Securing DNSSEC Keys via Threshold ECDSA From Generic MPC Kris Shrishak TU Darmstadt, Germany November 6, 2020 NIST Workshop on Multi-Party Threshold Schemes 2020 Based on work published at ESORICS20 with Anders Dalskov, Marcel Keller,

slide-1
SLIDE 1

Securing DNSSEC Keys via Threshold ECDSA From Generic MPC

Kris Shrishak

TU Darmstadt, Germany

November 6, 2020 NIST Workshop on Multi-Party Threshold Schemes 2020

Based on work published at ESORICS’20 with Anders Dalskov, Marcel Keller, Claudio Orlandi and Haya Shulman

slide-2
SLIDE 2

This work

Threshold ECDSA for DNS zone signing

1 / 20

slide-3
SLIDE 3

This work

Threshold ECDSA for DNS zone signing

  • Key security for DNSSEC
  • Generic way of doing threshold ECDSA (signing and key gen)
  • Support for lots of different threat models
  • As fast, or faster, than previous work

1 / 20

slide-4
SLIDE 4

Outline

DNS and DNSSEC Threshold signatures for DNSSEC

slide-5
SLIDE 5

Outline

DNS and DNSSEC Threshold signatures for DNSSEC

slide-6
SLIDE 6

DNS

DNS is a protocol for mapping names to addresses

Client DNS Server https://ducks.de 198.51.100.43 “Where is ducks.de.?” “It’s at 198.51.100.43” HTTP GET / Host: ducks.de

2 / 20

slide-7
SLIDE 7

DNS

DNS is a protocol for mapping names to addresses

Client DNS Server https://ducks.de 198.51.100.43 “Where is ducks.de.?” “It’s at 198.51.100.43” HTTP GET / Host: ducks.de

2 / 20

slide-8
SLIDE 8

DNS

DNS is a protocol for mapping names to addresses

Client DNS Server https://ducks.de 198.51.100.43 “Where is ducks.de.?” “It’s at 198.51.100.43” HTTP GET / Host: ducks.de

2 / 20

slide-9
SLIDE 9

DNS

DNS is a protocol for mapping names to addresses

Client DNS Server https://ducks.de 198.51.100.43 “Where is ducks.de.?” “It’s at 198.51.100.43” HTTP GET / Host: ducks.de

2 / 20

slide-10
SLIDE 10

DNS Insecurity

Poisoning/Spoofing is possible

3 / 20

slide-11
SLIDE 11

DNS Insecurity

Poisoning/Spoofing is possible First answer is accepted

3 / 20

slide-12
SLIDE 12

DNS Insecurity

Poisoning/Spoofing is possible First answer is accepted

Client ISP DNS Server https://ducks.de 198.51.100.43 Adversary 198.51.100.123 ducks.de.? ducks.de.? 198.51.100.123 HTTP GET / Host: ducks.de

3 / 20

slide-13
SLIDE 13

DNS Insecurity

Poisoning/Spoofing is possible First answer is accepted

Client ISP DNS Server https://ducks.de 198.51.100.43 Adversary 198.51.100.123 ducks.de.? ducks.de.? 198.51.100.123 HTTP GET / Host: ducks.de

3 / 20

slide-14
SLIDE 14

DNS Insecurity

Poisoning/Spoofing is possible First answer is accepted

Client ISP DNS Server https://ducks.de 198.51.100.43 Adversary 198.51.100.123 ducks.de.? ducks.de.? 198.51.100.123 HTTP GET / Host: ducks.de

3 / 20

slide-15
SLIDE 15

DNS Insecurity

Poisoning/Spoofing is possible First answer is accepted

Client ISP DNS Server https://ducks.de 198.51.100.43 Adversary 198.51.100.123 ducks.de.? ducks.de.? 198.51.100.123 HTTP GET / Host: ducks.de

3 / 20

slide-16
SLIDE 16

DNS Insecurity

Poisoning/Spoofing is possible First answer is accepted

Client ISP DNS Server https://ducks.de 198.51.100.43 Adversary 198.51.100.123 ducks.de.? ducks.de.? 198.51.100.123 HTTP GET / Host: ducks.de

3 / 20

slide-17
SLIDE 17

DNSSEC

DNSSEC fixes this problem

  • Data integrity: data was not changed in transit
  • Origin authentication: data originated from the owner

4 / 20

slide-18
SLIDE 18

DNS in practice

Azure DNS Cloudflare UltraDNS ducks.de cuteswans.de DNS Operators Domains

5 / 20

slide-19
SLIDE 19

DNSSEC deployment issues

Studies 12 have found that

  • Some operators use the same key for all domains
  • E.g., one key shared by > 132 000 domains

1A Longitudinal, End-to-End View of the DNSSEC Ecosystem (USENIX ’17) 2One Key to Sign Them All Considered Vulnurable: Evaluation of DNSSEC in the Internet (NSDI ’17) 6 / 20

slide-20
SLIDE 20

DNSSEC deployment issues

Studies 12 have found that

  • Some operators use the same key for all domains
  • E.g., one key shared by > 132 000 domains

1A Longitudinal, End-to-End View of the DNSSEC Ecosystem (USENIX ’17) 2One Key to Sign Them All Considered Vulnurable: Evaluation of DNSSEC in the Internet (NSDI ’17) 6 / 20

slide-21
SLIDE 21

DNSSEC deployment issues

Studies 12 have found that

  • Some operators use the same key for all domains
  • E.g., one key shared by > 132 000 domains
  • Default is 1024-bit RSA
  • Most keys 1024-bit, with ∼10K domains use 512-bit RSA
  • The majority of keys were not rotated in a 21-month period
  • Some providers use different keys but share the modulus

1A Longitudinal, End-to-End View of the DNSSEC Ecosystem (USENIX ’17) 2One Key to Sign Them All Considered Vulnurable: Evaluation of DNSSEC in the Internet (NSDI ’17) 6 / 20

slide-22
SLIDE 22

DNSSEC in practice

DNSSEC

  • Should use ECDSA instead of RSA
  • Shorter signatures reduce the chance of packet fragmentation 1

1RFC 6781 recommends 1024-bit RSA for this reason 2See 2016 Dyn attacks 3RFC 8901: Multi-Signer DNSSEC Models 7 / 20

slide-23
SLIDE 23

DNSSEC in practice

DNSSEC

  • Should use ECDSA instead of RSA
  • Shorter signatures reduce the chance of packet fragmentation 1
  • Support multiple name servers
  • better availability and DDoS protection 2
  • new standard 3 requires zone owner interaction while relinquishing key control

1RFC 6781 recommends 1024-bit RSA for this reason 2See 2016 Dyn attacks 3RFC 8901: Multi-Signer DNSSEC Models 7 / 20

slide-24
SLIDE 24

Outline

DNS and DNSSEC Threshold signatures for DNSSEC

slide-25
SLIDE 25

Threshold signatures for DNSSEC

Zone signing with Threshold ECDSA [sk] ← Share(sk)

8 / 20

slide-26
SLIDE 26

Threshold signatures for DNSSEC

Zone signing with Threshold ECDSA [sk] ← Share(sk)

ISP [sk] [sk] [sk] DNS Operators ducks.de.? MPC 1.2.3.4 Sigsk(1.2.3.4||ducks.de)

8 / 20

slide-27
SLIDE 27

Threshold signatures for DNSSEC

Zone signing with Threshold ECDSA [sk] ← Share(sk)

ISP [sk] [sk] [sk] DNS Operators ducks.de.? MPC 1.2.3.4 Sigsk(1.2.3.4||ducks.de)

8 / 20

slide-28
SLIDE 28

Threshold signatures for DNSSEC

Zone signing with Threshold ECDSA [sk] ← Share(sk)

ISP [sk] [sk] [sk] DNS Operators ducks.de.? MPC 1.2.3.4 Sigsk(1.2.3.4||ducks.de)

8 / 20

slide-29
SLIDE 29

Threshold signatures for DNSSEC

Zone signing with Threshold ECDSA [sk] ← Share(sk)

ISP [sk] [sk] [sk] DNS Operators ducks.de.? MPC 1.2.3.4 Sigsk(1.2.3.4||ducks.de)

8 / 20

slide-30
SLIDE 30

Threshold signatures for DNSSEC

Zone signing with Threshold ECDSA [sk] ← Share(sk)

ISP [sk] [sk] [sk] DNS Operators ducks.de.? MPC 1.2.3.4 Sigsk(1.2.3.4||ducks.de)

Threshold signing should not be much more expensive than regular DNSSEC

8 / 20

slide-31
SLIDE 31

ECDSA

s = k−1(H(M) + sk · rx)

9 / 20

slide-32
SLIDE 32

ECDSA

s = k−1(H(M) + sk · rx)

9 / 20

slide-33
SLIDE 33

Threshold ECDSA

s = H(M)[k−1] + [sk · k−1] · rx

10 / 20

slide-34
SLIDE 34

Threshold ECDSA signing in 3 phases s = H(M)[k−1] + [sk · k−1] · rx

Preprocessing: Key independent Preprocessing: Key independent Message independent Online phase DNS Operators MPC [k−1] [sk′] = [sk · k−1] s, rx

11 / 20

slide-35
SLIDE 35

Threshold ECDSA signing in 3 phases s = H(M)[k−1] + [sk · k−1] · rx

Preprocessing: Key independent Preprocessing: Key independent Message independent Online phase DNS Operators MPC [k−1] [sk′] = [sk · k−1] s, rx

11 / 20

slide-36
SLIDE 36

Threshold ECDSA signing in 3 phases s = H(M)[k−1] + [sk · k−1] · rx

[k−1] [k−1] [k−1] Preprocessing: Key independent Preprocessing: Key independent Message independent Online phase DNS Operators MPC [k−1] [sk′] = [sk · k−1] s, rx

11 / 20

slide-37
SLIDE 37

Threshold ECDSA signing in 3 phases s = H(M)[k−1] + [sk · k−1] · rx

[k−1], [sk−1] [k−1], [sk−1] [k−1], [sk−1] Preprocessing: Key independent Preprocessing: Key independent Message independent Online phase DNS Operators MPC [k−1] [sk′] = [sk · k−1] s, rx

11 / 20

slide-38
SLIDE 38

Threshold ECDSA signing in 3 phases s = H(M)[k−1] + [sk · k−1] · rx

[k−1], [sk−1], M [k−1], [sk−1], M [k−1], [sk−1], M Preprocessing: Key independent Preprocessing: Key independent Message independent Online phase DNS Operators MPC [k−1] [sk′] = [sk · k−1] s, rx

11 / 20

slide-39
SLIDE 39

Threshold ECDSA signing s = H(M)[k−1] + [sk · k−1] · rx Problems: How do we compute

  • 1. [k−1]
  • 2. rx

12 / 20

slide-40
SLIDE 40

Threshold ECDSA signing

Need to compute s = [k−1](H(M) + [sk] · rx)

13 / 20

slide-41
SLIDE 41

Threshold ECDSA signing

Need to compute s = [k−1](H(M) + [sk] · rx) Problem how do we compute [k−1]? Main difficulty with threshold ECDSA

13 / 20

slide-42
SLIDE 42

Threshold ECDSA signing

From [k] to [k−1] using a trick due to Bar-Ilan and Beaver4

4Non-cryptographic fault-tolerant computing in constant number of rounds of interaction (PODC ’89) 14 / 20

slide-43
SLIDE 43

Threshold ECDSA signing

From [k] to [k−1] using a trick due to Bar-Ilan and Beaver4

  • 1. Suppose we have ([k], [b], [c]) with c = k · b

4Non-cryptographic fault-tolerant computing in constant number of rounds of interaction (PODC ’89) 14 / 20

slide-44
SLIDE 44

Threshold ECDSA signing

From [k] to [k−1] using a trick due to Bar-Ilan and Beaver4

  • 1. Suppose we have ([k], [b], [c]) with c = k · b
  • 2. Open [c]

4Non-cryptographic fault-tolerant computing in constant number of rounds of interaction (PODC ’89) 14 / 20

slide-45
SLIDE 45

Threshold ECDSA signing

From [k] to [k−1] using a trick due to Bar-Ilan and Beaver4

  • 1. Suppose we have ([k], [b], [c]) with c = k · b
  • 2. Open [c]
  • 3. Compute c−1[b] = [(k · b)−1b] = [k−1]

4Non-cryptographic fault-tolerant computing in constant number of rounds of interaction (PODC ’89) 14 / 20

slide-46
SLIDE 46

Threshold ECDSA signing

From [k] to [k−1] using a trick due to Bar-Ilan and Beaver4

  • 1. Suppose we have ([k], [b], [c]) with c = k · b
  • 2. Open [c]
  • 3. Compute c−1[b] = [(k · b)−1b] = [k−1]

Computing [k−1] is the most expensive part of signing

4Non-cryptographic fault-tolerant computing in constant number of rounds of interaction (PODC ’89) 14 / 20

slide-47
SLIDE 47

Secure Computation over Elliptic Curves

Need to compute s = [k−1](H(M) + [sk] · rx)

15 / 20

slide-48
SLIDE 48

Secure Computation over Elliptic Curves

Need to compute s = [k−1](H(M) + [sk] · rx) Problem how do we compute rx?

15 / 20

slide-49
SLIDE 49

Secure Computation over Elliptic Curves

Need to compute s = [k−1](H(M) + [sk] · rx) Problem how do we compute rx? where (rx, ry) = R = k · G

15 / 20

slide-50
SLIDE 50

Secure Computation over Elliptic Curves

Need to compute s = [k−1](H(M) + [sk] · rx) Problem how do we compute rx? where (rx, ry) = R = k · G

15 / 20

slide-51
SLIDE 51

Secure Computation over Elliptic Curves

Let [k] denote an additive sharing of k over Zp Let k denote a sharing of k · G.

[k] k k R = k · G local conversion Open(k)

16 / 20

slide-52
SLIDE 52

Secure Computation over Elliptic Curves

Let [k] denote an additive sharing of k over Zp Let k denote a sharing of k · G.

[k] k k R = k · G local conversion Open(k)

16 / 20

slide-53
SLIDE 53

Secure Computation over Elliptic Curves

Let [k] denote an additive sharing of k over Zp Let k denote a sharing of k · G.

[k] k k R = k · G local conversion Open(k)

16 / 20

slide-54
SLIDE 54

Secure Computation over Elliptic Curves

Let [k] denote an additive sharing of k over Zp Let k denote a sharing of k · G.

[k] k k R = k · G local conversion Open(k)

16 / 20

slide-55
SLIDE 55

Secure Computation over Elliptic Curves

Let [k] denote an additive sharing of k over Zp Let k denote a sharing of k · G.

[k] k k R = k · G local conversion Open(k)

16 / 20

slide-56
SLIDE 56

Secure Computation over Elliptic Curves

Let [k] denote an additive sharing of k over Zp Let k denote a sharing of k · G. Supports all the usual suspects

  • Addition/constant addition
  • Constant scalar mult: a · x = a · x
  • Constant point mult: [a] · X = a · x, where X = x · G (note that x may be

unknown).

17 / 20

slide-57
SLIDE 57

Threshold ECDSA signing in 3 phases

Key independent pre-processing

  • 1. Use triples ([k], [b], [c]) to compute [k−1]
  • 2. k = cnv([k])

18 / 20

slide-58
SLIDE 58

Threshold ECDSA signing in 3 phases

Key independent pre-processing

  • 1. Use triples ([k], [b], [c]) to compute [k−1]
  • 2. k = cnv([k])

Message independent pre-processing

  • 1. [sk′] = [sk · k−1] = [sk] · [k−1]

18 / 20

slide-59
SLIDE 59

Threshold ECDSA signing in 3 phases

Key independent pre-processing

  • 1. Use triples ([k], [b], [c]) to compute [k−1]
  • 2. k = cnv([k])

Message independent pre-processing

  • 1. [sk′] = [sk · k−1] = [sk] · [k−1]

Signing (input is (k, [sk′], M))

  • 1. (rx, ry) = R = Open(k)
  • 2. [s] = H(M) · [k−1] + rx · [sk′]
  • 3. s = Open([s]), output (rx, s)

18 / 20

slide-60
SLIDE 60

Threshold ECDSA signing in 3 phases

Key independent pre-processing

  • 1. Use triples ([k], [b], [c]) to compute [k−1]
  • 2. k = cnv([k])

Message independent pre-processing

  • 1. [sk′] = [sk · k−1] = [sk] · [k−1]

Signing (input is (k, [sk′], M))

  • 1. (rx, ry) = R = Open(k)
  • 2. [s] = H(M) · [k−1] + rx · [sk′]
  • 3. s = Open([s]), output (rx, s)

18 / 20

slide-61
SLIDE 61

Threshold ECDSA signing in 3 phases

Key independent pre-processing

  • 1. Use triples ([k], [b], [c]) to compute [k−1]
  • 2. k = cnv([k])

Message independent pre-processing

  • 1. [sk′] = [sk · k−1] = [sk] · [k−1]

Signing (input is (k, [sk′], M))

  • 1. (rx, ry) = R = Open(k)
  • 2. [s] = H(M) · [k−1] + rx · [sk′]
  • 3. s = Open([s]), output (rx, s)

Key generation just generate random [x] and pk = Open(cnv([x]))

18 / 20

slide-62
SLIDE 62

Benchmarks

Comparison with prior work

LAN WAN n Sign(ms) KeyGen(ms) Sign(ms) KeyGen(ms) Rep3 3 2.78 1.45 367.87 291.32 Shamir 3 3.02 1.39 1140.09 486.82

  • Mal. Rep3

3 3.45 1.57 1128.01 429.47

  • Mal. Shamir

3 4.43 1.89 2340.53 485.11 MASCOT 2 6.56 4.32 2688.92 2632.07 MASCOT– 2 3.61 4.41 729.08 2654.59 DKLS 2 3.58 43.73 234.37 1002.97 Unbound 2 11.33 315.96 490.73 1010.98 Kzen † 2 310.71 153.87 14441.83 7237.93

†: Implementation of [GG18] Fast Multiparty Threshold ECDSA with Fast Trustless Setup (CCS ’18)

19 / 20

slide-63
SLIDE 63

Benchmarks

Throughput

LAN WAN Tuples per sec. Sign (ms) Tuples per sec. Sign (ms) Rep3 922.27 2.49 715.54 247.13 Shamir 1829.69 2.37 402.88 271.80

  • Mal. Rep3

914.65 2.52 309.76 245.14

  • Mal. Shamir

1792.30 2.91 172.87 416.60 MASCOT 380.19 4.82 31.98 756.34 MASCOT– 700.94 2.75 68.31 258.85

20 / 20
