Spark

Marco Serafini

COMPSCI 532 Lecture 4

33

Goals

• Support for iterative jobs
• Reuse of intermediate results without writing to disk
• Lineage-based fault tolerance
• Does not require checkpointing all intermediate results

4

Resilient Data Sets

• Collection of records (serialized objects)
• Read-only
• Created through deterministic transformations from
• Data in storage
• Other RDDs
• Lineage of an RDD
• Sequence of transformations that create it
• Replayed (in parallel) from persisted data to recreate lost RDD
• Caching an RDD: keeping it in memory for later

55

Spark terminology

• Driver
• Process executing the application code
• Sends RDD transformations and actions to workers
• Workers
• Host partitions of RDDs
• Execute transformations

66

More Terminology

• Task
• Unit of work that will be sent to one executor
• Partition of fundamental operator, such as Map and Reduce
• Stage
• Set of parallel tasks one task per partition
• Can include multiple pipelined tasks with no shuffling
• Job
• Parallel computation consisting of multiple stages
• Spawned in response to an action

77

More terminology

• Shuffle
• Data transfer among workers
• Partition
• Worker thread
• Transformation
• Function that produces new RDD but no output
• Lazily evaluated
• Actions
• Function that returns output
• Triggers evaluation

88

Spark API

99

Spark Computation

• Driver executes application code
• Workers execute only transformations
• Driver sends closure to workers
• Lazy evaluation
• Driver records transformations without

executing them

• It builds a a Directed Acyclic Graph (DAG)
• f transformations
• Execute only as needed when output

(action) required

10

10

Closures

• Driver serializes functions to be executed by workers
• It computes a “closure” and sends it to the workers
• Closure includes all objects referenced by the function
• Careful with references! Or you might send huge closures

11

11

Narrow vs. Wide Operators

• Narrow dependency
• Executes on data local to the same worker
• Can be pipelined locally
• Faster recovery (only local re-execution needed)
• Example: map à filter
• Wide dependency
• Requires a shuffle, which marks the end of a stage
• Complex recovery (multi-worker)
• Example: map à groupByKey (if don’t partition by that key)

12

12

Checkpoints and Partitioning

• Partitioning function declared when RDD created
• Checkpointing
• Speeds up recovery of lineage
• When to checkpoint is left to the user
• Checkpoint is stored (replicated) on file system

13

13

PageRank Example

14

14

Questions

• Which intermediate RDDs are created?
• Stages? Narrow/wide operators?
• How to reduce shuffling?
• Lineage graph

15

15

Lineage Graph
