Relational Learning from Ambiguous Examples Dominique Bouthinon Henry Soldano Laboratoire dInformatique de Paris Nord - UMR 7030 Universit Paris 13, Sorbonne Paris Cit ILP 2014 September 14-16, Nancy (France) Bouthinon, Soldano (LIPN)

slide-1
SLIDE 1

Relational Learning from Ambiguous Examples

Dominique Bouthinon Henry Soldano

Laboratoire d’Informatique de Paris Nord - UMR 7030 Université Paris 13, Sorbonne Paris Cité

ILP 2014 September 14-16, Nancy (France)

Bouthinon, Soldano (LIPN) Relational Learning from Ambiguous Examples ILP 2014 (Nancy) 1 / 27

slide-2
SLIDE 2

Ambiguous examples

The ambiguity comes from a lack of information

Bouthinon, Soldano (LIPN) Relational Learning from Ambiguous Examples ILP 2014 (Nancy) 2 / 27

slide-3
SLIDE 3

Ambiguous examples

The ambiguity comes from a lack of information

Bouthinon, Soldano (LIPN) Relational Learning from Ambiguous Examples ILP 2014 (Nancy) 2 / 27

slide-4
SLIDE 4

Learning from ambiguous examples

1

Learning from ambiguous examples

2

Sample complexity

3

Learning relational rules from ambiguous clauses

4

Lear

5

Experiments

6

Perspectives

Bouthinon, Soldano (LIPN) Relational Learning from Ambiguous Examples ILP 2014 (Nancy) 3 / 27

slide-5
SLIDE 5

Extensional representation of ambiguous examples

An ambiguous example is a set of possibilities {x1, . . . , xn} containing a single unknown possibility that describes the actual example

Bouthinon, Soldano (LIPN) Relational Learning from Ambiguous Examples ILP 2014 (Nancy) 4 / 27

slide-6
SLIDE 6

Extensional representation of ambiguous examples

An ambiguous example is a set of possibilities {x1, . . . , xn} containing a single unknown possibility that describes the actual example Background knowledge, if available, reduces the number of valid possibilities.

Bouthinon, Soldano (LIPN) Relational Learning from Ambiguous Examples ILP 2014 (Nancy) 4 / 27

slide-7
SLIDE 7

Learning from ambiguous examples

Let H and e = {x1, . . . , . . . , xn}, x(e) is the actual example (one of the xis) hidden in e

Bouthinon, Soldano (LIPN) Relational Learning from Ambiguous Examples ILP 2014 (Nancy) 5 / 27

slide-8
SLIDE 8

Learning from ambiguous examples

Let H and e = {x1, . . . , . . . , xn}, x(e) is the actual example (one of the xis) hidden in e

Credulous covering

H comp+e ⇔ ∃xi ∈ e, H covers xi H comp−e ⇔ ∃xi ∈ e, ¬(H covers xi)

Bouthinon, Soldano (LIPN) Relational Learning from Ambiguous Examples ILP 2014 (Nancy) 5 / 27

slide-9
SLIDE 9

Learning from ambiguous examples

Let H and e = {x1, . . . , . . . , xn}, x(e) is the actual example (one of the xis) hidden in e

Credulous covering

H comp+e ⇔ ∃xi ∈ e, H covers xi H comp−e ⇔ ∃xi ∈ e, ¬(H covers xi)

Coherence of an hypothesis

Let E = E+ ∪ E−, then H is coherent iff : ∀e ∈ E+, H comp+e ∀e ∈ E−, H comp−e

Bouthinon, Soldano (LIPN) Relational Learning from Ambiguous Examples ILP 2014 (Nancy) 5 / 27

slide-10
SLIDE 10

Sample complexity

1

Learning from ambiguous examples

2

Sample complexity

3

Learning relational rules from ambiguous clauses

4

Lear

5

Experiments

6

Perspectives

Bouthinon, Soldano (LIPN) Relational Learning from Ambiguous Examples ILP 2014 (Nancy) 6 / 27

slide-11
SLIDE 11

Sample complexity

LX (complete ex. ), Le = 2LX (ambiguous ex. ), LH (hypotheses)

Bouthinon, Soldano (LIPN) Relational Learning from Ambiguous Examples ILP 2014 (Nancy) 7 / 27

slide-12
SLIDE 12

Sample complexity

LX (complete ex. ), Le = 2LX (ambiguous ex. ), LH (hypotheses) How many ambiguous examples of Le are needed to learn with a probability (1 − δ) a hypothesis H ∈ LH whose error on LX is less than ǫ ?

Bouthinon, Soldano (LIPN) Relational Learning from Ambiguous Examples ILP 2014 (Nancy) 7 / 27

slide-13
SLIDE 13

Sample complexity

LX (complete ex. ), Le = 2LX (ambiguous ex. ), LH (hypotheses) How many ambiguous examples of Le are needed to learn with a probability (1 − δ) a hypothesis H ∈ LH whose error on LX is less than ǫ ?

Property

p(H is not compatible with e | H(x(e)) = c(x(e))) ≥ λ m ≥ 1 λ × ǫ × (ln(|LH|) + ln(1 δ )) H(x(e)) = c(x(e)) : classification error of the actual example x(e) ∈ e

Bouthinon, Soldano (LIPN) Relational Learning from Ambiguous Examples ILP 2014 (Nancy) 7 / 27

slide-14
SLIDE 14

Learning relational rules from ambiguous clauses

1

Learning from ambiguous examples

2

Sample complexity

3

Learning relational rules from ambiguous clauses

4

Lear

5

Experiments

6

Perspectives

Bouthinon, Soldano (LIPN) Relational Learning from Ambiguous Examples ILP 2014 (Nancy) 8 / 27

slide-15
SLIDE 15

Learning relational rules from ambiguous clauses

(LH, Le, comp+, comp−) H ∈ LH is a set of clauses e ∈ Le is a set of grounded clauses

Example

H = {stable(A,B) ← on(A,B) ∧ on(B,floor), stable(A,B) ← on(A,floor) ∧ on(B,floor)} e = {stable(a,b) ← on(a, b) ∧ red(a), stable(a,b) ← on(a,floor) ∧ on(b,floor) ∧ blue(b)}

Bouthinon, Soldano (LIPN) Relational Learning from Ambiguous Examples ILP 2014 (Nancy) 9 / 27

slide-16
SLIDE 16

Learning relational rules from ambiguous clauses

(LH, Le, comp+, comp−) H ∈ LH is a set of clauses e ∈ Le is a set of grounded clauses

Example

H = {stable(A,B) ← on(A,B) ∧ on(B,floor), stable(A,B) ← on(A,floor) ∧ on(B,floor)} e = {stable(a,b) ← on(a, b) ∧ red(a), stable(a,b) ← on(a,floor) ∧ on(b,floor) ∧ blue(b)}

Compatibility relations

H comp+ e ⇔ ∃xi ∈ e that is θ-subsumed by a clause of H H comp− e ⇔ ∃xi ∈ e that is θ-subsumed by no clause of H

Bouthinon, Soldano (LIPN) Relational Learning from Ambiguous Examples ILP 2014 (Nancy) 9 / 27

slide-17
SLIDE 17

Minimal and maximal sets of clauses

Let e = {x1, . . . , xn} be an ambiguous example

Bouthinon, Soldano (LIPN) Relational Learning from Ambiguous Examples ILP 2014 (Nancy) 10 / 27

slide-18
SLIDE 18

Minimal and maximal sets of clauses

Let e = {x1, . . . , xn} be an ambiguous example min(e) = {xi ∈ e | ∀xj ∈ e, xj ⊂ xi} max(e) = {xi ∈ e | ∀xj ∈ e, xi ⊂ xj}

Bouthinon, Soldano (LIPN) Relational Learning from Ambiguous Examples ILP 2014 (Nancy) 10 / 27

slide-19
SLIDE 19

Minimal and maximal sets of clauses

Let e = {x1, . . . , xn} be an ambiguous example min(e) = {xi ∈ e | ∀xj ∈ e, xj ⊂ xi} max(e) = {xi ∈ e | ∀xj ∈ e, xi ⊂ xj}

Property

H comp+ e ⇔ H comp+ max(e) H comp− e ⇔ H comp− min(e)

Bouthinon, Soldano (LIPN) Relational Learning from Ambiguous Examples ILP 2014 (Nancy) 10 / 27

slide-20
SLIDE 20

Minimal and maximal sets of clauses

Let e = {x1, . . . , xn} be an ambiguous example min(e) = {xi ∈ e | ∀xj ∈ e, xj ⊂ xi} max(e) = {xi ∈ e | ∀xj ∈ e, xi ⊂ xj}

Property

H comp+ e ⇔ H comp+ max(e) H comp− e ⇔ H comp− min(e) One represents each positive ambiguous example e by max(e), and each negative ambiguous example e by min(e)

Bouthinon, Soldano (LIPN) Relational Learning from Ambiguous Examples ILP 2014 (Nancy) 10 / 27

slide-21
SLIDE 21

Lear

1

Learning from ambiguous examples

2

Sample complexity

3

Learning relational rules from ambiguous clauses

4

Lear

5

Experiments

6

Perspectives

Bouthinon, Soldano (LIPN) Relational Learning from Ambiguous Examples ILP 2014 (Nancy) 11 / 27

slide-22
SLIDE 22

Lear

Bouthinon, Soldano (LIPN) Relational Learning from Ambiguous Examples ILP 2014 (Nancy) 12 / 27

slide-23
SLIDE 23

Lear

Greedy top-down algorithm using a separate and conquer strategy

Bouthinon, Soldano (LIPN) Relational Learning from Ambiguous Examples ILP 2014 (Nancy) 12 / 27

slide-24
SLIDE 24

Lear

Greedy top-down algorithm using a separate and conquer strategy

Principle

H is incrementally built H = { h1 , h2 , . . . , hm} E+ = E+

1

+ E+

2

+ . . . + E+

m

H comp+ E+ H comp− E−

Bouthinon, Soldano (LIPN) Relational Learning from Ambiguous Examples ILP 2014 (Nancy) 12 / 27

slide-25
SLIDE 25

Lear

Greedy top-down algorithm using a separate and conquer strategy

Principle

H is incrementally built H = { h1 , h2 , . . . , hm} E+ = E+

1

+ E+

2

+ . . . + E+

m

H comp+ E+ H comp− E− Lear uses an ambiguous seed to reduce the hypothesis search space

Bouthinon, Soldano (LIPN) Relational Learning from Ambiguous Examples ILP 2014 (Nancy) 12 / 27

slide-26
SLIDE 26

Experiments

1

Learning from ambiguous examples

2

Sample complexity

3

Learning relational rules from ambiguous clauses

4

Lear

5

Experiments

6

Perspectives

Bouthinon, Soldano (LIPN) Relational Learning from Ambiguous Examples ILP 2014 (Nancy) 13 / 27

slide-27
SLIDE 27

Objectives

Bouthinon, Soldano (LIPN) Relational Learning from Ambiguous Examples ILP 2014 (Nancy) 14 / 27

slide-28
SLIDE 28

Objectives

Study the accuracy (computed on complete examples) when learning from ambiguous examples

Bouthinon, Soldano (LIPN) Relational Learning from Ambiguous Examples ILP 2014 (Nancy) 14 / 27

slide-29
SLIDE 29

Objectives

Study the accuracy (computed on complete examples) when learning from ambiguous examples Compare LEar, Tilde ( [Blockeel & De Raedt, 1998]) and Nfoil ([Landwehr et al., 2007]) when learning from incomplete data

Bouthinon, Soldano (LIPN) Relational Learning from Ambiguous Examples ILP 2014 (Nancy) 14 / 27

slide-30
SLIDE 30

Bongard : accuracies on 1000 examples

10 20 30 40 50 60 70 80 90 60 65 70 75 80 85 90 95 100 bongard (artificial) 1000 ex Lear Nfoil Tilde ambiguity (%) accurracy (%) Bouthinon, Soldano (LIPN) Relational Learning from Ambiguous Examples ILP 2014 (Nancy) 15 / 27

slide-31
SLIDE 31

Bongard : accuracies on 2000 examples

10 20 30 40 50 60 70 80 90 60 65 70 75 80 85 90 95 100 bongard (artificial) 2000 ex Lear Tilde Nfoil ambiguity (%) accurracy (%) Bouthinon, Soldano (LIPN) Relational Learning from Ambiguous Examples ILP 2014 (Nancy) 16 / 27

slide-32
SLIDE 32

Bongard : accuracies on 4000 examples

10 20 30 40 50 60 70 80 90 60 65 70 75 80 85 90 95 100 bongard (artificial) 4 000 ex Lear Tilde Nfoil ambiguity (%) accurracy (%) Bouthinon, Soldano (LIPN) Relational Learning from Ambiguous Examples ILP 2014 (Nancy) 17 / 27

slide-33
SLIDE 33

Bongard : accuracies on 16000 examples

10 20 30 40 50 60 70 80 90 60 65 70 75 80 85 90 95 100 bongard (artificial) 16 000 ex Lear Tilde Nfoil ambiguity (%) accurracy (%) Bouthinon, Soldano (LIPN) Relational Learning from Ambiguous Examples ILP 2014 (Nancy) 18 / 27

slide-34
SLIDE 34

Loan : accuracies on 5000 examples

10 20 30 40 50 60 70 80 90 60 65 70 75 80 85 90 95 100 loan (UCI) 5000 ex Lear Tilde Nfoil ambiguity (%) accurracy (%) Bouthinon, Soldano (LIPN) Relational Learning from Ambiguous Examples ILP 2014 (Nancy) 19 / 27

slide-35
SLIDE 35

Loan : accuracies 15000 examples

10 20 30 40 50 60 70 80 90 60 65 70 75 80 85 90 95 100 loan (UCI) 15 000 ex Lear Nfoil Tilde ambiguity (%) accurracy (%) Bouthinon, Soldano (LIPN) Relational Learning from Ambiguous Examples ILP 2014 (Nancy) 20 / 27

slide-36
SLIDE 36

Why not completing the ambiguous examples ?

Bouthinon, Soldano (LIPN) Relational Learning from Ambiguous Examples ILP 2014 (Nancy) 21 / 27

slide-37
SLIDE 37

Why not completing the ambiguous examples ?

Because we generally have no support to impute the truth values of the undetermined atoms

Bouthinon, Soldano (LIPN) Relational Learning from Ambiguous Examples ILP 2014 (Nancy) 21 / 27

slide-38
SLIDE 38

Why not completing the ambiguous examples ?

Because we generally have no support to impute the truth values of the undetermined atoms

10 20 30 40 50 60 70 80 90 60 65 70 75 80 85 90 95 100 bongard (UCI) 1 500 ex. Lear comp. Lear ambiguity (%) accurracy (%) Bouthinon, Soldano (LIPN) Relational Learning from Ambiguous Examples ILP 2014 (Nancy) 21 / 27

slide-39
SLIDE 39

Perspectives

1

Learning from ambiguous examples

2

Sample complexity

3

Learning relational rules from ambiguous clauses

4

Lear

5

Experiments

6

Perspectives

Bouthinon, Soldano (LIPN) Relational Learning from Ambiguous Examples ILP 2014 (Nancy) 22 / 27

slide-40
SLIDE 40

Perspectives

Bouthinon, Soldano (LIPN) Relational Learning from Ambiguous Examples ILP 2014 (Nancy) 23 / 27

slide-41
SLIDE 41

Perspectives

Extend the ambiguity to the heads of the clauses of the examples

Bouthinon, Soldano (LIPN) Relational Learning from Ambiguous Examples ILP 2014 (Nancy) 23 / 27

slide-42
SLIDE 42

Perspectives

Extend the ambiguity to the heads of the clauses of the examples Apply Lear to learn action models and biological structures

Bouthinon, Soldano (LIPN) Relational Learning from Ambiguous Examples ILP 2014 (Nancy) 23 / 27

slide-43
SLIDE 43

Perspectives

Extend the ambiguity to the heads of the clauses of the examples Apply Lear to learn action models and biological structures Adapt Lear to Probabilistic Logic Programming [De Raedt et al, 2007]

Bouthinon, Soldano (LIPN) Relational Learning from Ambiguous Examples ILP 2014 (Nancy) 23 / 27

slide-44
SLIDE 44

Bongard (artificial)

5 relations

Bouthinon, Soldano (LIPN) Relational Learning from Ambiguous Examples ILP 2014 (Nancy) 24 / 27

slide-45
SLIDE 45

Bongard (artificial)

5 relations Concept

Bouthinon, Soldano (LIPN) Relational Learning from Ambiguous Examples ILP 2014 (Nancy) 24 / 27

slide-46
SLIDE 46

Bongard (artificial)

5 relations Concept B = { ← triangle(X) ∧ square(X), ← triangle(X) ∧ circle(X), triangle(X) ∨ circle(X) ∨ square(X), · · · }

Bouthinon, Soldano (LIPN) Relational Learning from Ambiguous Examples ILP 2014 (Nancy) 24 / 27

slide-47
SLIDE 47

Loan (UCI)

8 relations

Bouthinon, Soldano (LIPN) Relational Learning from Ambiguous Examples ILP 2014 (Nancy) 25 / 27

slide-48
SLIDE 48

Loan (UCI)

8 relations ec = no_paiement_due ← unemployed ∧ enlist(air_force) ∧ longest_absense_from_school(7) ∧ enrolled(occ, 9) ∧ enrolled(ucsd,5)

Bouthinon, Soldano (LIPN) Relational Learning from Ambiguous Examples ILP 2014 (Nancy) 25 / 27

slide-49
SLIDE 49

Loan (UCI)

8 relations ec = no_paiement_due ← unemployed ∧ enlist(air_force) ∧ longest_absense_from_school(7) ∧ enrolled(occ, 9) ∧ enrolled(ucsd,5) B = ∅

Bouthinon, Soldano (LIPN) Relational Learning from Ambiguous Examples ILP 2014 (Nancy) 25 / 27

slide-50
SLIDE 50

Multi-table representation

Bouthinon, Soldano (LIPN) Relational Learning from Ambiguous Examples ILP 2014 (Nancy) 26 / 27

slide-51
SLIDE 51

Multi-table representation

the bodies of the clauses of each ambiguous example can be represented as a cross-product (may lead to an exponential gain in space)

Bouthinon, Soldano (LIPN) Relational Learning from Ambiguous Examples ILP 2014 (Nancy) 26 / 27

slide-52
SLIDE 52

Multi-table representation

the bodies of the clauses of each ambiguous example can be represented as a cross-product (may lead to an exponential gain in space)

Exemple

e = { stable(a, b) ← on(a, b) ∧ on(b, floor) ∧ red(a) ∧ red(b), stable(a, b) ← on(a, b) ∧ on(b, floor) ∧ red(a) ∧ blue(b), stable(a, b) ← on(a, b) ∧ on(b, floor) ∧ red(a) ∧ green(b), · · · stable(a, b) ← on(a, b) ∧ on(b, floor) ∧ green(a) ∧ green(b)}

Bouthinon, Soldano (LIPN) Relational Learning from Ambiguous Examples ILP 2014 (Nancy) 26 / 27

slide-53
SLIDE 53

Multi-table representation

the bodies of the clauses of each ambiguous example can be represented as a cross-product (may lead to an exponential gain in space)

Exemple

e = { stable(a, b) ← on(a, b) ∧ on(b, floor) ∧ red(a) ∧ red(b), stable(a, b) ← on(a, b) ∧ on(b, floor) ∧ red(a) ∧ blue(b), stable(a, b) ← on(a, b) ∧ on(b, floor) ∧ red(a) ∧ green(b), · · · stable(a, b) ← on(a, b) ∧ on(b, floor) ∧ green(a) ∧ green(b)} T1 × T2 × T3

  • n(a, b) ∧ on(b, floor)

red(a) blue(a) green(a) red(b) blue(b) green(b)

Bouthinon, Soldano (LIPN) Relational Learning from Ambiguous Examples ILP 2014 (Nancy) 26 / 27

slide-54
SLIDE 54

Methodology

Bouthinon, Soldano (LIPN) Relational Learning from Ambiguous Examples ILP 2014 (Nancy) 27 / 27

slide-55
SLIDE 55

Methodology

C is a set of complete examples, B is the background knowledge Ci C = E =

Bouthinon, Soldano (LIPN) Relational Learning from Ambiguous Examples ILP 2014 (Nancy) 27 / 27

slide-56
SLIDE 56

Methodology

C is a set of complete examples, B is the background knowledge Ci C = E = 10 × 10 cross-validation on C : For each fold Ci (test) one builds a set of ambiguous example E (train) from complete examples drawn in C − Ci each atom of a drawn complete example is made undetermined according to a probability p (blocking process [Schuurmans et Greiner, 1997])

Bouthinon, Soldano (LIPN) Relational Learning from Ambiguous Examples ILP 2014 (Nancy) 27 / 27

slide-57
SLIDE 57

Methodology

C is a set of complete examples, B is the background knowledge Ci C = E = 10 × 10 cross-validation on C : For each fold Ci (test) one builds a set of ambiguous example E (train) from complete examples drawn in C − Ci each atom of a drawn complete example is made undetermined according to a probability p (blocking process [Schuurmans et Greiner, 1997]) Tilde and Nfoil assume each undetermined atom is false

Bouthinon, Soldano (LIPN) Relational Learning from Ambiguous Examples ILP 2014 (Nancy) 27 / 27
