Sparkmap Marsil Zakour, Sebastian Schlegel, Vladimir Yugay Technical University of Munich Department of Mathematics Data Innovation Lab Garching, 18. February 2020 Agenda Introduction & Objectives Related work Dataset

slide-1
SLIDE 1

Sparkmap

Marsil Zakour, Sebastian Schlegel, Vladimir Yugay Technical University of Munich Department of Mathematics Data Innovation Lab Garching, 18. February 2020

slide-2
SLIDE 2

Agenda

  • Introduction & Objectives
  • Related work
  • Dataset
  • "Feature Vector" Approach
  • Solution
  • Segmentation Network
  • Room Proposal Extraction
  • Algorithm for placing icons
  • Results
  • Conclusion & limitations
slide-3
SLIDE 3

Sebastian Schlegel

For a lot of simple architectural tasks a person is needed One reason: Used data in the form of rasterized floorplan images

Introduction & Objectives

3

Kitchen Living room Bed- room Bath

slide-4
SLIDE 4

Sebastian Schlegel

Introduction & Objectives

4

Kitchen Living room Bed- room Bath For a lot of simple architectural tasks a person is needed One reason: Used data in the form of rasterized floorplan images Goal of this Project: To place icons (furniture, facilities) on an "empty" floorplan

slide-5
SLIDE 5

Sebastian Schlegel

Related work – Liu et al. 2017

5

A multi-step process using a convolutional neural network (CNN) for automatically parsing rasterized floorplan images Approach:

CNN

slide-6
SLIDE 6

Sebastian Schlegel

Related work – Liu et al. 2017

6

A multi-step process using a convolutional neural network (CNN) for automatically parsing rasterized floorplan images Approach:

  • Extracting geometric and semantic information independently
  • M

geometries semantics

CNN

slide-7
SLIDE 7

Sebastian Schlegel

Related work – Liu et al. 2017

7

A multi-step process using a convolutional neural network (CNN) for automatically parsing rasterized floorplan images Approach:

  • Extracting geometric and semantic information independently
  • Merging both rule-based using Integer Programming
  • M

geometries semantics

CNN

Integer Programming

slide-8
SLIDE 8

Sebastian Schlegel 8

Geometric information is represented through "junction points"

  • 4 different junctions for "openings" (windows, doors):

Related work – Liu et al. 2017

slide-9
SLIDE 9

Sebastian Schlegel 9

Geometric information is represented through "junction points"

  • 4 different junctions for "openings" (windows, doors):
  • 4 different junctions for icons:

Related work – Liu et al. 2017

slide-10
SLIDE 10

Sebastian Schlegel 10

Geometric information is represented through "junction points"

  • 4 different junctions for "openings" (windows, doors):
  • 4 different junctions for icons:
  • 13 different junctions for walls:

In total: 21 different junction types

Related work – Liu et al. 2017

slide-11
SLIDE 11

Sebastian Schlegel 11

Network (modified ResNet 152) output: Geometric information:

  • 21 heatmaps – one regressed for every junction type

Related work – Liu et al. 2017

slide-12
SLIDE 12

Sebastian Schlegel 12

Related work – Liu et al. 2017

Network (modified ResNet 152) output: Geometric information:

  • 21 heatmaps – one regressed for every junction type

Semantic information:

  • One per-pixel classification for room types
slide-13
SLIDE 13

Sebastian Schlegel 13

Related work – Liu et al. 2017

Network (modified ResNet 152) output: Geometric information:

  • 21 heatmaps – one regressed for every junction type

Semantic information:

  • One per-pixel classification for room types
  • One per-pixel classification for icons, windows & doors
slide-14
SLIDE 14

Sebastian Schlegel

Related work – Kalervo et al. 2019 ("CubiCasa")

14

Modifying the approach of Liu et al. Differences:

  • Applying automatic weighting to the multi-task CNN of Liu et al.
  • Instead of Integer Programming a heuristic is used for merging

geometries semantics

CNN

Heuristic

slide-15
SLIDE 15

Sebastian Schlegel

Related work – Kalervo et al. 2019 ("CubiCasa")

15

Merging geometric and semantic information

  • Split floorplan in a grid of rectangular cells using triplets
  • f Junction points
slide-16
SLIDE 16

Sebastian Schlegel

Related work – Kalervo et al. 2019 ("CubiCasa")

16

Merging geometric and semantic information

  • Split floorplan in a grid of rectangular cells using triplets
  • f Junction points
  • Label cells applying pixel-wise maximum voting
slide-17
SLIDE 17

Sebastian Schlegel

Related work – Kalervo et al. 2019 ("CubiCasa")

17

Merging geometric and semantic information

  • Split floorplan in a grid of rectangular cells using triplets
  • f Junction points
  • Label cells applying pixel-wise maximum voting
  • Merge cells with the same label if no separating wall is

in between

slide-18
SLIDE 18

Agenda

  • Introduction & Objectives
  • Related work
  • Dataset
  • "Feature Vector" Approach
  • Solution
  • Segmentation Network
  • Room Proposal Extraction
  • Algorithm for placing icons
  • Results
  • Conclusion & limitations
slide-19
SLIDE 19

Vladimir Yugay

CubiCasa Dataset

19

Model

slide-20
SLIDE 20

Vladimir Yugay

CubiCasa input

20

slide-21
SLIDE 21

Vladimir Yugay

CubiCasa model generalization

21

Model

slide-22
SLIDE 22

Vladimir Yugay

CubiCasa model evaluation

22

slide-23
SLIDE 23

Vladimir Yugay

CubiCasa label

23

slide-24
SLIDE 24

Vladimir Yugay

Input generation

24

slide-25
SLIDE 25

Vladimir Yugay

Label generation

25

slide-26
SLIDE 26

Vladimir Yugay

Input generation

26

slide-27
SLIDE 27

Vladimir Yugay

Input generation

27

slide-28
SLIDE 28

Vladimir Yugay

Dataset randomization

28

  • Each image has a random texture
  • Each text annotation has a random font size, weight and family
  • Each text annotation is rotated from 0 to 11 degrees
slide-29
SLIDE 29

Vladimir Yugay

Dataset statistics

29

  • Number of room types were reduced from 65 to 8
  • Only rooms with kitchen and bathroom were kept
  • In total 1881 images split in 1281/300/300 as train/validation/test
slide-30
SLIDE 30

Marsil Zakour

  • Geometrical features (i.e. walls) are invariant to

text removal

  • Detect Rooms, and Find their types using walls.

Feature Vector Approach – Reusing Trained Model

30

Type IOU (Text) IOU (No Text) Wall 65.5% 64% Kitchen 63.9% 50.6% Living Room 73.1% 24.8%

slide-31
SLIDE 31

Marsil Zakour

Feature Vector Approach – Building a Graph

31

slide-32
SLIDE 32

Marsil Zakour

  • What Set of nodes makes a room.
  • Wall Features:
  • Geometrical
  • Relational
  • Room Features:
  • Aggregation/summary of walls features.
  • Or better use Graph Convolutions

Feature Vector Approach – Features

32

Wall features height width # rooms # walls

slide-33
SLIDE 33

Marsil Zakour

Why we Stopped:

  • Rooms are not only cycles
  • More support for segmentation than for GCNs

Feature Vector Approach - Stop

33

slide-34
SLIDE 34

Agenda

  • Introduction & Objectives
  • Related work
  • Dataset
  • "Feature Vector" Approach
  • Solution
  • Segmentation Network
  • Room Proposal Extraction
  • Algorithm for placing icons
  • Results
  • Conclusion & limitations
slide-35
SLIDE 35

Vladimir Yugay

Solution

35

Room type segmentation Room polygons Openings information Classified polygons Icon placement

slide-36
SLIDE 36

Vladimir Yugay

Segmentation network details

36

  • U-Net architecture
  • ResNet as a backbone
  • 25 millions of parameters
  • Dice loss
slide-37
SLIDE 37

Vladimir Yugay

Segmentation network

37 Segmentation Network Prediction tensor Label tensor

slide-38
SLIDE 38

Vladimir Yugay

Room type segmentation

38 Input image Predicted image Label image

slide-39
SLIDE 39

Vladimir Yugay

Openings segmentation

39 Input image Predicted image Label image

slide-40
SLIDE 40

Marsil Zakour

Room Proposals – New Formulation

40

Input Proposals

slide-41
SLIDE 41

Marsil Zakour

Room Proposals - Training

41

slide-42
SLIDE 42

Marsil Zakour

Room Proposals – Qualitative Results

42

Room Proposal Qualitative Results Labels Predictions Inputs

slide-43
SLIDE 43

Marsil Zakour

Predictions Fusion - Input

43

input Room Proposal Room Type

slide-44
SLIDE 44

Marsil Zakour

Predictions Fusion - Voting and Inpaint

44

Align Vote Inpaint

slide-45
SLIDE 45

Marsil Zakour

Predictions Fusion - Extract Polygons

45

Extract Polygons Polygons types

slide-46
SLIDE 46

Marsil Zakour

Predictions Fusion - Extract Polygon cont.

46

1 2 1 (0,0) - (5,5) y x (0,0) - (3,5) (3,0) - (5,5) (3,0) - (3,4) (3,4) - (5,5) X <= 3 X > 3 y <= 4 y > 4 1,1,… 2,2,… (0,0) (5,5)

slide-47
SLIDE 47

Marsil Zakour

Predictions Fusion - Example

47

slide-48
SLIDE 48

Sebastian Schlegel

Algorithm for placing icons

48

Kitchen Living room Bed- room Bath The task of placing icons is rule-based:

  • "don´t place an icon in front of a door"
  • "place a bath tube in a bath"
  • …
slide-49
SLIDE 49

Sebastian Schlegel

Algorithm for placing icons

49

Kitchen Living room Bed- room Bath The task of placing icons is rule-based:

  • "don´t place an icon in front of a door"
  • "place a bath tube in a bath"
  • …

"creative" (inconclusive):

  • There is not one optimal solution
  • Multiple constellations are possible
  • "Best choice" can depend on "taste" of a person
slide-50
SLIDE 50

Sebastian Schlegel

Algorithm for placing icons

50

Information used for placing icons:

  • Geometry of a room
  • Type of a room
  • Location of windows and doors

bed bedside table window door

slide-51
SLIDE 51

Sebastian Schlegel

Algorithm for placing icons

51

Information used for placing icons:

  • Distance from wall
  • If pixel in corner
  • Dist. From window
  • Dist. from door
slide-52
SLIDE 52

Sebastian Schlegel

Algorithm for placing icons

52

Information used for placing icons:

  • Distance from wall
  • If pixel in corner
  • Dist. from window
  • Dist. from door
  • Dist. from icon – long side
  • Dist. from icon – short side
  • eucl. Dist. from icon edge
slide-53
SLIDE 53

Sebastian Schlegel

Algorithm for placing icons

53

Information used for placing icons:

  • Distance from wall
  • If pixel in corner
  • Dist. from window
  • Dist. from door
  • Dist. from icon – long side
  • Dist. from icon – short side
  • eucl. Dist. from icon edge

One distance vector for every pixel

slide-54
SLIDE 54

Sebastian Schlegel

Algorithm for placing icons

54

Rules for placing icons: Implemented through a weighting vector

  • Weights can be positive (minimize dist.)
  • Or negative (maximize dist.)

weighting vector

slide-55
SLIDE 55

Sebastian Schlegel

Algorithm for placing icons

55

Rules for placing icons: Implemented through a weighting vector

  • Weights can be positive (minimize dist.)
  • Or negative (maximize dist.)

distance vector weighting vector

slide-56
SLIDE 56

Sebastian Schlegel

Algorithm for placing icons

56

Rules for placing icons: Implemented through a weighting vector

  • Weights can be positive (minimize dist.)
  • Or negative (maximize dist.)

distance vector weighting vector

Value for each pixel

slide-57
SLIDE 57

Sebastian Schlegel

Algorithm for placing icons

57

Rules for placing icons: Implemented through a weighting vector

  • Weights can be positive (minimize dist.)
  • Or negative (maximize dist.)
  • Additional conditions e.g.:
  • Placing "dummies" between icons allows for more

complex constellations

distance vector weighting vector

Value for each pixel

slide-58
SLIDE 58

Sebastian Schlegel

Algorithm for placing icons

58

Searching for best icon spots: Grid search over every possible icon spot

  • An area value is calculated for every spot
slide-59
SLIDE 59

Sebastian Schlegel

Algorithm for placing icons

59

Searching for best icon spots: Grid search over every possible icon spot

  • An area value is calculated for every spot
slide-60
SLIDE 60

Sebastian Schlegel

Algorithm for placing icons

60

Searching for best icon spots: Grid search over every possible icon spot

  • An area value is calculated for every spot
  • Repeated for icon being rotated by 90 degrees
slide-61
SLIDE 61

Sebastian Schlegel

Algorithm for placing icons

61

Searching for best icon spots: Grid search over every possible icon spot

  • An area value is calculated for every spot
  • Repeated for icon being rotated by 90 degrees
slide-62
SLIDE 62

Sebastian Schlegel

Algorithm for placing icons

62

Searching for best icon spots: Grid search over every possible icon spot

  • An area value is calculated for every spot
  • Repeated for icon being rotated by 90 degrees

Random factor for higher variability

  • Small random value for every area to randomly pick
  • ne of the optimal spots
slide-63
SLIDE 63

Sebastian Schlegel

Algorithm for placing icons

63

Searching for best icon spots: Grid search over every possible icon spot

  • An area value is calculated for every spot
  • Repeated for icon being rotated by 90 degrees

Random factor for higher variability

  • Small random value for every area to randomly pick
  • ne of the optimal spots
  • Order in which icons are placed is randomly, taking

rules into account (e.g. place chair after table)

slide-64
SLIDE 64

Sebastian Schlegel

Algorithm for placing icons

64

"Learning of rules":

  • Rules were first set due to common sense
  • Rules were fine-tuned according to feedback
  • Outlook: learn user preferences in a loop of human-

machine-interactions

slide-65
SLIDE 65

Sebastian Schlegel

Results

65

slide-66
SLIDE 66

Sebastian Schlegel

Conclusion & Limitations

66

Initial goals were met Limitations:

  • Room segmentation can´t tolerate text rotated by 90 degrees
  • Room proposal heavily depends on good proposals segmentation
  • Icon placing faces problems when dealing with complex room shapes
slide-67
SLIDE 67

Backup

67

slide-68
SLIDE 68
  • Dr. rer. nat. Erika Mustermann (TUM) | kann beliebig erweitert werden | Infos mit Strich trennen

Computer-based processing of floorplan images is well researched in pattern regocnition Early approaches mainly rely on low-level image processing heuristics:

  • Separating textual data from graphical
  • Detecting and grouping lines
  • Overcoming gaps through polygonal approximation or edge-linking

To increase performance, recent works applied deep convolutional neural networks (CNNs)

68

Related work – early approaches

slide-69
SLIDE 69
  • Dr. rer. nat. Erika Mustermann (TUM) | kann beliebig erweitert werden | Infos mit Strich trennen

69

Merging geometric and semantic information applying predefined constraints 5 different constraints

  • e.g. loop constraint

− High level: exterior boundary of a room must form a closed loop − Enforced locally: For each pair of walls the room type must be the same Constraints are applied using Integer programming Result: performance – especially for geometries – increases significantly

Related work – Liu et al. 2017

slide-70
SLIDE 70

Sebastian Schlegel

Performance

70

Related work – Liu et al.

slide-71
SLIDE 71

Sebastian

Performance

71

Related work – Kalervo et al.

slide-72
SLIDE 72

Marsil Zakour

Rotated Input

72

slide-73
SLIDE 73

Marsil Zakour

(image from https://datawarrior.wordpress.com/2018/08/08/graph-convolutional-neural- network-part-i/)

Graph Convolutional Networks (GCNs)

73

slide-74
SLIDE 74
  • Dr. rer. nat. Erika Mustermann (TUM) | kann beliebig erweitert werden | Infos mit Strich trennen

F1-loss

74

slide-75
SLIDE 75

Marsil Zakour

Voting

75

slide-76
SLIDE 76

Vladimir Yugay

U-Net

76

Olaf Ronneberger, Philipp Fischer, and Thomas Brox. U-net: Convolutional networks for biomedical image segmentation, 2015.

slide-77
SLIDE 77

Vladimir Yugay

ResNet

77

Kaiming He, Xiangyu Zhang, Shaoqing Ren, and Jian Sun. Deep residual learning for image recognition, 2015.

slide-78
SLIDE 78

Vladimir Yugay

Dice Loss

78

Dice loss
