Robust Relational Layout Synthesis from Examples Pavol Bielik , - PowerPoint PPT Presentation

May 08, 2023 •100 likes •763 views

Robust Relational Layout Synthesis from Examples Pavol Bielik , Marc Fischer, Martin Vechev Department of Computer Science ETH Zurich User Interface Design Today Designer Developer picture created by [Credits: Radu Cristian] Designer

  1. Robust Relational Layout Synthesis from Examples Pavol Bielik , Marc Fischer, Martin Vechev Department of Computer Science ETH Zurich

  2. User Interface Design Today Designer Developer picture created by [Credits: Radu Cristian]

  3. Designer

  5. Materialize GroundworkCSS 2 Developer

  6. User Interface Design Today Designer Developer

  7. Our Goal Tool Designer Developer

  8. Preventing Layout Errors Nexus 4 Alcatel Pop 3

  9. Preventing Layout Errors Nexus 4 Alcatel Pop 3

  10. Preventing Layout Errors Centering Asobimasu Overlaying Views Amigo Out of Screen Candid

  11. Improving Performance Slow Layout #1 Layout #2 Fast Layout #3 [Credits: Sriram Ramani]

  12. Code Porting Linear Layout (horizontal) Linear Layout (vertical) Constraint Layout Relative Layout >98% <2% Old / Deprecated

  13. Automating End-User Design Designer Developer picture created by [Credits: Radu Cristian]

  14. Machine Learning Approach Training </> Layout ✘ Syntactically Incorrect ✘ No Formal Guarantees ✘ Robustness ✘ User Feedback Design Specification

  15. Programming Languages Approach Layout Robustness User Formalization Properties Feedback </> Layout Layout Synthesis Probabilistic List of Devices Model Design Specification

  16. Relational Layout Constraints left right top View View baseline bottom Align left of B to right of A A B margin B.left = A.right + margin

  17. Relational Layout Constraints left right top View View baseline bottom Align left of B to right of A A B margin B.left = A.right + 0 A B A B ✘

  18. Relational Layout Constraints left right top View View baseline bottom Align left of B to right of A Center B in between right of A and left of C A B A B C margin B.left = A.right + margin A B A B ✘

  19. Relational Layout Constraints left right top View View baseline bottom Align left of B to right of A Center B in between right of A and left of C A B A B C margin margin B.left = A.right + margin A B A B ✘

  20. Relational Layout Constraints left right top View View baseline bottom Align left of B to right of A Center B in between right of A and left of C A B A B C m L margin bias = 0.25 B.left = A.right + margin A B A B ✘

  21. Relational Layout Constraints left right top View View baseline bottom Align left of B to right of A Center B in between right of A and left of C A B A B C m L margin bias = 0.25 B.left = A.right + margin Center B in between right of A and left of C (Dynamic Size) A B A B C margin A B ✘

  22. Relational Layout Constraints left right top View View baseline bottom Align Center of A to Center of B Center B in between right of A and left of C at an Angle + Distance A B C m L A r bias = 0.25 (1-b)*B.left + b*B.right = (1-b)*(A.right + m L ) + b*(C.left - m R ) α B Center B in between right of A and left of C (Dynamic Size) A B C margin B.left + B.right = 2r*sin( α ) + A.left + A.right B.left = A.right + m L ∧ B.right = A.left + m R

  23. Relational Layout Constraints left right top View View baseline bottom Align Center of A to Center of B Center B in between right of A and left of C Formalized 26 types of constraints used by the at an Angle + Distance latest Android Constraint Layout A B C m L A r bias = 0.25 (1-b)*B.left + b*B.right = (1-b)*(A.right + m L ) + b*(C.left - m R ) α B Center B in between right of A and left of C (Dynamic Size) A B C margin B.left + B.right = 2r*sin( α ) + A.left + A.right B.left = A.right + m L ∧ B.right = A.left + m R

  24. Overview Layout Robustness User Formalization Properties Feedback </> Layout Layout Synthesis Probabilistic List of Devices Model Design Specification

  25. Layout Solving Goal Compute absolute position of all the views left right top bottom

  26. Layout Solving Goal Compute absolute position of all the views A.left = ? B.left = ? v : Absolute Horizontal Positions A.right = ? B.right = ? A B 20 40 B.left = A.right + 40 c : Horizontal Position Constraints A.left = screen.left + 20 screen: Target Device screen.left = 0 ∧ screen.right = 240

  27. Layout Solving Goal Compute absolute position of all the views A.left = 20 B.left = ? v : Absolute Horizontal Positions A.right = ? B.right = ? A B 20 40 B.left = A.right + 40 c : Horizontal Position Constraints A.left = 0 + 20 screen: Target Device screen.left = 0 ∧ screen.right = 240

  28. Layout Solving Goal Compute absolute position of all the views A.left = 20 B.left = 140 v : Absolute Horizontal Positions A.right = 100 B.right = 220 A B 20 40 B.left = A.right + 40 c : Horizontal Position Constraints A.left = 0 + 20 screen: Target Device screen.left = 0 ∧ screen.right = 240 A.right - A.left = 80 s : Horizontal Size Constraints B.right - B.left = 80 v ⊧ ψ layout (screen, c , s )

  29. Layout Solving vs Layout Synthesis Goal Goal Compute absolute position of all the views Synthesize position and size constraints A.left = ? B.left = ? A.left = 0 B.left = 120 A.right = ? B.right = ? A.right = 80 B.right = 200 A B A B 20 40 20 40 B.left = A.right + 40 ? A.left = screen.left + 20 ? screen.left = 0 ∧ screen.right = 240 screen.left = 0 ∧ screen.right = 240 A.right - A.left = 80 ? B.right - B.left = 80 ? v ⊧ ψ layout (screen, c , s ) c ∧ s ⊧ ψ syn (screen, v )

  30. Layout Solving vs Layout Synthesis Goal Goal Compute absolute position of all the views Synthesize position and size constraints Approach A.left = ? B.left = ? A.left = 0 B.left = 120 A.right = ? B.right = ? A.right = 80 B.right = 200 1. Encode the synthesis program as a logical formula ψ syn (screen, v ) A B A B 20 40 20 40 2. Find a satisfying assignment to B.left = A.right + 40 ? A.left = screen.left + 20 ? c ∧ s ⊧ ψ syn (screen, v ) screen.left = 0 ∧ screen.right = 240 screen.left = 0 ∧ screen.right = 240 A.right - A.left = 80 ? B.right - B.left = 80 ? v ⊧ ψ layout (screen, c , s ) c ∧ s ⊧ ψ syn (screen, v )

  31. Layout Synthesis ψ syn (screen, v ) = φ position (screen, v ) ∧ φ constraints ( v ) ∧ φ valid ( v ) ∧ φ acyclic ( v ) Input Constraints Ensure Constraints Specification Encoding are Valid

  32. Layout Synthesis ψ syn (screen, v ) = φ position (screen, v ) ∧ φ constraints ( v ) ∧ φ valid ( v ) ∧ φ acyclic ( v ) Input Constraints Ensure Constraints Specification Encoding are Valid screen.left = 0 ∧ φ position ≝ screen.right = 240 ∧ A.left = 0 ∧ A.right = 80 ∧ B.left = 120 ∧ B.right = 200

  33. Layout Synthesis ψ syn (screen, v ) = φ position (screen, v ) ∧ φ constraints ( v ) ∧ φ valid ( v ) ∧ φ acyclic ( v ) Input Constraints Ensure Constraints Specification Encoding are Valid

  34. Layout Synthesis What are the possible constraints for view B? C (B, v, screen) = {c B , c B , c B , … , c B } C (B, v, screen) = {c 1 , c 2 , c 3 , … , c n }

  35. Layout Synthesis What are the possible constraints for view B? C (B, v, screen) = {c B , c B , c B , … , c B } C (B, v, screen) = {c 1 , c 2 , c 3 , … , c n } A B B.left = A.right + m L (c 1 )

  36. Layout Synthesis What are the possible constraints for view B? C (B, v, screen) = {c B , c B , c B , … , c B } C (B, v, screen) = {c 1 , c 2 , c 3 , … , c n } A B A B B.left = A.right + m L (c 1 ) B.left = screen.right + m L (c 2 )

  37. Layout Synthesis What are the possible constraints for view B? C (B, v, screen) = {c B , c B , c B , … , c B } C (B, v, screen) = {c 1 , c 2 , c 3 , … , c n } A B A B B.left = A.right + m L (c 1 ) B.left = screen.right + m L (c 2 ) A B (1-b)*B.left + b*B.right = (1-b)*(A.right + m L ) + b*(screen.right - m R ) (c 3 )

  38. Layout Synthesis What are the possible constraints for view B? O(|v| 2 ) C (B, v, screen) = {c B , c B , c B , … , c B } C (B, v, screen) = {c 1 , c 2 , c 3 , … , c n } A B A B B.left = A.right + m L (c 1 ) B.left = screen.right + m L (c 2 ) A B (1-b)*B.left + b*B.right = (1-b)*(A.right + m L ) + b*(screen.right - m R ) (c 3 )

  39. Layout Synthesis What are the possible constraints for view B? O(|v| 2 ) C (B, v, screen) = {c B , c B , c B , … , c B } C (B, v, screen) = {c 1 , c 2 , c 3 , … , c n } Select exactly one constraint for each view A B A B B.left = A.right + m L (c 1 ) B.left = screen.right + m L (c 2 ) A B (1-b)*B.left + b*B.right = (1-b)*(A.right + m L ) + b*(screen.right - m R ) (c 3 )

  40. Layout Synthesis What are the possible constraints for view B? O(|v| 2 ) C (B, v, screen) = {c B , c B , c B , … , c B } C (B, v, screen) = {c 1 , c 2 , c 3 , … , c n } Select exactly one constraint for each view g 1 ⇒ (B.left = A.right + m L ) (c 1 ) g 2 ⇒ (B.left = A.left + m L ) Boolean variables (c 2 ) denoting whether … constraint was selected g n ⇒ ((1-b)*B.left + b*B.right = … ) (c n )
