WECC Board Technical Session

March 5, 2019

Steve Ashbaker

Reliability Initiative Director

RC Footprints

2

Board RC Technical Session

• Reliability Coordination Tools
• Wide-Area Model
• Seams Issues
• RC Shadow Operations
• Outage Coordination
• RC Certification

3

RC Tools

• WECC Interchange Tool (WIT)
• Enhanced Curtailment Calculator (ECC)
• Reliability Messaging Tools

4

WECC Interchange Tool (WIT)

• WIT Governance
• Multi-RC Access
• WIT Administrator Duties (SPP & CAISO)
• Month-end Interchange Reconciliation
• Inadvertent Dispute tracking (NERC and PII)
• Perform NERC CERT monthly lockdown
• WIT Delta Time Error (CAISO)

5

WIT Architecture

6

WIT

BAs OATI NAI/NSI

(via EIDE)

Schedules

(via e-Tags)

Peak DTE

(primary)

WAPA DTE

(BU1)

AVA DTE

(BU2)

NERC CERTS

(EPG tool – manual)

WREGIS

(WECC–specific PSE/MISC info combo) EIDE EIDE Primary = BU1/BU2 OR requires manual action

Variable Bias

(3 entities via EIDE)

Enhanced Curtailment Calculator

• ECC manages congestion on USF Qualified

Paths and provides situation awareness

• CAISO provide WI model and State Estimation

data to OATI

• USFMP Step 4 implementation
• CAISO manages Path 66 (COI)
• SPP manages Paths 30, 31, 36
• ECC Governance (Funding, Change Orders)
• CAISO holds OATI Contract
• Multi-RC Access

7

ECC Inputs / Outputs

E-Tags State Estimator

Base Data

ECC Engine

Elements

SCADA WSM Model Contingencies

USF Curtailments Situational Awareness

ECC Congestion Management

9

RC Messaging Tools

• RC to RC communication via RCIS (NERC

hosted RC messaging tool)

• SPP has developed their own messaging tool

for BA/TOPs

• Peak is staying with RMT for their BA/TOPs
• CAISO has developed their own messaging

tool for their BA/TOPs (GMS)

10

RC Messaging Tools

11

Peak RMT TOP/ BA MAP/ USF SPP AESO BCH RC West GMS SPP TOP/ BA MAP/ USF TOP/ BA USF

API

Current ICCP Data Sharing

12

Future ICCP Data Sharing

13

WECC Board Technical Session

March 5, 2019

Brett Wangen

Vice President GridSME

Western Interconnection Model

Model must support

• Interconnection-

wide situational awareness/analysis

• Static (Power

Flow) studies

• Dynamic

(Transient) studies Key objectives

• Preserve the value
• f the West-wide

System Model

• Enable efficient

model sharing

• Common model

used by all RCs

15

IRO-002-5 WECC Variance

Common modeling and monitoring methodology for all RCs in the West, including methods for:

• Development, maintenance, and periodic review of

Western Interconnection model

• Assessment of inter-area oscillation impacts
• Determining Contingencies to include in analyses and

assessments

• Determining Remedial Action Schemes to include in

analyses and assessments

• Determining forecast data to include in analyses and

assessments

• Validation and periodic review of the model

16

Model Maintenance

17

AESO BAs/TOPs AESO RC BC Hydro BAs/TOPs BC Hydro RC SPP BAs/TOPs SPP RC CAISO BAs/TOPs CAISO RC CAISO Western Interconnection Model Export Process BAs, TOPs, RCs Note: this is illustrative; all RCs share among themselves CIM

Model Update Coordination

Each RC has authority to collect necessary model data through NERC standard IRO-010-2

• How often are updates available?
• How much advanced notice?
• What is modeled during construction?
• Exchangeable formats?
• What does IRO-002-5 variance

methodology say?

18

Remedial Action Schemes

RAS Modeling

• RAS data sharing

(TOP->RC, RC->RC)

• Identifying BES

impactful RAS

• Understanding

RAS interactions Monitoring RAS Impacts

• SCADA (ICCP

points, visualization)

• Alarming
• Real-time

Contingency Analysis

19

Seams Issues

20

Restoration

21

• Each BA and/or TOP must still have emergency
• perations plan (EOP-011-1)
• Identify blackstart generators
• Identify cranking paths
• Each RC will have an RC Area restoration plan (EOP-

006-2)

• Restoration training
• Coordination
• Simulation
• Operating Instructions
• RC-to-RC coordination and communication will be

critical during restoration or other emergencies

Outage Coordination

• IRO-017-1

requires each RC to have an

• utage

coordination process

• Outage data,

approvals, study expectations, and coordination

22

CAISO OMS SPP Outages BC Hydro Outages AESO Outages CAISO Outages GridForce Outages

System Balancing

Frequency ACE Reserves

23

• Each RC will monitor

ACE and frequency for all BAs

• Reserve Sharing Groups

span multiple RCs in some cases

• Coordinated operating

procedures will be critical

Unscheduled Flow

• Western Interconnection Unscheduled Flow

Mitigation Plan (WIUFMP)

• Coordinated Operations of Phase Shifters

(COPS)

• Curtailments
• Enhanced Curtailment Calculator
• Each RC participating in unscheduled flow

management must analyze the system to assess potential impact to its own system.

24

SOL/IROL Methodology

• Each RC required to have SOL methodology

for operations horizon (FAC-011-3)

• Defines SOL and IROL
• Defines acceptable system operations within SOLs

and IROLs

• Mitigation expectations
• RCs are coordinating on future SOL

methodology documents—consistency is goal

• Identify differences compared to Peak’s SOL

methodology and present to the group

25

Shadow Operations

• Each RC taking two months (or more) for

Shadow Operations

• Tools, data, models
• Procedures, studies, real-time coordination
• Each RC developing training prior to entering

Shadow Operations

• RC of record for an area always will have

authority

26

RC Certification

March 5, 2019

Tim Reynolds

• Sr. Reliability Engineer

Certification Process Overview

Pre- Certification

• Application
• WECC

reviews application for completeness and applicability

• WECC

notifies NERC

• f application

Planning

• Establish

Certification Team

• Certification

Scope

• Establish
• nline portal

to share documents

• Develop and

Send Certification Packet On-Site Visit

• Opening

Presentations

• Review

documents

• Interview

management and operators

• Tour the

facilities

• Bucket Items
• Exit

Presentation Reporting

• Create action

list of Bucket Item

• Draft Final

Report

• Approval

from Regional and NERC Management Data Retention

• Documents

retained for six years

• Final Report

posted on NERC’s website

28

Planning

• RC Certification Team
• An existing RC, a BA and a TOP in the

proposed RC area, each affected RE, and NERC

• Team Member Must Complete Training
• Certification Packet
• Logistical Information
• Master Matrix
• Requests for additional information

29

On-Site Visit

• At a minimum, the team will:
• Review documents and data with the entity
• Interview the operations and management

personnel

• Inspect the facilities and equipment
• Request demonstration of tools
• Review any additional documentation

resulting from inquiries arising during the site-visit

• Bucket Items

30

Reporting: The Final Steps

• Bucket 1 & 2 items will be on Final

Report

• Final Report approved by WECC/NERC

management

• Registration process can be completed

31

RC Certification Timelines

32

Dashboard

• Track RC Certification

https://www.wecc.org/EventAnalysisSituationalAwar eness/Pages/Certification.aspx

33

Contact:

Steve Ashbaker - sashbaker@wecc.org Tim Reynolds - treynolds@wecc.org Brett Wangen - bwangen@gridsme.com
