Role of storage in Role of storage in PV projects in Asia PV projects in Asia Daniel Gaefke, Managing Director BayWa r.e. (Thailand) Daniel Gaefke, Managing Director BayWa r.e. (Thailand) 6 th of June BITEC, Bangkok, Thailand. Contents About

slide-1
SLIDE 1

Role of storage in PV projects in Asia Role of storage in PV projects in Asia

Daniel Gaefke, Managing Director BayWa r.e. (Thailand) Daniel Gaefke, Managing Director BayWa r.e. (Thailand)

6th of June BITEC, Bangkok, Thailand.

slide-2
SLIDE 2

Contents

Why Energy Storage? Opportunities and Challenges Energy Storage Technologies Economics of Battery Storage Systems References Q&A

2

About BayWa r.e.

slide-3
SLIDE 3

BayWa r.e.

Making energy better.

3

slide-4
SLIDE 4

BayWa r.e. in figures – dynamic growth and sustainable profitability

4

Turnover 2017 Founded € 1,366.7 million Euro 2009

Gathering our combined market experience under the BayWa r.e. umbrella

EBIT 2017 Experience € 66.6 million Euro 2,000 MW

Development and realization

  • f projects in the area of solar,

wind power, bioenergy and geothermal energy

Employees Company 1,400

Wholly owned subsidiary

  • f BayWa AG
slide-5
SLIDE 5

Dynamic growth under the umbrella

  • f a stable parent company

5

Turnover 2017 Founded €16.1 billion Euro 1923 EBIT 2017 Core segment €171.3 million Euro Agriculture, energy, construction Employees Locations 17,550

More than 3,000 locations in 40 countries

slide-6
SLIDE 6

We provide experience in the development and realization

  • f wind farms with an installed capacity
  • f over 1,300 MW.

We have brought solar farms with an output of more than 600 MWp to the grid. We have supplied our installers with solar modules with a total output of 1,500 MWp.

The way ahead lies in a sound energy mix

6

In excess of 3,000 MW under our operations management Bioenergy Wind energy Solar energy

We have already developed and set up

34 biogas and biomethane plants with

a total biogas output of approx.

110 MW.

slide-7
SLIDE 7

Utilizing potential worldwide

BayWa r.e. location Active in the market Wind power projects and services Geothermal energy (Germany only) Trading in solar components Bioenergy Energy trading H

7

PV projects and services H

slide-8
SLIDE 8

Adding global experience to local knowledge in Asia Pacific

8 BayWa r.e. presence Markets under development

BayWa r.e. is joined by

  • ne of the most

experienced teams in the Asia Pacific region.

· With offices in Singapore, Bangkok, Tokyo and Perth, BayWa r.e. has significant local market experience · Full on-the-ground technical, commercial and financial capabilities · Combined with the financial support of a strong parent company, BayWa r.e. becomes the most complete platform to deliver results across the Asia Pacific region

slide-9
SLIDE 9

Our services for successful energy projects

To date, we have developed and realized wind farms with an installed output of

1,300 MW.

We have successfully put

600 MWp

  • f solar energy into the grid.

We have already set up and commissioned 34 biogas and biomethane plants with a biogas output

  • f about

110 MW. 2,000 MW

In further project rights have already been secured in Europe, America, Asia and Australia.

  • Green field project planning
  • Site analysis and assessment
  • Securing land and planning

permissions

In addition to the development and implementation of our own projects, we also build turnkey projects as a third party service

9

  • Turnkey construction
  • Project management
  • Project finance
slide-10
SLIDE 10

Why Energy Storage?

10

slide-11
SLIDE 11

Worldwide renewable and non-renewable power capacity additions The global trend is towards much more PV and wind

11

Why energy storage?

Source: IRENA (2017), REthinking Energy 2017: Accelerating the global energy transformation. International Renewable Energy Agency, Abu Dhabi.

slide-12
SLIDE 12

With wind and solar, new power system will be based on two technologies that completely change the picture

12

Gross electricity generation of renewable energies 2000 - 2035 Electricity generation and consumption in a sample week 2023

AGEB (2015a), BNetzA (2014), BNetzA (2015b), own calculations Fraunhofer IWES (2013)

Specific characteristics of Wind and Solar PV High capital costs 2 Very low variable cost 3 Variable 1

G W Why energy storage?

slide-13
SLIDE 13

Flexibility is the paradigm of the new power system – baseload capacities are hardly needed in longer future

Own calculations on basis of Agora Energiewende (2015b) 13

Electricity generation and consumption in a sample week with 50% RES share Key flexibility options

Flexible fossil and bioenergy power plants (incl. CHP) Grids and transmission capacities for exports/imports Demand Side Management Storage technologies (Batteries, Power-to-Gas) Integration of the power, heat and transport sectors (power-to-heat, electric cars)

Source: AGORA Dr. Patrick Graichen; Insights from Germany’s Energiewende, Berlin 2016

=> New coal power plants need to get flexible!

Why energy storage?

slide-14
SLIDE 14

Energy storage to optimize grid efficiency

14

Why energy storage? 500 1000 1500 2000 2500 3000 0:00 1:00 2:00 3:00 4:00 5:00 6:00 7:00 8:00 9:00 10:00 11:00 12:00 13:00 14:00 15:00 16:00 17:00 18:00 19:00 20:00 21:00 22:00 23:00 Power (kW) Diesel PV Curtailment Load Running genset capacity 500 1000 1500 2000 2500 3000 0:00 1:00 2:00 3:00 4:00 5:00 6:00 7:00 8:00 9:00 10:00 11:00 12:00 13:00 14:00 15:00 16:00 17:00 18:00 19:00 20:00 21:00 22:00 23:00 Power (kW) Grid (kW) Usable PV (kW) Charging Battery (kW) Discharging Battery (kW) Curtailed energy Running genset capacity Load (kW)

Current status: Diesel generators are started and stopped based on power demand. Battery discharge can be optimised to increase overall system efficiency, smoothening grid frequency.

BayWa r.e. case study for hybrid potential in Bula, Maluku, Indonesia.

slide-15
SLIDE 15

15

Why energy storage?

Future of energy systems – towards a new paradigm?

Why energy storage?

  • increased distributed energy resources increases grid variability.
  • Baseload capacities needed for grid flexibility.

 sustainable solution to emerging energy problems! Smart local grids, linking a diverse set of distributed resources across different sectors.

slide-16
SLIDE 16

Energy Storage Technologies

16

slide-17
SLIDE 17

Energy Storage Technologies available

Classification StorageType Energy form of storage

Mechanical Chemical Electrical Thermal

Fly wheel PumpedHydro

Compressed air

Battery Storage Hydrogen Power to gas Coil Capacitor Heat storage Rotational energy of the mass Potential energy of water Kinetic energy of the gas Chemical energy by redox reactions Chemical energy by redox reactions Chemical energy in the form of gas (Methane) Electrical Energy im Magnetic field Electrical Energy im Electrical field Thermal energy particle motion

slide-18
SLIDE 18

Lead Acid and Li- Ion Batteries the mature technologies at the moment

Relevant Range

  • Lead acid batteries most

mature technology

  • Li-Ion batteries are well

mature today.

  • Other technologies are in

development or market launch status:

  • Redox Flow
  • Salt water

100 kW 1 MW 10 MW 100 MW

mature developed In developement

Field tests Market launch 1 kW 10 kW

Lead acid il Lithium mob Redox flow H2 mobile H2 stationary Power to gas Salt water batteries Lithium stationar y

slide-19
SLIDE 19

Different battery technologies

Lead-Acid Flow-Batteries Salt water batteries Lithium-Ion

  • High efficiency
  • Low Maintenance cost
  • Many companies are
  • n the market
  • High price potential

caused byAutomobile industry

  • Mature
  • High maintenance
  • Short life time
  • Less potential of

price reduction

  • Too low efficiency
  • High maintenance
  • Not Mature today
  • High price potential
  • Many players on the

market

  • Too low efficiency
  • Not Mature today
  • High price potential
  • Only one company

NOW and in near future

Maybe in the future Past

Lithium is the state of the art

slide-20
SLIDE 20

A battery storage system consists

  • f more than just battery cells

Battery storage systems consists of:

  • Battery storage
  • Battery module
  • Cells
  • Housing
  • Battery management

(BMS)

  • If necessary, fan and

housing

  • Inverter
  • If necessary Energy-

management system (EMS)

  • Housing, possibly with

fan / can also be container format

slide-21
SLIDE 21

Lithium-Ion Batteries Lithium-Ion Batteries - SWOT

  • Strength
  • Weakness
  • High energy density
  • High power density
  • Long Life time
  • High efficiency
  • Low maintenance effort
  • Complex battery management
  • thermal runaway
  • Still relatively high investment costs
  • Sometimes cooling is necessary
  • Opportunities
  • Threats
  • Fully automated mass production of

electric vehicles leads to drastic cost reductions

  • No special requirements on the site
  • No gassing
  • Exploitation possibilities in a few

countries

  • Expensive high performance storage is

not necessary for stationary applications

  • Acceptance problems by safety issues
slide-22
SLIDE 22

Economics of Battery Storage Systems

22

slide-23
SLIDE 23

Battery Energy Storage Value Chain

Utility-Scale and Behind-The-Meter

23

Economics of Battery Storage Systems Source: IFC (2017). Energy Storage Opportunities and Challenges in Emerging Markets

slide-24
SLIDE 24

Relevant storage markets for BayWa r.e. solar projects

24

Economics and Markets

Application:

  • Fuel Saving
  • Off-Grid and micro grid

Customer:

  • IPP and utilities

Application:

  • Fuel Saving
  • Weak grid compensation
  • Microgrid
  • PV Ramping/Smoothing

Customer:

  • Commercial & Industrial
  • Farmers

Application:

  • Self-consumption
  • Peak shaving

Customer:

  • Commercial & Industrial

Application:

  • PV output smoothing
  • Capacity firming

Customer:

  • IPP and utilities

Application:

  • RE smoothing
  • Capacity firming

Customer:

  • IPP and utilities
slide-25
SLIDE 25

Price of lithium-Ion battery – drop of 73% since 2010.

25

Economics of Battery Storage Systems

Decreasing price trend lithium-ion batteries caused by:

  • Technological improvements

increasing efficiency.

  • Competition and economies of scale in

manufacturing industry (car companies such as Tesla, BMW, entering the market for EV sector).

  • Oversupply manufacturing companies

(EV demand lower than expected).

slide-26
SLIDE 26

Lithium-ion battery prices will fall to $73/kWh by 2030

26

Economics of Battery Storage Systems

  • Exponential growth in demand lithium-

ion batteries expected (especially due to growth EV sector).

  • Many new manufacturing plants

announced or under construction.

  • Intensified competition and high

learning rate expected to further decrease prices.

Forecasts:

slide-27
SLIDE 27

Projected ESS deployment by Market Segment

27

Economics of Battery Storage Systems

Increase ESS deployments APAC region:

  • 1GW in 2018 to 12GW

in 2025.

  • C&I and Utility-Scale

also in future highest relative share of ESS.

Source: IFC (2017). Energy Storage Opportunities and Challenges in Emerging Markets

slide-28
SLIDE 28

Opportunities and Challenges

28

slide-29
SLIDE 29

Opportunities & Challenges Battery Storage Systems

29

Opportunities & Challenges

  • Battery storage systems provide solution for

emerging need for grid flexibility due to increasing trend in RE and distributed energy resources.

  • ESS + PV lower LCOE than diesel gensets,

especially in remote area’s where diesel is expensive (islands Indonesia, Philippines).

  • Lithium-Ion battery systems expected to drop further

in price (1% per month).

  • New battery technologies such as Redox Flow at

launching stage, offering longer charge/discharge cycle more suitable for bigger solar PV projects. Opportunities Challenges

  • Despite price reductions, technology remains

expensive.

  • Storing energy from big solar projects would

need warehouses full of batteries due existing technology’s small charge/discharge cycle.

  • familiarity with storage technology among

utilities, regulators and financiers.

  • The need for highly skilled and experienced

technicians to maintain and operate systems correctly.

  • No solutions yet for after end of battery life-

time.

slide-30
SLIDE 30

References

30

slide-31
SLIDE 31

Solar Energy Storage

Project Agricultural Farm Zambia

Combination of grid connected PV, battery and water storage. Suppling power for 90.000m2 of crop. Project completed: September 2017 Project success Combination of grid connected PV, battery and water storage First Storage Project in Zambia/Africa. Output 86kWp 160kWh Lithium-Ion Battery

31

Reference project

slide-32
SLIDE 32

Projects – in progress

BayWa r.e. Company presentation 32

Reference Projects

Heggelbach farm: Self-consumption - going into operation 06/2018

grid APV 194 kWp Heggelbach farm peak 130 kW base 20 kW 150 kW 150 kWh

APV

194 kWp

Heggelbach farm

peak laod 130 kW- cons.240 MWh/yr

  • Organic farm in South Germany operating also the first Agro PV plant in Germany,

built by BayWa r.e.

  • The storage system helps the farm to become ~60 % self-sufficient on electricity
  • Design and testing of a suitable operation and maintenance concept for

commercial-scale battery

slide-33
SLIDE 33

Solar Energy

Project Arau Arau, Perlis, Malaysia

Start of construction: May 3rd 2017 Project completed: December 25th 2017 Project Success One of the first projects completed under Malaysia’s Large-Scale Solar program Output 5.2 MWp Status Sold

33

Reference Project

slide-34
SLIDE 34

Solar Energy

BayWa r.e. Company presentation 34

Reference Project

Project Karadoc Solar Farm Northern Western Vitoria, Australia

Start of Construction: March 2018 Project Completion: November 2018 Project success Largest BayWa r.e. project in Australia Output 112.534 MWp Status Under Construction

slide-35
SLIDE 35

Solar energy

35

Reference project

Project Vine Farm Cambridge, UK

Start of construction: September 2015 Project completed: March 2016 Project success Largest BayWa r.e. project in UK Output 46 MWp Status Sold

slide-36
SLIDE 36

Q&A Q&A

6th of June BITEC, Bangkok, Thailand.

Role of storage in PV Projects in Asia Role of storage in PV Projects in Asia
