SLIDE 1

Secure Resource Sharing for Embedded Protected Module Architectures

Jo Van Bulck

imec-DistriNet, KU Leuven, Celestijnenlaan 200A, B-3001 Belgium

MSc Thesis Presentation BELCLIV-CLUSIB, April 21, 2017

Jo Van Bulck Secure Resource Sharing for Embedded Protected Module Architectures MSc Thesis 1 / 20

SLIDE 2

Introduction

“Internet of Things [in]security keeps me up at night.”

— Rob Joyce, NSA’s Tailored Access Operations chief (MIT Technology Review, January 2016).

Jo Van Bulck Secure Resource Sharing for Embedded Protected Module Architectures MSc Thesis 2 / 20

SLIDE 3

Introduction Source: https://www.ncta.com/platform/industry-news/infographic-the-growth-of-the-internet-of-things/ Jo Van Bulck Secure Resource Sharing for Embedded Protected Module Architectures MSc Thesis 3 / 20

SLIDE 4

Introduction

Motivation: Embedded Device Security

TI MSP430: low-cost, low-power computing Runs ˜13 years on a single AA battery [Sea08] Single-address-space without memory protection Attacker can modify all code and data, and forge sensor readings or node identity

http://martybugs.net/ electronics/msp430/ Jo Van Bulck Secure Resource Sharing for Embedded Protected Module Architectures MSc Thesis 4 / 20

SLIDE 5

Introduction

Motivation: Embedded Device Security

TI MSP430: low-cost, low-power computing Runs ˜13 years on a single AA battery [Sea08] Single-address-space without memory protection Attacker can modify all code and data, and forge sensor readings or node identity

http://martybugs.net/ electronics/msp430/

Protected Module Architectures: isolation and attestation Minimal (hardware-only) Trusted Computing Base Server/desktop: Intel SGX, ARM TrustZone Low-end embedded: SMART, TrustLite, TyTAN, Sancus

Maene et al.: “Hardware-Based Trusted Computing Architectures for Isolation and Attestation”, 2017 [MGDC+17]. Jo Van Bulck Secure Resource Sharing for Embedded Protected Module Architectures MSc Thesis 4 / 20

SLIDE 6

Background: Protected Module Architectures

Unprotected memory 0x000000

Code

Protected mem. 0xFFFFFF ...

Data

Isolated execution in a single-address-space

Jo Van Bulck Secure Resource Sharing for Embedded Protected Module Architectures MSc Thesis 5 / 20

SLIDE 7

Background: Protected Module Architectures

Unprotected memory 0x000000

Code

Protected mem. 0xFFFFFF ...

Data

Isolated execution in a single-address-space Program counter based access control

From \ to Protected Unprotected Entry Code Data Protected r-x r-x rw- rwx Unprotected /

ther SM

r-x r--

rwx

Strackx et al.: “Efficient Isolation of Trusted Subsystems in Embedded Systems”, 2010 [SPP10]. Jo Van Bulck Secure Resource Sharing for Embedded Protected Module Architectures MSc Thesis 5 / 20

SLIDE 8

Background: Protected Module Architectures

Unprotected memory 0x000000

Code

Fields Secure stack

Data

Protected mem. 0xFFFFFF ...

Isolated execution in a single-address-space Program counter based access control Secure fully abstract compilation

From \ to Protected Unprotected Entry Code Data Protected r-x r-x rw- rwx Unprotected /

ther SM

r-x r--

rwx

Strackx et al.: “Efficient Isolation of Trusted Subsystems in Embedded Systems”, 2010 [SPP10]. Agten et al.: “Secure Compilation to Modern Processors”, 2012 [ASJP12]. Jo Van Bulck Secure Resource Sharing for Embedded Protected Module Architectures MSc Thesis 5 / 20

SLIDE 9

Background: Protected Module Architectures

Sancus PMA

[NAD+13, NVBM+17]

Zero-software TCB: extended openMSP430 instruction set

Unprotected Entry point Code & constants Unprotected SM1 text section Protected data SM1 data section Unprotected Memory KN,SP,SM1 IDSM1 Next ID Caller ID KN SM1 metadata Layout Key ID Protected storage area Node Noorman et al.: “Sancus 2.0: A Low-Cost Security Architecture for IoT Devices”, 2017 [NVBM+17]. Jo Van Bulck Secure Resource Sharing for Embedded Protected Module Architectures MSc Thesis 6 / 20

SLIDE 10

Background: Protected Module Architectures

Sancus PMA

[NAD+13, NVBM+17]

Zero-software TCB: extended openMSP430 instruction set SM == unit of isolation + authentication: Remote attestation / secure linking Hardware-level cryptographic key + ID per SM

Unprotected Entry point Code & constants Unprotected SM1 text section Protected data SM1 data section Unprotected Memory KN,SP,SM1 IDSM1 Next ID Caller ID KN SM1 metadata Layout Key ID Protected storage area Node Noorman et al.: “Sancus 2.0: A Low-Cost Security Architecture for IoT Devices”, 2017 [NVBM+17]. Jo Van Bulck Secure Resource Sharing for Embedded Protected Module Architectures MSc Thesis 6 / 20

SLIDE 11

Research Objectives

Secure Resource Sharing

PMAs assume the presence of an attacker:

Strong HW-enforced security guarantees No secure sharing of platform resources

SM_A SM_B

R

Unprotected MMIO

Jo Van Bulck Secure Resource Sharing for Embedded Protected Module Architectures MSc Thesis 7 / 20

SLIDE 12

Research Objectives

Secure Resource Sharing

PMAs assume the presence of an attacker:

Strong HW-enforced security guarantees No secure sharing of platform resources

⇒ Self-protecting “OS” modules to supplement HW: ↔ Monolithic privileged kernel ˜ Extreme microkernel idea

SM_A SM_B

R

Protected MMIO SM_Server

Jo Van Bulck Secure Resource Sharing for Embedded Protected Module Architectures MSc Thesis 7 / 20

SLIDE 13

Logical File Access Control

Sancus File System (SFS)

Front-End Access Control Layer

Protected file system SMsfs boundary

MMIO

Serial Flash Drive

CFS API

Flash Storage Back-End Shared Memory Back-End

CFS API

SMA SMB

SFS API

System boundary

OR

Jo Van Bulck Secure Resource Sharing for Embedded Protected Module Architectures MSc Thesis 8 / 20

SLIDE 14

Logical File Access Control

Sancus File System (SFS)

Front-End Access Control Layer

Protected file system SMsfs boundary

MMIO

Serial Flash Drive

CFS API

Flash Storage Back-End Shared Memory Back-End

CFS API

SMA SMB

SFS API

System boundary

OR

UNIX like file system API (incl. chmod)

Jo Van Bulck Secure Resource Sharing for Embedded Protected Module Architectures MSc Thesis 8 / 20

SLIDE 15

Logical File Access Control

Sancus File System (SFS)

Front-End Access Control Layer

Protected file system SMsfs boundary

MMIO

Serial Flash Drive

CFS API

Flash Storage Back-End Shared Memory Back-End

CFS API

SMA SMB

SFS API

System boundary

OR

UNIX like file system API (incl. chmod) Access control using sancus_get_caller_id

Jo Van Bulck Secure Resource Sharing for Embedded Protected Module Architectures MSc Thesis 8 / 20

SLIDE 16

Logical File Access Control

Sancus File System (SFS)

Front-End Access Control Layer

Protected file system SMsfs boundary

MMIO

Serial Flash Drive

CFS API

Flash Storage Back-End Shared Memory Back-End

CFS API

SMA SMB

SFS API

System boundary

OR

UNIX like file system API (incl. chmod) Access control using sancus_get_caller_id Pluggable private back-end encapsulating resource

Jo Van Bulck Secure Resource Sharing for Embedded Protected Module Architectures MSc Thesis 8 / 20

SLIDE 17

Logical File Access Control

Example Scenario

Jo Van Bulck Secure Resource Sharing for Embedded Protected Module Architectures MSc Thesis 9 / 20

SLIDE 18

Logical File Access Control

Discussion

⇒ Generic resource sharing mechanism SW-based access control guarantees: Build upon HW primitives (isolation + authentication) Non-persistent file protection Confined and explicit TCB: Principle of least privilege (˜ microkernel) Attestable via sancus verify

Jo Van Bulck Secure Resource Sharing for Embedded Protected Module Architectures MSc Thesis 10 / 20

SLIDE 19

Secure Scheduling

Secure Multithreading

Thread == synchronous control flow within address space Local thread context on call stack Conventional OS kernel saves CPU state on interrupt

Jo Van Bulck Secure Resource Sharing for Embedded Protected Module Architectures MSc Thesis 11 / 20

SLIDE 20

Secure Scheduling

Secure Multithreading

Thread == synchronous control flow within address space Local thread context on call stack Conventional OS kernel saves CPU state on interrupt PMA multithreading challenges: Unit of threading >> SM Compiler-generated sm entry asm stubs Inter-SM call/return flow integrity guards

SM_Bar SM_Foo SM_A 1.1.1: illegal return to A 1.1: call_bar 1: call_foo

Jo Van Bulck Secure Resource Sharing for Embedded Protected Module Architectures MSc Thesis 11 / 20

SLIDE 21

Secure Scheduling

Cooperative Scheduler Prototype

⇒ Scheduler SM interleaves multiple control flows

Regis- tered Running Ready Killed Finished start_fct register_thread_portal yield return from yield return from start_fct report_entry_violation

Jo Van Bulck Secure Resource Sharing for Embedded Protected Module Architectures MSc Thesis 12 / 20

SLIDE 22

Secure Scheduling

Threading-aware SMs

⇒ SM maintains at most one internal call stack per thread-ID

SM_foo SM_bar SM_sched 9: ... 8: continue 1: ... 7: yield_get_next 6: yield 5: return busy 4: cur_thr_id 3: get_cur_thr_id 2: call_foo

Jo Van Bulck Secure Resource Sharing for Embedded Protected Module Architectures MSc Thesis 13 / 20

SLIDE 23

Secure Scheduling

Example Scenario

Jo Van Bulck Secure Resource Sharing for Embedded Protected Module Architectures MSc Thesis 14 / 20

SLIDE 24

Secure Scheduling

Discussion

⇒ Isolated cross-SM control flow threads Division of responsibilities: Hardware: SM confidentiality/integrity (memory isolation) Compiler: entry call stack consistency (SM call/return) Unprivileged scheduler: scheduling policy (temporal isolation)

Jo Van Bulck Secure Resource Sharing for Embedded Protected Module Architectures MSc Thesis 15 / 20

SLIDE 25

Future Work

Future and Ongoing Work

Real-time secure multitasking [VBNMP16]: Hardware primitives: secure interrupts + atomicity monitor Compiler: SM-internal multithreading Preemptive scheduler: FreeRTOS prototype Efficient resource sharing: Controlling access to a multi-device I/O bus Hardware mechanisms for inter-SM sharing Case studies: Smart metering [MCM+16] Automotive computing [M¨

uh17]

Jo Van Bulck Secure Resource Sharing for Embedded Protected Module Architectures MSc Thesis 16 / 20

SLIDE 26

Thank you! Questions?

https://distrinet.cs.kuleuven.be/software/sancus/ https://github.com/jovanbulck/thesis-src/ https://distrinet.cs.kuleuven.be/software/sancus/publications/vanbulck15thesis.pdf

Jo Van Bulck Secure Resource Sharing for Embedded Protected Module Architectures MSc Thesis 17 / 20
