Improving Preemptive Scheduling with Application-Transparent Checkpointing in Shared Clusters

Jack Li, Calton Pu Georgia Institute of Technology Yuan Chen, Vanish Talwar, Dejan Milojicic Hewlett Packard Labs

Shared Clusters for Big Data Systems

– Dynamic resource sharing across multiple frameworks, apps and users

– Examples - Google cluster (Omega), Mesos, Hadoop YARN, Bing’s Dryad Dedicated Clusters Shared Cluster improved utilization and data sharing, reduced cost 3

Shared Hardware Cluster Manager (e.g. YARN, Mesos) Batch (MR) Streaming (Storm) In-Memory (Spark) Graph (Giraph) Online (Vertica)

Hardware Batch (MR) Cluster Hardware Streaming (Storm) Cluster Hardware Online (Vertica) Cluster

Preemption in Shared Clusters

– Coordinate resource sharing, guarantee QoS and enforce fairness – Problem: preemption in shared clusters is expensive!

– Simply kill and restart jobs later – Significant resource waste – Delays completion time of long running or low priority jobs

3 preemption

Real World Examples

– Google Cluster: 12.4% of scheduled tasks preempted and up to 30k CPU-hours (35% of total capacity) wasted! – Microsoft Dryad cluster[1]: ~21% jobs killed – Facebook Hadoop cluster[2]: repeatedly kill and restart long running jobs

4 Task Priority

• Num. of

Tasks Percent Evicted Free (0-1) 28.4M 20.26% Middle (2-8) 17.3M 0.55% Production (9-11) 1.70M 1.02% Latency Sensitivity

• Num. of

Tasks Percent Evicted 0 (lowest) 37.4M 11.76% 1 5.94M 18.87% 2 3.70M 8.14% 3 (highest) 0.28M 14.80%

Even latency-sensitive tasks are evicted 29-day trace from Google: 672,000 jobs on 12,500 machines

20 40 60 80 100 5 10 15 20 25 30

Preemption Rate [%] Time [Day]

Preemption Rate Timeline

Low Priority Medium Priority High Priority

[1] Scarlett: Coping with Skewed Popularity Content in MapReduce Clusters. Ananthanarayanan et. al. EuroSys 2011. [2] Mitigating the Negative Impact of Preemption on Heterogeneous MapReduce Workloads. Cheng et. al. CNSM 2011.

Many tasks preempted

Real World Examples

– Google Cluster: 12.4% of scheduled tasks preempted and up to 30k CPU-hours (35% of total capacity) wasted! – Microsoft Dryad cluster[1]: ~21% jobs killed – Facebook Hadoop cluster[2]: repeatedly kill and restart long running jobs

5 Task Priority

• Num. of

Tasks Percent Evicted Free (0-1) 28.4M 20.26% Middle (2-8) 17.3M 0.55% Production (9-11) 1.70M 1.02% Latency Sensitivity

• Num. of

Tasks Percent Evicted 0 (lowest) 37.4M 11.76% 1 5.94M 18.87% 2 3.70M 8.14% 3 (highest) 0.28M 14.80%

Even latency-sensitive tasks are evicted 29-day trace from Google: 672,000 jobs on 12,500 machines

20 40 60 80 100 5 10 15 20 25 30

Preemption Rate [%] Time [Day]

Preemption Rate Timeline

Low Priority Medium Priority High Priority

200 400 600 800 1000 1 2 3 4 5 6 7 8 9 >10 Distinct Tasks [thousands]

• Num. of Preemptions

Preemption Frequency Distribution

[1] Scarlett: Coping with Skewed Popularity Content in MapReduce Clusters. Ananthanarayanan et. al. EuroSys 2011. [2] Mitigating the Negative Impact of Preemption on Heterogeneous MapReduce Workloads. Cheng et. al. CNSM 2011.

Many tasks preempted 43% preempted more than once 17% 10 times

• r more

Checkpointing-based Preemptive Scheduling

Our solution: use checkpoint/restore for preemption instead of kill/restart

Use system level, application-transparent checkpointing mechanism

– Linux CRIU (Checkpoint-Restore In Userspace) – Distributed and remote checkpoint/restart

Leverage fast storage such as NVM for efficient checkpointing

– Store checkpoints on NVM (NVMFS or NVRAM)

Adaptive preemption policies and optimization techniques

– Combine checkpoint and kill, local and remote checkpointing/resumption – Incremental checkpointing with memory trackers

6

Application-transparent Suspend-Resume

Checkpointing using CRIU (Checkpoint/Restore In Userspace) – Freeze a running program and suspend it in memory or output to disk – Saves sockets, threads, namespaces, memory mappings, pipes Dump

– Build process tree from /proc/$pid/task/$tid/children and seize them with ptrace – Collect VMA areas, file descriptor numbers, registers, etc… of each process

Restore

– Read process tree from file and start saved processes with clone() call – New memory map created filled with checkpointed data 7

Suspend-Resume with DFS and NVM

Support distributed and remote checkpoint-resume

– Save checkpoints on HDFS

Checkpoint with NVM

– Use NVM as fast disk

– Save CRIU checkpoints in NVM- based file systems (e.g, PMFS)

– Use NVM as virtual memory (NVRAM)

– Copy checkpoints from DRAM to NVM using memory operations – Shadow buffer

Incremental checkpointing

8

Node A Node B Node C NVRAM NVRAM Distributed Shared NVRAM

process address space DRAM DRAM DRAM

NVRAM memory copy

Node A

process address space HDD, SSD, NVM DRAM checkpoint files Dump

Node B

process address space HDD, SSD, NVM DRAM checkpoint files

Node C

process address space HDD, SSD, NVM DRAM checkpoint files Restore

Distributed File System

Suspend and Restore Performance

9

100 200 300 400 500 600 2 4 6 8 10

Total Dump Restore Time [s] Checkpoint Size [GB]

Local File System

HDD SSD NVM 100 200 300 400 500 600 2 4 6 8 10

Total Dump Restore Time [s] Checkpoint Size [GB]

HDFS

HDD SSD PMFS

Benefits of Incremental Checkpointing

5GB initial dump size, change 10% of the memory and dump again

10

Storage First Checkpoint Second Checkpoint HDD 169.18s 15.34s SSD 43.73s 4.08s PMFS 2.92s 0.28s

Google Trace-driven Simulation

11

500 1000 1500 2000 2500 3000 3500

Wasted CPU Capacity [core-hours] Preempt Method

Resource Wastage

Preempt-Kill Basic-HDD Basic-SSD Basic-NVM 3800 3850 3900 3950 4000 4050 4100

Energy [kW*h) Preempt Method

Energy Consumption

0.2 0.4 0.6 0.8 1 1.2 1.4

Lowest Priority Medium Priority Highest Priority Normalized Response Time

Performance

1 2 3 4 5 6 1 2 3 4 5

Normalized Completion Time

Checkpoint Bandwidth (GB/s) Low Priority Job Performance

0.5 1 1.5 2 2.5 3 3.5 1 2 3 4 5

Normalized Completion Time

Checkpoint Bandwidth (GB/s) High Priority Job Performance Wait Kill Checkpoint 0.5 1 1.5 2 2.5 3 3.5 4 1 2 3 4 5 Normalized Power Consumption Checkpoint Bandwidth (GB/s) Energy Consumption

23%

• 6%

76% 5% 74%

Adaptive Policies and Optimization

Adaptive preemption dynamically selects victim tasks and preemption mechanisms (checkpoint or kill) based on the progress of each task and its checkpoint/restore overhead. Adaptive resumption restores preempted jobs/tasks locally or remotely according to their overheads and available resources. Incremental checkpointing with memory trackers

12

Adaptive Preemption Algorithms

13

Performance Improvement with Adaptive Policies

14

0.2 0.4 0.6 0.8 1 Lowest Priority Medium Priority Highest Priority Normalized Response Time

HDD

Basic Adaptive 0.2 0.4 0.6 0.8 1 Lowest Priority Medium Priority Highest Priority Normalized Response Time

SSD

0.2 0.4 0.6 0.8 1 Lowest Priority Medium Priority Highest Priority Normalized Response Time

NVM

36% 55% 29% 12% 17% 8% 3% 8%

• 0.5%

Implementation with Hadoop YARN

YARN – cluster resource manager

– Global resource scheduler (ResourceManager) – Submit ApplicationMasters (jobs) to RM – Supports capacity and fair scheduling

DistributedShell

– Comes standard with YARN – Runs a shell command in a set of containers in a distributed and parallel manner

15

YARN ApplicationMaster Application Preemption Manager

• 2. Preemption

Request

• 3. Suspend
• 6. Resume
• 3. Suspend
• 6. Resume
• 4. Suspend

Complete YARN Resource Manager YARN Cluster Scheduler

• 5. Container

Request YARN NodeManager

HDD, SSD, NVM (PMFS)

HDFS Task CRIU Task

dump restore

YARN NodeManager

HDD, SSD, NVM (PMFS)

HDFS Task CRIU Task

dump restore

• 1. New

Job

Testbed and Experiment Setup

– 8 node Hadoop YARN cluster

– Dual socket Xeon 5650 CPU (6 cores/each) – 96GB memory (48GB emulated NVM using PMFS) – 500GB HDD (un-optimized) – 120GB SSD – 24 concurrent containers (1 CPU/2 GB memory)

– Workload

– Modeled after Facebook workload[1] – Mix of high/low priority jobs (7,000+ tasks) 16

[1] Mitigating the Negative Impact of Preemption on Heterogeneous MapReduce Workloads. Cheng et. al. CNSM 2011.

Comparison of Different Preemption Policies on YARN

17

50 100 150 200 250 CPU Wastage [core-hours]

Resource Wastage

Kill Chk-HDD Chk-SSD Chk-NVM 2 4 6 8 10 Energy [kW*h]

Energy Consumption

2 4 6 8 10 12 14 16 Low Priority High Priority Response Time [min]

Average Job Performance

0.25 0.5 0.75 1 5 10 15 20 25 30 Response Time [min]

Basic Preemption CDF

Kill Chk-HDD Chk-SSD Chk-NVM

• 22%

61% 35% 67%

Benefits of Adaptive Preemption

18

2 4 6 8 10 12 14 Low Priority High Priority Response Time [min]

HDD

Basic Adaptive 1 2 3 4 5 6 7 8 Low Priority High Priority Response Time [min]

SSD

1 2 3 4 5 6 7 Low Priority High Priority Response Time [min]

NVM

28% 7% 16% 7% 20% 14%

Overhead of Checkpoint-based Preemption

CPU overhead is negligible, but I/O overhead is significant on slow storage

19

10 20 30 40 50 60 70 80 90 100 HDD SSD NVM

CPU Overhead [%]

CPU Overhead

Basic Adaptive 10 20 30 40 50 60 70 80 90 100 HDD SSD NVM

I/O Overhead [%]

I/O Overhead

Basic Adaptive

Conclusion and Future Work

– Preemption in shared clusters is expensive and preemption using application-transparent checkpointing is able to improve resource efficiency and overall application performance. – Adaptive preemption that combines checkpoint and kill can further improve the performance and reduce the preemption cost. – By leveraging emerging fast storage technologies such as NVM, even more savings can be achieved.

Future Work

– A wide range of applications – Checkpointing with NVRAM – Integration with other cluster scheduling policies
