SLIDE 1
CP1507020 Dublin Port Greenway Tender Package July 2019
Contents
- Overview
- Scheme Layout
- Construction Details
- Programme
Scheme Update July 2019 CP1507020 Dublin Port Greenway Tender - - PowerPoint PPT Presentation
Scheme Update July 2019 CP1507020 Dublin Port Greenway Tender - - PowerPoint PPT Presentation
Scheme Update July 2019 CP1507020 Dublin Port Greenway Tender Package July 2019 Contents Overview Scheme Layout Construction Details Programme CP1507020 Dublin Port Greenway Tender Package July 2019 Overview A key feature
SLIDE 2
SLIDE 3
CP1507020 Dublin Port Greenway Tender Package July 2019
Overview
- A key feature within Dublin Port Company’s Masterplan
- Increase the accessibility of the Port from the City
- Emphasising the heritage importance of the Port
- An amenity for the local residential and working populations
SLIDE 4
CP1507020 Dublin Port Greenway Tender Package July 2019
Overview
- 3.1km of new Greenway from Bond Road to Alexandra Road
Extension
- Feature park at Alexandra Road Extension
- Revetment repair / reinforcement
- Focussed low-impact lighting
- Management controls during construction and operation to avoid
impacting on Biosphere
SLIDE 5
CP1507020 Dublin Port Greenway Tender Package July 2019
Overview
- Phased removal and replacement / enhancement of landscaping.
- Landscaping scheme includes a combination of 6-10m high semi-
mature Linden, Sycamore, Silver Birch, Holly Oak, London Plane and Scots Pine (c. 900) supplemented by immature (whips) Grey Willow, Common Alder, Hazel, Guelder Rose, Hawthorn, Blackthorn & Field Maple (c. 10,000) and a variety of shrubs at ground level.
- Box hedging along greenway boundary, primarily consisting of
Lonicera Pileata, interspersed with Brachyglottis, Eleagnus, Damask Rose, Dogwood, Spindle and Guilder Rose 1m – 2m high
SLIDE 6
CP1507020 Dublin Port Greenway Tender Package July 2019
Layout – Bond Road to Customs House
SLIDE 7
CP1507020 Dublin Port Greenway Tender Package July 2019
Section – Bond Road to Customs House
SLIDE 8
CP1507020 Dublin Port Greenway Tender Package July 2019
Layout – Bond Road to Customs House
SLIDE 9
CP1507020 Dublin Port Greenway Tender Package July 2019
Customs House Observation Point
SLIDE 10
CP1507020 Dublin Port Greenway Tender Package July 2019
Layout – Customs House to Terminal Road
SLIDE 11
CP1507020 Dublin Port Greenway Tender Package July 2019
Section – Customs House to Terminal Road
SLIDE 12
CP1507020 Dublin Port Greenway Tender Package July 2019
Terminal Road Viewing Area
SLIDE 13
CP1507020 Dublin Port Greenway Tender Package July 2019
Terminal Road Viewing Area
SLIDE 14
CP1507020 Dublin Port Greenway Tender Package July 2019
Layout – Alexandra Road Extension
SLIDE 15
CP1507020 Dublin Port Greenway Tender Package July 2019
Section – Alexandra Road Extension
SLIDE 16
CP1507020 Dublin Port Greenway Tender Package July 2019
Dublin Port Park
SLIDE 17
CP1507020 Dublin Port Greenway Tender Package July 2019
Dublin Port Park
SLIDE 18
CP1507020 Dublin Port Greenway Tender Package July 2019
Construction Details
- Box hedging along greenway boundary, primarily consisting of Lonicera
Pileata, interspersed with Brachyglottis, Eleagnus, Damask Rose, Dogwood, Spindle and Guilder Rose 1m – 2m high
- Bespoke Lighting Scheme incorporating 5m high lighting standards with
cowled, focussed, low-energy lighting to avoid light spill and sections of handrail lighting.
- Revetment repair and reinforcement where eroded
- Stepped park area with plastic reinforced concrete benches with inset
lighting
- Durable wooden benches
- Provision for viewing areas and observation points
SLIDE 19
CP1507020 Dublin Port Greenway Tender Package July 2019
Details – Box Hedge
SLIDE 20
CP1507020 Dublin Port Greenway Tender Package July 2019
Details – Lighting
SLIDE 21
CP1507020 Dublin Port Greenway Tender Package July 2019
Viewing Areas and Observation Points
SLIDE 22
CP1507020 Dublin Port Greenway Tender Package July 2019
Programme
- Tendering Period: May – October 2019
- Mobilisation: November 2019
- Phased Construction Works: 2020 – 2022
SLIDE 23
