Legacy: informing future projects

1

Opportunities in Smart Grid Stewart Reid

Future Networks Manager

Legacy: informing future projects

Scottish and Southern Energy Power Distribution

• We own

–one electricity transmission network –two electricity distribution networks

• 106,000 substations
• 128,000 km of circuit
• 100+ submarine cable links
• across one third of the UK

landmass.

• Serving 3.5 million customers

Legacy: informing future projects

What are we trying to do in a Smarter way?

Energy Efficiency Asset Management Customer Service and connections Supply Reliability - Resilience

3

Legacy: informing future projects

Some Examples to get you thinking

Moving Demand New services for customers Storing Energy New market models Better modelling and predictions Using energy where it is created Optimising traditional systems

4

Legacy: informing future projects

Street based Energy Storage

5

Legacy: informing future projects

Phase Balance

them work ?

6

Legacy: informing future projects

Managing Demand Side Management

7

Legacy: informing future projects

Default water temperature

Water Temperature = 60 °C Energy Stored = 9 kWh Available Energy storage = 4 kWh

Maximum water temperature

Water temperature = 80 ° C Energy Stored = 13 kWh Available Energy Storage = 0 kWh

Water Cylinders

If all water tanks on Shetland converted then 2.5MW of control

• n island 25% of

summer demand If all domestic tanks in UK 6GW

Legacy: informing future projects

Commercial premises ADR with Honeywell.

1st ADR Event @ Honeywell House Aggregated Load Shed – Bracknell & Wokingham College Aggregated Load Shed – Bracknell Forest Council Aggregated Load Shed – Honeywell House

Legacy: informing future projects

+

• +
• +
• +
• +
• +
• +
• +
• +
• +
• +
• +
• 8+ regulated projects

Northconnect Offshore Renewables

Multi Terminal Test Environment for HVDC

Legacy: informing future projects

My Electric Avenue (I2EV)

11

Legacy: informing future projects

How would a DNO model the future loading of the low voltage network?

• DNOs understand that:
• Customers are different
• The use of ADMD may not be appropriate in the future
• Grouping customers by energy profile may be more relevant
• Large amounts of data may be required

S/S

Customer ADMD 1 Customer ADMD 1 Customer ADMD 1 Customer ADMD 1 Customer ADMD 1 300 wavecon 185 wavecon 185 wavecon 185 wavecon 95 wavecon

Legacy: informing future projects

Data Analytics and forecasting techniques

13

Legacy: informing future projects

Thank you

• More information at:

http://www.ssepd.co.uk/HaveYourSay/Innovation/Portfolio/
