slide-1
SLIDE 1

Black Hat USA 2007

Side Channel Attacks and Countermeasures for Embedded Systems

Job de Haas

Black Hat USA August 2, 2007

slide-2
SLIDE 2

Black Hat USA 2007

Agenda

  • Advances in Embedded Systems Security

– From USB stick to game console – Current attacks – Cryptographic devices

  • Side Channels explained

– Principles – Listening to your hardware – Types of analysis

  • Attacks and Countermeasures

– Breaking a key – Countermeasures theory – Practical implementations

slide-3
SLIDE 3

Black Hat USA 2007

Security in embedded systems

slide-4
SLIDE 4

Black Hat USA 2007

Trends in embedded hardware security

  • Preventing debug access

– Fuses, Secure access control

  • Protecting buses and memory components

– Flash memories with security, DRAM bus scrambling

  • Increase in code integrity

– Boot loader ROM in CPU, Public key signature checking

  • Objectives:

– Prevent running unauthorized code – Prevent access to confidential information

  • Effective against most “conventional” attacks
slide-5
SLIDE 5

Black Hat USA 2007

Popular ‘hardware’ attacks

slide-6
SLIDE 6

Black Hat USA 2007

Attacks on glue and BGA

  • Cheap BGA reballing

in phone unlocking and repair

  • Glue can be removed

with chemicals or hot air

(See also Joe Grand’s BH presentations on hardware attacks)

slide-7
SLIDE 7

Black Hat USA 2007

Towards cryptographic devices

  • Smart cards represent the ultimate cryptographic device:

– Operate in a hostile environment – Perform cryptographic operations on data – Harnessing both the cryptographic operation and the key – Tamper resistant

  • General purpose processors are incorporating more and more

smart card style security

  • Why not use a smart card?

– Also adds complexity – How to communicate securely with it? – Some do (PayTV, TPM etc)

slide-8
SLIDE 8

Black Hat USA 2007

Agenda

  • Advances in Embedded Systems Security

– From USB stick to game console – Current attacks – Cryptographic devices

  • Side Channels explained

– Principles – Listening to your hardware – Types of analysis

  • Attacks and Countermeasures

– Breaking a key – Countermeasures theory – Practical implementations

slide-9
SLIDE 9

Black Hat USA 2007

Side Channel Analysis

  • What?

– read ‘hidden’ signals

  • Why?

– retrieve secrets

  • How?

– Attack channels – Methods – Tools

slide-10
SLIDE 10

Black Hat USA 2007

Attack Channels

  • Time
  • Power consumption
  • Electro-Magnetic radiation
  • Light emission
  • Sound
slide-11
SLIDE 11

Black Hat USA 2007

Passive versus active attacks

  • Passive attacks

– Only observing the target – Possibly modifying it to execute a specific behavior to observe – Examples: time, power or EM measurements

  • Active attacks

– Manipulating the target or its environment outside of its normal behavior – Uncovering cryptographic keys through ‘fault injection’ – Changing program flow (eg. circumvent code integrity checks) – Examples: Voltage or clock glitching, laser pulse attacks

slide-12
SLIDE 12

Black Hat USA 2007

Principle of timing analysis

Process 2 Process 2 Process 2 Start Start Start End End End Decision Decision Decision Process 1 Process 1 Process 1

t = 10ms t = 10ms t = 20ms t = 20ms

slide-13
SLIDE 13

Black Hat USA 2007

  • Semiconductors use current while

switching

  • Shape of power consumption profile

reveals activity

  • Comparison of profiles reveals

processes and data

  • Power is consumed when switching from

1→0 or 0→1

Principle of power analysis

slide-14
SLIDE 14

Black Hat USA 2007

Principle of electromagnetic analysis

  • Electric and Magnetic field are related to current
  • Probe is a coil for magnetic field
  • Generally the near field (distance << λ) is most suitable
  • Adds dimension position compared to the one dimensional

power measurement

slide-15
SLIDE 15

Black Hat USA 2007

Side channel analysis tools

  • Probes

– Power: Intercept power circuitry with small resistor – EM: Coil with low noise amplifier

  • Digital storage oscilloscope
  • High bandwidth amplifier
  • Computer with analysis and control software
slide-16
SLIDE 16

Black Hat USA 2007

Test equipment

  • CPU: Ti OMAP 5912 150Mhz
slide-17
SLIDE 17

Black Hat USA 2007

Listening to your hardware - demo

Oscilloscope CPU Embedded system sensor amplifier Analysis Software I/O trigger analog signal digitized signal EM probe

slide-18
SLIDE 18

Black Hat USA 2007

Simple Power/EM Analysis

  • Recover information by inspection of single or averaged traces
  • Can also be useful for reverse engineering algorithms and

implementations

slide-19
SLIDE 19

Black Hat USA 2007

Differential Power/EM Analysis

  • Recover information by inspection difference between traces

with different (random) inputs

  • Use correlation to retrieve information from noisy signals
slide-20
SLIDE 20

Black Hat USA 2007

Data/signal correlation

slide-21
SLIDE 21

Black Hat USA 2007

Agenda

  • Advances in Embedded Systems Security

– From USB stick to game console – Current attacks – Cryptographic devices

  • Side Channels explained

– Principles – Listening to your hardware – Types of analysis

  • Attacks and Countermeasures

– Breaking a key – Countermeasures theory – Practical implementations

slide-22
SLIDE 22

Black Hat USA 2007

Secure CPUs

slide-23
SLIDE 23

Black Hat USA 2007

Breaking a key - demo

  • Example breaking a DES key with a differential attack
  • Starting a measurement
  • Explaining DES analysis
  • Showing results
slide-24
SLIDE 24

Black Hat USA 2007

DES

16 rounds

  • Input and output are 64 bits
  • Key K is 56 bits

round keys are 48 bits

  • Cipher function F mixes

input and round key

slide-25
SLIDE 25

Black Hat USA 2007

F- function

E permutation S box 1 P permutation S box 2 S box 8 Round key 32 → 48 8 * (6 → 4) 32 → 32 48

slide-26
SLIDE 26

Black Hat USA 2007

DPA on DES

  • Simulate DES algorithm based on input bits and

hypotheses k.

  • Select one S-Box, and one output bit x. Bit x

depends on only 6 key bits.

  • Calculate differential trace for the 64 different

values of k.

  • Incorrect guess will show noise, correct guess will

show peaks. E permutation S box i Round key 32 → 48 48

Bit 1 Bit 4

6

slide-27
SLIDE 27

Black Hat USA 2007

DPA on DES results

slide-28
SLIDE 28

Black Hat USA 2007

Countermeasures

  • Decrease leakage

– Balance processing of values – Limit number of operations per key

  • Increase noise

– Introduce timing variations in processing – Use hardware means

slide-29
SLIDE 29

Black Hat USA 2007

Countermeasures concepts

  • Passive Side channel attacks:

– Hiding: Break relation between processed value and power consumption – Masking / Blinding: Break relation between algorithmic value and processed value Algorithmic value Processed value Measured value (at guessed position) Masking Hiding

slide-30
SLIDE 30

Black Hat USA 2007

Countermeasure examples

  • Change the crypto protocol to use key material only for a

limited amount of operations. For instance, use short lived session keys based on a hash of an initial key. Example:

Source: Kocher, P. Design and Validation Strategies for Obtaining Assurance in Countermeasures to Power Analysis and Related Attacks

slide-31
SLIDE 31

Black Hat USA 2007

Countermeasure examples

  • Remove any execution time dependence on data and key. Do

not forget cache timing and branch prediction. Also remove conditional execution that depends on the key.

  • Randomly insert instructions with no effect on the algorithm.

Use different instructions that are hard to recognize in a trace

MOV XOR ADD INC CMP MOV NOP XOR ADD NOP INC NOP CMP MOV XOR NOP ADD INC CMP

default random random

slide-32
SLIDE 32

Black Hat USA 2007

Countermeasure examples

  • Shuffling: Changing the order of independent operations (for

instance S-box calculations) per round. This reduces correlation with a factor equal to the number of shuffled operations

  • Implement a masked version of the cryptographic algorithm.

Examples can be found in research literature for common algorithms (RSA, AES).

Sbox 1 Sbox 2 Sbox 3 Sbox 4 Sbox 5 Sbox 6 Sbox 7 Sbox 8 Sbox 4 Sbox 8 Sbox 1 Sbox 3 Sbox 6 Sbox 5 Sbox 2 Sbox 7

default random

slide-33
SLIDE 33

Black Hat USA 2007

Countermeasure demos

  • Simple analysis of unprotected trace
  • Effect of randomly inserting NOP instructions
  • Effect of making RSA square-multiply constant
slide-34
SLIDE 34

Black Hat USA 2007

1 1

Key bits revealed

1 1 1 1 0 0 1 1

key bits revealed signal processing to high-light dips variation of interval between dips

SPA attack on RSA

slide-35
SLIDE 35

Black Hat USA 2007

RSA implementations

  • Algorithm for M=cd, with di

is exponent bits (0≤i≤t)

– M := 1 – For i from t down to 0 do:

  • M := M * M
  • If di = 1, then M := M*C
  • Algorithm for M=cd, with di group of exponent bits (0≤i≤t)

– Precompute multipliers Ci – M := 1 – For i from t down to 0 do:

  • For j = 1 to groupSize: M := M * M
  • M := M* Ci
slide-36
SLIDE 36

Black Hat USA 2007

Example: RSA message blinding

  • Normal encryption: M = Cd mod n under condition:

– n = p·q – e·d = 1 mod lcm(p-1, q-1)

  • Choose a random r, then Cr = C re mod n
  • Perform RSA: Mr = Cr

d mod n = Cdr mod n

  • M = Mr r-1 mod n
  • During the RSA operation itself the operations with exponent d

do not depend on C

slide-37
SLIDE 37

Black Hat USA 2007

Test and verification

  • The best way to understand side channel leakage is to measure

your own implementation

  • Side channels analysis can be performed on a device to assess

its level of vulnerability to such attacks

  • Such analysis is part of certification processes in the payment

industry and in Common Criteria evaluations.

  • FIPS 140-3 will require side channel testing for certain levels
slide-38
SLIDE 38

Black Hat USA 2007

Countermeasure licensing

  • DPA attacks were first published by Paul Kocher et al. from

Cryptography Research, Inc. (CRI)

  • A large range of countermeasures are patented by CRI and
  • ther companies
  • CRI licenses the use of them
  • The patents give a good idea of possible countermeasures,

check with CRI

slide-39
SLIDE 39

Black Hat USA 2007

Conclusions

  • With the increase of security features in embedded devices the

importance of side channel attacks will also increase

  • Most of these devices with advanced security features do not

yet contain hardware countermeasures against side channel attacks

  • Side channel attacks present a serious threat with wide range
  • f possibilities and a large impact
  • Still, software developers can reduce the risks of side channel

attacks by securing their implementations with software countermeasures

slide-40
SLIDE 40

Black Hat USA 2007

More info

Job de Haas dehaas@riscure.com

slide-41
SLIDE 41

Black Hat USA 2007

References

1. Joe Grand, “Advanced Hardware Hacking Techniques”, Defcon 12 http://www.grandideastudio.com/files/security/hardware/advanced_hardware_hacking_techniq ues_slides.pdf 2. Josh Jaffe, “Differential Power Analysis”, Summer School on Cryptographic Hardware http://www.dice.ucl.ac.be/crypto/ecrypt-scard/jaffe.pdf http://www.dice.ucl.ac.be/crypto/ecrypt-scard/jaffe2.pdf 3.

  • S. Mangard, E. Oswald, T. Popp, “Power Analysis Attacks -

Revealing the Secrets of Smartcards” http://www.dpabook.org/ 4. Dan J. Bernstein, ''Cache-timing attacks on AES'', http://cr.yp.to/papers.html#cachetiming, 2005. 5.

  • D. Brumley, D. Boneh, “Remote Timing Attacks are Practical”

http://crypto.stanford.edu/~dabo/papers/ssl-timing.pdf 6.

  • P. Kocher, "Design and Validation Strategies for Obtaining Assurance in Countermeasures to

Power Analysis and Related Attacks", NIST Physical Security Testing Workshop - Honolulu,

  • Sept. 26, 2005

http://csrc.nist.gov/cryptval/physec/papers/physecpaper09.pdf 7.

  • E. Oswald, K. Schramm, “An Efficient Masking Scheme for AES Software Implementations”

www.iaik.tugraz.at/research/sca-lab/publications/pdf/Oswald2006AnEfficientMasking.pdf 8. Cryptography Research, Inc. Patents and Licensing http://www.cryptography.com/technology/dpa/licensing.html
