slide-1
SLIDE 1

SAT Solvers

Ranjit Jhala, UC San Diego April 9, 2013

slide-2
SLIDE 2

Decision Procedures

We will look very closely at the following

  • 1. Propositional Logic
  • 2. Theory of Equality
  • 3. Theory of Uninterpreted Functions
  • 4. Theory of Difference-Bounded Arithmetic

Decision Problem: Satisfaction

◮ Does eval s p return True for some assignment s ? ◮ “Can we assign the variables to make the formula true” ?

slide-3
SLIDE 3

Decision Procedures

We will look very closely at the following

  • 1. Propositional Logic
  • 2. Theory of Equality
  • 3. Theory of Uninterpreted Functions
  • 4. Theory of Difference-Bounded Arithmetic

Why?

◮ Representative ◮ Have “efficient” algorithms

slide-4
SLIDE 4

Decision Procedures

We will look very closely at the following

  • 1. Propositional Logic
  • 2. Theory of Equality
  • 3. Theory of Uninterpreted Functions
  • 4. Theory of Difference-Bounded Arithmetic

Plan

◮ First in isolation ◮ Then in combination ◮ Very slick SW-Eng, based on logic

slide-5
SLIDE 5

Decision Procedures: Propositional Logic

Popularly called SAT Solvers

slide-6
SLIDE 6

Decision Procedures: Propositional Logic

Basics

◮ Propositional Logic 101 ◮ Conjunctive Normal Form ◮ Resolution

Algorithms

◮ Resolution ◮ Backtracking Search ◮ Boolean Constraint Propagation ◮ Conflict Driven Learning & Backjumping

slide-7
SLIDE 7

Decision Procedures: Propositional Logic

Basics

◮ Propositional Logic 101 ◮ Conjunctive Normal Form ◮ Resolution

Algorithms

◮ Resolution ◮ Backtracking Search ◮ Boolean Constraint Propagation ◮ Conflict Driven Learning & Backjumping

slide-8
SLIDE 8

Propositional Logic 101

Propositional Variables

data PVar

Propositional Formulas

data Formula = Prop PVar | Not Formula | Formula ‘And‘ Formula | Formula ‘Or‘ Formula

slide-9
SLIDE 9

Decision Procedures: Propositional Logic

Basics

◮ Propositional Logic 101 ◮ Conjunctive Normal Form ◮ Resolution

Algorithms

◮ Resolution ◮ Backtracking Search ◮ Boolean Constraint Propagation ◮ Conflict Driven Learning & Backjumping

slide-10
SLIDE 10

Conjunctive Normal Form

Restricted representation of Formula

Literals: Variables or Negated Variables

data Literal = Pos PVar | Neg PVar

Clauses: Disjunctions (Or) of Literals

data Clauses = [Literal]

CNF Formulas: Conjunctions (And) of Clauses

data CnfFormula = [Clauses]

slide-11
SLIDE 11

Conjunctive Normal Form: Example

Consider a Formula

(x1 ∨ x2) ∧ (¬x1 ∨ x3) ∧ ¬x3

Represented as a Formula

(Prop 1 ‘Or‘ Prop 2) ‘And‘ (Not (Prop 1) ‘Or‘ Prop 3) ‘And‘ (Not (Prop 3) )

Represented as a CnfFormula

[ [Pos 1 , Pos 2] , [Neg 1 , Pos 3] , [Neg 3 ] ]

slide-12
SLIDE 12

Conjunctive Normal Form Conversion

Theorem There is a poly-time function toCNF :: Formula -> CnfFormula toCNF = error "Exercise For The Reader" Such that any f is satisfiable iff (toCNF f) is satisfiable.

◮ toCNF adds new variables for sub-formulas ◮ otherwise, an exponential blowup in CnfFormula size

slide-13
SLIDE 13

Conjunctive Normal Form Conversion

Theorem There is a poly-time function toCNF :: Formula -> CnfFormula toCNF = error "Exercise For The Reader" Such that any f is satisfiable iff (toCNF f) is satisfiable. Henceforth Only consider formulas in Conjunctive Normal Form Formulas

slide-14
SLIDE 14

Decision Procedures: Propositional Logic

Basics

◮ Propositional Logic 101 ◮ Conjunctive Normal Form

Algorithms

◮ Resolution ◮ Backtracking Search ◮ Boolean Constraint Propagation ◮ Conflict Driven Learning & Backjumping

slide-15
SLIDE 15

Properties of CNF

Pure Variable

◮ One which appears only +ve or −ve in a CnfFormula

Empty Clause

◮ If a CnfFormula has some Clause without Literals ◮ Then the CnfFormula is UNSAT

Trivial Formula

◮ If a CnfFormula has no Clause ◮ Or every variable is pure ◮ Then the CnfFormula is SAT

slide-16
SLIDE 16

Goal

Determine satisfaction by reducing CnfFormula to one of

◮ Empty Clause (ie UNSAT), or ◮ Trivial Formula (ie SAT).

slide-17
SLIDE 17

Reducing Formulas By Resolution

(“Reduce” is, perhaps, not the best word. . . ) Resolution: For any A, B and variable x, the formula (A ∨ x) ∧ (B ∨ ¬x) is equivalent to the formula (A ∨ B)

◮ The variable x is called a pivot variable

slide-18
SLIDE 18

General Resolution

Resolution: For any Ai, Bj and variable x, the formula

  • i

(Ai ∨ x) ∧

  • j

(Bj ∨ ¬x) is equivalent to the formula

  • i,j

(Ai ∨ Bj)

◮ Pivot variable x is eliminated by resolution

slide-19
SLIDE 19

Davis-Putnam Algorithm: Example 1

Input Formula

◮ (x1 ∨ x2 ∨ x3) ∧ (x2 ∨ ¬x3 ∨ x5) ∧ (¬x2 ∨ x4))

Pivot on x2

◮ (x1 ∨ x3 ∨ x4) ∧ (¬x3 ∨ x5 ∨ x4)

Pivot on x3

◮ (x1 ∨ x4 ∨ x5)

All variables are pure . . . hence, SAT

slide-20
SLIDE 20

Davis-Putnam Algorithm: Example 2

Input Formula

◮ (x1 ∨ x2) ∧ (x1 ∨ ¬x2) ∧ (¬x1 ∨ x3) ∧ (¬x1 ∨ ¬x3)

Pivot on x2

◮ (x1) ∧ (¬x1 ∨ x3) ∧ (¬x1 ∨ ¬x3)

Pivot on x3

◮ (x1) ∧ (¬x1)

Pivot on x1

◮ ()

Empty clause . . . hence, UNSAT

slide-21
SLIDE 21

Davis-Putnam Algorithm

Algorithm

  • 1. Select pivot and perform resolution
  • 2. Repeat until SAT or UNSAT

Issues?

◮ Space blowup (formula size blows up on resolution)

slide-22
SLIDE 22

Decision Procedures: Propositional Logic

Basics

◮ Propositional Logic 101 ◮ Conjunctive Normal Form

Algorithms

◮ Resolution ◮ Backtracking Search ◮ Boolean Constraint Propagation ◮ Conflict Driven Learning & Backjumping

slide-23
SLIDE 23

Decision Tree: Describes Space of All Assignments

Figure: SAT Decision Tree (Courtesy: Lintao Zhang)

slide-24
SLIDE 24

Decision Tree: SAT via Depth First Search

Figure: DFS On Decision Tree (Courtesy: Lintao Zhang)

slide-25
SLIDE 25

Backtracking Search

Don’t build whole tree, but lazily search solutions

◮ Choose a variable x, set to True ◮ Remove constraints where x appears ◮ Recurse on remaining constraints ◮ Backtrack if a contradiction is found

slide-26
SLIDE 26

Backtracking Search (1/21)

Figure: Basic DLL (Courtesy: Lintao Zhang)

slide-27
SLIDE 27

Backtracking Search (2/21)

Figure: Basic DLL (Courtesy: Lintao Zhang)

slide-28
SLIDE 28

Backtracking Search (3/21)

Figure: Basic DLL (Courtesy: Lintao Zhang)

slide-29
SLIDE 29

Backtracking Search (4/21)

Figure: Basic DLL (Courtesy: Lintao Zhang)

slide-30
SLIDE 30

Backtracking Search (5/21)

Figure: Basic DLL (Courtesy: Lintao Zhang)

slide-31
SLIDE 31

Backtracking Search (6/21)

Figure: Basic DLL (Courtesy: Lintao Zhang)

slide-32
SLIDE 32

Backtracking Search (7/21)

Figure: Basic DLL (Courtesy: Lintao Zhang)

slide-33
SLIDE 33

Backtracking Search (8/21)

Figure: Basic DLL (Courtesy: Lintao Zhang)

slide-34
SLIDE 34

Backtracking Search (9/21)

Figure: Basic DLL (Courtesy: Lintao Zhang)

slide-35
SLIDE 35

Backtracking Search (10/21)

Figure: Basic DLL (Courtesy: Lintao Zhang)

slide-36
SLIDE 36

Backtracking Search (11/21)

Figure: Basic DLL (Courtesy: Lintao Zhang)

slide-37
SLIDE 37

Backtracking Search (12/21)

Figure: Basic DLL (Courtesy: Lintao Zhang)

slide-38
SLIDE 38

Backtracking Search (13/21)

Figure: Basic DLL (Courtesy: Lintao Zhang)

slide-39
SLIDE 39

Backtracking Search (14/21)

Figure: Basic DLL (Courtesy: Lintao Zhang)

slide-40
SLIDE 40

Backtracking Search (15/21)

Figure: Basic DLL (Courtesy: Lintao Zhang)

slide-41
SLIDE 41

Backtracking Search (16/21)

Figure: Basic DLL (Courtesy: Lintao Zhang)

slide-42
SLIDE 42

Backtracking Search (17/21)

Figure: Basic DLL (Courtesy: Lintao Zhang)

slide-43
SLIDE 43

Backtracking Search (18/21)

Figure: Basic DLL (Courtesy: Lintao Zhang)

slide-44
SLIDE 44

Backtracking Search (19/21)

Figure: Basic DLL (Courtesy: Lintao Zhang)

slide-45
SLIDE 45

Backtracking Search (20/21)

Figure: Basic DLL (Courtesy: Lintao Zhang)

slide-46
SLIDE 46

Backtracking Search (21/21)

Figure: Basic DLL (Courtesy: Lintao Zhang)

slide-47
SLIDE 47

Backtracking Search

Don’t build whole tree, but lazily search solutions

◮ Choose a variable x, set to True ◮ Remove constraints where x appears ◮ Recurse on remaining constraints ◮ Backtrack if a contradiction is found

(whew!)

◮ DFS avoids space blowup (only need to save stack) . . . ◮ . . . but not time (natch)

slide-48
SLIDE 48

Decision Procedures: Propositional Logic

Basics

◮ Propositional Logic 101 ◮ Conjunctive Normal Form

Algorithms

◮ Resolution ◮ Backtracking Search ◮ Boolean Constraint Propagation ◮ Conflict Driven Learning & Backjumping

slide-49
SLIDE 49

Boolean Constraint Propagation

Often, we don’t really have a choice. . .

slide-50
SLIDE 50

Boolean Constraint Propagation

Unit Clause Rule

◮ If an (unsatisfied) Clause has one unassigned Literal ◮ Then that Literal must be True in any SAT assignment

Example

◮ Formula (x1 ∨ ¬x2 ∨ x3) ∧ (x2 ∨ ¬x3) ∧ (¬x1 ∨ ¬x3) ◮ Assignment x1 = T, x2 = T ◮ The last clause is a unit clause ◮ Any SAT assigment must set ¬x3 = T (i.e. x3 = F)

slide-51
SLIDE 51

Boolean Constraint Propagation

Unit Clause Rule

◮ If an (unsatisfied) Clause has one unassigned Literal ◮ Then that Literal must be True in any SAT assignment

BCP or Unit Propagation

◮ Repeat applying unit clause rule ◮ Until no unit clause remains.

slide-52
SLIDE 52

Boolean Constraint Propagation: Example

Revisit Example With BCP

Figure: Boolean Constraint Propagation (Courtesy: Lintao Zhang)

slide-53
SLIDE 53

Boolean Constraint Propagation

DPLL = Backtracking Search + BCP

◮ Backtracking: Avoids space blowup ◮ BCP: Avoid doing obvious work ◮ Still repeatedly explore all choices (e.g. whole left subtree)

Wanted

◮ Means to learn to repeat dead ends ◮ Key to scaling to practical problems

slide-54
SLIDE 54

Decision Procedures: Propositional Logic

Basics

◮ Propositional Logic 101 ◮ Conjunctive Normal Form

Algorithms

◮ Resolution ◮ Backtracking Search ◮ Boolean Constraint Propagation ◮ Conflict Driven Learning & Backjumping

slide-55
SLIDE 55

Conflict Driven Learning

Key Insight

◮ On finding conflict, don’t (just) backtrack ◮ Learn new clause to prevent same conflict in future

Major breakthrough

◮ J. P. Marques-Silva and K. A. Sakallah, “GRASP – A New

Search Algorithm for Satisfiability,” Proc. ICCAD 1996.

◮ R. J. Bayardo Jr. and R. C. Schrag “Using CSP look-back

techniques to solve real world SAT instances.” Proc. AAAI, 1997

slide-56
SLIDE 56

Conflict Driven Learning

◮ Resolve on conflict variable to learn new conflict clause ◮ Add clause to set of clauses ◮ Backjump using conflict clause

slide-57
SLIDE 57

Conflict Driven Learning

Revisit Example With CDL

◮ Learn, Add, Backjump ◮ Vastly faster search

Figure: Boolean Constraint Propagation (Courtesy: Lintao Zhang)

slide-58
SLIDE 58

Backtracking Only (01/26)

slide-59
SLIDE 59

Backtracking Only (02/26)

slide-60
SLIDE 60

Backtracking Only (03/26)

slide-61
SLIDE 61

Backtracking Only (04/26)

slide-62
SLIDE 62

Backtracking Only (05/26)

slide-63
SLIDE 63

Backtracking Only (06/26)

slide-64
SLIDE 64

Backtracking Only (07/26)

slide-65
SLIDE 65

Backtracking Only (08/26)

slide-66
SLIDE 66

Backtracking Only (09/26)

slide-67
SLIDE 67

Backtracking Only (10/26)

slide-68
SLIDE 68

Backtracking Only (11/26)

slide-69
SLIDE 69

Backtracking Only (12/26)

slide-70
SLIDE 70

Backtracking Only (13/26)

slide-71
SLIDE 71

Backtracking Only (14/26)

slide-72
SLIDE 72

Backtracking Only (15/26)

slide-73
SLIDE 73

Backtracking Only (16/26)

slide-74
SLIDE 74

Backtracking Only (17/26)

slide-75
SLIDE 75

Backtracking Only (18/26)

slide-76
SLIDE 76

Backtracking Only (19/26)

slide-77
SLIDE 77

Backtracking Only (20/26)

slide-78
SLIDE 78

Backtracking Only (21/26)

slide-79
SLIDE 79

Backtracking Only (22/26)

slide-80
SLIDE 80

Backtracking Only (23/26)

slide-81
SLIDE 81

Backtracking Only (24/26)

slide-82
SLIDE 82

Backtracking Only (25/26)

slide-83
SLIDE 83

Backtracking Only (26/26)

slide-84
SLIDE 84

Boolean Constraint Propagation (01/23)

slide-85
SLIDE 85

Boolean Constraint Propagation (02/23)

slide-86
SLIDE 86

Boolean Constraint Propagation (03/23)

slide-87
SLIDE 87

Boolean Constraint Propagation (04/23)

slide-88
SLIDE 88

Boolean Constraint Propagation (05/23)

slide-89
SLIDE 89

Boolean Constraint Propagation (06/23)

slide-90
SLIDE 90

Boolean Constraint Propagation (07/23)

slide-91
SLIDE 91

Boolean Constraint Propagation (08/23)

slide-92
SLIDE 92

Boolean Constraint Propagation (09/23)

slide-93
SLIDE 93

Boolean Constraint Propagation (10/23)

slide-94
SLIDE 94

Boolean Constraint Propagation (11/23)

slide-95
SLIDE 95

Boolean Constraint Propagation (12/23)

slide-96
SLIDE 96

Boolean Constraint Propagation (13/23)

slide-97
SLIDE 97

Boolean Constraint Propagation (14/23)

slide-98
SLIDE 98

Boolean Constraint Propagation (15/23)

slide-99
SLIDE 99

Boolean Constraint Propagation (16/23)

slide-100
SLIDE 100

Boolean Constraint Propagation (17/23)

slide-101
SLIDE 101

Boolean Constraint Propagation (18/23)

slide-102
SLIDE 102

Boolean Constraint Propagation (19/23)

slide-103
SLIDE 103

Boolean Constraint Propagation (20/23)

slide-104
SLIDE 104

Boolean Constraint Propagation (21/23)

slide-105
SLIDE 105

Boolean Constraint Propagation (22/23)

slide-106
SLIDE 106

Boolean Constraint Propagation (23/23)

slide-107
SLIDE 107

Conflict Driven Learning (01/21)

slide-108
SLIDE 108

Conflict Driven Learning (02/21)

slide-109
SLIDE 109

Conflict Driven Learning (03/21)

slide-110
SLIDE 110

Conflict Driven Learning (04/21)

slide-111
SLIDE 111

Conflict Driven Learning (05/21)

slide-112
SLIDE 112

Conflict Driven Learning (06/21)

slide-113
SLIDE 113

Conflict Driven Learning (07/21)

slide-114
SLIDE 114

Conflict Driven Learning (08/21)

slide-115
SLIDE 115

Conflict Driven Learning (09/21)

slide-116
SLIDE 116

Conflict Driven Learning (10/21)

slide-117
SLIDE 117

Conflict Driven Learning (11/21)

slide-118
SLIDE 118

Conflict Driven Learning (12/21)

slide-119
SLIDE 119

Conflict Driven Learning (13/21)

slide-120
SLIDE 120

Conflict Driven Learning (14/21)

slide-121
SLIDE 121

Conflict Driven Learning (15/21)

slide-122
SLIDE 122

Conflict Driven Learning (16/21)

slide-123
SLIDE 123

Conflict Driven Learning (17/21)

slide-124
SLIDE 124

Conflict Driven Learning (18/21)

slide-125
SLIDE 125

Conflict Driven Learning (19/21)

slide-126
SLIDE 126

Conflict Driven Learning (20/21)

slide-127
SLIDE 127

Conflict Driven Learning (21/21)

slide-128
SLIDE 128

More Details about SAT Solvers

Lectures By Lintao Zhang (ZChaff)

◮ 1 ◮ 2

slide-129
SLIDE 129

Next Time: SMT = SAT + Theories

  • 1. Propositional Logic
  • 2. Combining Theories

◮ Equality + Uninterpreted Functions ◮ Difference-Bounded Arithmetic

  • 3. Combining SAT + Theories
