Introduction to Computational Modeling of Social Systems

• Prof. Lars-Erik Cederman

Center for Comparative and International Studies (CIS) Seilergraben 49, Room G.2, lcederman@ethz.ch Nils Weidmann, CIS Room E.3, weidmann@icr.gess.ethz.ch http://www.icr.ethz.ch/teaching/compmodels Lecture, December 14, 2004

RePast Tutorial II

2

Today’s agenda

• IPD: Experimental dimensions
• EvolIPD model
• Random numbers
• How to build a model (2)
• Scheduling
• Homework C

3

Three crucial questions:

• 1. Variation: What are the actors’

characteristics?

• 2. Interaction: Who interacts with whom,

when and where?

• 3. Selection: Which agents or strategies are

retained, and which are destroyed?

(see Axelrod and Cohen. 1999. Harnessing Complexity)

4

Experimental dimensions

• 2 strategy spaces: B, C
• 6 interaction processes: RWR, 2DK, FRN,

FRNE, 2DS, Tag

• 3 adaptive processes: Imit, BMGA, 1FGA

5

“Soup-like” topology: RWR

ALLC ALLC TFT ALLD ATFT TFT ALLD

In each time period, a player interacts with four other random players.

6

2D-Grid Topology: 2DK

TFT ALLD ALLD ALLD TFT TFT ALLC ATFT ALLC

The players are arranged on a fixed torus and interact with four neighbors in the von-Neumann neighborhood.

7

Fixed Random Network: FRN

ALLC ALLC TFT ALLD ATFT TFT ALLD TFT ATFT

The players have four random neighbors in a fixed random

• network. The relations

do not have to be symmetric.

8

Adaptation through imitation

ALLC ALLC TFT ALLD ATFT TFT? ALLD

Neighbors at t Imitation

9

Adaptation with BMGA

Comparison error (prob. 0.1)

2.8 6.0 0.8 9.0

Genetic adaptation

2.2

Fixed spatial neighborhood

10

BMGA continued

Copy error (prob. 0.04 per “bit”)

2.8 6.0 0.8 9.0

Genetic adaptation

6.0

p=0; q=0 => p=1; q=0 Fixed spatial neighborhood

11

Tutorial Sequence

December 7 SimpleIPD: strategy space Today EvolIPD: RWR December 21 GraphIPD: charts and GUI GridIPD: 2DK January 11 ExperIPD: batch runs and parameter sweeps

12

EvolIPD: flowchart

setup() buildModel() resetPlayers() interactions() adaptation() reportResults() step()

play() play() remember() remember() addPayoff() addPayoff()

13

Markovian vs. asynchronous adaptation

Markovian

t t-1

asynchronous

14

Going sequential

private void stepMarkovian() { // We carry out four sub-activities: // Reset the agents' statistics // Loop through the entire agent list for (int i = 0; i < numPlayers; i++) { // Pick the agent final Player aPlayer = (Player) agentList.get(i); resetPlayer(aPlayer); } // Let them interact with their neighbors for (int i = 0; i < numPlayers; i++) { final Player aPlayer = (Player) agentList.get(i); interactions(aPlayer); } // FIRST STAGE OF DOUBLE BUFFERING! // Let all agents calculate their adapted type first for (int i = 0; i < numPlayers; i++) { final Player aPlayer = (Player) agentList.get(i); adaptation(aPlayer); } // SECOND STAGE OF DOUBLE BUFFERING! // Second, once they know their new strategy, // let them update to the new type for (int i = 0; i < numPlayers; i++) { final Player aPlayer = (Player) agentList.get(i); updating(aPlayer); } reportResults(); // Report some statistics } private void stepAsynchronous() { // We carry out four sub-activities: for (int i = 0; i < numPlayers; i++) { // Pick an agent at random final Player aPlayer = (Player) agentList.get( this.getNextIntFromTo(0, numPlayers - 1)); // Reset the agent's statistics resetPlayer(aPlayer); // Let it interact with its neighbors interactions(aPlayer); // Let it adapt adaptation(aPlayer); // Let it update its new type updating(aPlayer); } reportResults(); // Report some statistics }

15

How to work with random numbers

• RePast full-fledged random number generator:

uchicago.src.sim.util.Random

• Encapsulates the Colt library random number

distributions: http://hoschek.home.cern.ch/hoschek/colt/

• Each distribution uses the same random number

stream, to ease the repeatability of a simulation

• Every distribution uses the MersenneTwister

pseudo-random number generator

16

Pseudo-random numbers

• Computers normally cannot generate real

random numbers

• “Random number generators should not be

chosen at random” - Knuth (1986)

• A simple example (Cliff RNG):

X0 = 0.1 Xn+1 = |100 ln(Xn) mod 1|

x1 = 0.25850929940455103 x2 = 0.28236111950289455 x3 = 0.4568461655760814 x4 = 0.3408562751932891 x5 = 0.6294370918024157 x6 = 0.29293640856857195 x7 = 0.7799729122847907 x8 = 0.849608774153694 x9 = 0.29793011540822434 x10 = 0.08963320319223556 x11 = 0.2029456303939412 ...

20 40 60 80 100 120 140 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1 Frequency

17

“True” random numbers

• New service offered by the University of

Geneva and the company id Quantique http://www.randomnumber.info/

• No (yet) integrated into RePast

18

Simple random numbers distribution

• Initialization:

Random.setSeed(seed); Random.createUniform(); Random.createNormal(0.0, 1.0);

• Usage:

int i = Random.uniform.nextIntFromTo(0, 10); double v1 = Random.normal.nextDouble(); double v2 = Random.normal.nextDouble(0.5, 0.3);

mean standard deviation standard deviation mean standard deviation Automatically executed by SimpleModel

19

Available distributions

• Normal (or Gaussian)
• Pareto
• Poisson
• Uniform
• …
• Beta
• Binomial
• Chi-square
• Empirical (user-

defined probability distribution function)

• Gamma
• Hyperbolic
• Logarithmic

Beta Normal

20

Custom random number generation

• May be required if two independent random number streams are

desirable

• Bypass RePast’s Random and use the Colt library directly:

import cern.jet.random.*; import cern.jet.random.engine.MersenneTwister; public class TwoStreamsModel extends SimModel { Normal normal; Uniform uniform; public void buildModel() { super.buildModel(); MersenneTwister generator1 = new MersenneTwister(123); MersenneTwister generator2 = new MersenneTwister(321); uniform = new Uniform(generator1); normal = new Normal(0.0, 1.0, generator2); } public void step() { int i = uniform.nextIntFromTo(0, 10); double value = normal.nextDouble(); } }

seeds

21

How to build a model (2)

• If more flexibility is desired, one can extend

SimModelImpl instead of SimpleModel

• Differences to SimpleModel

– No buildModel(), step(), ... methods – No agentList, schedule, params, ... fields – Most importantly: no default scheduling

• Required methods:

public void setup() public String[] getInitParam() public void begin() public Schedule getSchedule() public String getName()

22

SimModelImpl

import uchicago.src.sim.engine.Schedule; import uchicago.src.sim.engine.SimInit; import uchicago.src.sim.engine.SimModelImpl; public class MyModelImpl extends SimModelImpl { public static final int TFT = 1; public static final int ALLD = 3; private int a1Strategy = TFT; private int a2Strategy = ALLD; private Schedule schedule; private ArrayList agentList; public void setup() { a1Strategy = TFT; a2Strategy = ALLD; schedule = new Schedule(); agentList = new ArrayList(); } public String[] getInitParam() { return new String[]{"A1Strategy"}; }

23

SimModelImpl (cont.)

public String getName() { return "Example Model"; } public void begin() { Agent a1 = new Agent(a1Strategy); Agent a2 = new Agent(a2Strategy); agentList.add(a1); agentList.add(a2); schedule.scheduleActionBeginning(1, this, "step"); } public void step() { for (Iterator iterator = agentList.iterator(); iterator.hasNext();) { Agent agent = (Agent) iterator.next(); agent.play(); } }

introspection

24

SimModelImpl (cont.)

public String[] getInitParam() { return new String[]{"A1Strategy"}; } public int getA1Strategy() { return a1Strategy; } public void setA1Strategy(int strategy) { this.a1Strategy = strategy; } public static void main(String[] args) { SimInit init = new SimInit(); SimModelImpl model = new MyModelImpl(); init.loadModel(model, null, false); }

25

How to use a schedule

• Schedule object is responsible for all the

state changes within a Repast simulation

schedule.scheduleActionBeginning(1, new DoIt()); schedule.scheduleActionBeginning(1, new DoSomething()); schedule.scheduleActionAtInterval(3, new ReDo()); tick 1: DoIt, DoSomething tick 2: DoSomething, DoIt tick 3: ReDo, DoSomething, DoIt tick 4: DoSomething, DoIt tick 5: DoIt, DoSomething tick 6: DoSomething, ReDo, DoIt

26

Different types of actions

• Inner class

class MyAction extends BasicAction { public void execute() { doSomething(); } } schedule.scheduleActionAt(100, new MyAction());

• Anonymous inner class

schedule.scheduleActionAt(100, new BasicAction(){ public void execute() { doSomething(); } );

• Introspection

schedule.scheduleActionAt(100, this, "doSomething");

27

Schedule in SimpleModel

public void buildSchedule() { if (autoStep) schedule.scheduleActionBeginning(startAt, this,"runAutoStep"); else schedule.scheduleActionBeginning(startAt, this, "run"); schedule.scheduleActionAtEnd(this, "atEnd"); schedule.scheduleActionAtPause(this, "atPause"); schedule.scheduleActionAt(stoppingTime, this, "stop", Schedule.LAST); } public void runAutoStep() { public void run() { preStep(); preStep(); autoStep(); step(); postStep(); postStep(); } } private void autoStep() { if (shuffle) SimUtilities.shuffle(agentList); int size = agentList.size(); for (int i = 0; i < size; i++) { Stepable agent = (Stepable)agentList.get(i); agent.step(); } }

28

Scheduling actions on lists

• An action can be scheduled to be executed on

every element of a list:

public class Agent { public void step() { } } schedule.scheduleActionBeginning(1, agentList, "step");

• is equivalent to:

public void step() { for(Iterator it = agentList.iterator(); it.hasNext();) { Agent agent = (Agent) it.next(); agent.step(); } } schedule.scheduleActionBeginning(1, model, "step");

step() in SimpleModel step() in Agent

29

Different types of scheduling

• scheduleActionAt(double at, …)

executes at the specified clock tick

• scheduleActionBeginning(double begin, …)

executes starting at the specified clock tick and every tick thereafter

• scheduleActionAtInterval(double in, …)

executes at the specified interval

• scheduleActionAtEnd(…)

executes the end of the simulation run

• scheduleActionAtPause(…)

executes when a pause in the simulation occurs

30

Homework C

Modify the EvolIPD program by introducing a selection mechanism that eliminates inefficient players. The current adaptation() method should thus be modified such that the user can switch between the old adaptation routine, which relies

• n strategic learning, and the new “Darwinian” selection
• mechanism. The selection mechanism should remove the 10%

least successful players from the agentList after each round of

• interaction. To keep the population size constant, the same

number of players should be “born” with strategies drawn randomly from the 90% remaining players. Note that because it generates a population-level process, the actual selection mechanism belongs inside the Model class rather than in Player. Does this change make any difference in terms of the output?
