SLIDE 1
Glenn Dearth, Vyas Venkataraman Mar 28, 2018
2
Agenda
Why was DGX-2 created DGX-2 internal architecture Software programming model Simple application Results
S8688 : INSIDE DGX-2 Glenn Dearth, Vyas Venkataraman Mar 28, 2018 - - PowerPoint PPT Presentation
S8688 : INSIDE DGX-2 Glenn Dearth, Vyas Venkataraman Mar 28, 2018 - - PowerPoint PPT Presentation
S8688 : INSIDE DGX-2 Glenn Dearth, Vyas Venkataraman Mar 28, 2018 Why was DGX-2 created DGX-2 internal architecture Agenda Software programming model Simple application Results 2 DEEP LEARNING TRENDS Application properties Explosive DL
SLIDE 2
SLIDE 3
3
DEEP LEARNING TRENDS
Application properties
Explosive DL growth:
Increasing data, computation & complexity demands Exceeds memory capacity of single GPU Exceeds compute performance of a single GPU
Driving scale-out across GPUs
2011 2012 2013 2014 2015 2016 2017
(GOP * Bandwidth) ResNet-50 Inception-v2 Inception-v4 AlexNet GoogleNet
350X
SLIDE 4
4
DGX-1
8 V100 GPUs 6 NVLinks per GPU Each link is 50GB/s (bidirectional) 300GB/s bidirectional BW from GPU DGX-1 uses Hybrid Cube Mesh topology Internal bisection bandwidth 300GB/s Optimized data parallel training with NCCL
SLIDE 5
5
DESIRED SCALE-OUT BEHAVIOR
Scale up to 16 GPUs Direct peer GPU memory access Full non-blocking bandwidth Utilize all GPU links when accessing memory Simplify multi-GPU programming
SLIDE 6
6
SCALE UP TO 16 GPUS
GPU 8 GPU 9 GPU 10 GPU 11 GPU 12 GPU 13 GPU 14 GPU 15 GPU GPU 1 GPU 2 GPU 3 GPU 4 GPU 5 GPU 6 GPU 7
SLIDE 7
7
DIRECT PEER MEMORY ACCESS
GPU 8 GPU 9 GPU 10 GPU 11 GPU 12 GPU 13 GPU 14 GPU 15 GPU GPU 1 GPU 2 GPU 3 GPU 4 GPU 5 GPU 6 GPU 7
NVSwitch NVSwitch
SLIDE 8
8
FULL NON-BLOCKING BANDWIDTH
GPU 8 GPU 9 GPU 10 GPU 11 GPU 12 GPU 13 GPU 14 GPU 15 GPU GPU 1 GPU 2 GPU 3 GPU 4 GPU 5 GPU 6 GPU 7
NVSwitch NVSwitch NVSwitch NVSwitch NVSwitch NVSwitch NVSwitch NVSwitch NVSwitch NVSwitch NVSwitch NVSwitch
SLIDE 9
9
DGX-2 AT A GLANCE
NVSWITCHES
6x NVLink
DGX-2 GPU Density 16 1GPU to 1GPU Always 6 NVLink Connectivity Fully Connected Topology Symmetric Bisection Bandwidth 2.4 TB/s
SLIDE 10
10
DESIGNED TO TRAIN THE PREVIOUSLY IMPOSSIBLE
1 2 3 5 4 6 Two Intel Xeon Platinum CPUs 7 1.5 TB System Memory
10
30 TB NVME SSDs Internal Storage NVIDIA Tesla V100 32GB Two GPU Boards 8 V100 32GB GPUs per board 6 NVSwitches per board 512GB Total HBM2 Memory interconnected by Plane Card Twelve NVSwitches 2.4 TB/sec bi-section bandwidth Eight EDR Infiniband/100 GigE 1600 Gb/sec Total Bi-directional Bandwidth PCIe Switch Complex 8 Dual 10/25 GigE 9
Introducing NVIDIA DGX-2
SLIDE 11
11
NVSWITCH
Features: 18 NVLink ports @ 50GB/s per port 900 GBs total Fully connected crossbar x4 PCIe Gen2 Management Port GPIO I2C Transistor count: 2 billion Package: 47.5 x 47.5mm 1937 Ball @ 1mm pitch
SLIDE 12
12
SWITCH FUNCTIONS
NVLink Performs physical, datalink & transaction layer functions Forwarding Determines packet routing Crossbar (non-blocking) Schedules traffic flows to outputs Management Configuration, errors, monitors
NVLINK NVLINK MANAGEMENT CROSSBAR FORWARDING FORWARDING
SLIDE 13
13
NVSWITCH RELIABILITY FEATURES
Link CRC and retry ECC on routing structures and data path Secondary checks: Routing checks Data path overflow/underflow checks Access control checks
SLIDE 14
14
Programming Model
SLIDE 15
15
MULTI GPU PROGRAMMING IN CUDA
GPU GPU 1
SLIDE 16
16
EXECUTION CONTROL
Asynchronous CUDA calls execute in a CUDA stream Default to null stream Can specify stream explicitly CUDA runtime API calls have implicit current device selected Current device can be changed using cudaSetDevice() call Cooperative groups have a multi device launch cudaLaunchCooperativeKernelMultiDevice()
SLIDE 17
17
CUDA ON DGX-2
DGX-2 enables up to 16 peer GPUs DGX-2 enables full NVLink bandwidth to peer GPUs GPU memory model extended to all GPUs Unified Memory and CUDA aware MPI use NVLink for transfers
SLIDE 18
18
MEMORY MANAGMENT
NVLINK PROVIDES
All-to-all high-bandwidth peer mapping between GPUs Full inter-GPU memory interconnect (incl. Atomics)
GPU GPU 1 GPU 2 GPU 3 GPU 4 GPU 5 GPU 6 GPU 7
16x 32GB Independent Memory Regions
GPU 8 GPU 9 GPU 10 GPU 11 GPU 12 GPU 13 GPU 14 GPU 15
SLIDE 19
19
PINNED MEMORY ALLOCATION
Enable peer memory access
// Enable Peer accesses between all pairs of GPUs for (int i = 0; i < numDevices; ++i) for (int j = 0; j < numDevices; ++j) if (i != j) { cudaEnablePeerAccess(i, j); }
SLIDE 20
20
PINNED MEMORY ALLOCATION
cudaMalloc with CUDA P2P
int* ptr[MAX_DEVICES]; for (int i = 0; i<numDevices; ++i) { // Set a device cudaSetDevice(i); // Allocate memory on the device cudaMalloc((void**)&ptr[i], size); }
SLIDE 21
21
UNIFIED MEMORY PROVIDES
Single memory view shared by all GPUs Automatic migration of data between GPUs User control of data locality
UNIFIED MEMORY + DGX-2
GPU GPU 1 GPU 2 GPU 3 GPU 4 GPU 5 GPU 6 GPU 7 GPU 8 GPU 9 GPU 10 GPU 11 GPU 12 GPU 13 GPU 14 GPU 15
512 GB Unified Memory
SLIDE 22
22
UNIFIED MEMORY
Allocating across multiple GPUs
int* ptr; // Allocate memory cudaMallocManaged((void**)&ptr, size * numDevices);
SLIDE 23
23
UNIFIED MEMORY
Allocating across multiple GPUs
int* ptr; // Allocate memory cudaMallocManaged((void**)&ptr, size * numDevices); for (int i = 0; i < numDevices; ++i) { // Mark the memory as preferring a specific GPU cudaMemAdvise(ptr + i*size, size, cudaMemAdviseSetPreferredHome, i); // Mark this memory accessed by all devices for (int j = 0; j < numDevices; ++j) { cudaMemAdvise(ptr + i*size, size, cudaMemAdviseSetAccessedBy, j); } }
SLIDE 24
24
BROADCAST ON DGX-1
Ring Scatter
Time = 0
SLIDE 25
25
BROADCAST ON DGX-1
Ring Scatter
Time = 0 Time = 1
SLIDE 26
26
BROADCAST ON DGX-1
Ring Scatter
Time = 0 Time = 2 Time = 1
SLIDE 27
27
BROADCAST ON DGX-1
Ring Scatter
Time = 0 Time = 7
SLIDE 28
28
BROADCAST ON DGX-2
Direct Broadcast (DGX-2)
Time = 0
SLIDE 29
29
IMPLEMENTATION COMPARISON
__global__ void broadcast_ring(int *src, int *dst) { int index = blockIdx.x*gridDim.x + threadIdx.x; dst[index] = src[index]; } // CPU Code cudaEvent_t ev[MAX_DEVICES]; For (int i = 0; i < numDevices - 1; i++) { cudaEventCreate(&ev[i]); cudaSetDevice(i); if (i > 0) cudaStreamEventWait(NULL, ev[i-1], 0); broadcast_ring<<<blocks, threads >>>(ptr[i], ptr[i+1]); cudaEventRecord(ev[i]) } cudaSetDevice(0); cudaStreamWaitEvent(NULL, ev[numDevices – 2], 0); cudaDeviceSynchronize(); __global__ void broadcast_direct(int *src, int **pDst, int numDevices) { int index = blockIdx.x*gridDim.x + threadIdx.x; for (int i = 0; i < numDevices; ++i) { int *dst = pDst[i]; dst[index] = src[index]; } } // CPU code cudaSetDevice(0); broadcast_direct<<<blocks, threads>>>(ptr[0], dPtr); cudaDeviceSynchronize();
Ring Scatter (DGX-1) Direct broadcast (DGX-2)
SLIDE 30
30
ALL REDUCE BENCHMARK
20000 40000 60000 80000 100000 120000 2 8 32 128 512 2048 8192 32768 131072 524288
Achieved Bandwidth (MB/sec) Message Size (kB)
2x DGX-1v w/ 100Gb Infiniband 2x DGX-1v w/ 400Gb Infiniband DGX-2 (ring) DGX-2 (direct)
Direct All reduce ~50 lines of code Better performance for small messages
Source: Performance measured on pre production NVSwitch hardware
SLIDE 31
31
NVSWITCH FFT BENCHMARK
0x 1x 2x 3x 4x 4 GPU 8 GPU 16 GPU DGX-1 (Volta) DGX-2
3484 3598 1374 6965 13K
3D FFT 1280 x 1280 x 1280 in GFLOPS (FP32 Complex)
Performance is measured. NVSwitch uses early bring-up software FFT is measured with cufftbench
N/A
SLIDE 32
32
2X HIGHER PERFORMANCE WITH NVSWITCH
2 DGX-1V servers have dual socket Xeon E5 2698v4 Processor. 8 x V100 GPUs. Servers connected via 4X 100Gb IB ports | DGX-2 server has dual-socket Xeon Platinum 8168 Processor. 16 V100 GPUs
Physics (MILC benchmark) 4D Grid Weather (ECMWF benchmark) All-to-all Recommender (Sparse Embedding) Reduce & Broadcast Language Model (Transformer with MoE) All-to-all
DGX-2 with NVSwitch 2x DGX-1 (Volta) 2X FASTER 2.4X FASTER 2X FASTER 2.7X FASTER
SLIDE 33
33
SUMMARY
Faster Solutions
DGX-2 Advantages
Faster Development Gigantic Problems
Physics (MILC benchmark) 4D Grid
2X FASTER
…
GPU GPU 1 GPU 2 GPU 3 GPU 4 GPU 5 GPU 6 GPU 7 GPU 8 GPU 9 GPU 10 GPU 11 GPU 12 GPU 13 GPU 14 GPU 15
512 GB Unified Memory
SLIDE 34
34
OTHER NVIDIA SESSIONS TO ATTEND
ADDITIONAL NVIDIA LED SESSIONS S8670 Wed 3/28 Time? Multi-GPU Programming Techniques in CUDA
- Stephen Jones (Software Architect)
S8474 Thur 3/29 10:00 am GPUDirect: Life in the Fast Lane
- Davide Rosetti (Software Architect)
