Semantic Assessment and Monitoring of Crowdsourced Geographic Information Hamish McNair, Paul Goodhue University of Canterbury Christchurch, New Zealand Outline Our research Project outline FOSS framework for the project

slide-1
SLIDE 1

Semantic Assessment and Monitoring of Crowdsourced Geographic Information

Hamish McNair, Paul Goodhue

University of Canterbury Christchurch, New Zealand

slide-2
SLIDE 2

Outline

  • Our research
  • Project outline
  • FOSS framework for the project
  • Crowdsourcing information
  • Determining Trust
  • Ontologies
  • Linked Data
  • Future direction & Conclusion
slide-3
SLIDE 3

Our Research

  • Trusting Crowdsourced Geographic Information

– Improving the trust of crowdsourced geographic information

  • Crowdsourcing Spatial Data Supply Chains

– Implications of trust beyond the capture of crowdsourced geographic information.

slide-4
SLIDE 4

Project – Fruit Trees

slide-5
SLIDE 5

Project – Fruit Trees

slide-6
SLIDE 6

Project – Fruit Trees

slide-7
SLIDE 7

INPUT TRUST RATING ONTOLOGY LINKED DATA OUTPUT

SPARQL RDFLib RDFLib Folium

slide-8
SLIDE 8

INPUT

slide-9
SLIDE 9

Crowdsourcing

User Interface WFS-T Data Server Database

slide-10
SLIDE 10

Data Model

slide-11
SLIDE 11

TRUST RATING

slide-12
SLIDE 12

Conceptual Trust Model

Intrinsic: Extrinsic:

Spatio-temporal Social Semantic

Components of CGI:

Spatial: Spatial comparison to neighbours based on rules about the CGI Temporal: Temporal comparison to neighbours based on rules about the CGI Spatial: Shape metrics of the geometry based on geometry type Temporal: Assessment of feature changelog or age of feature Assessment of the trust

  • f the author as

reviewed by the crowd, e.g. through Linus’ Law, peer reviews and Consensus Crowdsorucing Assessment of the author’s trust and likely influence on the trust

  • f the CGI, e.g. through

previous trust ratings or assessments of local knowledge Assessment of internal consistency of CGI with

  • ntologies describing

the CGI Assessment of CGI to external data and

  • ntologies known to

influence the CGI Assessments of the Information Assessments of the Informations Source

slide-13
SLIDE 13

Trust Model

Python PostgreSQL/ PostGIS OWL

Feature type rules queried from OWL Features queried From PostgreSQL Trust rating written Back to database Comparisons between Features and ontology in python

slide-14
SLIDE 14

Feature Trust Rating

fruit_tree_species Lemon fruit_tree_height 2m fruit_tree_crown_diameter 1m fruit_tree_dbh 0.12m fruiting_observation Fruiting fruit_tree_trust_rating_overall 100 fruit_tree_trust_rating_metrics 100 fruit_tree_trust_rating_fruiting 100 fruit_tree_trust_rating_location 100

slide-15
SLIDE 15

Feature Trust Rating

fruit_tree_species Coconut fruit_tree_height 5m fruit_tree_crown_diameter 2m fruit_tree_dbh 0.3m fruiting_observation Fruiting fruit_tree_trust_rating_overall 66.67 fruit_tree_trust_rating_metrics 100 fruit_tree_trust_rating_fruiting 100 fruit_tree_trust_rating_location

slide-16
SLIDE 16

ONTOLOGY

slide-17
SLIDE 17

Ontologies

  • Ontologies in crowdsourcing?

– accessibility – adjustability – versatility

  • Implementation

– Protégé – OWL/RDFS/XML

slide-18
SLIDE 18

Ontology

slide-19
SLIDE 19

Ontology

hasMaxHeight

slide-20
SLIDE 20

Ontology

hasMaxHeight

10 metres

slide-21
SLIDE 21

Protégé

slide-22
SLIDE 22

Protégé

slide-23
SLIDE 23

Protégé

slide-24
SLIDE 24

Protégé

slide-25
SLIDE 25

LINKED DATA

SPARQL RDFLib

slide-26
SLIDE 26

SPARQL Query in RDFLib

  • Return reference attributes (via URIs)

SELECT ?O WHERE { <http://somethingGoesHere.org/foss4tree#appleTree> foss4tree:hasMaxHeight ?O }

slide-27
SLIDE 27

SPARQL Query in RDFLib

  • Return reference attributes (via URIs)

SELECT ?O WHERE { <http://somethingGoesHere.org/foss4tree#appleTree> foss4tree:hasMaxHeight ?O }

slide-28
SLIDE 28

SPARQL Query in RDFLib

  • Return reference attributes (via URIs)

SELECT ?O WHERE { <http://somethingGoesHere.org/foss4tree#appleTree> foss4tree:hasMaxHeight ?O }

slide-29
SLIDE 29

SPARQL Query in RDFLib

  • Return reference attributes (via URIs)

SELECT ?O WHERE { <http://somethingGoesHere.org/foss4tree#appleTree> foss4tree:hasMaxHeight ?O }

slide-30
SLIDE 30

SPARQL Query in RDFLib

  • Return reference attributes (via URIs)

SELECT ?O WHERE { <http://somethingGoesHere.org/foss4tree#appleTree> foss4tree:hasMaxHeight ?O }

slide-31
SLIDE 31

SPARQL Query in RDFLib

  • Return reference attributes (via URIs)

SELECT ?O WHERE { <http://somethingGoesHere.org/foss4tree#appleTree> foss4tree:hasMaxHeight ?O }

TO THE TRUST MODEL

slide-32
SLIDE 32

Linked Data

  • Structure of RDF

– Triples (Subject, Predicate, Object)

<http://somethingGoesHere.org/foss4tree#t44> <foss4tree:hasHeight> <2.5>

– Familiar (URIs), accessible, mashups

slide-33
SLIDE 33

OUTPUT

RDFLib Folium

slide-34
SLIDE 34

LINKED DATA PYTHON MODEL WUNDERGROUND FOLIUM OUTPUT

slide-35
SLIDE 35

LINKED DATA PYTHON MODEL WUNDERGROUND FOLIUM OUTPUT PYTHON MODEL TRUST RATING > 70 WINDSPEED MAP THIS

slide-36
SLIDE 36

LINKED DATA PYTHON MODEL WUNDERGROUND FOLIUM OUTPUT LINKED DATA

?id <http://somethingGoesHere.org/foss4tree#hasTR> ?tr . FILTER (?tr > 70) ?id <http://somethingGoesHere.org/foss4tree#hasSpecies> ?species . ?id <http://somethingGoesHere.org/foss4tree#hasFruiting> ?fruiting . ?id <http://somethingGoesHere.org/foss4tree#hasLat> ?lat . ?id <http://somethingGoesHere.org/foss4tree#hasLong> ?long . ?id <http://somethingGoesHere.org/foss4tree#hasHeight> ?height

slide-37
SLIDE 37

LINKED DATA PYTHON MODEL WUNDERGROUND FOLIUM OUTPUT PYTHON MODEL TRUST RATING > 70 ID i LAT i LONG i … ID ii LAT ii LONG ii … ID iii LAT iii LONG iii … ID iv LAT iv LONG iv …

slide-38
SLIDE 38

LINKED DATA PYTHON MODEL WUNDERGROUND FOLIUM OUTPUT WEATHER UNDERGROUND

http://api.wunderground.com/api/##/geolookup/q/%f,%f.json http://api.wunderground.com/api/##/conditions/q/pws:%s.json www.wunderground.com

slide-39
SLIDE 39

LINKED DATA PYTHON MODEL WUNDERGROUND FOLIUM OUTPUT PYTHON MODEL TRUST RATING > 70 WINDSPEED

slide-40
SLIDE 40

LINKED DATA PYTHON MODEL WUNDERGROUND FOLIUM OUTPUT FOLIUM

map1 = folium.Map(location = [Lat,Long], zoom_start=16) . . . For tree in trees: map1.simple_marker(treeLat, treeLong, popup = '''... https://github.com/python-visualization/folium

slide-41
SLIDE 41

LINKED DATA PYTHON MODEL WUNDERGROUND FOLIUM OUTPUT OUTPUT html ...

slide-42
SLIDE 42
slide-43
SLIDE 43
slide-44
SLIDE 44

Where to from here…

slide-45
SLIDE 45

Where to from here…

WHY? Improved credibility of crowdsourced data

slide-46
SLIDE 46

Where to from here…

WHY? Improved credibility of crowdsourced data HOW? Trust models and implementation

slide-47
SLIDE 47

Where to from here…

WHY? Improved credibility of crowdsourced data HOW? Trust models and implementation THE HERE AND NOW

slide-48
SLIDE 48

Traditional Spatial Datasets

  • Credibility from legacy
  • Provenance for tracing errors
  • Dataset-level consideration
slide-49
SLIDE 49

W3C PROV

DATASET COLLECTION wasGeneratedBy

slide-50
SLIDE 50

W3C PROV

DATASET COLLECTION wasGeneratedBy

… back to triples!

slide-51
SLIDE 51

W3C PROV

DATASET COLLECTION AGENCY wasGeneratedBy wasAttributedTo

slide-52
SLIDE 52

W3C PROV

DATASET COLLECTION AGENCY wasGeneratedBy wasAssociatedWith wasAttributedTo

slide-53
SLIDE 53

Authoritative Data

  • Dataset-level reactive provenance
slide-54
SLIDE 54

Authoritative Data

  • Dataset-level reactive provenance
slide-55
SLIDE 55

Authoritative Data

  • Dataset-level reactive provenance
slide-56
SLIDE 56

Crowdsourced Data

  • Feature level
slide-57
SLIDE 57

Crowdsourced Data

  • Feature level
slide-58
SLIDE 58

Crowdsourced Data

  • Feature level
slide-59
SLIDE 59

Crowdsourced Data

  • Feature level
slide-60
SLIDE 60

Crowdsourced Data

  • Feature level
slide-61
SLIDE 61

Trust Ratings

  • Simple indication of credibility of

Datasets Features Attributes

  • Provides proactive provenance
  • Increases usability of crowdsourced data
