SZMC a Sunyaev Zeldovich Meta Catalogue of galaxy clusters M. DOUSPIS (IAS, Orsay) N. Aghanim, A. Nastasi, E. Soubrie, H. Ballans, A. Beelen, and G. Hurier Looking for clusters Hot intra-cluster gas Gas ~10s 10 6 K Bremsstrahlung

slide-1
SLIDE 1

SZMC a Sunyaev Zeld’ovich Meta Catalogue of galaxy clusters

  • M. DOUSPIS

(IAS, Orsay)

  • N. Aghanim, A. Nastasi, E. Soubrie, H. Ballans, A. Beelen, and G. Hurier
slide-2
SLIDE 2
  • M. Douspis, 01/12/2015, SZ Meta-Catalogue

Looking for clusters

2

low energy CMB photon higher energy photon

Two independent probes of the same physical component Hot intra-cluster gas

Total SZ “flux” proportional to Bremsstrahlung → X-ray emission Inverse Compton → SZ effect

COMA, Planck X-rays ~100s galaxies

  • ptical

Gas ~10s 106K Dark matter ~80% mass

slide-3
SLIDE 3
  • M. Douspis, 01/12/2015, SZ Meta-Catalogue

SZ effect: hot baryon tracer

3

Electron énergétique

Amas de Galaxies: galaxies + gaz

CMB photon Photon diffusé plus chaud

  • R. A. Sunyaev
  • Ya. B. Zeldovich

“Hole in the sky” SZ,Comments on Astrophysics and Space Physics 1972

→Planck, ACT, SPT

slide-4
SLIDE 4
  • M. Douspis, 01/12/2015, SZ Meta-Catalogue

Planck: SZ machine

4

slide-5
SLIDE 5
  • M. Douspis, 01/12/2015, SZ Meta-Catalogue

Planck: SZ machine

  • Weak signal, contaminated

by CMB and foregrounds

  • Clusters published in 2011

with S/N>6 ie S/N~1 per map !

  • S/N >4.5 in 2015 release
  • Planck beam ~7arcmin

5

High purity means: Detection, Validation, Confirmation

slide-6
SLIDE 6
  • M. Douspis, 01/12/2015, SZ Meta-Catalogue

«manual» validation

  • Internal Planck checks

(CC, IRPS, SSO)

  • Matching with existing

catalogues

  • Search in logs and databases
  • Search in data (RASS, SDSS)

6

Planck early VIII 2011

slide-7
SLIDE 7
  • M. Douspis, 01/12/2015, SZ Meta-Catalogue

«Automatic» validation

  • For each candidate:

F(ν) = ASZFSZ(ν) + ACMBFCMB(ν) + AIRFIR(ν)+ ARADFRAD(ν) + ACOFCO(ν) + N(ν)

  • Use of Neural network and

training sets to separate good, bad, and ugly candidates

  • 3 numbers / candidate

7

Aghanim et al. 2015

slide-8
SLIDE 8
  • M. Douspis, 01/12/2015, SZ Meta-Catalogue

Confirmation

  • From X-ray (XMM,

Chandra)

  • In optical (ESO, RTT,

ENO, NOAO)

  • In SZ (AMI)

8

RTT XMM Planck int. XXVI 2015 Planck early IX 2011, Int 1,IV 2012

slide-9
SLIDE 9
  • M. Douspis, 01/12/2015, SZ Meta-Catalogue

Planck SZ catalogs

  • ESZ first SZ catalogue at the 2011 release
  • 6 month of data (1 full sky), using [100-857]GHz
  • 189 clusters (one without redshift)
  • PSZ1 at 2013 release
  • 15 month of data (2.5 full sky)
  • 1227 clusters and candidates
  • PSZ2 at 2015 release
  • 30 month of data (full sky)
  • 1653 clusters and candidates
  • ~ 84% of the sky
  • total of 1953 clusters and candidates

9

  • 120
  • 6

6 120

  • 75
  • 60
  • 45
  • 30
  • 15

15 30 45 60 75

Planck VIII 2011, Planck XXIX, XXXIV 2014, Planck XXVII, 2015

slide-10
SLIDE 10
  • M. Douspis, 01/12/2015, SZ Meta-Catalogue
  • ex. PSZ1 catalogue

PSZ1 based on [100-857]GHz 3 detection algorithms on ~84% of sky

  • 1227 clusters & candidates
  • 683 previously known
  • 264 new clusters
  • 280 candidates (class1-2-3)
  • z in [0-1]
  • M in [1~20] 1014 M☉
  • Mmed ~ 3.5 1014 M☉
  • z, z_source, z_type, z_ref, Y, M500, Qn, Pos_X, alt_name, ...
  • see Planck legacy archive

10

slide-11
SLIDE 11
  • M. Douspis, 01/12/2015, SZ Meta-Catalogue

South Pole Telescope & Atacama Cosmology Telescope

  • SPT since 2009
  • First blindly discovered SZ

cluster

  • 95,150, 220 Ghz
  • 747 clusters and candidates
  • SPT
  • Pol ongoing

11

  • ACT since 2009
  • 148 GHz + optical Fus
  • 5 years observation
  • 91 clusters and candidates
  • ACT
  • Pol ongoing

Hasselfield et al. 2013 Bleem et al. 2015

slide-12
SLIDE 12
  • M. Douspis, 01/12/2015, SZ Meta-Catalogue

Why a meta-catalogue ?

  • Planck provides well caracterised catalogues over the full sky but

limited range of redshift

  • SPT, ACT, AMI, Carma are lists of samples, part of the sky but

higher resolution, thus higher z

  • Overlap and complementarity between samples
  • Known clusters
  • complementary information, ease comparison, ...
  • Candidates
  • list with usefull info for FUs

Create a unique reference catalogue with homogenized quantities as MCXC (Piffaretti et al. 2011) is for Xray

12

slide-13
SLIDE 13
  • M. Douspis, 01/12/2015, SZ Meta-Catalogue

Building meta-catalogue

  • Compile from litterature list of clusters and candidates
  • Use previous associations (eg. Planck catalogues)
  • Make positional association between lists + checks
  • Chose a reference coordinates (SPT>ACT>PSZ2>PSZ1>ESZ>AMI>CARMA)
  • Chose a reference redshift (spec>phot, PSZ1>)
  • Agregate informations from all experiments
  • Distribute and allow for query
  • szcluster-db.ias.u-psud.fr (Sitools) + VO

13

slide-14
SLIDE 14
  • M. Douspis, 01/12/2015, SZ Meta-Catalogue

SZMC properties

14

Douspis, Aghanim et al. submitted to A&A

slide-15
SLIDE 15
  • M. Douspis, 01/12/2015, SZ Meta-Catalogue

SZMC

  • 2690 clusters and candidates
  • 166 seen by a leats 2 exp.
  • position distrib < 5
  • redshift distrib <10%
  • 1747 (891) redshifts (spec)
  • 1696 z and Mass estimates
  • 591 common with MCXC
  • 943 candidates

15

0.0 0.2 0.4 0.6 0.8 1.0 1.2 1.4 Redshift 50 100 150 200 250 300 N SZMC SZMC with spectroscopic redshift

slide-16
SLIDE 16
  • M. Douspis, 01/12/2015, SZ Meta-Catalogue

Known clusters

  • Multi-nu images for all

clusters

  • SZ-planck, DSS/SDSS,

WISE-1, WISE-ρ, ROSAT

  • Distribution Mass/z for 1696

clusters

  • masses not homogenized

yet

16

0.0 0.2 0.4 0.6 0.8 1.0 1.2 1.4 Redshift 1 10 M500 [1014 Msol] PSZ1 PSZ2 (not in PSZ1) SPT 2500deg

2

ACT CARMA

slide-17
SLIDE 17
  • M. Douspis, 01/12/2015, SZ Meta-Catalogue

example of use

  • Scaling relation between

mass estimates of different experiments (PLCK/ACT/ SPT)

  • Indirect measure of the

compatible SZ signal seen by SPT and Planck as masses agree for the same cosmology

  • Tcmb(z)
  • other mass comparisons

17

Douspis et al. 2015 Hurier et al. 2014, Guzzi et al. 2015 Van der linden et al. 2014, Israel et al. 2015, Ilic et al. 2015

slide-18
SLIDE 18
  • M. Douspis, 01/12/2015, SZ Meta-Catalogue

Candidates

  • Estimates of reliability (from

Planck maps and neural network) of candidates is provided to priorize follow-ups for 943 sources (online asap)

  • 204 bad (likely PS/ISM source)
  • 481ugly (noise in Planck)
  • 258 good :)

18

slide-19
SLIDE 19
  • M. Douspis, 01/12/2015, SZ Meta-Catalogue

Distribution

  • szcluster-db
  • VO
  • http://szcluster-db.ias.u-psud.fr/global_dataset/plugin/

conesearch?RA=307.9&DEC=-40.6&SR=1.0

19 «SZ-Cluster Database operated by the Integrated Data and Operation Center (IDOC) at the Institut d'Astrophysique Spatiale (IAS) under contract with CNES and CNRS»

slide-20
SLIDE 20
  • M. Douspis, 01/12/2015, SZ Meta-Catalogue

SZMC

  • Unique reference catalogue for SZ observations of clusters
  • baseline for different studies
  • Available online and

VO

  • Updated with new redshift and information
  • Compiled input catalogues also available
  • Add-ons online (visualisation, link to simbad,...)
  • New version of catalogue and interface beginning 2016

20

slide-21
SLIDE 21
  • M. Douspis, 01/12/2015, SZ Meta-Catalogue

21

thank you!
