Serialisation in Life Science: Time to Harness the Opportunity - - PowerPoint PPT Presentation

... bridging your enterprise and your plant Serialisation in Life Science: Time to Harness the Opportunity Europe - Cork Office North America - Massachusetts Office West Coast Office Nore House 36 Mechanic Street 533 Airport Blvd Bessboro


slide-1
SLIDE 1

t: 1-877-7784771 f: ++1 (508) 302-5364 e: info@esp.ie w: www.esp-corp.com

Europe - Cork Office Nore House Bessboro Road Blackrock, Cork Ireland t: +353 21 4614400 North America - Massachusetts Office West Coast Office 36 Mechanic Street 533 Airport Blvd Unit 109 , Suite 400 Foxboro, MA 02035 Burlingame, CA 94010 USA USA t: +1 774-215-5522 t: +1 650-919-3377

www.EnterpriseSystemPartners.com

Serialisation in Life Science: Time to Harness the Opportunity

... bridging your enterprise and your plant

1

slide-2
SLIDE 2

www.EnterpriseSystemPartners.com

Eamonn O’Mathuna Personal Introduction

  • Over 26 years as Systems Expert in Big Pharma
  • Automation Team Leader on Serialisation Project in

Genzyme Waterford

  • Joined ESP in 2012 as Manufacturing Systems

Consultant, expert in MES, Automation and Serialisation solutions

  • Currently Project Manager on Serialisation Rollout in

Teva Runcorn, UK

2

slide-3
SLIDE 3

www.EnterpriseSystemPartners.com

Enterprise System Partners

Enterprise System Partners (ESP) is a Global Consultancy Company specialising in; » Manufacturing Execution Systems (MES) » Serialisation, Track & Trace

Also ERP & Process Automation but primarily in support of the above

3

slide-4
SLIDE 4

www.EnterpriseSystemPartners.com

Enterprise System Partners

A Global Track Record of Success

Medical Device Pharmaceutical /Biotechnology

4

slide-5
SLIDE 5

www.EnterpriseSystemPartners.com

Agenda

  • Understanding the Impact of Serialisation on Business
  • The Business (Case) Drivers for Serialisation
  • Optimising Your Serialisation Investment
  • A Proven Serialisation Strategy
  • Standardisation – An Effective Approach – A Case

Study

Impact on Business Business Drivers Optimise Investment Strategy Effective Approach

5

slide-6
SLIDE 6

www.EnterpriseSystemPartners.com

The Impact of Serialisation on Business

Impact on Business Business Drivers Optimise Investment Strategy Effective Approach

Serialisation isn’t new… …it has been in industry for decades

1990’s 2000’s 2010’s

Pacemaker 6

slide-7
SLIDE 7

www.EnterpriseSystemPartners.com

Impact on Business Business Drivers Optimise Investment Strategy Effective Approach

The Impact of Serialisation on Business

7

» Put a serial number on a box. » Read it into a database. » Job Done? Do We Underestimate Serialisation?

slide-8
SLIDE 8

www.EnterpriseSystemPartners.com

End to End (European EFPIA Approach)

Closing Comments Execution Business Drivers Big Picture Fundamentals Overview

8

Serialization Types

Source : EFPIA European Medicines Verification System 11 Mar 2013

Tamper Evident Seal

slide-9
SLIDE 9

www.EnterpriseSystemPartners.com

Aggregation

Closing Comments Execution Business Drivers Big Picture Fundamentals Overview

9

» Important to remember that once aggregation is complete, it must also be maintained and then broken down as product gets closer to the patient.

1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1

Case Unit Bundle Pallet

Serialization Types

slide-10
SLIDE 10

www.EnterpriseSystemPartners.com

ePedigree (California)

1

Hospital / Pharmacy Manufacturer Distributor Wholesaler

Product Flow

Serialization Types

Next Steps Plans/Progress Req's Lessons Learned Approach ESP Serialization

Pedigree is built as product flows through the supply chain

slide-11
SLIDE 11

www.EnterpriseSystemPartners.com

Impact on Business Business Drivers Optimise Investment Strategy Effective Approach

Serialisation Impact

Enterprise Application (Company Wide) Site Manager (Site Level)

LEVEL 4 LEVEL 3

Line Manager (Line Level)

LEVEL 2

Device Level

LEVEL 1

Supplier Manufacturer Distributor Distributor/ Wholesaler Hospital / Pharmacy

Entire IT Architecture Entire Supply Chain

Serialisation Impacts the Entire Business

The Impact of Serialisation on Business

11

slide-12
SLIDE 12

www.EnterpriseSystemPartners.com

Impact on Business Business Drivers Optimise Investment Strategy Effective Approach

The Impact of Serialisation on Business

12

Protect the patient

» Counterfeit product is dangerous!

More efficient recalls

» Minimise patient impact » Minimise financial impact to the company

Brand Protection

» Protecting your supply chain is critical in protecting your brand » If counterfeiters see your supply chain as being weaker than that of

  • ther companies, then they will specifically target your products

Avoid Revenue Loss.

» Each counterfeit unit is potentially a unit of lost revenue

Regulatory compliance.

» Meeting regulatory requirements will be mandatory

slide-13
SLIDE 13

www.EnterpriseSystemPartners.com

Impact on Business Business Drivers Optimise Investment Strategy Effective Approach

The Impact of Serialisation on Business

13

Main Markets » US Market was driven by CA law. This regulation requires full ePedigree. » Recent Federal (FDA) Drug Quality and Security Act (H.R.3204) if signed will supersede CA law.

» Serialisation by Q4 2017 » Aggregation and full traceability by 2023 (FDA to define mechanism)

slide-14
SLIDE 14

www.EnterpriseSystemPartners.com

Impact on Business Business Drivers Optimise Investment Strategy Effective Approach

The Impact of Serialisation on Business

14

Main Markets continued » European requirement based on EFPIA guidelines (European Federation of Pharmaceutical Industries and

Associations). These require Serialisation with Tamper

Evidence and the use of a Randomised set of numbers but not full Track & Trace. Approval expected Q2 2014 » Other markets are tending to go with one or other or a combination of the above. Korea, Turkey, Saudi Arabia

slide-15
SLIDE 15

www.EnterpriseSystemPartners.com

Impact on Business Business Drivers Optimise Investment Strategy Effective Approach

The Business (Case) Drivers for Serialisation

15

slide-16
SLIDE 16

www.EnterpriseSystemPartners.com

Impact on Business Business Drivers Optimise Investment Strategy Effective Approach

The Business (Case) Drivers for Serialisation

16

Counterfeit Medicines – Can YOU Tell the Difference?

FAKE AUTHENTIC

slide-17
SLIDE 17

www.EnterpriseSystemPartners.com

17

Counterfeits seized in Beijing

slide-18
SLIDE 18

www.EnterpriseSystemPartners.com

18

Not cGMP

slide-19
SLIDE 19

www.EnterpriseSystemPartners.com

  • Patient Safety
  • Supply Chain Management
  • Business Continuity
  • Brand Protection

Impact on Business Business Drivers Optimise Investment Strategy Effective Approach

The Business (Case) Drivers for Serialisation

19

Core Business Drivers

SERIALISATION

slide-20
SLIDE 20

www.EnterpriseSystemPartners.com

Impact on Business Business Drivers Optimise Investment Strategy Effective Approach

Optimising Your Serialisation Investment

20

slide-21
SLIDE 21

www.EnterpriseSystemPartners.com

Impact on Business Business Drivers Optimise Investment Strategy Effective Approach

Optimising Your Serialisation Investment

21

Complexity & Cost of Serialisation

ePedigree Aggregation End to End

slide-22
SLIDE 22

www.EnterpriseSystemPartners.com

Impact on Business Business Drivers Optimise Investment Strategy Effective Approach

Optimising Your Serialisation Investment

22

Global Considerations » Requires global multifunctional multi-disciplined implementation team (Including Partners) » Anticipate and risk assess any expected changes in regulatory requirements & timelines » Plan artwork changes early » Readiness of CMOs & distribution partners

slide-23
SLIDE 23

www.EnterpriseSystemPartners.com

Impact on Business Business Drivers Optimise Investment Strategy Effective Approach

Optimising Your Serialisation Investment

23

Site Considerations » Agree impact on OEE and

  • ther KPIs at both ramp-up

and steady state » Plan inventory levels well in advance to allow for line installation downtime » Fail safe design of data capture & management

slide-24
SLIDE 24

www.EnterpriseSystemPartners.com

Impact on Business Business Drivers Optimise Investment Strategy Effective Approach

A Proven Serialisation Strategy

24

slide-25
SLIDE 25

www.EnterpriseSystemPartners.com

Impact on Business Business Drivers Optimise Investment Strategy Effective Approach

A Proven Serialisation Strategy

25

It is Vital to Approach Serialisation with a Strategy which: » Is not sensitive to subtle changes in regulations » Allows for phased execution » Avoids unnecessary complexity

slide-26
SLIDE 26

www.EnterpriseSystemPartners.com

Impact on Business Business Drivers Optimise Investment Strategy Effective Approach

A Proven Serialisation Strategy

26

High Level Process Design » Top down approach » Clear understanding of market and business requirements from Pharmacy/Hospital right back to Packaging Line » Develop a top level realistic time line » Clearly understand the business and regulatory constraints » Identify, document and clearly communicate the agreed business process to all stake holders Requirements

slide-27
SLIDE 27

www.EnterpriseSystemPartners.com

Impact on Business Business Drivers Optimise Investment Strategy Effective Approach

A Proven Serialisation Strategy

27

Requirements Typical Plant Level Requirements » No impact to Pack Line capacities » Maintain Paperless (MES) operation » Minimise manual input of data during batch » Ensure data integrity through out all systems particularly at Line level » Obtain Serial Numbers from Corporate server & manage locally » Print serial numbers on each shelf unit (child), Case label (parent), Pallet label (grandparent)

slide-28
SLIDE 28

www.EnterpriseSystemPartners.com

Impact on Business Business Drivers Optimise Investment Strategy Effective Approach

A Proven Serialisation Strategy

28

Project Team – Cross Functional Across All Departments » Technology selection » Vendor selection » Detailed understanding of timelines » Functional Design

  • Data carrier process
  • Line and existing equipment integration
  • ERP/MES/EPCIS integration
  • Artwork and Label Design/changes
slide-29
SLIDE 29

www.EnterpriseSystemPartners.com

Impact on Business Business Drivers Optimise Investment Strategy Effective Approach

A Proven Serialisation Strategy

29

Planning » Do not underestimate;

  • the challenge in getting a project of this scope underway
  • the complexity of Serialisation

» Availability of key vendors will inevitably be an issue. Lead-times are already getting longer » Vendor management is critical

  • Tight timelines
  • Diverse vendor set
  • Pressure on vendors from other customers
slide-30
SLIDE 30

www.EnterpriseSystemPartners.com

Impact on Business Business Drivers Optimise Investment Strategy Effective Approach

A Proven Serialisation Strategy

30

Planning (Contd..) » Plan packaging line downtime. Try to plan pilot implementation on line with low utilization » Plan artwork changes early, these changes require significant management

slide-31
SLIDE 31

www.EnterpriseSystemPartners.com

Impact on Business Business Drivers Optimise Investment Strategy Effective Approach

A Proven Serialisation Strategy

31

» Map out the business process across the entire

  • rganization. Involve strategic partners in this

process » Identify and prioritise countries based on defined business drivers Process » Get clear understanding of Business Drivers & Constraints (Ensure this is user driven)

slide-32
SLIDE 32

www.EnterpriseSystemPartners.com

Impact on Business Business Drivers Optimise Investment Strategy Effective Approach

A Proven Serialisation Strategy

32

» Agree benefits with business owners » Agree impact on OEE and other KPIs at both ramp-up and steady state Process (Contd..) » Anticipate and risk assess any expected changes in regulatory requirements

slide-33
SLIDE 33

www.EnterpriseSystemPartners.com

Impact on Business Business Drivers Optimise Investment Strategy Effective Approach

Standardisation – A Case Study

33

Case Study – Design Challenge » Develop a flexible serialisation solution for multiple market requirements across multiple packaging lines.

slide-34
SLIDE 34

www.EnterpriseSystemPartners.com

Impact on Business Business Drivers Optimise Investment Strategy Effective Approach

Standardisation – A Case Study

34

Design Solution » Create a standard design solution with the same equipment and configuration across all packaging lines » The solution involves 4 elements at the end of the packing lines

  • 1. Carton printer and check weigher
  • 2. Semi-automatic case packer
  • 3. Case sealer and case label print and apply
  • 4. Automatic aggregation of manual pallet building
slide-35
SLIDE 35

www.EnterpriseSystemPartners.com

Impact on Business Business Drivers Optimise Investment Strategy Effective Approach

Standardisation – A Case Study

35

  • 1. Carton printer and check weigher.

» Cartons are printed (Lot, Expiry date and 2D data matrix) » Carton print is inspected » Carton is weighed » When successful, carton serial number is commissioned

slide-36
SLIDE 36

www.EnterpriseSystemPartners.com

Impact on Business Business Drivers Optimise Investment Strategy Effective Approach

Standardisation – A Case Study

36

  • 2. Semi-automatic case packer

» Cartons are scanned as they enter case packer » Cartons are aggregated to the case once case is full.

slide-37
SLIDE 37

www.EnterpriseSystemPartners.com

Impact on Business Business Drivers Optimise Investment Strategy Effective Approach

Standardisation – A Case Study

37

  • 3. Case sealer and case label

print and apply » Case is sealed » Case label is applied » Case label is inspected » When successful, case auto commissioned and aggregated to pallet

slide-38
SLIDE 38

www.EnterpriseSystemPartners.com

Impact on Business Business Drivers Optimise Investment Strategy Effective Approach

Standardisation – A Case Study

38

  • 3. Automatic aggregation of

manual pallet building » Successful cases are automatically aggregated to pallet » When desired number cases are aggregated pallet is closed and a pallet label is printed » Pallet is then commissioned using HHT

slide-39
SLIDE 39

www.EnterpriseSystemPartners.com

Impact on Business Business Drivers Optimise Investment Strategy Effective Approach

Standardisation – A Case Study

39

Design challenges - Design must allow for; » Manual case packing on two lines » A fully automatic case packer and automatic palletiser on one line » Any line must be capable of running any product (for flexibility and redundancy)

slide-40
SLIDE 40

www.EnterpriseSystemPartners.com

Impact on Business Business Drivers Optimise Investment Strategy Effective Approach

Standardisation – A Case Study

40

Benefits » Implementation cost for subsequent lines have been reduced by ~19% » Validation effort reduced and standardised with generic URS, DS, IQ, OQ, PQ doc’s for subsequent lines. Strict control of “core” configuration required (no adhoc changes) » Off line validation of equipment reduced the downtime requirements of production line » Same configuration on packaging lines allows all lines to run the same products

slide-41
SLIDE 41

www.EnterpriseSystemPartners.com

Impact on Business Business Drivers Optimise Investment Strategy Effective Approach

Standardisation – A Case Study

41

Benefits Continued » Reduced training, spare parts as solution is

  • generic. Increased operator mobility

» Manual packaging line can be used to complete testing for system upgrades (off-line) prior to implementation on all lines

slide-42
SLIDE 42

www.EnterpriseSystemPartners.com

Impact on Business Business Drivers Optimise Investment Strategy Effective Approach

Standardisation – A Case Study

42

Program Status (September 2013) » 1 line is in production for non-serialised products » 3 lines are in validation testing » 2 lines ordered for go-live Q1 2014 » 5 lines scheduled for go-live 2014

slide-43
SLIDE 43

www.EnterpriseSystemPartners.com

Thank You

43

Eamonn O’Mathuna Manufacturing Systems Consultant

m: +353 87 7377545 eamonn.omathuna@esp.ie

www.EnterpriseSystemPartners.com

Europe Cork – Head Office Dublin North America Boston San Francisco
