Research on Efficient Erasure-Coding- Based Cluster Storage Systems

Patrick P. C. Lee

The Chinese University of Hong Kong

NCIS’14

Joint work with Runhui Li, Jian Lin, Yuchong Hu

Motivation

• Clustered storage systems are widely

deployed to provide scalable storage by striping data across multiple nodes

• e.g., GFS, HDFS, Azure, Ceph, Panasas, Lustre, etc.
• Failures are common

2

LAN

Failure Types

• Temporary failures
• Nodes are temporarily inaccessible (no data loss)
• 90% of failures in practice are transient [Ford, OSDI’10]
• e.g., power loss, network connectivity loss, CPU
• verloading, reboots, maintenance, upgrades
• Permanent failures
• Data is permanently lost
• e.g., disk crashes, latent sector errors, silent data

corruptions, malicious attacks

3

Replication vs. Erasure Coding

• Solution: Add redundancy:
• Replication
• Erasure coding
• Enterprises (e.g., Google, Azure, Facebook)

move to erasure coding to save footprints due to explosive data growth

• e.g., 3-way replication has 200% overhead; erasure

coding can reduce overhead to 33% [Huang, ATC’12]

4

Background: Erasure Coding

• Divide file to k data chunks (each with multiple blocks)
• Encode data chunks to additional n-k parity chunks
• Distribute data/parity chunks to n nodes
• Fault-tolerance: any k out of n nodes can recover file data

5

File encode divide Nodes (n, k) = (4, 2) A B C D A+C B+D A+D B+C+D A B C D A+C B+D A+D B+C+D A B C D

Erasure Coding

• Pros:
• Reduce storage space with high fault tolerance
• Cons:
• Data chunk updates imply parity chunk updates 

expensive updates

• In general, k chunks are needed to recover a single lost

chunk  expensive recovery

• Our talk: Can we improve recovery of erasure-

coding-based clustered storage systems, while preserving storage efficiency?

6

Our Work

• CORE [MSST’13, TC]
• Augments existing regenerating codes to support

both optimal single and concurrent failure recovery

• Degraded-read scheduling [DSN’14]
• Improves MapReduce performance in failure mode
• Designed, implemented, and experimented on

Hadoop Distributed File System

7

Recover a Failure

• Q: Can we minimize recovery traffic?

8

Node 1 Node 2 Node 3 Node 4

repaired node

• Conventional recovery: download data from any k nodes

Recovery Traffic = = M ＋

A B C D A+C B+D A+D B+C+D C D A+C B+D A B File of size M A B C D

9

Node 1 Node 2 Node 3 Node 4

Regenerating Codes

[Dimakis et al.; ToIT’10]

A B C D A+C B+D A+D B+C+D C A+C A+B+C A B

＋ ＋ Recovery Traffic = = 0.75M repaired node

File of size M A B C D

• Repair in regenerating codes:
• Surviving nodes encode chunks (network coding)
• Download one encoded chunk from each node

Concurrent Node Failures

• Regenerating codes only designed for single

failure recovery

• Optimal regenerating codes collect data from n-1

surviving nodes for single failure recovery

• Correlated and co-occurring failures are possible
• In clustered storage [Schroeder, FAST’07; Ford, OSDI’10]
• In dispersed storage [Chun NSDI’06; Shah NSDI’06]
• CORE augments regenerating codes for optimal

concurrent failure recovery

• Retains regenerating code construction

10

CORE’s Idea

• Consider a system with n nodes
• Two functions for regenerating codes in single

failure recovery:

• Enc: storage node encodes data
• Rec: reconstruct lost data using encoded data from

n-1 surviving nodes

• t-failure recovery (t > 1):
• Reconstruct each failed node as if other n-1 nodes

are surviving nodes

11

Example

12

CORE

S0,0 S0,1 S0,2 S1,0 S1,1 S1,2 S2,0 S2,1 S2,2 S3,0 S3,1 S3,2 S4,0 S4,1 S4,2 S5,0 S5,1 S5,2 Node 0 Node 1 Node 2 Node 3 Node 4 Node 5

• Setting: n=6, k=3
• Suppose now Nodes 0 and 1 fail
• Recall that optimal regenerating codes collect data from n-

1 surviving nodes for single failure recovery

• How does CORE work?

Example

s0,0, s0,1, s0,2 = Rec0(e1,0, e2,0, e3,0, e4,0, e5,0) e0,1 = Enc0,1(s0,0, s0,1, s0,2) = Enc0,1(Rec0(e1,0, e2,0, e3,0, e4,0, e5,0))

s1,0, s1,1, s1,2 = Rec1(e0,1, e2,1, e3,1, e4,1, e5,1) e1,0 = Enc1,0(s1,0, s1,1, s1,2) = Enc1,0(Rec1(e0,1, e2,1, e3,1, e4,1, e5,1))

CORE

S0,0 S0,1 S0,2 S1,0 S1,1 S1,2 S2,0 S2,1 S2,2 S3,0 S3,1 S3,2 S4,0 S4,1 S4,2 S5,0 S5,1 S5,2

e0,1 e2,1 e3,1 e4,1 e5,1 e1,0 e2,0 e3,0 e4,0 e5,0

13 Node 0 Node 1 Node 2 Node 3 Node 4 Node 5

Example

• We have two equations

e0,1 = Enc0,1(Rec0(e1,0, e2,0, e3,0, e4,0, e5,0)) e1,0 = Enc1,0(Rec1(e0,1, e2,1, e3,1, e4,1, e5,1))

• Trick: They form a linear system of equations
• If the equations are linearly independent, we

can calculate e0,1 and e1,0

• Then we obtain lost data by

s0,0, s0,1, s0,2 = Rec0(e1,0, e2,0, e3,0, e4,0, e5,0) s1,0, s1,1, s1,2 = Rec1(e0,1, e2,1, e3,1, e4,1, e5,1)

14

Bad Failure Pattern

• A system of equations may not have a unique
• solution. We call this a bad failure pattern
• Bad failure patterns count for less than ~1%
• Our idea: reconstruct data by adding one

more node to bypass the bad failure pattern

• Suppose nodes 0,1 form a bad failure pattern and

nodes 0,1,2 form a good failure pattern. Reconstruct lost data for nodes 0,1,2

• Still achieve bandwidth saving over conventional

15

Bandwidth Saving

• Bandwidth Ratio: Ratio of CORE to conventional in

recovery bandwidth

0.5 1

1 2 3 4 5 6 7 8 9 10

Bandwidth Ratio

Good Failure Pattern

(12,6) (16,8) (20,10)

0.5 1

2 3 4 5 6 7 8 9

Bandwidth Ratio

Bad Failure Pattern

(12,6) (16,8) (20,10)

• Bandwidth saving of CORE is significant
• e.g., (n, k) = (20,10)
• Single failure: ~80%
• 2-4 concurrent failures: 36-64%

16

t t

Theorem

• Theorem: CORE, which builds on regenerating

codes for single failure recovery, achieves the lower bound of recovery bandwidth if we recover a good failure pattern with t ≥ 1 failed nodes

• Over ~99% of failure patterns are good

17

CORE Implementation

18 Namenode Datanode Datanode block block block block block block block RaidNode

• 1. Identify corrupted blocks
• 2. Send recovered blocks

Encoder Encoder Encoder CORE Encoder/Decoder

CORE Implementation

• Parallelization
• Erasure coding
• n C++
• Executed

through JNI

19

Experiments

• Testbed:
• 1 namenode, and up to 20 datanodes
• Quad core 3.1GHz CPU, 8GB RAM, 7200RPM SATA harddisk,

1Gbps Ethernet

• Coding schemes:
• Reed-Solomon codes vs. CORE (interference alignment codes)

20

Namenode

Datanode Datanode Datanode

Decoding Throughput

• Evaluate computational

performance:

• Assume single failure (t=1)
• Surviving data for recovery

first loaded in memory

• Decoding throughput: ratio
• f size of recovered data to

decoding time

• CORE (regenerating

codes) achieves ≥500MB/s at packet size 8KB

21

Recovery Throughput

• CORE shows significantly higher throughput
• e.g., in (20, 10), for single failure, the gain is 3.45x;

for two failures, it’s 2.33x; for three failures, is 1.75x

10 20 30 40 50 60 70 (12, 6) (16, 8) (20, 10) Recovery thpt (MB/s) CORE t=1 RS t=1 CORE t=2 RS t=2 CORE t=3 RS t=3

22

MapReduce

• Q: How does erasure-coded storage affect

data analytics?

• Traditional MapReduce is designed with

replication storage in mind

• To date, no explicit analysis of MapReduce on

erasure-coded storage

• Failures trigger degraded reads in erasure coding

23

MapReduce

• MapReduce idea:
• Map tasks process blocks and generate intermediate results
• Reduce tasks collect intermediate results and produce final output
• Constraint: cross-rack network resource is scarce

24

WordCount Example:

<A,2> <B,2> <C,2> Map tasks Reduce tasks <A,1> B C A C A B Slave 0 Slave 1 Slave 2 Shuffle

MapReduce on Erasure Coding

• Show that default scheduling hurts MapReduce

performance on erasure-coded storage

• Propose Degraded-First Scheduling for

MapReduce task-level scheduling

• Improves MapReduce performance on erasure-coded

storage in failure mode

25

Default Scheduling in MapReduce

• Locality-first scheduling: the master gives the first

priority to assigning a local task to a slave

26

while a heartbeat from slave s arrives do for job in jobQueue do if job has a local task on s then assign the local task else if job has a remote task then assign the remote task else if job has a degraded task then assign the degraded task endif endfor endwhile

Processing a block stored in another rack Processing an unavailable block in the system

Locality-First in Failure Mode

27

B0,0 B0,1 P0,0 P0,1 B1,0 B2,0 B3,0 P2,1 B4,0 P5,0 B1,1 P3,0 B4,1 P5,1 P1,0 B2,1 P3,1 P4,0 B5,0 P1,1 P2,0 B3,1 P4,1 B5,1 Core Switch ToR Switch ToR Switch S0 S1 S2 S3 S4 10 30 40 time(s) slaves S1 S2 S3 S4

Process B1,1 Process B5,1 Process B2,1 Process B5,0 Process B3,1 Process B5,1 Process B0,1 Process B4,0 Download P2,0 Download P0,0 Download P1,0

Map finishes

Process B0,0 Process B3,0 Process B2,0 Download P3,0 Process B1,0

Problems & Intuitions

• Problems:
• Degraded tasks are launched simultaneously
• Start degraded reads together and compete for network

resources

• When local tasks are processed, network resource is

underutilized

• Intuitions: ensure degraded tasks aren’t running

together to complete for network resources

• Finish running degraded tasks before all local tasks
• Keep degraded tasks separated

28

29

25% saving

Core Switch ToR Switch ToR Switch B0,0 B1,0 B2,0 B3,0 B0,1 P2,1 B4,0 P5,0 B1,1 P3,0 B4,1 P5,1 P0,0 P1,0 B2,1 P3,1 P4,0 B5,0 P0,1 P1,1 P2,0 B3,1 P4,1 B5,1 S0 S1 S2 S3 S4 10 30 Map finishes time(s) S1 S2 S3 S4 slaves

Degraded-First in Failure Mode

Process B1,1 Process B5,1 Process B4,0 Download P0,0 Download P2,0 Process B5,0 Process B3,1 Process B5,1 Process B0,0 Process B0,1 Process B2,0 Download P1,0 Download P3,0 Process B1,0 Process B2,1 Process B3,0

Degraded-First Scheduling

30

while a heartbeat from slave s arrives do if

𝒏 𝑵 ≥ 𝒏𝒆 𝑵𝒆 and job has a degraded task then

assign the degraded task endif assign other map slots as in locality-first scheduling endwhile

• Idea: Launch a degraded task only if the fraction of

degraded tasks being launched (𝒏𝒆 / 𝑵𝒆) is no more than the fraction of all map tasks being launched (𝒏 / 𝑵)

• Control the pace of launching degraded tasks
• Keep degraded tasks separated in whole map phase

Example

31

Core Switch ToR Switch ToR Switch B0,0 B1,0 B2,0 B3,0 B0,1 P2,1 B4,0 P5,0 B1,1 P3,0 B4,1 P5,1 P0,0 P1,0 B2,1 P3,1 P4,0 B5,0 P0,1 P1,1 P2,0 B3,1 P4,1 B5,1 10 30 50 S1 S2 S3

Download P0,0 Process B0,0 Process B2,1 Process B1,1 (1) (2) (3) Process B3,1 Download P1,0 Process B1,0 Process B0,1 Process B5,0 Process B3,0 Download P2,0 Process B2,0 Process B4,1 Process B4,0 Process B5,1 (4) (5) (6) (7) (8) (9) (10) (11) (12)

Degraded tasks are well separated

Properties

• Gives higher priority to degraded tasks if

conditions are appropriate

• That’s why we call it “degraded-first” scheduling
• Preserves MapReduce performance as in

locality-first scheduling in normal mode

• Enhanced degraded first scheduling (EDF)
• Takes into account network topology when assigning

degraded tasks

32

Experiments

33

• Prototype on HDFS-RAID
• Hadoop cluster:
• Single master and 12 slaves
• Slaves grouped into three racks, four slaves each
• Both ToR and core switches have 1Gbps bandwidth
• 64MB per block
• Workloads:
• Jobs: Grep, WordCount, LineCount
• Each job processes a 240-block file

Experiment Results

• Single Job

Gain of EDF over LF

• 27.0% for wordcount
• 26.1% for grep
• 24.8% for linecount
• Multiple Jobs

Gain of EDF over LF

• 16.6% for wordcount
• 28.4% for grep
• 22.6% for linecount

34

Other Projects on Erasure Coding

• Mixed failures
• STAIR codes: a general, space-efficient erasure code for tolerating both device

failures and latent sector errors [FAST’14]

• I/O-efficient integrity checking against silent data corruptions [MSST’14]
• Efficient updates
• CodFS: enhanced parity logging to reduce network and disk I/Os in erasure-

coded storage [FAST’14]

• Efficient recovery
• NCCloud: reduce bandwidth for archival storage [FAST’12, INFOCOM’13, TC’14]
• I/O-efficient recovery schemes for erasure codes [MSST’12, DSN’12, TC’14, TPDS’14]
• Modeling of SSD RAID
• Stochastic model to capture reliability changes as SSDs age [SRDS’13, TC]
• Secure outsourced storage
• FMSR-DIP: remote data checking for regenerating codes [SRDS’12, TPDS’14]
• Convergent dispersal: unifying security, deduplication, and erasure coding

[HotStorage’14] 35

Conclusions

• Provide insights into the use of erasure coding on

clustered storage systems

• Two systems
• CORE: improve concurrent recovery performance
• Degraded-first scheduling: improve MapReduce performance

in erasure-coded storage in failure mode

• Approach:
• Build prototypes, backed by extensive experiments and

theoretical analysis

• Open-source software

http://www.cse.cuhk.edu.hk/~pclee

36
