Fall 2014:: CSE 506:: Section 2 (PhD)

Signals and Inter-Process Communication (IPC)

Nima Honarmand (Based on slides by Don Porter and Mike Ferdman)

Fall 2014:: CSE 506:: Section 2 (PhD)

Outline

• Signals

– Overview and APIs – Handlers – Kernel-level delivery – Interrupted system calls

• Interprocess Communication (IPC)

– Pipes and FIFOs – System V IPC

Fall 2014:: CSE 506:: Section 2 (PhD)

What is a signal?

• Like an interrupt, but for applications

– < 64 numbers with specific meanings – Sending: A process can raise a signal to another process or thread – Sending: Kernel can send signals to processes or threads – Receiving: A process or thread registers a handler function

• For both IPC and delivery of hardware exceptions

– Application-level handlers: divzero, segfaults, etc.

• No “message” beyond the signal was raised

– And maybe a little metadata

• PID of sender, faulting address, etc.

Fall 2014:: CSE 506:: Section 2 (PhD)

Example

Pid 300 int main() { ... signal(SIGUSR1, &usr_handler); ... }

Register usr_handler() to handle SIGUSR1

Fall 2014:: CSE 506:: Section 2 (PhD)

Example

Pid 300 kill(300, SIGUSR1);

Send signal to PID 300

Pid 400 int main() { ... } int usr_handler() { …

PC

Fall 2014:: CSE 506:: Section 2 (PhD)

Basic Model

• Application registers handlers with signal() or

sigaction()

• Send signals with kill() and friends

– Or raised by hardware exception handlers in kernel

• Signal delivery jumps to signal handler

– Irregular control flow, similar to an interrupt

API names are admittedly confusing

Fall 2014:: CSE 506:: Section 2 (PhD)

Some Signal Types

• See man 7 signal for the full list: (varies by sys/arch)

SIGTSTP: Stop typed at terminal (Ctrl+Z) SIGKILL: Kill a process SIGSEGV: Segmentation fault SIGPIPE: Broken pipe (write with no readers) SIGALRM: Timer SIGUSR1: User-defined signal 1 SIGCHLD: Child stopped or terminated SIGSTOP: Stop a process SIGCONT: Continue if stopped

Fall 2014:: CSE 506:: Section 2 (PhD)

Language Exceptions

• Signals are the underlying mechanism for

Exceptions and catch blocks

• JVM or other runtime system sets signal handlers

– Signal handler causes execution to jump to the catch block

Fall 2014:: CSE 506:: Section 2 (PhD)

Signal Handler Control Flow

From Understanding the Linux Kernel

Fall 2014:: CSE 506:: Section 2 (PhD)

Alternate Stacks

• Signal handlers can execute on a different stack

than program execution.

– Why?

• Safety: App can ensure stack is actually mapped

– Set with sigaltstack() system call

• Like an interrupt handler, kernel pushes register

state on interrupt stack

– Return to kernel with sigreturn() system call – App can change its own on-stack register state!

Fall 2014:: CSE 506:: Section 2 (PhD)

Nested Signals

• What happens when you get a signal in the signal

handler?

• And why should you care?

Fall 2014:: CSE 506:: Section 2 (PhD)

The Problem with Nesting

int main() { /* ... */ signal(SIGINT, &handler); signal(SIGTERM, &handler); /* ... */ } int handler() { free(buf1); free(buf2); }

SIGINT SIGTERM Signal Stack PC

Calls munmap() Another signal delivered on return Double free!

Fall 2014:: CSE 506:: Section 2 (PhD)

Nested Signals

• The original signal() specification was a total mess!

– Now deprecated---do not use!

• New sigaction() API lets you specify this in detail

– What signals are blocked (and delivered on sigreturn) – Similar to disabling hardware interrupts

• As you might guess, blocking system calls inside of

a signal handler are only safe with careful use of sigaction()

Fall 2014:: CSE 506:: Section 2 (PhD)

Application vs. Kernel

• App: signals appear to be delivered roughly

immediately

• Kernel (lazy):

– Send a signal == mark a pending signal in the task

• And make runnable if blocked with TASK_INTERRUPTIBLE flag

– Check pending signals on return from interrupt or syscall

• Deliver if pending

Fall 2014:: CSE 506:: Section 2 (PhD)

Example

Pid 300 RUNNING

kill(300, SIGUSR1);

Send signal to PID 300

Pid 400

int main() { read(); } int usr_handler() { …

PC … … SIGUSR1

Pid 300

INTERRUPTIBLE

Block on disk read! Mark pending signal, unblock What happens to read?

Fall 2014:: CSE 506:: Section 2 (PhD)

Interrupted System Calls

• If a system call blocks in the INTERRUPTIBLE state, a

signal wakes it up

• Yet signals are delivered on return from a system

call

• How is this resolved?
• The system call fails with a special error code

– EINTR and friends – Many system calls transparently retry after sigreturn – Some do not – check for EINTR in your applications!

Fall 2014:: CSE 506:: Section 2 (PhD)

Default handlers

• Signals have default handlers:

– Ignore, kill, suspend, continue, dump core – These execute inside the kernel

• Installing a handler with signal/sigaction overrides

the default

• A few (SIGKILL, SIGSTOP) cannot be overridden

Fall 2014:: CSE 506:: Section 2 (PhD)

RT Signals

• Default signals are only in 2 states: signaled or not

– If I send 2 SIGUSR1’s to a process, only one may be delivered – If system is slow and I furiously hit Ctrl+C over and over,

• nly one SIGINT delivered
• Real time (RT) signals keep a count

– Deliver one signal for each one sent

Fall 2014:: CSE 506:: Section 2 (PhD)

Other IPC

• Pipes, FIFOs, and Sockets
• System V IPC

Fall 2014:: CSE 506:: Section 2 (PhD)

Pipes

• Stream of bytes between two processes
• Read and write like a file handle

– But not anywhere in the hierarchical file system – And not persistent – And no cursor or seek()-ing – Actually, 2 handles: a read handle and a write handle

• Primarily used for parent/child communication

– Parent creates a pipe, child inherits it

Fall 2014:: CSE 506:: Section 2 (PhD)

Example

int pipe_fd[2]; int rv = pipe(pipe_fd); int pid = fork(); if (pid == 0) { close(pipe_fd[1]); // Close unused write end dup2(pipe_fd[0], 0); // Make the read end stdin exec(“grep”, “quack”); } else { close (pipe_fd[0]); // Close unused read end …

Fall 2014:: CSE 506:: Section 2 (PhD)

FIFOs (aka Named Pipes)

• Existing pipes can’t be opened---only inherited

– Or passed over a Unix Domain Socket (beyond today’s lec)

• FIFOs, or Named Pipes, add an interface for opening

existing pipes

Fall 2014:: CSE 506:: Section 2 (PhD)

Sockets

• Similar to pipes, except for network connections
• Setup and connection management is a bit trickier

– A topic for another day (or class)

Fall 2014:: CSE 506:: Section 2 (PhD)

Select()

• What if I want to block until one of several handles

has data ready to read?

• Read will block on one handle, but perhaps miss

data on a second…

• Select will block a process until a handle has data

available

– Useful for applications that use pipes, sockets, etc.

Fall 2014:: CSE 506:: Section 2 (PhD)

Synthesis Example: The Shell

• Almost all ‘commands’ are really binaries

– /bin/ls

• Key abstraction: Redirection over pipes

– ‘>’, ‘<‘, and ‘|’implemented by the shell itself

Fall 2014:: CSE 506:: Section 2 (PhD)

Shell Example

• Ex: ls | grep foo
• Implementation sketch:

– Shell parses the entire string – Sets up chain of pipes – Forks and exec’s ‘ls’ and ‘grep’ separately – Wait on output from ‘grep’, print to console

Fall 2014:: CSE 506:: Section 2 (PhD)

Job control in a shell

• Shell keeps its own “scheduler” for background

processes

• How to:

– How to suspend the foreground process?

• SIGTSTP handler catches Ctrl-Z
• Send SIGSTOP to current foreground child

– Resume execution (fg)?

• Send SIGCONT to paused child, use waitpid() to block until

finished

– Execute in background (bg)?

• Send SIGCONT to paused child, but block on terminal input

Fall 2014:: CSE 506:: Section 2 (PhD)

Other hints

• Splice(), tee(), and similar calls are useful for

connecting pipes together

– Avoids copying data into and out-of application

Fall 2014:: CSE 506:: Section 2 (PhD)

System V IPC

• Semaphores – Lock
• Message Queues – Like a mail box, “small”

messages

• Shared Memory – particularly useful

– A region of non-COW anonymous memory – Map at a given address using shmat()

• Can persist longer than an application

– Must be explicitly deleted – Can leak at system level – But cleared after a reboot
