SIMULATIONS WITH ALGEBRAIC MULTI GRID Chris Gottbrath, Nov 2016 - - PowerPoint PPT Presentation

Chris Gottbrath, Nov 2016

ACCELERATING CFD AND RESERVOIR SIMULATIONS WITH ALGEBRAIC MULTI GRID

2

AGENDA

Challenges What is Algebraic Multi-Grid (AMG)? Why use AMG? When to use AMG? NVIDIA AmgX Results

3

CHALLENGES

Large Volumes Complex Geometry High Velocities Turbulence Multiple fluids

Computational Fluid Dynamics and Reservoir Simulations

4

ACCURACY & PERFORMANCE MATTERS

Quality Matters

Designing critical systems Oil field management -- $$$

Time to solution matters

Limits size and accuracy Limits coverage

5

WHAT IS AMG – ALGEBRAIC MULTI GRID

System: Ax – b = 0 A = matrix - system x,b = vector - state Residual Function : r= b-Ax

Start with a proposed solution vector x Iterative process – reduces |r| Trick: approximate solutions

Make a small system “based on” the big one Solve that to get a good approximation Project back to full system

A way to efficiently solve very large systems

Fast, powerful, general technique!

6

ALGEBRAIC MULTI GRID – THE V CYCLE

Repeat a few times Full Size System Full Size System Medium System Tiny System Solve Tiny System Medium System Coarsen + Smooth Prolong+ Smooth Prolong+ Smooth Coarsen + Smooth

7

Coarsening

8

Coarsening

9

Why use AMG?

Handles Complex Geometries Complex Physics Huge Systems High Resolution Fast Algorithm – Each iteration reduces |r| by 2-10x. Converge with 6-20 iterations It runs really well on NVIDIA GPUs!

A Powerful Solver

10

https://developer.nvidia.com/amgx

NVIDIA AmgX

Unstructured Implicit Linear Systems - Solved > 15x Speedup vs HYPRE

14x 14x 16x 15x 17x 15x

0x 2x 4x 6x 8x 10x 12x 14x 16x 18x

HYPRE K40 M40 P100-SXM2 Speedup vs. HYPRE

• Florida Matrix Collection; Total Time to Solution
• HYPRE AMG Package (http://acts.nersc.gov/hypre) on Intel Xeon E5-2697 v4@2.3GHz, 3.6GHz

Turbo, Hyperthreading off

• AmgX on K40m, M40, P100; Base clocks
• Host system: Intel Xeon Haswell single-socket 16-core E5-2698 v3 @ 2.3GHz, 3.6GHz Turbo
• CentOS 7.2 x86-64 with 128GB System Memory

The AmgX library provides a configurable and scalable GPU accelerated algebraic multi-grid solver for large sparse linear systems.

CFD and Reservoir Simulation Scales up to hundreds of GPUs Rich collection of algorithms Accelerate existing simulations

11

6 CPU cores + K80 GPU

1.8x

8 CPU cores

135 247

Distributed ANSYS Mechanical 16.0 with Ivy Bridge (Xeon E5-2697 V2 2.7 GHz) 8-core CPU and a Tesla K80 GPU.

ANSYS Mechanical 16.0 on Tesla K80

Simulation productivity (with HPC Pack)

Higher is Better

V15sp-4 Model

Turbine geometry 3,200,000 DOF SOLID187 FEs Static, nonlinear Distributed ANSYS 16.0 Direct sparse solver 6 CPU cores + K80 GPU

2.3x

8 CPU cores

159 371

V15sp-5 Model

Ball Grid Array geometry 6,000,000 DOF Static, nonlinear Distributed ANSYS 16.0 Direct sparse solver

ANSYS Mechanical jobs/day

V15sp-5 Model V15sp-4 Model THE Industry Standard CFD is accelerated with AmgX

12

1150 197 98

500 1000 1500 CPU GPU Custom AmgX

AmgX in Reservoir Simulation

Application Time (seconds)

Lower is Better

3-phase Black Oil Reservoir Simulation. 400K grid blocks solved fully implicitly. CPU: Intel Xeon CPU E5-2670 GPU: NVIDIA Tesla K10

13

Minimal Example With Config

//One header #include “amgx_c.h” //Read config file AMGX_create_config(&cfg, cfgfile); //Create resources based on config AMGX_resources_create_simple(&res, cfg); //Create solver object, A,x,b, set precision AMGX_solver_create(&solver, res, mode, cfg); AMGX_matrix_create(&A,res,mode); AMGX_vector_create(&x,res,mode); AMGX_vector_create(&b,res,mode); //Read coefficients from a file AMGX_read_system(&A,&x,&b, matrixfile); //Setup and Solve Loop AMGX_solver_setup(solver,A); AMGX_solver_solve(solver, b, x); //Download Result AMGX_download_vector(&x) solver(main)=FGMRES main:max_iters=100 main:convergence=RELATIVE_MAX main:tolerance=0.1 main:preconditioner(amg)=AMG amg:algorithm=AGGREGATION amg:selector=SIZE_8 amg:cycle=V amg:max_iters=1 amg:max_levels=10 amg:smoother(smoother)=BLOCK_JACOBI amg:relaxation_factor= 0.75 amg:presweeps=1 amg:postsweeps=2 amg:coarsest_sweeps=4 determinism_flag=1

14

AmgX

Flexible & powerful technique Simple to adopt Get results 15x faster with Pascal Scales out to handle large systems http://developer.nvidia.com/amgx

GPU acceleration for your simulation

Thanks! Questions?

http://developer.nvidia.com/amgx cgottbrath@nvidia.com

16

Numerical Models

AmgX is only used for PDE type models It works best with unstructured implicit code. Other code can be Accelerated using the CUDA libraries such as cuRAND, cuBLAS, cuFFT, cuSPARSE, and cuSOLVER

There are a lot of different ways to model

PDE based models

• Grid
• Structured
• Unstructured
• Method
• Implicit
• Explicit

Event Based Models

• Lattice

Boltzman

• Monte Carlo
• Finite State

Machine

• N-body / SPH

17

Second Order PDEs

Hyperbolic Parabolic Elliptic

Helmholtz

Pure Hyperbolic

Use Other Solvers Use AmgX

Helmholtz problems are currently not well suited Many physical problem domains can be modeled using 2nd order PDE These can be classified based on how they behave mathematically

• Parabolic – Solutions smooth out
• ver time.
• Heat transfer
• Elliptic – Smooth within volume,

potentially discontinuous boundary values.

• Subsonic fluid flow
• Hyperbolic – Discontinuities

(shocks) will persist

• Wave equation
• Supersonic fluid flow

18

KEY FEATURES

Classical and Aggregation AMG Robust Aggressive Coarsening Algorithms

Krylov methods: CG, GMRES, BiCGStab, IDR Smoothers / Solvers

Jacobi-L1,Block-Jacobi, ILU[0,1,2], DILU, Dense LU, KPZ- Polynomial, Chebyshev

High level API with composition through configuration MPI support with consolidation Multi-precision Adaptors for: HYPRE, PETSc, Trilinos Python bindings
