Smart Storage， The Missing Piece

Presented by Alpha ESS Co., Ltd. James Xu, 28 April 2016

Limitations on Existing Energy Generation

• Non-environmental friendly of fossil and nuclear energy
• Uncertainty in availability and quality of solar power
• Unpredictable and low performance efficiency of wind power
• Unsustainable and low calorific value of biomass
• Decreasing ROI rate due to Feed-in-Tariff being cut

Energy Revolution

Energy Transformation

Smart Grid Increasing Energy Efficiency Energy Storage Wind Energy Solar Energy Biogas Energy

Future of energy supply

Wind Energy Solar Energy Biogas Energy

Why Storage is a Missing Piece?

Multi-Function and Trends

• Maximize self-consumption
• Uninterrupted power supply (UPS) in case of grid
• utage
• Maximized profit – peak/off-peak management
• Off-grid function
• Microgrid
• Electric vehicle and charging stations

PV Self-consumption

Morning

Energy produced by the PV generation is used to optimize self-consumption; excess energy is used to recharge the batteries.

Afternoon

When the batteries are fully charged and AlphaESS system already meets your self- consumption requirements; excess energy is fed into the utility grid. Once the sun has set, AlphaESS system automatically switches to energy from batteries. Since the system is grid connected, the grid and the system will supply the load consistently

• together. If the load cannot be supplied solely

by system, the electricity is then obtained from the utility grid.

Evening

At night, Alpha system can obtain off-peak electricity from the grid and charge into battery for customers to use during the peak hours next morning

Night

UPS Function

① When the grid fails, system can switch to off-grid mode automatically and supply the loads. ② The system can also be set as UPS priority. In this case, the system will charge the battery first before supply the electricity to the load and grid. ③ In order to fulfill different customer requirements, the system can also set a UPS reserved capacity under the self-consumption logic.

Maximized Profit

Peak and Off-peak Management

① Buy electricity and charge battery off-peak at the lowest price ① Feed in electricity to grid at the highest tariff

Off-grid Function

① Places with no accessibility to the public grid: Off-grid system can be used in the remote places where there is no access to the public grid. ② Generator: The system can be connected to the generator. When there is not enough electricity supply from battery and PV, system can switch automatically to the generator to supply the loads and charge the battery. When the battery is full, the generator becomes standby. The system is able to work constantly 24/7 and provide power to remote rural settlements with no grid connection.

Microgrid

• Being able to disconnect to centralized

grid

• Being applicable to low power area

with no access to public grid, e.g. Tibet

• Creating an energy community, to be

tailored to local resources which are in abundance. A collection of distributed energy systems communication and acting like a virtual power plant.

Electric Vehicle and Charging Stations

• PV energy produced in the day is stored and can charge car at night.
• EV can be charged at charging stations with PV generation and energy

storage on high way after dark or in winter.

• The excess electricity of EV charging point could be fed into grid.
• EV charging points could be networked as a virtual power plants and

transferred to low storage charging point.

Germany – A Front-Runner

• More than 1.5 million renewable power plants have been installed over the past 25

years.

• 27 percent of the electricity consumed produced from renewables.
• By 2050, the emission of greenhouse gases to be reduced by 80% - 95%. To achieve

this, energy consumption will be reduced by 50 percent and at least 80% of electricity will come from renewable.

• Around 10,000 solar battery systems being installed in German households in 2014
• alone. Experts expect the market to expand tenfold by 2018.

Energy Revolution On the Way……

Number of subsidy granted to Storage system from KFW Bank each year in Germany,2013-2015

 Newly installed system with battery storage  Retrofit installation with battery storage

Total installation of PV battery system each year in Germany,2013-2015

 Lithium battery system  Lead-acid battery system

Alpha ESS Milestones

2012 2013 2014 2015

Sales & Marketing subsidiary founded Intersolar Exhibition Battery module: M4850-M Inverter: AEV-3048 AlphaESS-CS001 Product Family Europe Subsidiary ROW Market Australia Subsidiary 6000㎡new manufactory

2016

Storion-Eco

Company Product

Mass Production Sales & Market Expansion

Product Range

Storion S3/S5/T5 Storion PowerPlug 2.5KWh/3.0KWh Storion - ECO S3/S5 Centauri 3KW/5KW

All-in-One Modern Design

• We have combined the energy management system, the system nerve

centre, with the other necessities, inverter, cables and batteries together into

• ne compact unit which can fit perfect to your household.

Multi-functionality

• UPS
• Maximize self-consumption

Compatibility

• Fit for both new installation & retrofit
• Plug & Play Modular battery design

Visualization

• 7inch EMS touch screen
• Web & APP monitoring system

Safety

• German design & quality control
• 5 year product warranty

Superior Battery Choice

LFP Lithium Iron Phosphate LiFePO4

LiFePO4  Highest safety  High peak power  Long lifespan

Calendar Life: 20 years Metal Can

Metal Can

 Thick wall for superior protection  10 year battery performance warranty without cycle-life limitation

Best Supplier  World’s top 5 manufactures.  Strict quality control and excellent workmanship

 Long circle life of battery modules: ≥8000.  Modular design – can add more modules

• r PowerPlug for future extension.

Years Of

Product Warranty Battery Perf. Warranty Without Cycle-life Limitation

Quality and Warranty

Alpha Cloud

– APP/Web Monitoring

Operation Summary Real-time Data History Record System Info

Alpha Cloud

– APP/Web Monitoring

 Free online visualization through friendly

user design

 Easy updating by using standard USB

flash/online update

 Professional technical support from

AlphaESS

 Future access to Energy Internet available

First Alpha ESS System sold with insurance from Mannheimer Lumit in Germany

People in the picture: MD of Alpha ESS GmbH – James Xu System owner – Mr. Ralf Kessel Solar Center Hessen – Mr. Biber Mannheimer Insurance – Mr. Holz

Report of Alpha ESS on Offenback – the top newspaper in Germany

Alpha ESS Case Study

• Australia

Microgrid Application

20 rooftop project in Sydney Each system includes：

• 5kW PV
• Alpha Storion S5
• 12kWh battery

42 villa house project in Adelaide Each system includes：

• 4kW PV
• Alpha Storion S3
• 6kWh battery

Alpha ESS Case Study

• China

Off-grid System

22kWp project located in Huangpu river in Shanghai, which is also a ZeroCO2 system center. System includes

• - 73 x 300Wp PV
• - 30kVA off-grid inverter
• - 100A solar charger
• - 20kWh battery

Alpha-ESS helps to

Smarten Your Energy
