RIEDHAMMER serving the LiB industry

• The Company
• Business Units
• Heat Treatment Portfolio

for Advanced Materials and

• Lithium-battery market and

products

RIEDHAMMER serving the LiB industry

Founding of Riedhammer for development and construction

• f industrial

furnaces for manufactured carbon

THE COMPANY

THE COMPANY

The global partner for all thermal processes

THE COMPANY

BASIC INFORMATION Business field Technological and Technical Solutions for all thermal processes General managers Number of employees Export business Kiln plants supplied Patents Quality standard Matthias Uhl, Stefano Lanzoni ~ 140 > 90 % > 8500 worldwide > 200 Certified in accordance with German/European Standard ISO 9001 - 2008

THE COMPANY

BUSINESS UNITS

ADVANCED MATERIALS TABLEWARE SANITARY WARE REFRACTORIES CARBON

Advanced Materials

Confidential, Property of RIEDHAMMER GmbH

The business unit ADVANCED MATERIALS includes our products for the LiB business. ADVANCED MATERIALS

Riedhammer GmbH – Advanced Materials

» German Engineering since 1924 » Wide product range (< 9.000 kiln plants built worldwide so far) » Long experiance in industrial kiln plants and heat treatment » Thermal treatment for battery powder materials » Riedhammer kilns are used all over the world. » Reliable technology also suitable for most demanding requirements for the production of Lithium battery materials in regard to atmosphere, temperature homogeneity, heating and cooling rates or chemical resistance.

RIEDHAMMER serving the LiB industry

Confidential, Property of RIEDHAMMER GmbH

The LiB business is served by our business unit ADVANCED MATERIALS.

• ur

MARKETS

• ur

CUSTOMERS

• ur

PRODUCTS

• ur

STRENGTH

• ur

FOCUS

RIEDHAMMER serving the LiB industry

Confidential, Property of RIEDHAMMER GmbH

• ur

MARKETS

• ur

CUSTOMERS

• ur

FOCUS

» Our customers are battery

manufactuers and especially the supplying industry for cathode and anode battery material.

» Our focus on Li-battery market

is on the battery materials production.

Process chain LiB production

Confidential, Property of RIEDHAMMER GmbH

» General process chain of LiB production:

Our focus in LiB production

Confidential, Property of RIEDHAMMER GmbH

» Typical processes LiB production:

• ur

FOCUS

» Our focus: Material processing and synthesis.

Our products for LiB production

Confidential, Property of RIEDHAMMER GmbH

» Roller hearth kilns and » Rotary kilns

with direct or indirect heating

» Customized kiln engineering

• ur

PRODUCTS

Electrically heated Rotary Kiln with flanged cooling pipe

Processes requiring demanding thermal treatment:

» Precoursor material, » Active material for Anode and

Cathode

Electrically heated Roller Hearth Kilns for different atmospheres

Our products for LiB production

Confidential, Property of RIEDHAMMER GmbH

• ur

PRODUCTS

» Roller Hearth Kilns

Our products for LiB production

Confidential, Property of RIEDHAMMER GmbH

• ur

PRODUCTS

» Rotary Kilns

Our strength in battery business

Confidential, Property of RIEDHAMMER GmbH

• ur

STRENGTH

Expertise in battery manufacturing

» Solutions for following process steps

• Thermal treatment for Li-Ion battery powder materials
• Processes for all cathode materials like NCM, NCA, LFP, high-nickel,

LCO, LMO, precursor.

• Processes for all anode materials like graphite, graphite-

composites.

• Customized process and product requirements
• Sintering / Calcination
• 1st baking / Re-baking processes

» Wide product range (< 9.000 kiln plants built worldwide so far),

» Long experiance in industrial kiln plants and heat treatment, » Well-proven and perfected technology, » Ongoing technical development, » Innovative products.

Our strength in battery business

Confidential, Property of RIEDHAMMER GmbH

• ur

STRENGTH

Expertise in battery manufacturing

» Solutions for following process steps

• Long experiance in industial kiln plants and battery heat treatment,
• Well-Proven and perfected technology.

► Large number of REFERENCE PROJECTS worldwide:

More than 170 battery kilns successfully built and in operation! > 100 kilns for High O2 operation! > 130 kilns in Asia! Successfull projects in China, South Korea, North America and Europe! Supplying successful companies in the battery business, such as CATL, BTR, SinoChem and other big players.

Our strength in battery business

Confidential, Property of RIEDHAMMER GmbH

• ur

STRENGTH

Expertise in battery manufacturing

» High manufacturing quality

• Workshop and workshop equipment,
• Quality control system by Riedhammer / Sacmi (German staff for

quality management),

• Using of high grade materials and components,
• Quality and performance confirmation at FAT in our workshop,
• ISO 9001 certified,
• QMS,
• German Engineering with 90 year tradition and experiance in kiln

construction,

• fabrication tolerances after german manufacturing standards,
• continuous further development and improvement of equipment,
• special solution and taylormade solutions,
• reliable suppliers,
• reliably stable operating processes (TA).

Our strength in battery business

Confidential, Property of RIEDHAMMER GmbH

• ur

STRENGTH

Expertise in battery manufacturing

» High efficiency in respect of:

• Reliable equipment, reliable long-term operation,
• Very high kiln availability,
• Low specific energy consumption,
• High productivity,
• Excelent temperature uniformity,
• Strong and reliable tray transportation system,
• Minimized chemical attack on kiln lining due to special protection

layers,

• Fully automatic operation by PLC system,
• Availability of muntible temperature profiles.

» Excellent service performance:

• Efficient operator training,
• 24h reaction time for trouble shooting,
• Availability of remote control for fast technical support.
