SLIDE 1
TYPE-GUIDED WORST-CASE INPUT GENERATION
Di Wang, Jan Hoffmann
Carnegie Mellon University
RESOURCE ANALYSIS
Programs
2
T YPE -G UIDED W ORST -C ASE I NPUT G ENERATION Di Wang , Jan - - PowerPoint PPT Presentation
T YPE -G UIDED W ORST -C ASE I NPUT G ENERATION Di Wang , Jan - - PowerPoint PPT Presentation
T YPE -G UIDED W ORST -C ASE I NPUT G ENERATION Di Wang , Jan Hoffmann Carnegie Mellon University R ESOURCE A NALYSIS Programs 2 R ESOURCE A NALYSIS Programs Performance 2 R ESOURCE A NALYSIS Time Memory Power Programs Performance
SLIDE 2
SLIDE 3
RESOURCE ANALYSIS
Programs
2
Performance
SLIDE 4
RESOURCE ANALYSIS
Programs
2
Performance Time Memory Power …
SLIDE 5
RESOURCE ANALYSIS
Programs Worst-Case Analysis
Performance bottlenecks Algorithmic complexity vulnerabilities Timing side channels
2
Performance Time Memory Power …
SLIDE 6
EXAMPLE OF WORST-CASE ANALYSIS
PHP
1 CVE - CVE-2011-4885. Available on: https://cve.mitre.org/cgi-bin/cvename.cgi?name=CVE-2011-4885. 2 PHP 5.3.8 - Hashtables Denial of Service. Available on https://www.exploit-db.com/exploits/18296/. 3 PHP: PHP 5 ChangeLog. Available on http://www.php.net/ChangeLog-5.php#5.3.9.
3
SLIDE 7
EXAMPLE OF WORST-CASE ANALYSIS
PHP Potential Denial-of-Service attack1
1 CVE - CVE-2011-4885. Available on: https://cve.mitre.org/cgi-bin/cvename.cgi?name=CVE-2011-4885. 2 PHP 5.3.8 - Hashtables Denial of Service. Available on https://www.exploit-db.com/exploits/18296/. 3 PHP: PHP 5 ChangeLog. Available on http://www.php.net/ChangeLog-5.php#5.3.9.
3
SLIDE 8
EXAMPLE OF WORST-CASE ANALYSIS
PHP Potential Denial-of-Service attack1 Concrete exploits (by hash collisions)2
1 CVE - CVE-2011-4885. Available on: https://cve.mitre.org/cgi-bin/cvename.cgi?name=CVE-2011-4885. 2 PHP 5.3.8 - Hashtables Denial of Service. Available on https://www.exploit-db.com/exploits/18296/. 3 PHP: PHP 5 ChangeLog. Available on http://www.php.net/ChangeLog-5.php#5.3.9.
3
SLIDE 9
EXAMPLE OF WORST-CASE ANALYSIS
PHP Potential Denial-of-Service attack1 Concrete exploits (by hash collisions)2 Bug fixed!3
1 CVE - CVE-2011-4885. Available on: https://cve.mitre.org/cgi-bin/cvename.cgi?name=CVE-2011-4885. 2 PHP 5.3.8 - Hashtables Denial of Service. Available on https://www.exploit-db.com/exploits/18296/. 3 PHP: PHP 5 ChangeLog. Available on http://www.php.net/ChangeLog-5.php#5.3.9.
3
SLIDE 10
EXAMPLE OF WORST-CASE ANALYSIS
PHP Potential Denial-of-Service attack1 Concrete exploits (by hash collisions)2 Bug fixed!3
Worst-case inputs are instrumental to understand and fix performance bugs!
1 CVE - CVE-2011-4885. Available on: https://cve.mitre.org/cgi-bin/cvename.cgi?name=CVE-2011-4885. 2 PHP 5.3.8 - Hashtables Denial of Service. Available on https://www.exploit-db.com/exploits/18296/. 3 PHP: PHP 5 ChangeLog. Available on http://www.php.net/ChangeLog-5.php#5.3.9.
3
SLIDE 11
EXISTING APPROACHES
4
SLIDE 12
EXISTING APPROACHES
Fuzz testing Symbolic execution Dynamic worst-case analysis … Flexible & universal Potentially unsound: The resulting inputs might not expose the worst-case behavior. Dynamic
4
SLIDE 13
EXISTING APPROACHES
Fuzz testing Symbolic execution Dynamic worst-case analysis … Flexible & universal Potentially unsound: The resulting inputs might not expose the worst-case behavior. Type systems Abstract interpretation … Sound upper bounds Potentially not tight: No concrete witness — the bound might be too conservative. Dynamic Static
4
SLIDE 14
CONTRIBUTIONS
A type-guided worst-case input generation algorithm Proof of soundness and relative completeness Heuristics to improve scalability
5
SLIDE 15
CONTRIBUTIONS
λ
A type-guided worst-case input generation algorithm Proof of soundness and relative completeness Heuristics to improve scalability
5
SLIDE 16
CONTRIBUTIONS
λ
A type-guided worst-case input generation algorithm Proof of soundness and relative completeness Heuristics to improve scalability
Resource Aware ML (RaML)
5
SLIDE 17
CONTRIBUTIONS
λ
A type-guided worst-case input generation algorithm Proof of soundness and relative completeness Heuristics to improve scalability
Resource Aware ML (RaML)
5
SLIDE 18
CONTRIBUTIONS
λ
A type-guided worst-case input generation algorithm Proof of soundness and relative completeness Heuristics to improve scalability
Resource Aware ML (RaML) Symbolic Execution
5
SLIDE 19
CONTRIBUTIONS
λ
A type-guided worst-case input generation algorithm Proof of soundness and relative completeness Heuristics to improve scalability
Resource Aware ML (RaML) Symbolic Execution Guide
5
SLIDE 20
OVERVIEW
Motivation Resource Aware ML (RaML) Type-Guided Worst-Case Input Generation Evaluation
6
SLIDE 21
AMORTIZED RESOURCE ANALYSIS
The potential method
7
SLIDE 22
AMORTIZED RESOURCE ANALYSIS
The potential method
D0 D1 D2 D3 … Dn
7
D4 D5 …
SLIDE 23
AMORTIZED RESOURCE ANALYSIS
The potential method
D0 D1 D2 D3 … Dn
Di’s are program states
7
D4 D5 …
SLIDE 24
AMORTIZED RESOURCE ANALYSIS
The potential method
D0 D1 D2 D3 … Dn
Di’s are program states Arrows are transitions with actual costs
7
D4 D5 …
SLIDE 25
AMORTIZED RESOURCE ANALYSIS
The potential method
D0 D1 D2 D3 … Dn
Di’s are program states Arrows are transitions with actual costs
Φ(D0) Φ(D1) Φ(D2) Φ(D3) Φ(Dn)
7
D4 D5 …
SLIDE 26
AMORTIZED RESOURCE ANALYSIS
The potential method
D0 D1 D2 D3 … Dn
Di’s are program states Arrows are transitions with actual costs
Φ(D0) Φ(D1) Φ(D2) Φ(D3) Φ(Dn)
The potential function maps program states to nonnegative numbers
7
D4 D5 …
SLIDE 27
AMORTIZED RESOURCE ANALYSIS
The potential method
D0 D1 D2 D3 … Dn
Di’s are program states Arrows are transitions with actual costs
Φ(D0) Φ(D1) Φ(D2) Φ(D3) Φ(Dn)
The potential function maps program states to nonnegative numbers
Φ(D2) ≥ Cost(D2, D3) + Φ(D3)
7
D4 D5 …
SLIDE 28
AMORTIZED RESOURCE ANALYSIS
The potential method
D0 D1 D2 D3 … Dn
Di’s are program states Arrows are transitions with actual costs
Φ(D0) Φ(D1) Φ(D2) Φ(D3) Φ(Dn)
The potential function maps program states to nonnegative numbers
Φ(D2) ≥ Cost(D2, D3) + Φ(D3)
The initial potential is an upper bound!
7
D4 D5 …
SLIDE 29
TYPE-BASED ANALYSIS
let rec lpairs l = match l with | [] -> [] | x1 :: xs -> match xs with | [] -> [] | x2 :: xs’ -> if (x1:int) < (x2:int) then (x1, x2) :: lpairs xs’ else lpairs xs’
The potential at a program point is defined by a static annotation of data structures. A list of length n annotated with a nonnegative number q has q·n units of potential.
8
SLIDE 30
TYPE-BASED ANALYSIS
let rec lpairs l = match l with | [] -> [] | x1 :: xs -> match xs with | [] -> [] | x2 :: xs’ -> if (x1:int) < (x2:int) then (x1, x2) :: lpairs xs’ else lpairs xs’
The potential at a program point is defined by a static annotation of data structures. A list of length n annotated with a nonnegative number q has q·n units of potential.
Each of [], ::, (,) consumes 2 memory cells.
8
SLIDE 31
TYPE-BASED ANALYSIS
let rec lpairs l = match l with | [] -> [] | x1 :: xs -> match xs with | [] -> [] | x2 :: xs’ -> if (x1:int) < (x2:int) then (x1, x2) :: lpairs xs’ else lpairs xs’
The potential at a program point is defined by a static annotation of data structures. A list of length n annotated with a nonnegative number q has q·n units of potential.
Each of [], ::, (,) consumes 2 memory cells.
8
Cost = 2 ⋅ |ℓ| + 2
SLIDE 32
TYPE-BASED ANALYSIS
let rec lpairs l = match l with | [] -> [] | x1 :: xs -> match xs with | [] -> [] | x2 :: xs’ -> if (x1:int) < (x2:int) then (x1, x2) :: lpairs xs’ else lpairs xs’
The potential at a program point is defined by a static annotation of data structures. A list of length n annotated with a nonnegative number q has q·n units of potential.
L2(𝗃𝗈𝗎) 2/0 L0(𝗃𝗈𝗎 × 𝗃𝗈𝗎)
Each of [], ::, (,) consumes 2 memory cells.
8
SLIDE 33
TYPE-BASED ANALYSIS
let rec lpairs l = match l with | [] -> [] | x1 :: xs -> match xs with | [] -> [] | x2 :: xs’ -> if (x1:int) < (x2:int) then (x1, x2) :: lpairs xs’ else lpairs xs’
The potential at a program point is defined by a static annotation of data structures. A list of length n annotated with a nonnegative number q has q·n units of potential.
L2(𝗃𝗈𝗎) 2/0 L0(𝗃𝗈𝗎 × 𝗃𝗈𝗎)
Each of [], ::, (,) consumes 2 memory cells.
Φ0 = 2 ⋅ |ℓ| + 2
8
SLIDE 34
TYPE-BASED ANALYSIS
let rec lpairs l = match l with | [] -> [] | x1 :: xs -> match xs with | [] -> [] | x2 :: xs’ -> if (x1:int) < (x2:int) then (x1, x2) :: lpairs xs’ else lpairs xs’
The potential at a program point is defined by a static annotation of data structures. A list of length n annotated with a nonnegative number q has q·n units of potential.
L2(𝗃𝗈𝗎) 2/0 L0(𝗃𝗈𝗎 × 𝗃𝗈𝗎)
Each of [], ::, (,) consumes 2 memory cells.
Φ0 = 2 ⋅ |ℓ| + 2 Cost = 2
8
SLIDE 35
TYPE-BASED ANALYSIS
let rec lpairs l = match l with | [] -> [] | x1 :: xs -> match xs with | [] -> [] | x2 :: xs’ -> if (x1:int) < (x2:int) then (x1, x2) :: lpairs xs’ else lpairs xs’
The potential at a program point is defined by a static annotation of data structures. A list of length n annotated with a nonnegative number q has q·n units of potential.
L2(𝗃𝗈𝗎) 2/0 L0(𝗃𝗈𝗎 × 𝗃𝗈𝗎)
Each of [], ::, (,) consumes 2 memory cells.
Φ1 = 2 ⋅ |xs| + 4
8
SLIDE 36
TYPE-BASED ANALYSIS
let rec lpairs l = match l with | [] -> [] | x1 :: xs -> match xs with | [] -> [] | x2 :: xs’ -> if (x1:int) < (x2:int) then (x1, x2) :: lpairs xs’ else lpairs xs’
The potential at a program point is defined by a static annotation of data structures. A list of length n annotated with a nonnegative number q has q·n units of potential.
L2(𝗃𝗈𝗎) 2/0 L0(𝗃𝗈𝗎 × 𝗃𝗈𝗎)
Each of [], ::, (,) consumes 2 memory cells.
Φ2 = 2 ⋅ |xs′| + 6
8
SLIDE 37
TYPE-BASED ANALYSIS
let rec lpairs l = match l with | [] -> [] | x1 :: xs -> match xs with | [] -> [] | x2 :: xs’ -> if (x1:int) < (x2:int) then (x1, x2) :: lpairs xs’ else lpairs xs’
The potential at a program point is defined by a static annotation of data structures. A list of length n annotated with a nonnegative number q has q·n units of potential.
L2(𝗃𝗈𝗎) 2/0 L0(𝗃𝗈𝗎 × 𝗃𝗈𝗎)
Each of [], ::, (,) consumes 2 memory cells.
Φ2 = 2 ⋅ |xs′| + 6 Cost = 4
8
SLIDE 38
TYPE-BASED ANALYSIS
let rec lpairs l = match l with | [] -> [] | x1 :: xs -> match xs with | [] -> [] | x2 :: xs’ -> if (x1:int) < (x2:int) then (x1, x2) :: lpairs xs’ else lpairs xs’
The potential at a program point is defined by a static annotation of data structures. A list of length n annotated with a nonnegative number q has q·n units of potential.
L2(𝗃𝗈𝗎) 2/0 L0(𝗃𝗈𝗎 × 𝗃𝗈𝗎)
Each of [], ::, (,) consumes 2 memory cells.
Φ2 = 2 ⋅ |xs′| + 6 Φ3 = 2 ⋅ |xs′| + 2 Cost = 4
8
SLIDE 39
TYPE-BASED ANALYSIS
let rec lpairs l = match l with | [] -> [] | x1 :: xs -> match xs with | [] -> [] | x2 :: xs’ -> if (x1:int) < (x2:int) then (x1, x2) :: lpairs xs’ else lpairs xs’
The potential at a program point is defined by a static annotation of data structures. A list of length n annotated with a nonnegative number q has q·n units of potential.
L2(𝗃𝗈𝗎) 2/0 L0(𝗃𝗈𝗎 × 𝗃𝗈𝗎)
Each of [], ::, (,) consumes 2 memory cells.
Φ2 = 2 ⋅ |xs′| + 6 Φ3 = 2 ⋅ |xs′| + 2 Cost = 4
8
SLIDE 40
OVERVIEW
Motivation Resource Aware ML (RaML) Type-Guided Worst-Case Input Generation Evaluation
9
SLIDE 41
SYMBOLIC EXECUTION
Idea: search all execution paths, record path constraints, and compute resource usage
γ ⊢ e ⇒ ⟨ψ, S⟩
SLIDE 42
SYMBOLIC EXECUTION
Idea: search all execution paths, record path constraints, and compute resource usage
γ ⊢ e ⇒ ⟨ψ, S⟩
symbolic environment
SLIDE 43
SYMBOLIC EXECUTION
Idea: search all execution paths, record path constraints, and compute resource usage
γ ⊢ e ⇒ ⟨ψ, S⟩
symbolic environment expression
SLIDE 44
SYMBOLIC EXECUTION
Idea: search all execution paths, record path constraints, and compute resource usage
γ ⊢ e ⇒ ⟨ψ, S⟩
symbolic environment expression path constraints
SLIDE 45
SYMBOLIC EXECUTION
Idea: search all execution paths, record path constraints, and compute resource usage
γ ⊢ e ⇒ ⟨ψ, S⟩
symbolic environment expression symbolic evaluation result path constraints
SLIDE 46
SYMBOLIC EXECUTION
Idea: search all execution paths, record path constraints, and compute resource usage
γ ⊢ e ⇒ ⟨ψ, S⟩
symbolic environment expression symbolic evaluation result path constraints
Symbolic execution rules for conditional expressions
SLIDE 47
SYMBOLIC EXECUTION
Idea: search all execution paths, record path constraints, and compute resource usage
γ ⊢ e ⇒ ⟨ψ, S⟩
symbolic environment expression symbolic evaluation result path constraints
10
γ ⊢ e1 ⇒ ⟨ψ, S⟩ γ ⊢ 𝗃𝗀 e 𝗎𝗂𝖿𝗈 e1 𝖿𝗆𝗍𝖿 e2 ⇒ ⟨γ(e) ∧ ψ, S⟩ γ ⊢ e2 ⇒ ⟨ψ, S⟩ γ ⊢ 𝗃𝗀 e 𝗎𝗂𝖿𝗈 e1 𝖿𝗆𝗍𝖿 e2 ⇒ ⟨¬γ(e) ∧ ψ, S⟩
Symbolic execution rules for conditional expressions
Then Else
SLIDE 48
SYMBOLIC EXECUTION
let rec lpairs l = match l with | [] -> [] | x1 :: xs -> match xs with | [] -> [] | x2 :: xs’ -> if (x1:int) < (x2:int) then (x1, x2) :: lpairs xs’ else lpairs xs’
11
SLIDE 49
An example of worst-case execution paths for input lists
- f length 4
SYMBOLIC EXECUTION
let rec lpairs l = match l with | [] -> [] | x1 :: xs -> match xs with | [] -> [] | x2 :: xs’ -> if (x1:int) < (x2:int) then (x1, x2) :: lpairs xs’ else lpairs xs’
ℓ ↦ [𝗃𝗈𝗎1, 𝗃𝗈𝗎2, 𝗃𝗈𝗎3, 𝗃𝗈𝗎4] ⊢ 𝗆𝗊𝖻𝗃𝗌𝗍 ℓ ⇒ ⟨(𝗃𝗈𝗎1 < 𝗃𝗈𝗎2) ∧ (𝗃𝗈𝗎3 < 𝗃𝗈𝗎4), [(𝗃𝗈𝗎1, 𝗃𝗈𝗎2), (𝗃𝗈𝗎3, 𝗃𝗈𝗎4)]⟩
11
SLIDE 50
An example of worst-case execution paths for input lists
- f length 4
SYMBOLIC EXECUTION
let rec lpairs l = match l with | [] -> [] | x1 :: xs -> match xs with | [] -> [] | x2 :: xs’ -> if (x1:int) < (x2:int) then (x1, x2) :: lpairs xs’ else lpairs xs’
ℓ ↦ [𝗃𝗈𝗎1, 𝗃𝗈𝗎2, 𝗃𝗈𝗎3, 𝗃𝗈𝗎4] ⊢ 𝗆𝗊𝖻𝗃𝗌𝗍 ℓ ⇒ ⟨(𝗃𝗈𝗎1 < 𝗃𝗈𝗎2) ∧ (𝗃𝗈𝗎3 < 𝗃𝗈𝗎4), [(𝗃𝗈𝗎1, 𝗃𝗈𝗎2), (𝗃𝗈𝗎3, 𝗃𝗈𝗎4)]⟩
Invoke an SMT solver to find a model, e.g., [0,1,0,1]
11
SLIDE 51
TYPE-GUIDED SYMBOLIC EXECUTION
Nondeterminism leads to state explosion
γ ⊢ e1 ⇒ ⟨ψ, S⟩ γ ⊢ 𝗃𝗀 e 𝗎𝗂𝖿𝗈 e1 𝖿𝗆𝗍𝖿 e2 ⇒ ⟨γ(e) ∧ ψ, S⟩ γ ⊢ e2 ⇒ ⟨ψ, S⟩ γ ⊢ 𝗃𝗀 e 𝗎𝗂𝖿𝗈 e1 𝖿𝗆𝗍𝖿 e2 ⇒ ⟨¬γ(e) ∧ ψ, S⟩ Then Else
12
SLIDE 52
TYPE-GUIDED SYMBOLIC EXECUTION
Nondeterminism leads to state explosion
γ ⊢ e1 ⇒ ⟨ψ, S⟩ γ ⊢ 𝗃𝗀 e 𝗎𝗂𝖿𝗈 e1 𝖿𝗆𝗍𝖿 e2 ⇒ ⟨γ(e) ∧ ψ, S⟩ γ ⊢ e2 ⇒ ⟨ψ, S⟩ γ ⊢ 𝗃𝗀 e 𝗎𝗂𝖿𝗈 e1 𝖿𝗆𝗍𝖿 e2 ⇒ ⟨¬γ(e) ∧ ψ, S⟩ Then Else
12
Use the information about potentials obtained from resource aware type checking to prune the search space of symbolic execution.
SLIDE 53
13
TYPE-GUIDED SYMBOLIC EXECUTION
let rec lpairs l = match l with | [] -> [] | x1 :: xs -> match xs with | [] -> [] | x2 :: xs’ -> if (x1:int) < (x2:int) then (x1, x2) :: lpairs xs’ else lpairs xs’
L2(𝗃𝗈𝗎) 2/0 L0(𝗃𝗈𝗎 × 𝗃𝗈𝗎)
SLIDE 54
13
TYPE-GUIDED SYMBOLIC EXECUTION
let rec lpairs l = match l with | [] -> [] | x1 :: xs -> match xs with | [] -> [] | x2 :: xs’ -> if (x1:int) < (x2:int) then (x1, x2) :: lpairs xs’ else lpairs xs’
L2(𝗃𝗈𝗎) 2/0 L0(𝗃𝗈𝗎 × 𝗃𝗈𝗎) ℓ ↦ [𝗃𝗈𝗎1, 𝗃𝗈𝗎2, 𝗃𝗈𝗎3, 𝗃𝗈𝗎4]
SLIDE 55
13
TYPE-GUIDED SYMBOLIC EXECUTION
let rec lpairs l = match l with | [] -> [] | x1 :: xs -> match xs with | [] -> [] | x2 :: xs’ -> if (x1:int) < (x2:int) then (x1, x2) :: lpairs xs’ else lpairs xs’
L2(𝗃𝗈𝗎) 2/0 L0(𝗃𝗈𝗎 × 𝗃𝗈𝗎) ℓ ↦ [𝗃𝗈𝗎1, 𝗃𝗈𝗎2, 𝗃𝗈𝗎3, 𝗃𝗈𝗎4] x1 ↦ 𝗃𝗈𝗎1, x2 ↦ 𝗃𝗈𝗎2, xs′ ↦ [𝗃𝗈𝗎3, 𝗃𝗈𝗎4]
SLIDE 56
13
TYPE-GUIDED SYMBOLIC EXECUTION
let rec lpairs l = match l with | [] -> [] | x1 :: xs -> match xs with | [] -> [] | x2 :: xs’ -> if (x1:int) < (x2:int) then (x1, x2) :: lpairs xs’ else lpairs xs’
Φ2 = 2 ⋅ |xs′| + 6 = 10 L2(𝗃𝗈𝗎) 2/0 L0(𝗃𝗈𝗎 × 𝗃𝗈𝗎) ℓ ↦ [𝗃𝗈𝗎1, 𝗃𝗈𝗎2, 𝗃𝗈𝗎3, 𝗃𝗈𝗎4] x1 ↦ 𝗃𝗈𝗎1, x2 ↦ 𝗃𝗈𝗎2, xs′ ↦ [𝗃𝗈𝗎3, 𝗃𝗈𝗎4]
SLIDE 57
13
TYPE-GUIDED SYMBOLIC EXECUTION
let rec lpairs l = match l with | [] -> [] | x1 :: xs -> match xs with | [] -> [] | x2 :: xs’ -> if (x1:int) < (x2:int) then (x1, x2) :: lpairs xs’ else lpairs xs’
Φ2 = 2 ⋅ |xs′| + 6 = 10 Cost = 4 L2(𝗃𝗈𝗎) 2/0 L0(𝗃𝗈𝗎 × 𝗃𝗈𝗎) ℓ ↦ [𝗃𝗈𝗎1, 𝗃𝗈𝗎2, 𝗃𝗈𝗎3, 𝗃𝗈𝗎4] x1 ↦ 𝗃𝗈𝗎1, x2 ↦ 𝗃𝗈𝗎2, xs′ ↦ [𝗃𝗈𝗎3, 𝗃𝗈𝗎4]
SLIDE 58
13
TYPE-GUIDED SYMBOLIC EXECUTION
let rec lpairs l = match l with | [] -> [] | x1 :: xs -> match xs with | [] -> [] | x2 :: xs’ -> if (x1:int) < (x2:int) then (x1, x2) :: lpairs xs’ else lpairs xs’
Φ2 = 2 ⋅ |xs′| + 6 = 10 Φ3 = 2 ⋅ |xs′| + 2 = 6 Cost = 4 L2(𝗃𝗈𝗎) 2/0 L0(𝗃𝗈𝗎 × 𝗃𝗈𝗎) ℓ ↦ [𝗃𝗈𝗎1, 𝗃𝗈𝗎2, 𝗃𝗈𝗎3, 𝗃𝗈𝗎4] x1 ↦ 𝗃𝗈𝗎1, x2 ↦ 𝗃𝗈𝗎2, xs′ ↦ [𝗃𝗈𝗎3, 𝗃𝗈𝗎4]
SLIDE 59
13
TYPE-GUIDED SYMBOLIC EXECUTION
let rec lpairs l = match l with | [] -> [] | x1 :: xs -> match xs with | [] -> [] | x2 :: xs’ -> if (x1:int) < (x2:int) then (x1, x2) :: lpairs xs’ else lpairs xs’
Φ2 = 2 ⋅ |xs′| + 6 = 10 Φ3 = 2 ⋅ |xs′| + 2 = 6 Cost = 4 L2(𝗃𝗈𝗎) 2/0 L0(𝗃𝗈𝗎 × 𝗃𝗈𝗎) ℓ ↦ [𝗃𝗈𝗎1, 𝗃𝗈𝗎2, 𝗃𝗈𝗎3, 𝗃𝗈𝗎4] x1 ↦ 𝗃𝗈𝗎1, x2 ↦ 𝗃𝗈𝗎2, xs′ ↦ [𝗃𝗈𝗎3, 𝗃𝗈𝗎4]
SLIDE 60
13
TYPE-GUIDED SYMBOLIC EXECUTION
let rec lpairs l = match l with | [] -> [] | x1 :: xs -> match xs with | [] -> [] | x2 :: xs’ -> if (x1:int) < (x2:int) then (x1, x2) :: lpairs xs’ else lpairs xs’
Φ2 = 2 ⋅ |xs′| + 6 = 10 Φ3 = 2 ⋅ |xs′| + 2 = 6 Cost = 4 L2(𝗃𝗈𝗎) 2/0 L0(𝗃𝗈𝗎 × 𝗃𝗈𝗎) ℓ ↦ [𝗃𝗈𝗎1, 𝗃𝗈𝗎2, 𝗃𝗈𝗎3, 𝗃𝗈𝗎4] x1 ↦ 𝗃𝗈𝗎1, x2 ↦ 𝗃𝗈𝗎2, xs′ ↦ [𝗃𝗈𝗎3, 𝗃𝗈𝗎4] Waste!
SLIDE 61
13
TYPE-GUIDED SYMBOLIC EXECUTION
let rec lpairs l = match l with | [] -> [] | x1 :: xs -> match xs with | [] -> [] | x2 :: xs’ -> if (x1:int) < (x2:int) then (x1, x2) :: lpairs xs’ else lpairs xs’
Φ2 = 2 ⋅ |xs′| + 6 = 10 Φ3 = 2 ⋅ |xs′| + 2 = 6 Cost = 4 L2(𝗃𝗈𝗎) 2/0 L0(𝗃𝗈𝗎 × 𝗃𝗈𝗎) ℓ ↦ [𝗃𝗈𝗎1, 𝗃𝗈𝗎2, 𝗃𝗈𝗎3, 𝗃𝗈𝗎4] x1 ↦ 𝗃𝗈𝗎1, x2 ↦ 𝗃𝗈𝗎2, xs′ ↦ [𝗃𝗈𝗎3, 𝗃𝗈𝗎4]
If an execution path does not have potential waste, it must expose the worst- case resource usage.
Waste!
SLIDE 62
13
TYPE-GUIDED SYMBOLIC EXECUTION
let rec lpairs l = match l with | [] -> [] | x1 :: xs -> match xs with | [] -> [] | x2 :: xs’ -> if (x1:int) < (x2:int) then (x1, x2) :: lpairs xs’ else lpairs xs’
Φ2 = 2 ⋅ |xs′| + 6 = 10 Φ3 = 2 ⋅ |xs′| + 2 = 6 Cost = 4 L2(𝗃𝗈𝗎) 2/0 L0(𝗃𝗈𝗎 × 𝗃𝗈𝗎) ℓ ↦ [𝗃𝗈𝗎1, 𝗃𝗈𝗎2, 𝗃𝗈𝗎3, 𝗃𝗈𝗎4] x1 ↦ 𝗃𝗈𝗎1, x2 ↦ 𝗃𝗈𝗎2, xs′ ↦ [𝗃𝗈𝗎3, 𝗃𝗈𝗎4]
If an execution path does not have potential waste, it must expose the worst- case resource usage.
Waste!
SLIDE 63
SOUNDNESS & COMPLETENESS
14
SLIDE 64
SOUNDNESS & COMPLETENESS
Soundness: If the algorithm generates an input, then the input will cause the program to consume exactly the same amount of resource as the inferred upper bound (by RaML).
14
SLIDE 65
SOUNDNESS & COMPLETENESS
Soundness: If the algorithm generates an input, then the input will cause the program to consume exactly the same amount of resource as the inferred upper bound (by RaML). Relative completeness: If there is an input of some given shape that causes the program to consume exactly the same amount of resource as the inferred upper bound (by RaML), then the algorithm is able to find a corresponding execution path.
14
SLIDE 66
15
γ ⊢ e1 ⇒ ⟨ψ, S⟩ γ ⊢ 𝗃𝗀 e 𝗎𝗂𝖿𝗈 e1 𝖿𝗆𝗍𝖿 e2 ⇒ ⟨γ(e) ∧ ψ, S⟩ γ ⊢ e2 ⇒ ⟨ψ, S⟩ γ ⊢ 𝗃𝗀 e 𝗎𝗂𝖿𝗈 e1 𝖿𝗆𝗍𝖿 e2 ⇒ ⟨¬γ(e) ∧ ψ, S⟩ Then Else
SPEED UP INPUT GENERATION
SLIDE 67
How about eliminating some generation rules?
15
γ ⊢ e1 ⇒ ⟨ψ, S⟩ γ ⊢ 𝗃𝗀 e 𝗎𝗂𝖿𝗈 e1 𝖿𝗆𝗍𝖿 e2 ⇒ ⟨γ(e) ∧ ψ, S⟩ γ ⊢ e2 ⇒ ⟨ψ, S⟩ γ ⊢ 𝗃𝗀 e 𝗎𝗂𝖿𝗈 e1 𝖿𝗆𝗍𝖿 e2 ⇒ ⟨¬γ(e) ∧ ψ, S⟩ Then Else
SPEED UP INPUT GENERATION
SLIDE 68
How about eliminating some generation rules?
15
γ ⊢ e1 ⇒ ⟨ψ, S⟩ γ ⊢ 𝗃𝗀 e 𝗎𝗂𝖿𝗈 e1 𝖿𝗆𝗍𝖿 e2 ⇒ ⟨γ(e) ∧ ψ, S⟩ γ ⊢ e2 ⇒ ⟨ψ, S⟩ γ ⊢ 𝗃𝗀 e 𝗎𝗂𝖿𝗈 e1 𝖿𝗆𝗍𝖿 e2 ⇒ ⟨¬γ(e) ∧ ψ, S⟩ Then Else
SPEED UP INPUT GENERATION
SLIDE 69
How about eliminating some generation rules?
15
γ ⊢ e1 ⇒ ⟨ψ, S⟩ γ ⊢ 𝗃𝗀 e 𝗎𝗂𝖿𝗈 e1 𝖿𝗆𝗍𝖿 e2 ⇒ ⟨γ(e) ∧ ψ, S⟩ γ ⊢ e2 ⇒ ⟨ψ, S⟩ γ ⊢ 𝗃𝗀 e 𝗎𝗂𝖿𝗈 e1 𝖿𝗆𝗍𝖿 e2 ⇒ ⟨¬γ(e) ∧ ψ, S⟩ Then Else
Still Sound!
SPEED UP INPUT GENERATION
SLIDE 70
How about eliminating some generation rules?
15
γ ⊢ e1 ⇒ ⟨ψ, S⟩ γ ⊢ 𝗃𝗀 e 𝗎𝗂𝖿𝗈 e1 𝖿𝗆𝗍𝖿 e2 ⇒ ⟨γ(e) ∧ ψ, S⟩ γ ⊢ e2 ⇒ ⟨ψ, S⟩ γ ⊢ 𝗃𝗀 e 𝗎𝗂𝖿𝗈 e1 𝖿𝗆𝗍𝖿 e2 ⇒ ⟨¬γ(e) ∧ ψ, S⟩ Then Else
Still Sound!
SPEED UP INPUT GENERATION
Generalization: enforce all the calls with the same shape of inputs execute the same path in the function body.
SLIDE 71
OVERVIEW
Motivation Resource Aware ML (RaML) Type-Guided Worst-Case Input Generation Evaluation
16
SLIDE 72
IMPLEMENTATION
17
We implemented the generation algorithm for a purely functional fragment of Resource Aware ML (RaML), including higher-order functions, user-defined data structures, and polynomial resource bounds. We used the off-the-shelf SMT solver Z3.
SLIDE 73
BENCHMARKS (SELECTED)
18
Description Shape ALG ALG+H1 ALG+H2
Insertion sort
200 integers 7.74s 6.97s 94.81s
Quicksort
200 integers T/O 53.23s 157.21s
Lexicographic quicksort
Lists of length 100, 99, …, 1 439.35s 438.79s T/O
Functional queue
200 operations 444.64s T/O T/O
Zigzag on a tree
200 internal nodes T/O T/O 4.87s
Hash table for 8-char strings
64 insertions 7.64s 7.62s 181.74s
SLIDE 74
19
EXAMPLE: HASH TABLE
SLIDE 75
19
EXAMPLE: HASH TABLE
Customized resource metric: count for hash collisions
SLIDE 76
19
EXAMPLE: HASH TABLE
Customized resource metric: count for hash collisions Use a hash function from a vulnerable PHP implementation
SLIDE 77
19
EXAMPLE: HASH TABLE
Customized resource metric: count for hash collisions Use a hash function from a vulnerable PHP implementation The program inserts 64 strings into an empty hash table
SLIDE 78
19
EXAMPLE: HASH TABLE
Customized resource metric: count for hash collisions Use a hash function from a vulnerable PHP implementation The program inserts 64 strings into an empty hash table Our algorithm “realizes” that it should find 64 strings with the same hash key, in order to trigger the most collisions
SLIDE 79
SUMMARY
20
λ
TYPE-GUIDED SYMBOLIC EXECUTION
FOR WORST-CASE INPUT GENERATION
SLIDE 80
SUMMARY
20
λ
TYPE-GUIDED SYMBOLIC EXECUTION
FOR WORST-CASE INPUT GENERATION
Formally developed algorithm Soundness & relative completeness Theoretical Results
SLIDE 81
SUMMARY
20
λ
TYPE-GUIDED SYMBOLIC EXECUTION
FOR WORST-CASE INPUT GENERATION
Integrated with RaML Effective on 22 benchmark programs Formally developed algorithm Soundness & relative completeness Theoretical Results Experimental Results
SLIDE 82
SUMMARY
20
Limitations: Purely functional programs Only work for tight bounds Depend on RaML
λ
TYPE-GUIDED SYMBOLIC EXECUTION
FOR WORST-CASE INPUT GENERATION
Integrated with RaML Effective on 22 benchmark programs Formally developed algorithm Soundness & relative completeness Theoretical Results Experimental Results
SLIDE 83
SUMMARY
20
Limitations: Purely functional programs Only work for tight bounds Depend on RaML Future work: Support side effects Interact with resource analysis General theory for worst- case analysis
