Semantics-Aware Prediction for Analytic Queries in MapReduce Environment

Weikuan Yu, Zhuo Liu, Xiaoning Ding Florida State University Auburn University New Jersey Institute of Technology

P2S2: S2

Background

n

MapReduce is a popular data-centric programming model.

n

Hive and Pig are popular data warehouse systems.

Ø

More than 40% of Hadoop jobs at Yahoo! were Pig programs back in 2009, more with Hive now.

Ø

In Facebook, 95% of MR jobs are generated by Hive.

n

In Hive, each SQL query is compiled and translated into a DAG (Directed Acyclic Graph) of MapReduce jobs with inner-dependencies.

Source: ICDE’10 by Facebook AGG (J1) Join (J3) Join (J2) AGG (J4)

P2S2: S3

Motivation

n Semantic gap: between Hive and Hadoop

Ø Hadoop is

un-aware of such dependency and inter-job relationship, just treating all jobs as the same.

Ø Without such awareness, it will be difficult for Hadoop to

schedule jobs that belong to a query efficiently.

n Problems:

Ø Suboptimal query response time Ø Unfairness among queries

P2S2: S4

Efficiency issue for queries with varied sizes

n In this test, QA, QB and QC are issued in sequence, where QB is a

large query.

n Under HCS, interleaved execution happens among queries’ jobs.

AGG (J1) Join (J3) Join (J2) AGG (J4) AGG (J1) Sort (J2)

QB QC

AGG (J1) Sort (J2)

QA

QC J2 QBJ2 QC J1 QBJ1 QA J2 QA J1 QB J3 QB J4

Resource Allocation

P2S2: S5

Query Delays shown by GANTT Chart

n QA arrives first with its J1 job, QB and QC afterwards with their

jobs listed accordingly.

n QA-J2 gets delayed by QB-J1. QC-J2 gets delayed by QB-J2. n Query response time can be improved if the scheduler is aware of

the query semantics, therefore the relationship among the jobs.

100 200 300 400 500 600 700

QA QB QC

Time Elapse (seconds)

J1 J2 J3 J4 J1 J1 J2 J2

Execution Map Stall Reduce Stall

P2S2: S6

Semantics-Aware Query Prediction

n Three main techniques

Ø Semantics extraction (DAG, operator type, predicates, etc.) Ø Selectivity Estimation Ø Query prediction

JobTracker

TaskTracker

Hadoop

JobListener

Semantics Extraction

TaskTracker TaskTracker

Query prediction Selectivity Estimation Execution Engine Parser Semantics Analyzer HiveQL Queries

Job & Semantics

Results

Hive

P2S2: S7

n Selectivity estimation

Ø Predict each job node’s intermediate (Med) and output (Out) data sizes

recursively along the DAG (from bottom to top).

Ø For different job types, e.g., Groupby, Join, Select, we reply on certain

formulas and offline-built histograms to estimate their selectivities.

n Logic: Selectivity estimation=>Job/query resource estimation and

time modeling =>Used for efficient query scheduling

Selectivity estimation for a query’s jobs

AGG Join Join

SORT

T1 T2 T3 Med

Out

Map Reduce In(T1)

P2S2: S8

Selectivity Estimation

n IS is used for estimating MOF size

Ø IS = DMed/DIn

n Final Selectivity (FS) is defined as:

Ø FS = |Out|*WOut/DIn

n Predicate selectivity (ratio of selected rows to input rows)

Ø Spred = |Med| /|In|

n Projection selectivity (ratio of selected cols to tuple width)

Ø Sproj = ∑ "#$%ℎ'() * +,),'-,. /01234"#$%ℎ

P2S2: S9

Intermediate Selectivity - IS

Ø For extract job such as select and order by,

IS = Spred * Sproj

Ø For join job:

IS = Spred 1 * Sproj 1 *r1+Spred 2 * Sproj 2 *(1-r1)

Ø Groupby can involve local combine: IS = Scomb * Sproj

Ø For clustered keys,

Scomb = min(1,

!.#$% ! ∗'()*#)* Spred = min(Spred, !.#$% ! )

Ø For randomly distributed keys,

Scomb= min(Spred,

!.#$% ! /N-.(/)

P2S2: S10

Final Selectivity – Output

n For extract job,

Ø For “top k” job, |Out|=min(|In|, k) Ø For “order by” job, |Out|=|In|

n For groupby job,

Ø |Out|= min(|T|*Spred, T.dxy)

n For join job,

Ø Equ-join with uniform keys:

|Out| = |T1⋈ T2| = |T1|∗|T2|∗

& '()(+&.-., +0.-.)

Ø Chained joins:

|Out| = |T1. pred1 ⋈ T2. pred2 ⋈ T3. pred3| =Spred 1∗Spred 2∗Spred 3 max(|T1|, |T2|, |T3|)

P2S2: S11

An example for selectivity estimation

n Predict jobs’ selectivity recursively in a query.

Pred

Group by n

25 24 800000 10000 10000 9600 9600 800000 768000 768000 200000

Job 1 Job 2 Job 3

|Out|= 0.96*25*10000 *1/max(25,25) |Out|= 0.96 * max(25, 10000, 800000) |Out| = min(768000,200000)

s ps n⋈s

MED2 MED1

Join

MED2 MED1

Join resl

MED1

n⋈s ⋈ps

P2S2: S12

Multivariate Time Prediction

n List of Considered Input Features

Ø Operators Ø Input Data Ø Output Data Ø Data Growth

P2S2: S13

Job Time Prediction Model

Ø Model job execution time based on selectivity estimation Ø Training on over 5647 MR jobs, about 1000 queries from TPC-

DS and TPC-H of different scales.

Ø ! is trained for extract, groupby and join jobs respectively.

P2S2: S14

Task Time Prediction Model

Ø Data size:

Ø TDIn_i and TDOut_i

Ø The predicted time for the i-th task: ETi

Ø ETi = k0 + k1 TDIn_i + k2 TDOut_i + k3 * P (1-P) TDIn_i

P2S2: S15

Scheduling with Semantics Awareness

n Semantics-Aware Resource Demand

Ø Weight Resource Demand (WRD): aggregate the demand from

all map tasks (MTi) and Reduce tasks (RTi)

Ø WRD = ∑(#$% ∗ '#% ) + ∑(($% ∗ '(%)

n Experimented with a simple greedy scheduling policy

Ø Prioritizing smallest Queries for fast turnaround

Ø Smallest WRD First (SWRD) query scheduling

P2S2: S16

Evaluation setup

n Benchmarks.

Ø Built with TPC-H, TPC-DS queries and

Terasort/Grep/Wordcount MapReduce jobs.

Ø Submitted in Poisson interval

n Metrics

Ø Accuracy of the prediction via semantics awareness Ø Efficiency: query execution time

P2S2: S17

Estimation of Job Execution time

n Accuracy

Ø On average, 13.98% error rate for the test set of jobs.

Job Time Estimation

P2S2: S18

Estimation of Task Execution

n Map Task Execution Time

Ø Join operators lead to lower accuracy

n Reduce Task Execution Time

P2S2: S19

Validation of job and query time estimation

n Predicted time accuracy for queries

Ø Error rate is 8.3% on average for 22 100G TPC-H queries.

Query Time Estimation

200 400 600 800 1000 1200 1400 Q1 Q2 Q3 Q4 Q5 Q6 Q7 Q8 Q9 Q10 Q11 Q12 Q13 Q14 Q15 Q16 Q17 Q18 Q19 Q20 Q21 Q22

Query Response Time (sec) Actual Estm

P2S2: S20

Benefits of Semantics-Aware Scheduling

n Execution time of queries

Ø Compared to HFS, SWRD improves the execution of Bing and

Facebook workloads by 44% and 40%, respectively.

Ø Compared to HCS, SWRD improves by 27.4% and 72.8%,

respectively.

0" 400" 800" 1200" 1600" 2000"

Bing"" Facebook"

Execu&on)Time)(seconds))

HFS" HCS" SWRD"

P2S2: S21

Conclusion and Future Work

n Introduced cross-layer semantics extraction and percolation to

increase the semantics awareness of the Hadoop job scheduler

n Formalized the estimation of selectivity for intermediate data

and final output

n Developed a multivariate prediction model for job and task

execution time and validated the accuracy

Ø Leveraged semantics awareness for efficient query scheduling in HIVE

n Plan to pursue further integration of semantics awareness in

complex query scheduling and other data analytics systems.

P2S2: S22

Acknowledgement
