Solid Waste Materials Management

Israel’s Solid Waste Revolution

Naama Ashur Ben Ari – Director, Solid Waste Division November 2012

Ministry of Environmental Protection

4.8 million tons

Quantity of municipal and commercial solid waste generated in Israel per year

2 million tons

Quantity of biodegradable solid waste

1.9 kilograms

Quantity of solid waste per person per day

Increase of 3%-5%

in the annual quantity of solid waste

Israel 2012

100 200 300 400 500 600 700 800 900 C H N C Z E S V K P O L C H L M E X K O R C A N J P N Z A F T U R S V N R U S E S T G R C H U N P R T B E L F I N E U 2 7 S W E F R A I T A I S L O E C D G B R D E U E S P A U T I S R N L D L U X C H E U S A I R L D N K N O R

High international ranking

Kilograms per capita per year

EU 27 OECD Israel USA

Source: OECD 2010

Landfilling

Past Policy

Change of concept – solid waste as a raw material

Hazards of continued landfilling:

 Air pollution and odor  Greenhouse gas emissions  Soil and groundwater contamination  Consumption of scarce land resources  Effects on public health  Economic implications

Availability of landfills and treatment of solid waste up to 2030

Existing situation



Indications are that in the existing situation, the solid waste market will become saturated already in 2014, with no solution for 14% of the quantity

• f generated solid waste.
• 20

20 40 60 80 100 120

2011 2012 2013 2014 2015 2016 2017 2018 2019 2020 2021 2022 2023 2024 2025 2026 2027 2028 2029 2030

הנמטהל תלוספ זוחא יללכ רוזחימ זוחא ו הנמטה ןורתפ אלל תלוספ זוחא/רוזחימ וא

Percentage of solid waste for landfilling Percentage of general recycling Percentage of solid waste with no landfilling

• r recycling solution

Solid waste treatment methods in Western countries

Source: OECD 2008

Solid Waste Materials Management

Current Policy

Materials management – integrated treatment of solid waste

Landfilling Energy Recycling Reuse Reduction

Production of energy from solid waste or processing of solid waste into materials used to produce energy Reduction in the quantity

• f solid waste generated

Processing of solid waste into products, materials

• r raw materials

The target:

50% recycling by 2020

Reducing the quantity of solid waste destined for landfilling by:

 SMM – Sustainable Materials Management  Urban Mining

The key to the recycling revolution - Separation of solid waste into at least two streams

Biodegradable solid waste as a clean solid waste stream that should be separated at source

Biodegradable solid waste

Leftover food and

• rganic components

40%

Dry waste

Packaging and other materials

60%

Paper and cardboard Packaging

For each stream – its own dedicated treatment

Wet stream

Biodegradable organic solid waste

Dry stream

Packaging and other materials Transfer station for solid waste sorting Solid waste recycling plant

12

Biodegradable solid waste treatment plant

Anaerobic plant Composting facility

Transfer station for solid waste sorting

Separation at source – how does it work in the local authorities?

Recycling points Transportation of separated solid waste Collection bins

For each stream – its own dedicated treatment

Treatment of Biodegradable Solid Waste

Local authorities selected to receive support

A total of 31 local authorities were selected

Breakdown of types of support to the selected authorities

Total support: NIS 342,370,399

Residents’ participation in separation at source in the selected authorities

187,298 4,100 25,555 119,429 44,443 52,199

At present 96,161 households separate their solid waste at source. By the end of the year, another 24,848 households are expected to join the process.

Selected authorities that joined the process of separation at source

Name of authority District Amount of support Number of households that joined the separation process Dimona South NIS 10,581,438 Beersheba NIS 66,226,057 Ashkelon NIS 28,456,295 Ofakim NIS 6,917,171 1,517 Ramat Negev NIS 1,587,871 320 Ashdod NIS 54,694,821 4,000 Sdot Negev NIS 970,388 Kiryat Bialik Haifa NIS 9,358,268 4,800 Zichron Yaacov NIS 4,029,805 2,500 Hadera NIS 17,922,525 7,170

Selected authorities that joined the process of separation at source

Name of authority District Amount of support Number of households that joined the separation process Gush Etzion Jerusalem NIS 4,289,911 1,000 Kfar Saba Center NIS 13,391,517 9,700 Modiin Maccabim Reut NIS 11,567,996 10,800 Emek Hefer NIS 5,627,318 12,700 Hod Hasharon NIS 7,591,710 4,500 Brener NIS 1,383,451 2,240 Shoham NIS 3,161,126 5,000 Rosh Haayin NIS 6,584,388 1,800 Nes Ziona NIS 7,399,541 5,200 Ramla NIS 18,152,666 4,135

Name of authority District Amount of support Number of households that joined the separation process Yokneam Ilit North NIS 4,584,900 2,320 Migdal Haemek NIS 4,262,052 1,932 Rosh Pina NIS 699,075 263 Megiddo NIS 2,943,175 1,166 Misgav NIS 5,758,754 2,500 Gilboa NIS 4,408,484 Mateh Asher NIS 8,367,739 1,800 Afula NIS 9,556,860 3,036 Golan NIS 6,011,305 462 Kiryat Ono Tel Aviv NIS 7,257,041 1,800 Ramat Hasharon NIS 8,581,750 3,500

Selected authorities that joined the process of separation at source

A total of 96,161 households separate at source.

Additional authorities that joined the process of separation at source

Name of authority District Number of households that joined the separation process Menashe Regional Council Haifa 1,500 Hof Hacarmel Regional Council Haifa 517 Natania Center 3,500 Raanana Center 9,000 Savyon Center 1,200 (the entire authority) Yavneh Center 300 Bat Yam Tel Aviv 3,000 Ramat Gan Tel Aviv 2,200 Tel Aviv Tel Aviv 2,500

A total of 23,717 households separate at source.

Current situation: Separation at source in the local authorities

 Preparation of master plan and detailed plan for two

streams

 Thirty one local authorities are beginning a process of

separation of solid waste at source

 Contract with an end facility  Purchase of bins for sorting the waste into two streams  Purchase of trucks for collecting solid waste that was separated at

source

 Renovation and adaptation of garbage rooms and surfaces

in residential buildings

 Local activity to advertise, explain and educate  Operational assistance in the transition to separating the

waste at source plus other assistance

 Collection of solid waste in two separate streams – biodegradable

(“wet”) and dry

Construction and upgrade of facilities for the production

• f green electricity from solid waste

Anaerobic digestion facilities

Production of energy from biogas

Composting plants

Addition of land for agriculture

Assumptions:

• 1. Three percent annual increase in solid waste quantities, with each person generating around 1.9 kilograms per day.
• 2. The quantity of organic solid waste is calculated at 30% of the total quantity of generated solid waste.

District Total quantity of solid waste (ton/day) 2012 Quantity of

• rganic solid

waste (ton/day) 2012 Total quantity of solid waste (ton/day) 2015 Quantity of

• rganic solid

waste (ton/day) 2015 Total quantity of solid waste (ton/day) 2020 Quantity of

• rganic solid

waste (ton/day) 2020 Northern District 2,551 765 2,788 836 3,232 970 Haifa District 1,822 546 1,990 597 2,308 692 Central District 3,996 1,199 4,367 1,310 5,063 1,519 Tel Aviv District 2,588 776 2,827 848 3,278 983 Jerusalem District 2,184 655 2,387 716 2,767 830 Southern District 2,200 600 2,404 721 2,787 836 Total 15,341 4,601 16,763 5,028 19,435 5,830

Data on quantities of solid waste in Israel

Segmenting by streams and assessments, 2012-2020

District Organic material generated (ton/day) 2015 Organic material – selected local authorities (ton/day) 2015 Capacity – existing end solutions (ton/day) 2015 Capacity – end solutions per RFI (ton/day) Treatment volume (ton/day) 2015 North 836 111

• 560

560 Haifa 597 94 5 100 105 Center 1,310 263 250 140 440 Tel Aviv 848 46 50

• Jerusalem

716 10 125

• 500

South 721 374 250 968 1,218 Total 5,029 900 690 1,768 2,823

Data on quantities of solid waste in Israel

Capacity analysis of treatment facilities, 2015

Summary Support for construction / upgrade of facilities for the production of electricity from solid waste and for Transfer Stations

District Number of Facilities for the production of electricity from Solid waste Number of Transfer Stations North 4 3 Haifa 1 1 Center 2 1 Jerusalem 1 South 5 4 Total 12 10

Total Support

• facilities for the production of electricity from solid waste: 118,735,050 NIS
• Transfer Stations: 139,133,391 NIS

Applicant Quantity of municipal organic solid waste per day Type of facility Amount of support SDM for the Environment

• Ltd. – Evlayim

200 tons Open aerated composting facility NIS 1,775,000 Afula Municipality 160 tons Closed composting facility NIS 7,287,700 Univerve Energy Ways Biogas Ltd. – Dimona 60 tons Energy production facility NIS 5,400,000 Univerve Energy Ways Biogas Ltd. – Dimona 100 tons Energy production facility NIS 9,960,000 Evron – Tamam Recycling Limited Partnership 200 tons Energy production facility NIS 17,200,000 Hadera Municipality 100 tons Energy production facility NIS 9,180,000

Support for construction / upgrade of facilities for the production of electricity from solid waste

Applicant Quantity of municipal organic solid waste per day Type of facility Amount of support Bnei Shimon Regional Council 620 tons Closed composting facility NIS 24,417,400 Compost Bay and Western Galilee 350 tons Closed composting facility NIS 11,901,618 YRAV Sherutei Noy (1985) Ltd. 200 tons Electricity production facility NIS 17,200,000 Eco Energy Golan Ltd. 50 tons Upgrade of electricity production facility NIS 6,385,350 Tambour Hefer Ecology 40 tons Energy production facility NIS 5,336,600 Hayun Ecology 88 tons Upgrade of open aerated composting facility NIS 1,775,000 Total 1,618 tons NIS 117,818,668

Support for construction / upgrade of facilities for the production of electricity from solid waste

Construction / upgrade of facilities for the production

• f electricity from solid waste

Construction of anaerobic digestion facility Construction of closed composting facility Construction of open composting facility Upgrade of anaerobic digestion facility Legend Evron I’billin Hadera Emek Hefer Afula Immanuel Gevim Ein Hashlosha Bnei Shimon Dimona

30

PPP-supported construction of facility (private-public partnership) in 2016

 Regional anaerobic digestion facility for

1,000 tons/day – Central District

Adoption of master plans for end facilities

District Date North February 6, 2012 Haifa February 14, 2012 Center May 2010 Tel Aviv February 27, 2012 Jerusalem January 3, 2012 South January 9, 2012

32

Target for 2015:

 1.5 million residents separating solid waste  Recycling on a scope of 350,000 tons of

household waste per year

 Active end facilities

Treatment of Dry Waste

Applicant Daily treated quantity

• f solid waste

Amount of support GreenNet (Atarot) 1,236 tons NIS 17,601,750 A.N. Recycling Center (Evlayim) 500 tons NIS 5,059,350 SIE Ashkelon Ltd. 1,035 tons NIS 13,263,750 Univerve Biogas Ltd. – Immanuel 200 tons NIS 3,600,000 Evron – Tamam Recycling Limited Partnership 1,000 tons NIS 20,250,000 Hadera Municipality 500 tons NIS 17,054,483 Afula Municipality 385 tons NIS 10,689,750 Bnei Shimon Regional Council 1,265 tons NIS 29,533,000 Ashdod Municipality 500 tons NIS 16,081,308 Compost Bay and Western Galilee 260 tons NIS 10,400,000 Total 6,881 tons NIS 143,533,391

Sorting transfer stations approved in the RFI framework

Evron Evlayim Afula Hadera Immanuel Atarot Ashkelon Bnei Shimon Construction of sorting stations – subject to budgetary approval Construction of sorting stations Upgrade of sorting stations

Construction / upgrade of sorting stations

Stage B: Energy production from dry waste

 Solid waste that is not economically or technologically

recyclable will be used for the production of energy/fuel, as a preferred alternative over landfilling.

 The following technologies will be used to produce energy:

 RDF  Gasification  Pyrolysis  Plasma

Summary: Evolution of solid waste treatment in Israel

Maintenance of Cleanliness Law Regulation of landfills

 National waste

disposal plan (“TAMA 16”)

 Recycling

Regulations Beverage Container Deposit Law Tire Disposal and Recycling Law Landfill levy Packaging Law Waste Recycling Law

1984 1998 1993 1999 2007 2009 2011

Support: Separation at source, end solutions and transfer stations Law for Environmental Management of Electric and Electronic Equipment

2012

Next steps

 Additional RFI for separation at source

Issued on October 15, 2012, submission deadline – December 16, 2012

 Additional RFI for facilities for the production of green

electricity from solid waste –

Issued on August 7, 2012, submission deadline – November 1, 2012

 Regulations for the separation of biodegradable solid waste  Regulations for the separation of paper and cardboard  Amendment to the Maintenance of Cleanliness Law –

construction debris

 Solid Waste Law: Compilation of all the laws dealing with

solid waste

 Prohibition of landfilling  Updating of solid waste treatment methods  Updating of definition of types of solid waste

Pictures from Israel

Pictures from around the world

Thank you!
