Soio IoT Universal Solution Soio Concepto Raw IoT Data UNIVERSAL GUARANTEED SERVICE Physical-chemical, biological, machine, Instant accessibility and lossless User complete abstraction of any or object (IoT) calibrated Raw Data,
Soio · Concepto
Physical-chemical, biological, machine,
instantaneously available and universally accessible. Instant accessibility and lossless historical record. User complete abstraction of any technological detail or constrain. UNIVERSAL GUARANTEED SERVICE
Control panel
WEB access to the entire system with full control of parameters calibration, alarms, signals and devices configuration, tailored exclusively for each client.
Simplicity
Integral service customized to fulfil your requirements by a very economical monthly fee.
Fluency
Flawless and faultless traffic between nodes and servers guaranteed.
Universal connectivity
Able to connect and integrate with any commercial sensor or sensor controller device.
Security
Data hosting tailored to secure your property and the confidentiality of the information.
Accessibility
Direct access to raw data stored in unipersonal Databases.
Readiness
Immediate service registration and data synchronization
Scalability
Abled to be expanded to unlimited number of signals.
Soio · Overview | Values and attributes
An elegant solution presented here as a journey that overcomes all technological layers required to provide with flawless IoT data, reaching its destination timely, faultlessly, perfectly
Soio · Overview
Complexity made simple to deliver just IoT flawless and faultless Data
MEASURE PHYSICAL WORLD READING COMMUNICATION TRANSPORT DATA COLLECTOR STORAGE SERVER Sensor Controller Sensor Controller Sensor Internet Server process BD1 BD2 BDN IS Software 1 IS Software 2 IS Software N User 1 User 2 User N Web MANAGEMENT CONTROL PANEL USERS Node X
Soio · Overview | Data Flow
MEASURE & READINGS
Concept
Sensors are devices capable of transforming physical-chemical magnitude variations into electrical signals. Sensors Controllers are self-sufficient controlling, recording, and observing devices that concentrate and store sensors signals (PLCs, Solar Invertors, Meteorological Stations, etc).
Consulting & installation
Defining the right Sensors is the key element to acquire quality and reliable data. Soio relies on commercial manufacturers for both, sensors and controllers, and
and installation based on specific consumption, precision, robustness and maintenance requirements for each case.
Soio · Overview | Data Flow
COMMUNICATION
Universal connectivity
Soio communications node can be directly connected with any commercial Sensor, or Sensors Controller. Able to adapt to any new Controller. Independent and self-sufficient communications Network
Data protection
Configurable signal registration period. Multi-threading designed for parallel processing reading, transmitting and receiving orders. Safety remote-programming and automatic reset system. Alarms locally generated and directly transmitted by web, mail mobile text messages and/or other means.
Soio · Overview | Data Flow
TRANSPORT
Safety
Independent subnetwork used to connect with internet. Own protocol TCP/IP specially designed to prevents data loss. M2M communications using local mobile network system throughout a global international operator (non-dependent from local operators).
Traffic optimization
Own protocol TCP / IP optimized to assure a flowless data traffic. Transmissions optimized to occur just when there is actual data to be transmitted.
Soio · Overview | Data Flow
HOSTING
Safety
Client’s cloud access to sensors data Redundant servers owned by the client. One server per client with single
Own developed Supervisory system for prevention, detection and correction of problems in all services. Unlimited capacity / Unlimited Scalability.
Soio · Overview | Data Flow
DATA COLECTOR
Fluidity
Steady continuous communication processes with nodes. Node autonomous functions: data will be always register and stored even if the system is temporary offline, so it would be sent immediately after connections would be reestablished. Optimized to admit data form any type and from any number of nodes.
Soio · Overview | Data Flow
Accesibility
One Data Base per customer. Historical data chronologically stored. Data registering process fully customizable. Raw data directly accessible from Databases to allow immediate integration with Customers Information Systems Applications.
STORAGE
Soio · Overview | Data Flow
Location maps
Addressing utility locations and alarms using Google Maps platform.
Charts & reports
Historical trends, custom reports, export to excel.
Alarms
Communicated via SMS or email, with available historical reports.
Real time
Real time screen sensor readings.
Synoptic panels
Installations represented by customized synoptics panels to allocate sensors and devices.
Scalability
Full and immediate access to nodes configuration by registering new nodes/installations, users, alarms, controllers and signals management control.
CONTROL PANEL
Soio · Overview | Data Flow
GESTIÓN
Tailor made
Direct access to data is provided within
immediate integration with a existing complex information system platforms. In case the client does not have any application for data processing, Soio Cotrol Panel usually covers software needs of the client. Soio provides with the optional service
by developing tailor made software to cover end user needs.
Soio · Overview | Data Flow
Soio · Overview
SOIO’S BACKGROUND
First approach Raw solution designed to remotely measure and monitoring physical and chemical parameters of water in real time for a water analysis lab
2002
Mobile tech & Internet Development of proprietary technology incorporating mobile networks to communicate directly with internet to remotely measure environmental parameters for environment quality control firms.
2003
Social Introduction Our technology is introduced in SMAGUA (Water Technology and Environmental Control Internatio- nal Exhibition) receiving great reception, and a technological innovation award.
2004
Sensors Universal Connectivity A hardware solution is developed to allow linking the physical world (of things, connectivity with any sensor) and internet to provide with specific solutions in diverse environmental fields.
2005
Vertical Solutions Developping Sacrina: noise control. Atlas: early detection of earthquakes and floods. Miranda: SCADA and remote monitoring solution for fish farming. Tentusol: Monitoring and Control of Solar Farms.
2008
Horizontal Layers Model An external funding is raised to develop to solve all layers of technology required to provide with a universal solution applicable to the development of vertical solutions.
2011
Product Design of the first marketable monitoring product: Qmonitor
2014
Soio Soio is created by packing the technological background and business model “service
time, calibrated and robust IoT.
2018
Soio · Overview | Our history
Ultimate Data Accuracy
Electronic solutions for industrial machinery based on Linux and artifical vision technologies LINDA Vision technologies for human identification and monitoring SIDE VIEW Low cost fish farm complex monitoring and process control systems MIRANDA Sensors remote monitoring universal platform QMONITOR
With more than 20 years of experience towards innovation and technological development that has produced different line of products.
HISTORY
Soio · Overview | Our history
