Ethan L. Miller & Thomas J. E. Schwarz

Storage Systems Research Center University of California, Santa Cruz

Store, Forget & Check: Using Algebraic Signatures to Check Remotely Administered Storage

What’s the problem?

• Systems store data on remote nodes
• Remote nodes may not be trustworthy
• Data owner must check to ensure that data is really

stored

• Two current approaches:
• Read data from multiple sites and check for consistency
• Generate checksum remotely and compare to checksum of local data
• We developed an efficient algorithm that does not

require keeping a local copy of the data

2

Internet storage: backup

• Participants in the scheme offer limited storage on

their machine in exchange for storing their own data

• Data protected using parity or redundancy
• Extra blocks calculated using m/n redundancy codes
• Generate n blocks
• Require any m of the blocks to rebuild the data
• Many known mechanisms for m/n codes
• Linear interpolation
• XOR and Galois field-based
• Participants need to be able to verify that other nodes

are doing their part...

3

Storage Service Providers

• Storage utility provides remotely managed storage
• Client sends data to the SSP
• Client retrieves data as needed
• Trust issue: how can client tell if SSP is doing its job?
• Read data, check (public key-based) signature
• Read data, decrypt, check secure hash and object ID
• SafeStore does something like this
• Other approaches that don’t use network bandwidth?

4

Peer-to-peer file systems

• Farsite: uses free space on workstations within an
• rganization
• Freehaven: anonymity of storer
• OceanStore
• “Billions of users”
• Byzantine fault tolerance, k-availability through erasure-

codes

• PAST
• Users can store files up to their quota
• Provides k-availability through replication
• CFS, Intermemory, Ivy, Starfish, …

5

Common challenges

• Storage nodes cannot be trusted
• Storage nodes might lack high uplink bandwidth
• Storage nodes might have low availability
• Free Rider problem
• Node pretends to store data
• In reality, uses replicas (or protection against unavailability

mechanism) to fetch requested file from elsewhere

• Gains the benefits of participation without providing storage

6

Terribly naïve algorithm

7

• Maintain local copy of data
• Periodically request blocks of data and compare to the local copy
• Problems
• Very bandwidth-intensive
• Can’t check much data
• Need to keep the original!

Terribly naïve algorithm

7

• Maintain local copy of data
• Periodically request blocks of data and compare to the local copy
• Problems
• Very bandwidth-intensive
• Can’t check much data
• Need to keep the original!

Terribly naïve algorithm

≟

7

• Maintain local copy of data
• Periodically request blocks of data and compare to the local copy
• Problems
• Very bandwidth-intensive
• Can’t check much data
• Need to keep the original!

Verification: existing algorithm

8

• Periodically, verify random blocks
• Compute function across the blocks (m/n coding)
• Alternative: verify keyed hash stored with the block
• Problems:
• Need to transfer entire block
• Taxes network with diagnostic data
• Peers often have asymmetric Internet connections
• Leaks information heavily

Verification: existing algorithm

8

• Periodically, verify random blocks
• Compute function across the blocks (m/n coding)
• Alternative: verify keyed hash stored with the block
• Problems:
• Need to transfer entire block
• Taxes network with diagnostic data
• Peers often have asymmetric Internet connections
• Leaks information heavily

Verification: existing algorithm

⊕ ⊕

8

• Periodically, verify random blocks
• Compute function across the blocks (m/n coding)
• Alternative: verify keyed hash stored with the block
• Problems:
• Need to transfer entire block
• Taxes network with diagnostic data
• Peers often have asymmetric Internet connections
• Leaks information heavily

Verification: existing algorithm

⊕ ⊕

≟

8

• Periodically, verify random blocks
• Compute function across the blocks (m/n coding)
• Alternative: verify keyed hash stored with the block
• Problems:
• Need to transfer entire block
• Taxes network with diagnostic data
• Peers often have asymmetric Internet connections
• Leaks information heavily

Verification using algebraic signatures

• Solution: use checksums?
• Cryptographic checksums (like SHA-1) won’t work for

randomly selected ranges

• Requires original data for comparison
• Our scheme
• Uses small challenges and responses
• Allows unpredictable tests
• Free rider can’t just store the answer to all possible challenges (with any

storage benefit)

• Verifies that all remote chunks are consistent with each other
• Requires that parity is calculated with an XOR code, a linear m/n code, or

a convolutional code

• Examples: X-code, EvenOdd, row-diagonal parity, linear codes over a

Galois field

9

What is a Galois field?

• Simple answer:
• Calculations on a set of symbols
• A field called GF(2n) uses n-bit symbols
• Two kinds of operations
• Addition (done by XOR)
• Multiplication (more complex, done by tables)
• Complex answer:
• Galois fields are math done using the coefficients of polynomial

equations

• Often, coefficients are represented in base-2
• Galois field using polynomials with maximum degree n and

base-2 coefficients are called GF(2n)

• This answer explains how the addition and multiplication tables

are generated

10

What is an algebraic signature?

D1 D2 D3 Dm P1 P2 P3 Pk

(sig(D1),sig(D2),sig(D3), … sig(Dm), sig(P1),sig(P2),sig(P3)…sig(Pk))

• is a codeword!

11

• Digital hash with algebraic properties
• Important properties:
• Small changes in data result in complete change of signature
• Signature of parity is parity of signatures

• Defined over same Galois field as the linear m/n code
• Use “primitive” element a
• All non-zero elements are powers of a
• Consists of n coordinates
• Additional properties if ai = ai
• Coordinate signature defined by

Algebraic signatures

12

Algebraic signatures

• Algebraic properties
• Assume that X and Y are large data objects:
• sig(X⊕Y) = sig(X) ⊕ sig(Y)
• sig(β⋅X) = β⋅sig(X)
• Multiplication is in the Galois field of the signature calculation
• Signatures and parity formation commute
• Signatures can be updated from the old signature and the

signature of the delta (XOR) between old and new data

• Signature calculation is fast!
• Hundreds of megabytes per second on a modern CPU
• Speed limited by disk bandwidth

13

Our algorithm

• Store data across

distributed system

• Challenge sites to prove

that they hold the data

• Sites respond with the

signatures of requested data

• Sites reveal tiny amount of

information: size of signature

• Challenger verifies that the

signatures are consistent

D1 D2 D3 P

14

Our algorithm

• Store data across

distributed system

• Challenge sites to prove

that they hold the data

• Sites respond with the

signatures of requested data

• Sites reveal tiny amount of

information: size of signature

• Challenger verifies that the

signatures are consistent

D1 D2 D3 P

Calculate signature of 32 byte ranges at 4+i×71, i = 5,…,20

14

Our algorithm

• Store data across

distributed system

• Challenge sites to prove

that they hold the data

• Sites respond with the

signatures of requested data

• Sites reveal tiny amount of

information: size of signature

• Challenger verifies that the

signatures are consistent

D1 D2 D3 P

Calculate signature of 32 byte ranges at 4+i×71, i = 5,…,20

14

Our algorithm

• Store data across

distributed system

• Challenge sites to prove

that they hold the data

• Sites respond with the

signatures of requested data

• Sites reveal tiny amount of

information: size of signature

• Challenger verifies that the

signatures are consistent

D1 D2 D3 P

Calculate signature of 32 byte ranges at 4+i×71, i = 5,…,20 sig1

14

Our algorithm

• Store data across

distributed system

• Challenge sites to prove

that they hold the data

• Sites respond with the

signatures of requested data

• Sites reveal tiny amount of

information: size of signature

• Challenger verifies that the

signatures are consistent

D1 D2 D3 P

Calculate signature of 32 byte ranges at 4+i×71, i = 5,…,20 sig1 sig2 sig3 sigp

14

Our algorithm

• Store data across

distributed system

• Challenge sites to prove

that they hold the data

• Sites respond with the

signatures of requested data

• Sites reveal tiny amount of

information: size of signature

• Challenger verifies that the

signatures are consistent

D1 D2 D3 P

sig1 sig2 sig3 sigp

14

Our algorithm

• Store data across

distributed system

• Challenge sites to prove

that they hold the data

• Sites respond with the

signatures of requested data

• Sites reveal tiny amount of

information: size of signature

• Challenger verifies that the

signatures are consistent

D1 D2 D3 P

sig1 ⊕ sig2 ⊕ sig3 ≟ sigP sig1 sig2 sig3 sigp

14

Collusion protection

D1 D2 D3

• Need for collusion protection
• All data and parity storing sites could collude to undetectably change the contents of data

(or just throw it away)

• Return signatures that are internally consistent
• Modify scheme to prevent collusion by:
• Using random m/n linear codes to generate parity blocks
• Blinding data or parity by XORing with pseudo-random stream
• Stream cipher seeded with block ID and secret known only to data owner

15

Collusion protection

D1 D2 D3 P1 P2

• Need for collusion protection
• All data and parity storing sites could collude to undetectably change the contents of data

(or just throw it away)

• Return signatures that are internally consistent
• Modify scheme to prevent collusion by:
• Using random m/n linear codes to generate parity blocks
• Blinding data or parity by XORing with pseudo-random stream
• Stream cipher seeded with block ID and secret known only to data owner

15

Collusion protection

D1 D2 D3 P1 P2 D1 D2 D3

• Need for collusion protection
• All data and parity storing sites could collude to undetectably change the contents of data

(or just throw it away)

• Return signatures that are internally consistent
• Modify scheme to prevent collusion by:
• Using random m/n linear codes to generate parity blocks
• Blinding data or parity by XORing with pseudo-random stream
• Stream cipher seeded with block ID and secret known only to data owner

15

Collusion protection

D1 D2 D3 P1 P2

random

D1 D2 D3 P1

• Need for collusion protection
• All data and parity storing sites could collude to undetectably change the contents of data

(or just throw it away)

• Return signatures that are internally consistent
• Modify scheme to prevent collusion by:
• Using random m/n linear codes to generate parity blocks
• Blinding data or parity by XORing with pseudo-random stream
• Stream cipher seeded with block ID and secret known only to data owner

15

Collusion protection

D1 D2 D3 P1 P2 D1 D2 D3 P1 P2

• Need for collusion protection
• All data and parity storing sites could collude to undetectably change the contents of data

(or just throw it away)

• Return signatures that are internally consistent
• Modify scheme to prevent collusion by:
• Using random m/n linear codes to generate parity blocks
• Blinding data or parity by XORing with pseudo-random stream
• Stream cipher seeded with block ID and secret known only to data owner

15

Blinding with a random stream

Data

Pseudo-random stream generator

16

• XOR data stream with a known pseudo-random stream
• Algebraic signature of blinded data is the XOR of the signature of

the original data and of the blinding stream

• Data owner need only keep the seed of the pseudo-random stream
• Reconstruct signature by recalculating stream

Blinding with a random stream

Data

Pseudo-random stream generator Seed1 Seed2

16

• XOR data stream with a known pseudo-random stream
• Algebraic signature of blinded data is the XOR of the signature of

the original data and of the blinding stream

• Data owner need only keep the seed of the pseudo-random stream
• Reconstruct signature by recalculating stream

Blinding with a random stream

Data

Pseudo-random stream generator Seed1 Seed2

Out

16

• XOR data stream with a known pseudo-random stream
• Algebraic signature of blinded data is the XOR of the signature of

the original data and of the blinding stream

• Data owner need only keep the seed of the pseudo-random stream
• Reconstruct signature by recalculating stream

Blinding with random stream

• Prevent colluding sites from discovering parity calculation

scheme by XORing blocks with pseudo-random data

• Several possibilities:
• Blind only parity
• Blind only data after calculating parity
• Calculate parity, then blind data and parity
• Blinding must be done after parity calculation
• Necessary to ensure that storage servers can’t solve for the

generator matrix

• Storage servers missing both pseudo-random stream and generator
• Blinding doesn’t prevent data recovery!
• Example: blinding just the parity means data can be read

17

Generating random m/n codes

• Linear m/n codes are defined over Galois field with 2f

elements

• Galois fields have addition, subtraction, multiplication,

division, 0, 1

• Same rules in Galois fields as for real, rational, complex, … numbers
• Code defined by a generator matrix G with m rows

and n columns

• G has special form ( Im | P )
• Im is the m×m identity matrix
• Every m×m submatrix of G is invertible

18

Generating random m/n codes

Vandermonde matrix Generator matrix

• Generation of generator matrix with n = 2f:
• Start with all 2f GF elements in a given order:

a1, a2, … an

• Order can be changed for a different code
• Form Vandermonde matrix
• Use Gaussian algorithm to transfer to desired form

19

Generating random m/n codes

• Given data bytes d1, d2, … dm, calculate parity bytes by:

(d1, d2, … dm)⋅G = (d1, d2, … dm, p1, p2, … , pk)

• Generate random code by starting with a random

permutation of the GF elements

• Pick a random code using a seed the data owner keeps
• If all sites collude:
• G can be reconstructed from known encoding
• This can be prevented if the sites don’t know the correct values
• f dx or px for the calculation
• Blinding ensures they don’t!

20

Securing a single site

• Use our scheme to secure data stored on a single site
• Can place all data and one or two parity chunks on a single site
• Single site cannot undetectably alter the contents
• Storage overhead can be made arbitrarily small
• Anyone knowing the erasure coding and the blinding scheme

can now check that the data is stored accurately

• May use any randomly-selected slice of the data
• Storage site can’t only keep data block hashes

21

Securing a single site

• Use our scheme to secure data stored on a single site
• Can place all data and one or two parity chunks on a single site
• Single site cannot undetectably alter the contents
• Storage overhead can be made arbitrarily small
• Anyone knowing the erasure coding and the blinding scheme

can now check that the data is stored accurately

• May use any randomly-selected slice of the data
• Storage site can’t only keep data block hashes

21

Example

• Create a backup peer-to-peer system
• Business model
• Clients
• Register with central site
• Clients pay annual registration fee
• Clients promise
• to store 10GB + ~2% on their computer
• to have their machine connected to the internet at least 20 hours every

24 hours

• Enterprise promises
• To establish an addressing scheme that allows clients to store data

remotely

• To verify that clients fulfill their promises

22

Example

• Use of our technique:
• Enterprise can verify that the data is stored correctly
• Client might encrypt data to prevent anyone else from

rebuilding it

• May use any desired encryption algorithm, as long as the parity is

calculated after encryption

• Blinding still has to be done...
• Signatures don’t leak much data anyway...
• Alternative
• Client that stores data also prepares a number of signature

challenges

• Client gives those to the enterprise
• Enterprise uses the challenge, but might run out of them

23

Future work

• Implementing a peer-to-peer backup system using this

approach

• Includes techniques from prior peer-to-peer backup systems
• Adds low-overhead verification
• Using this technique in POTSHARDS to verify that

remote servers are maintaining data

• Limited leakage is critical for this application
• Use this technique for storage service providers?

24

Conclusions

• We developed a scheme that can verify data stored on

storage sites outside of our administrative control

• Small challenges and responses
• Good for network load
• Limits information leakage to negligible sizes.
• Sufficient variety to force potential free-loaders to store the data

—not potential answers

• Secure against collusion
• Basic scheme for storage schemes that use parity or m/n

coding for high availability

• Extension to storing data on a single site
• Incurs arbitrarily small overhead from storing additional parity

data

25

Questions?

More information on the Web at http://www.ssrc.ucsc.edu/proj/archive.html Thanks to SSRC faculty, students, and sponsors!

26
