia

1984

Produced MM & SM optical fiber (G.652)

1955 1961 1966 1977 1984 TAIHAN FIBEROPTICS

8

History – recent three decades

1987

Developed OPGW

1988

Developed submarine fiber

• ptic cable

1999

Established SKYTEL, wireless telco in Mongoli a

1997

Developed ribbon‐type fiber optic cable

2001

ISO 14001 certified

2010

Developed NZDSF G.655

2012

Established TAIHAN Fiberoptics

2013

Developed ultra low loss fiber & G.656

1987 1997 1999 2012 2013 TAIHAN FIBEROPTICS

9

TAIHAN OSP solution

Our offerings meet customers’ demand on every end

• Application: Indoor, outdoor, long span, short span, undersea, aerial,

underground, wireless towers

• User: telecom, Power utility, contractor, CATV, Cable/equipment maker

TAIHAN FIBEROPTICS

10

Vertically integrated product line‐up

We manufacture from glass to cables to accessories

• produce glass core, preform, and fiber from scratch
• capable of manufacturing all kinds of fiber optic cables
• supply cable accessories and FTTH solutions

Optical Fiber

SSLT SMF ZWPF BIF NZF AW‐ Fine Submarine Cable OPGW Ribbon Loose Tube Cable Indoor/Drop Cable Loose Tube Cable

Cables & OPGW Preform Hybrid /Accessory

Hybrid Cable Patch Cord Optical Termination Type Optical Distribution Frame Fiber optic Termination Box

TAIHAN FIBEROPTICS

11

Optical fiber

Types: Single‐mode/Multi‐mode Categories: Zero Water Peak fibers (G.652) Non‐Zero Dispersion Shifted (G.655) Bending Loss Insensitive (G.657) Ribbon type Ultra Low Loss (<0.18dB@1550nm) Next generation (G.656)

Premise Access Metro Backbone <5km 5‐30km 10‐50km 50‐300km

Single Mode Fiber Zero Water Peak Fiber Bending Loss Insensitive Fiber Non‐Zero Dispersion Shifted Fiber Ultra Low Loss Fiber TAIHAN FIBEROPTICS

12

Fiber comparison

Zero Water Peak Fiber

(G.652.D) Items Unit Taihan Anywave

Fujikura FutureGuide

Corning SMF‐28e OFS AllWave Attenuation at 1310 nm

dB/km

≤ 0.334 0.327 ≤ 0.35 0.33 ~ 0.35 ≤ 0.34 Attenuation at 1383 nm

dB/km

≤ 0.31 0.281 ≤ 0.31 0.31 ~ 0.35 ≤ 0.31 Attenuation at 1550 nm

dB/km

≤ 0.194 0.187 ≤ 0.21 0.19 ~ 0.20 ≤ 0.21 Attenuation at 1625 nm

dB/km

≤ 0.22 0.202 ≤ 0.23 0.20 ~ 0.23 ≤ 0.24 MFD at 1310 nm

µm

9.2 ± 0.4 9.15 9.2 ± 0.4 9.2 ± 0.4 9.2 ± 0.4 MFD at 1550 nm

µm

10.4 ± 0.5 10.3 10.4 ± 0.8 10.4 ± 0.5 10.4 ± 0.5 Dispersion value at 1550 nm

ps/nm.km

≤ 18.0 16.67 ≤ 18 ≤ 18.0 ≤ 18.0 Zero dispersion slope

ps/(nm2.km)

≤ 0.090 0.086 ≤ 0.092 ≤ 0.089 ≤ 0.090 PMD link design value

ps/√km

< 0.1 0.05 ≤ 0.08 ≤ 0.06 < 0.06 PMD individual value

ps/√km

< 0.15 0.03 ≤ 0.1 ≤ 0.2 < 0.1 Cladding diameter

µm

125 ± 0.7 125.1 125 ± 0.7 125 ± 0.7 125 ± 0.7 Core‐clad concentricity

µm

≤ 0.5 0.11 ≤ 0.8 ≤ 0.5 ≤ 0.5 Cladding non‐circularity

%

≤ 0.7 0.22 ≤ 1.0 ≤ 0.7 ≤ 1 Coating‐cladding concentricity

µm

≤ 12 4.02 ≤ 12.5 ≤ 12 ≤ 12 Tensile proof test

kpsi

≥ 120 125 ≥ 120 ≥ 100 ≥ 100

Our specification is compatible with standard SMF

TAIHAN FIBEROPTICS

13

Fiber optic cables

Duct type

• Fiber count : up to 312 fibers
• Application : Long haul, Metro, Access
• Anti‐termite/rodent

Direct‐ buried type

• Fiber count : up to 312 fibers
• Application : Long haul, Metro, Access
• Steel tape/wire, Anti‐termite/rodent

Aerial type

• Fiber count : up to 312 fibers
• Application : Long haul, Metro, Access
• Galvanized steel suspension wire

Micro type

• Fiber count : up to 60 fibers
• Application : Long haul, Metro, Access
• Light weight with smaller diameter

Outdoor

14

Fiber optic cables

Drop type

• Application: Fiber‐To‐The‐Premises
• Compact design for limited space
• Pre‐connected

ADSS Short span

• Power line operation system
• Single or double jacket
• Long haul communication

ADSS Long span

• Power line operation system
• Double jacket
• Long haul communication

Indoor ADSS (All Di‐electric Self Supported) for transmission line

15

FOC global supply record – last 5 years

Customer Description Amount Period

Saudi Telecom Company (Saudi Arabia) Backbone network $8mm 2008 ~ (On going) MOC(MIN. OF COMMUNICATION)

FTTH project

$6mm 2006 ~ 2008 SINGTEL(SINGAPOLE TELECOM) Blanket order $3mm 2005 ~ 2007 SIEMENS, EGYPT Great Cairo backbone project $1mm 2001 ~ 2003 Sky networks (Mongolia) Backbone network Project $1mm 2009 ~ (On going) Florida Power & Light (USA) Backbone network Project $0.4mm 2012 COLOMBIA TELECOMUNICACIONES TELEFONICA – TELECOM ‐ INTER Cable TV network $3.4mm 2009 ~ 2010

TAIHAN FIBEROPTICS

16

OPGW – Optical ground wire

Variety of choices depending on operating conditions

• Stainless Steel Loose Tube (SSLT) type
• Non‐Metallic Loose Tube type
• Central SSLT type
• Aluminum covered SSLT type

ACS SUS Tube AL alloy (AA)

Standard: ITU‐T G650, 651, 652, 655, IEEE1138, IEC60793/IEC60794, Korean Standard Tested and proven by Kinetrics (Stress strain, strain margin, short‐circuit, galloping, lightning arc)

Taihan’s representative SSLT OPGW construction

TAIHAN FIBEROPTICS

17

OPGW

SSLT

• Stainless steel loose tube
• The core of OPGW acting as a telecom fiber unit
• Protect transmission line, supporting communication

SSLT stranding

• High tensile strength/Long span capability
• Up to 288 fibers

Non‐ metallic

• Flexibility
• Easy break out

SS/AL tube

• Excellent crush resistance and low resistivity
• Up to 48 fibers

For transmission line protection and communication

18

OPGW – Recent experience

Application Year User / Location  OPGW 48 Core Aluminium tube type under The PORTLAND‐SKALA‐CANON CITY 115kV TRANSMISSION LINE Project  Short circuit current capacity : 37kA2.sec (Initial temperature : 25'C~Maximum temperature : 210'C)  Ultimate tensile strength : 15,919 lbs 2013~ Black Hills Energy, S. Dakota  Composite fiber of 6 Core G655C and 18Core G652D OPGW SSLT Type  Short circuit current capacity : 190kA2.sec (Initial temperature : 20'C~Maximum temperature : 180'C)  Ultimate tensile strength : 18,000 lbs 2008~2012 Northeast Utility, Connecticut  OPGW 24 Core Almunium tube type under The PNM TO DULCE INTERCONNECT Project  Short circuit current capacity : 70kA2.sec  Ultimate tensile strength : 19,841 KGS 2013 Western United Electric Supply, Colorado  OPGW 48 Core and 96 Core SSLT TYPE  Short circuit current capacity : 61kA2.sec (Initial temperature : 20'C~Maximum temperature : 210'C)  Ultimate tensile strength : 15,034 lbs 2012~2013 Tucson Electric Power, Arizona  OPGW with Composite fiber of OPGW 16 Core G652D and 8 Core G655B to Moinak Electricity Transmission Project in Kazakhstan 2011 KEPCO, Kazakhstan  Supply of OPGW 96 Core SSLT Type under TOP ENERGY Project  Short circuit current capacity : 106kA2.sec (Initial temperature : 40'C~Maximum temperature : 200'C)  Ultimate tensile strength : 65.8kN 2013 Top Energy, New Zealand  OPGW 12core SSLT 2012 Peng Kabel GmbH, Austria  OPGW under T001412 PPC 40813 LGAGADAS Project INTRAKAT, Greece  OPGW 8 core and fittings Hyosung Corporation, Albania  OPGW 24 Core with NZ fiber and hardware under SARIR‐AJDABIA 400Kv OHTL Project Hyundai Engineering & Const, Lybia  OPGW 24 Core SSLT type Liccsa, Argentina  OPGW 48 Core under PLANTA FOTOVOLTAICA DESANPEDRO Project Elecnor, Chile  OPGW 24 Core Non‐metallic type with Optical cable and Hardwares under MASTER COMMUNICATION PLAN IN WESTERN REGION PACKAGE‐1 2013 KEC International Ltd, India

TAIHAN FIBEROPTICS

19

OPGW – Recent experience

User Application Amount Year

Energia de Bogota (Guatemala) 230kV TL for Guatemala Project $2.6mm 2011~ (On going) Abencor USA (USA) Mojave Solar Plant Project $0.05mm 2012 Myanmar Electric Power Enterprise (Myanmar) THAHTAY CHAUNG HYDRO POWER Project $1.4mm 2012 Saudi Electric Company (Saudi Arabia) Saudi TL project $2.00mm 2012 ~ (On going) Powergrid Corporation of India Ltd (India) Western Region‐01 Project $5.8mm 2012 ~ (On going) TOP ENERGY (New zealand) New zealand TL Project $0.2mm 2013 ~ (On going) General Electricity Company of Libya (Libya) LT‐402 (Sarir‐Ajdabia 400kV OHTL Project) $1.7mm 2013

TAIHAN FIBEROPTICS

20

Hybrid cables and accessories

Hybrid cable

• Fiber + Power composite
• Comes with FTTA (Fiber to the Antenna) solution
• Application: CCTV and wireless towers/antennas

Patch cord

• Convenient handling
• Adaptable to various connectors

Termination

• Diverse acceptability
• Low optical connection loss
• Deliverable length up to 1,500m

ODF

• 19” rack
• Adaptable to various types of fiber cables

Termination box

• Strong durability and easy handling
• Excellent connector protection and storage

21

Manufacturing facilities

Centralized manufacturing plant

• Located in Ansan Industrial Park, Korea
• Highly skilled 170 engineers and technicians
• Annual production capability:

3,800,000 miles fiber | 440,000 miles fiber cables | 6,500 miles OPGW

22

Fiber and cable manufacturing process

VAD Core Preform Drawing Testing Coloring Loose Tubing SZ Conform Jacketing Testing Fiber

TAIHAN FIBEROPTICS

23

Certificates

ISO 9001 ISO 14001 OHSAS 18001 BSI‐TL 9000 Telcordia ‐ Fiber Kinetrics ‐ OPGW 24

Global reach

Head Office USA

• S. Africa

D.R.Congo UAE Vietnam Australia Saudi Arabia Main office and plant Subsidiary Branch office TAIHAN FIBEROPTICS

25
